To address the limitations of traditional methods in modeling complex nonlinear relationships in horizontal in situ stress prediction for shale reservoirs, this study proposes an integrated framework that combines well logging interpretation with machine learning to accurately predict horizontal in situ stress in shale reservoirs. Based on the logging data from five wells in the Luzhou Block of the Sichuan Basin (16,000 samples), Recursive Feature Elimination (RF-RFE) was used to identify nine key factors, including Stoneley wave slowness and caliper, from 30 feature parameters. Bayesian optimization was employed to fine-tune the hyperparameters of the XGBoost model globally. Results indicate that the XGBoost model performs optimally in predicting maximum horizontal principal stress (SHmax) and minimum horizontal principal stress (SHmin). It achieves R² values of 0.978 and 0.959, respectively, on the test set. The error metrics (MAE, MSE, RMSE) of the XGBoost model are significantly lower than those of SVM and Random Forest, demonstrating its precise capture of the nonlinear relationships between logging parameters and in situ stress. This framework enhances the model’s adaptability to complex geological conditions through multi-well data training and eliminating redundant features, providing a reliable tool for hydraulic fracturing design and wellbore stability assessment in shale gas development. Full article

In the existing studies of slope stability under seismic excitation, the non-uniform spatiotemporal dynamic response and amplification effect caused by the slope scale are often overlooked. In order to analyze the dynamic response of large-scale slopes under non-uniform seismic excitation, this study presents an analytical model based on the Hilbert’s best approximation problem (BAP), taking into account the scale of slopes under seismic incidence. A methodology for differentiating between the plane wave assumption of Huygens’ principle and BAP principle is proposed. A Stoneley equation considering the scale of the slope on the interface is proposed to analyze the non-uniform spatiotemporal dynamic response. Meanwhile, the Knott equation is subjected to non-uniform seismic waves and adopted to describe the amplification factor of spectral response accelerations (SRA). To visually represent the non-uniform spatiotemporal dynamic response and amplification effect, numerical models based on the finite difference method (FDM) are established to simulate the non-uniform incidence of seismic waves. The numerical simulation results show that the non-uniform dynamic response cannot be disregarded in cases where $L/h>4:20$. Slopes of this scale subjected to seismic wave incidence satisfy the BAP principle. Conversely, the dynamic response exhibits uniformity in cases where $L/h<1:20$, which is in accordance with the plane wave assumption of Huygens’ principle. Full article

The formation and development of fractures increase reservoir heterogeneity and improve reservoir performance. Therefore, it is of great research value to accurately identify the development of fractures. In this paper, two- and three-dimensional models are constructed based on the finite element method and compared with the real axis integration method. The influence of different geometric parameters on the Stoneley wave amplitude is studied to assess the propagation of Stoneley waves in the fracture zone in the well. The results show a significant positive correlation between the width and number of fractures and the attenuation coefficient of Stoneley waves. The fracture angle has a negative correlation with the attenuation coefficient and lesser impact on Stoneley waves. In addition, Stoneley waves are less sensitive to changes in fracture location, while the sensitivity to fracture spacing is significant in the range of 50 cm to 75 cm. The main propagation depth of Stoneley waves occurs 20 cm from the wall of the well. Quantitative analyses of the fracture width, number, location, spacing, depth, and angle are conducted to determine the influence of the fracture parameters on the Stoneley wave attenuation coefficient, clarify Stoneley wave propagation in wells, and provide a theoretical basis for the accurate evaluation of fractures. Full article

It is shown that in auxetic materials (materials with negative Poisson’s ratio), supersonic Stoneley waves travelling without attenuation with a velocity equal to or exceeding maximum bulk wave velocity, may exist. Analytical expressions for the relation between negative Poisson’s ratio and Young’s moduli of the contacting isotropic media ensuring the condition of propagation for supersonic Stoneley waves, are derived by solving a secular equation for Stoneley waves. Full article

A knowledge of wave propagation in boreholes with gas hydrate-bearing sediments, a typical three-phase porous medium, is of great significance for better applications of acoustic logging information on the exploitation of gas hydrate. To study the wave propagation in such waveguides based on the Carcione–Leclaire three-phase theory, according to the equations of motion and constitutive relations, a staggered-grid finite-difference time-domain (FDTD) scheme and a real axis integration (RAI) algorithm in a two-dimensional (2D) cylindrical coordinate system are proposed. In the FDTD scheme, the partition method is used to solve the stiff problem, and the nonsplitting perfect matched layer (NPML) scheme is extended to solve the problem of the false reflection waves from the artificial boundaries of the computational region. In the RAI algorithm, combined with six boundary conditions, the displacement potentials of waves are studied to calculate the borehole acoustic wavefields. The effectiveness is verified by comparing the results of the two algorithms. On this basis, the acoustic logs within a gas hydrate-bearing sediment are investigated. In particular, the wave field in a borehole is analyzed and the amplitude of a Stoneley wave under different hydrate saturations is studied. The results indicate that the attenuation coefficient of the Stoneley wave increases with the increase of gas hydrate saturation. The acoustic responses in a borehole embedded in a horizontally stratified hydrate formation are also simulated by using the proposed FDTD scheme. The result shows that the amplitude of the Stoneley wave from the upper interface is smaller than that from the bottom interface. Full article

