Search Results (80)

The icebreaking process of water-exiting vehicles involves complex nonlinear interactions as well as multi-physical field coupling effects among ice, solids, and fluids, which poses enormous challenges for numerical calculations. Addressing the low solution accuracy of traditional grid methods in simulating large deformation and destruction of ice layers, a numerical model was established based on the FEM-SPH-SALE coupling algorithm to study the dynamic characteristics of the water-exiting vehicle on the icebreaking process. The FEM-SPH adaptive algorithm was used to simulate the damage performance of ice, and its feasibility was verified through the four-point bending test and vehicle breaking ice experiment. The S-ALE algorithm was used to simulate the process of fluid/structure interaction, and its accuracy was verified through the wedge-body water-entry test and simulation. On this basis, numerical simulations were performed for different ice thicknesses and initial velocities of vehicles. The results show that the motion characteristics of the vehicle undergoes a sudden change during the ice-breaking. The head and middle section of the vehicle are subject to greater stress, which is related to the transmission of stress waves and inertial effect. The velocity loss rate of the vehicle and the maximum stress increase with the thickness of ice. The higher the initial velocity of the vehicle, the larger the acceleration and maximum stress in the process of the vehicle breaking ice. The acceleration peak is sensitive to the variation in the vehicle’s initial velocity but insensitive to the thickness of the ice. Full article

Abrasive waterjet technology is a promising sustainable and green technology for cutting underground structures. Abrasive waterjet usage in demolition promotes sustainable and green construction practices by reduction of noise, dust, secondary waste, and disturbances to the surrounding infrastructure. In this study, a numerical framework based on a coupled Smoothed Particle Hydrodynamics (SPH)–Finite Element Method (FEM) algorithm incorporating the Riedel–Hiermaier–Thoma (RHT) constitutive model is proposed to investigate the damage mechanism of concrete subjected to abrasive waterjet. Numerical simulation results show a stratified damage observation in the concrete, consisting of a crushing zone (plastic damage), crack formation zone (plastic and brittle damage), and crack propagation zone (brittle damage). Furthermore, concrete undergoes plastic failure when the shear stress on an element exceeds 5 MPa. Brittle failure due to tensile stress occurs only when both the maximum principal stress (σ₁) and the minimum principal stress (σ₃) are greater than zero at the same time. The damage degree ($\chi$) of the concrete is observed to increase with jet diameter, concentration of abrasive particles, and velocity of jet. A series of orthogonal tests are performed to analyze the influence of velocity of jet, concentration of abrasive particles, and jet diameter on the damage degree and impact depth (h). The parametric numerical studies indicates that jet diameter has the most significant influence on damage degree, followed by abrasive concentration and jet velocity, respectively, whereas the primary determinant of impact depth is the abrasive concentration followed by jet velocity and jet diameter. Based on the parametric analysis, two optimized abrasive waterjet configurations are proposed: one tailored for rock fragmentation in tunnel boring machine (TBM) operations; and another for cutting reinforced concrete piles in shield tunneling applications. These configurations aim to enhance the efficiency and sustainability of excavation and tunneling processes through improved material removal performance and reduced mechanical wear. Full article

In the cotton fields in Xinjiang, residual film is present in the soil for a long period of time, leading to a decrease in the tensile strength of the residual film and increasing the difficulty of recycling. Existing technologies for residual film recovery focus on mechanical properties and ignore the dragging and tearing of residual film by cotton stubble. The effect of cotton straw–root stubble on residual film recovery can only be better determined by appropriate machine operating parameters, which are essential to improving residual film recovery. Through analyses of the pickup device, key parameters were identified, and a model was built by combining the FEM and SPH algorithms to simulate the interaction of nail teeth, residual film, soil and root stubble. The simulation revealed the force change law of residual film in root stubble-containing soil and the influence of root stubble. By simulating the changes in the characteristics of the residual film during the process, the optimum operating parameters for the nail teeth were determined: a forward speed of 1849.57 mm/s, a rotational speed of 5.5 r/s and a soil penetration angle of 30°. Under these optimized conditions, the maximum shear strain, pickup height (maximum deformation) and average peak stress of the residual film were 1293, 363.81 mm and 3.42 MPa, respectively. Subsequently, field trials were conducted to verify the change in the impact of the nail teeth at the optimized speed on the recovery of residual film in plots containing root stubble. The results demonstrated that when the root stubble height was 5–8 cm, the residual film averaged a recovery rate of 89.59%, with a dragging rate of only 4.10% at crossings. In contrast, 8–14 cm stubble plots showed an 82.86% average recovery and an 11.91% dragging rate. In plots with a root stubble height of 5–8 cm, compared with plots with a root stubble height of 8–14 cm, the recovery rate increased by 6.73%, and the dragging rate of residual film on root stubble decreased by 7.81%. The percentage of entangled residual film out of the total unrecovered film was 30.10% lower in the 5–8 cm stubble plots than in the 8–14 cm stubble plots. It was confirmed that the effect of cotton root stubble on residual film recovery could be reduced under appropriate machine operating parameters. This provides strong support and a theoretical and practical basis for future research on the correlation between root stubble and residual film and how to improve the residual film recovery rate. Full article

