Vortex beams characterized by helical phase wavefronts enable innovative explorations of optical and physical interactions. This work experimentally realizes longitudinally polarized vortices with arbitrary topological charges in terahertz (THz) frequencies using a silicon ring resonator integrated with a second-order diffraction grating. The implemented configuration enables flexible topological charge manipulation in longitudinally polarized electric fields through the excitation of quasi-transverse-magnetic (TM) waveguide modes with different frequencies. By employing a terahertz near-field measurement system, the spatial intensity patterns and phase characteristics of emitted waves are quantitatively analyzed via a precision probe. This strategy shows promising potential for applications in particle manipulation techniques and advanced imaging technologies. Full article

Similar to optical vortex beams, terahertz (THz) vortex beams (TVBs) also carry orbital angular momentum (OAM). However, little research has been reported on the generation of TVBs. In this paper, based on the detour phase technique, we design a series of spintronic terahertz emitters with a helical Fresnel zone plate (STE-HFZP) to directly generate focused TVBs with topological charges (TCs) of l = ±1, ±2 and ±3, respectively. The STE-HFZP is a hybrid THz device composed of a terahertz emitter and a THz lens, and it has a high numerical aperture (NA), achieving subwavelength focal spots. Its focus properties are surveyed systemically through accurate simulations. This STE-HFZP can also generate focused TVBs with higher order TCs. More importantly, the components of the focused electric field with OAM make up the majority of the intensity and have potential applications in the field of THz communications, THz imaging and atom trapping. Full article

Terahertz technology and vortex beams have demonstrated powerful capabilities in enhancing the channel capacity of communication systems. This work proposes a design strategy of dual-band and dual-function 3-bit coding metasurface based on beam polarization characteristics. The unit cell of the metasurface is composed of two pattern structures, which has the ability to flexibly and independently control the reflection phases of incident plane wave at two frequency bands. The metasurface designed in this work is a combination of two patterns according to the addition operation and the convolution operation. The 3-bit coding metasurface generates two orbital angular momentum (OAM) beams with a deflection of 12.1° with modes $l_1=+1$ and $l_2=-1$ under the y-polarized incidence at 0.6 THz. Similarly, the designed metasurface produces two OAM beams with a deflection of 16.5° under the incidence of x-polarized wave at 0.9 THz, and the modes are $l_3=+1$ and $l_4=-2$. The full-wave simulation results agree well with the theoretical predictions, which could prove the correctness and effectiveness of the proposed method. The metasurface designed according to this method has potential applications in multiple-input multiple-output (MIMO) communication systems. Full article

Most of the reported vortex beam generators with orbital angular momentum (OAM) in the terahertz region only operate in either the reflection mode or the transmission mode, which greatly limits the integration and application in terahertz technology systems. Herein, we propose a full-space vortex beam regulator at two different frequencies. By changing the VO₂ phase transition state, the transmission and reflection mode OAM beams can be flexibly controlled by a single metasurface. For the transmission mode, the proposed structure realizes an OAM beam at the topological charges of l = 1 and 2 at 0.6 THz and 1.4 THz. For the reflection mode, our structure generates an OAM beam at the topological charges of l = 1 and 2 at 0.9 THz and 1.5 THz. Based on the superposition theorem and convolution operation principle, the regulation of an OAM vortex beam with a specific deflection angle and a symmetrical deflection OAM vortex beam are realized. The designed metasurface integrates multiple transmitted and reflected vortex beam functions in full space and has potential application in different terahertz systems. Full article

In the past decades, metasurfaces have shown their extraordinary abilities on manipulating the wavefront of electromagnetic wave. Based on the ability, various kinds of metasurfaces are designed to realize new functional metadevices based on wavefront manipulations, such as anomalous beam steering, focus metalens, vortex beams generator, and holographic imaging. However, most of the previously proposed designs based on metasurfaces are fixed once design, which is limited for applications where light modulation needs to be tunable. In this paper, we proposed a design for THz tunable wavefront manipulation achieved by the combination of plasmonic metasurface and phase change materials (PCMs) in THz region. Here, we designed a metal-insulator-metal (MIM) metasurface with the typical C-shape split ring resonator (CSRR), whose polarization conversion efficiency is nearly 90% for circular polarized light (CPL) in the range of 0.95~1.15 THz when PCM is in the amorphous state, but the conversion efficiency turns to less than 10% in the same frequency range when PCM switches into the crystalline state. Then, benefiting from the high polarization conversion contrast of unit cell, we can achieve tunable wavefront manipulation by utilizing the Pancharatnam–Berry (PB) phase between the amorphous and crystalline states. As a proof-of-concept, the reflective tunable anomalous beam deflector and focusing metalens are designed and characterized, and the results further verify their capability for tunable wavefront manipulation in THz range. It is believed that the design in our work may pave the way toward the tunable wavefront manipulation of THz waves and is potential for dynamic tunable THz devices. Full article