The finite difference (FD) method of monopole source is used to simulate the response of full-wave acoustic-logging in cave formations. The effect of the cave in the formation of borehole full-waves was studied. The results show that the radius of cave is not only linearly related to the first arrival of the compressional wave (P-wave), but also to the energy of the shear wave (S-wave). The converted S (S–S wave) and P-waves (S–P wave) are formed when the S-wave encounters the cave. If the source distance is small, the S–S and S–P waves are not separated, and the attenuation of the S-wave is not large, due to superposition of the converted waves. The S–P wave has been separated from the S-wave when the source distance is large, so the attenuation of the S-wave increases. The amplitude of the P and S–waves changes most when the distance of the cave to the borehole wall reaches a certain value; this value is related to the excitation frequency. The amplitude of the Stoneley wave (ST wave) varies directly with the radius of cave. If the radius of the cave is large, the energy of ST wave is weak. The scattered wave is determined by the radius and position of the cave. The investigation depth of a monopole source is limited. When the distance of the cave to the borehole wall exceeds the maximum investigation depth, the borehole acoustic wave is little affected by the cave. In actual logging, the development of the cave can be evaluated by using the first arrival of the P-wave and the energy of the S and ST waves. Full article

A 3D seismic survey was done on a near surface karstic reservoir located at the hydrogeological experimental site (HES) of the University of Poitiers (France). The processing of the 3D data led to obtaining a 3D velocity block in depth. The velocity block was converted in pseudo porosity. The resulting 3D seismic pseudo-porosity block reveals three high-porosity, presumably-water-productive layers, at depths of 30–40, 85–87 and 110–115 m. This paper shows how full wave acoustic logging (FWAL) can be used to validate the results obtained from the 3D seismic survey if the karstic body has a lateral extension over several seismic. If karstic bodies have a small extension, FWAL in open hole can be fruitfully used to: detect highly permeable bodies, thanks to measurements of acoustic energy and attenuation; detect the presence of karstic bodies characterized by a very strong attenuation of the different wave trains and a loss of continuity of acoustic sections; confirm the results obtained by vertical seismic profile (VSP) data. The field example also shows that acoustic attenuation of the total wavefield as well as conversion of downward-going P-wave in Stoneley waves observed on VSP data are strongly correlated with the presence of flow. Full article

The partial-wave method takes advantage of the Christoffel equation’s generality to represent waves within a waveguide. More specifically, the partial-wave method is well known for its usefulness when calculating dispersion curves for multilayered and/or anisotropic plates. That is, it is a vital component of the transfer-matrix method and the global-matrix method, which are used for dispersion curve calculation. The literature suggests that the method is also exceptionally useful for conceptual interpretation, but gives very few examples or instruction on how this can be done. In this paper, we expand on this topic of conceptual interpretation by addressing Rayleigh waves, Stoneley waves, shear horizontal waves, and Lamb waves. We demonstrate that all of these guided waves can be described using the partial-wave method, which establishes a common foundation on which many elastodynamic guided waves can be compared, translated, and interpreted. For Lamb waves specifically, we identify the characteristics of guided wave modes that have not been formally discussed in the literature. Additionally, we use what is demonstrated in the body of the paper to investigate the leaky characteristics of Lamb waves, which eventually leads to finding a correlation between oblique bulk wave propagation in the waveguide and the transmission amplitude ratios found in the literature. Full article

Conventionally discussed dynamic mechanisms of elastic strain energy redistribution in near-contact surface regions include P and S elastic wave pulses radiating from the contact surface. At the same time, the elastic strain energy can be transferred by localized vortex-like elastic waves (Rayleigh, Love, Stoneley wave, and so on). In the paper, we numerically studied the main features of the formation and propagation of localized vortex-like waves in the surface layers under the contact zone. The study was done using the numerical method of movable cellular automata. We showed that the initial phase of dynamic contact interaction with a nonzero tangential component of contact velocity is accompanied by the formation of a so-called elastic vortex. The elastic vortex is a fully dynamic object, which is characterized by shear stress concentration and propagates at the shear wave speed. We first revealed the ability of the elastic vortex to propagate toward the bulk of the material and transfer elastic strain energy deep into the surface layer in a localized manner. We analyzed the dependence of the direction of vortex propagation on the tangential contact velocity, contact pressure and Young’s modulus of the material. The results of the study are important for better understanding the dynamic mechanisms contributing to inelastic strain accumulation or gradual degradation of surface layers. Full article