In recent years, geological disasters such as water inrush during drilling and blasting operations have posed significant challenges in tunnel engineering. This paper presents a novel continuous-discrete coupling method based on LS-DYNA, combining the finite element method (FEM) and smoothed particle hydrodynamics (SPH), to simulate the water inrush phenomenon in blasting engineering. The proposed FEM-SPH model effectively captures the propagation of explosion shock waves, simulates small deformation areas with solid grids, and models water behavior using SPH. This study systematically investigates the dynamic evolution of water inrush, divided into three distinct phases: the rupture of the water-resistant rock layer, the emergence of fluid-conducting channels, and the onset of large-scale water influx. Results indicate that under blasting load, the stress of the surrounding rock increases sharply, leading to instantaneous water inrush. The FEM-SPH model demonstrates superior performance in simulating the complex interactions between blasting stress waves, water pressure, and rock mass damage. This research provides new insights and methods for water control in tunnel engineering and offers significant potential for preventing water inrush disasters in underground construction. Full article

This study systematically analyzes the influence of the charge length-to-diameter ratio and stemming length on the radius and volume of blasting craters in coal and rock blasting crater tests to effectively address the challenge of achieving coal–rock separation in mixed blasting construction. In addition, it examines the energy distribution mechanism of blasting fragmentation and establishes characteristic equations for coal and rock blasting craters. Numerical simulations and blasting tests are conducted to investigate the casting effect of rock benches and the fragmentation characteristics of coal and rock benches under different charge structures. The results indicate that when the ratio of charge length to stemming length exceeds 0.91 and 0.74 for the coal and rock benches, respectively, the utilization rate of explosive energy for rock fragmentation gradually surpasses that for rock throwing. The charging structure is identified as a key factor in achieving coal–rock mixed blasting and separation mining. The explosive energy is effectively utilized with a bottom interval length of 2 m for rock benches and a stemming length ranging from 2.5 to 3 m for coal seams. This configuration raises the connectivity of rock damage cracks, improves the distribution of tensile cracks at the top of the coal seam, and prevents bulging or coal–rock interactions (blasting mixing) at the coal–rock interface. The findings demonstrate that the optimized charging structure effectively achieves separate mining in coal–rock mixed blasting, fulfilling the requirement of avoiding coal–rock mixing during blasting. The research provides valuable mining strategies and technical experience for achieving separate mining in coal–rock mixed blasting in open-pit coal mines and improving the recovery of thin coal seams. Full article