Terahertz (THz) orbital angular momentum (OAM) technology provides promising applications in future wireless communication with large bandwidth and high capacity. However, the ring radius of the conventional THz vortex beam is related to the topological charge, limiting the co-propagation of multiple OAM modes in the THz communication systems. Although the perfect vortex beam (PVB) based on traditional methods can solve this problem, they are usually bulky and unstable. Here, we demonstrate two PVB generators based on a single all-dielectric metasurface to obtain polarization-independent PVB and spin multiplexed PVB, respectively. The former regulates the propagation phase by using isotropic unit cells; the latter simultaneously manipulates the propagation and geometric phase to achieve the spin-decoupled phase control by arranging anisotropic unit cells. In addition, we also demonstrate the stable generation of a perfect Poincaré beam with arbitrary polarization and phase distribution on a hybrid-order Poincaré Sphere via a spin-decoupled metasurface, which is achieved by the linear superposition of two PVBs with orthogonal circular polarizations. The proposed scheme provides a compact and efficient platform for the generation and superposition of PVBs in THz region, and will speed up the progress of THz communication systems, complex light field generation, and quantum information sciences. Full article

Recently, terahertz (THz) wireless communication has been widely investigated as the future prospect of wireless network architecture. However, most of the natural existing materials are inapplicable for THz devices, which hinder their further development. To promote the integration and channel capacity of the THz wireless communication systems, an ultrabroadband polarization conversion metasurface for efficient multi-functional wavefront manipulation is proposed. The designed metasurface is composed of an arrow-type structure sandwiched by a pair of orthogonal gratings, which can induce the Fabry-Pérot-like cavity for improving the transmission. Simulated results indicate that the transmission coefficient of the cross-polarization metasurface is higher than 90% from 0.73 THz to 2.24 THz, and the corresponding polarization conversion ratio is greater than 99.5%. Moreover, the phase coverage of 0–2π at operation frequency can be easily obtained by altering the geometric parameter of the metasurface. To demonstrate the concept of wavefront manipulation, anomalous refraction, focusing metalens, and vortex beam generation are investigated in detail. All of these applications exhibit a remarkable performance of the proposed metasurface that has great potential in prompting the efficient, broadband and compact systems for THz wireless communication. Full article

The stable propagation of orbital angular momentum and cylindrical vector beams in a newly designed annular core photonic crystal fiber (AC-PCF) tailored for the broadband single-radial order beam transmission (within the so-called “endlessly mono-radial” guiding regime) is demonstrated for the first time. It is shown that the vector-vortex beams can maintain high mode purities above 18 dB after propagation in the fiber under test over all of the wavelength range from 805 to 845 nm (over 17 THz bandwidth) investigated with the help of a tunable laser and an S-plate for the generation of singular beams in free space. Our results confirm that the AC-PCF is a promising design for the broadband transmission of vector-vortex beams that have potential applications in space-division multiplexing, quantum communications, optical sensing and trapping. Full article

Three kinds of multifunctional graphene metasurfaces based on Pancharatnam–Berry (PB) phase cells are proposed and numerically demonstrated to control a reflected wave’s spin angular momentum (SAM) and orbital angular momentum (OAM) in the terahertz (THz) regime. Each proposed metasurface structure is composed of an array of graphene strips with different deviation angles and a back-grounded quartz substrate. In order to further help readers have a deeper insight into the graphene-based metasurfaces, a detailed design strategy is also provided. With the aid of the designed graphene elements, the proposed metasurfaces can achieve the full 360° range of phase coverage and provide manipulation of SAM and OAM of a circularly polarized (CP) wave at will. More importantly, simultaneous control of these two momentums can also be realized, and in order to demonstrate this function, a THz spin-controlled OAM beam generator with diverse topological charges is created, which can provide one more degree of freedom to improve the channel capability without increasing the bandwidth compared to a linearly polarized (LP) OAM beam. Numerical results verify the proposed graphene metasurfaces, which pave the way for generating spin OAM vortex waves for THz communication systems. Full article

Liquid crystal (LC) is a promising candidate for terahertz (THz) devices. Recently, LC has been introduced to generate THz vortex beams. However, the efficiency is intensely dependent on the incident wavelength, and the transformed THz vortex beam is usually mixed with the residual component. Thus, a separating process is indispensable. Here, we introduce a gradient blazed phase, and propose a THz LC forked polarization grating that can simultaneously generate and separate pure THz vortices with opposite circular polarization. The specific LC gradient-rotation directors are implemented by a photoalignment technique. The generated THz vortex beams are characterized with a THz imaging system, verifying features of polarization controllability. This work may pave a practical road towards generating, separating and polarizing THz vortex beams, and may prompt applications in THz communications, sensing and imaging. Full article