This study explores the damage behavior of typical titanium alloy aircraft panel structures under high-speed fragment impacts via ballistic experiments and FEM-SPH simulations. Using a ballistic gun and two-stage light gas gun, tests were conducted with spherical, rhombic, and rod-shaped fragments at 1100–2100 m/s to analyze damage morphology. The FEM-SPH method effectively modeled dynamic impacts, capturing primary penetration and debris cloud-induced secondary damage. Residual strength under tension was evaluated via multiple restart analysis, linking impact dynamics to post-damage mechanics. Experimental results revealed fragment-dependent damage modes: spherical fragments caused circular shear holes with conical/jet-like debris clouds; rhombic fragments induced irregular tearing and triangular perforations due to unstable flight; rod-shaped fragments produced elongated breaches with extensive plastic deformation in stringers. Numerical simulations accurately reproduced debris cloud diffusion and secondary effects like spallation. Residual strength analysis showed tensile capacity was governed by breach geometry and location: rhombic breaches (34.6 kN) had lower strength than circular/square ones (38.1–38.3 kN) due to tip stress concentration, while stringer-located damage increased ultimate load by 8–12% via structural redundancy. In conclusion, high-speed fragment impacts dominate shear/tensile tearing, with morphology dependent on fragment characteristics and impact conditions. Debris cloud-induced secondary damage must be considered in structural assessments. The FEM-SPH method is effective for complex damage simulation, while breach geometry and damage location are critical for residual strength. Stringer involvement enhances load-bearing capacity, highlighting component-level design importance for aircraft survivability. The study results and methodologies presented herein can serve as references for aircraft structural damage analysis, residual strength evaluation of battle-damaged structures, and survivability design. Full article

The coordinated optimization of free-surface dynamics tracking and solid deformation computation remains a persistent challenge in casting filling simulations. While the traditional smoothed particle hydrodynamics (SPH) method suffers from prohibitive computational costs limiting practical applications, the delayed interface updates of the finite element method (FEM) compromise simulation fidelity. This study proposes a symmetric SPH-FEM coupling algorithm that integrates real-time particle-grid data exchange, and validation through ring filling simulations demonstrated close agreement with Schmid’s benchmark experiments, confirming flow field reconstruction reliability. Furthermore, bottom-injection plate experiments verified the method’s thermal modeling stability, achieving fully coupled flow–thermal–stress simulations with enhanced computational efficiency. The proposed symmetric coupling framework achieves engineering-ready simulation speeds without compromising accuracy, and this advancement establishes a novel computational tool for predicting casting defects including porosity and hot tears, significantly advancing the implementation of high-fidelity numerical simulation in foundry engineering applications. Full article

Apron is a commonly used structure in the downstream of debris-flow-retaining dams. Its function is to resist the impact and erosion of debris flow on the dam foundation. In order to enhance the impact resistance of the apron to boulders, increasing the apron thickness and filling the block stone are usually adopted. However, the apron is still often destroyed by bouldery debris flow. Therefore, we propose a kind of toughness apron. Physical test and numerical simulation are used to reveal the dynamic response of the toughness apron. The results show that both tire cushion and stone cushion can buffer the impact of boulders. The physical test showed that the cushion reduces impact force and vibration acceleration, and the numerical simulation results indicate that the cushion significantly reduces damage to the protection apron while dissipating most of the energy. It was also found that there is an energy threshold of impact damage resistance of the apron. When the impact kinetic energy is higher than this threshold, the apron will be damaged. These findings highlight its potential for debris flow protection. According to the corresponding impact characteristics of the dam, the design method of the toughness apron is proposed. Full article

After existing ultra-deep vertical rotary tillers work in sugarcane stubble fields, the stubble chopping performance is poor, and the reason for this is unknown. To solve this, this paper develops a simulation model of ultra-deep vertical rotary tillage (UDVRT) in a sugarcane stubble field using the FEM-SPH coupling method and physical testing. The simulation model is used to investigate the rotary tillage process in the stubble field and the stubble chopping mechanism of the UDVRT cutter, identifying the causes of inadequate stubble chopping effectiveness. The results show that, when comparing the simulation with the field test, the magnitude and variation of the cutter’s torque curves are relatively consistent, the relative error of the topsoil fragmentation rate is 9.5%, the entire cultivated layer of soil fragmentation rate is 11.3%, and the average number of times the stubble stem was cut off is closer; thus, the modeling method of the simulation model is reasonable and accurate. When the cutter cuts the soil and the stubble simultaneously, the soil’s constraint on the stubble is gradually weakened, the velocity difference between the blade and the stem becomes smaller, the tilt of the stems becomes larger, and the number of times the blade can cut the stems reduces, leading to the poor chopping effect of stubble. The cutter cuts the stubble in the order of the blade from top to bottom, with the blade cutting the stem first and then the root, which is an effective measure to increase the stubble fragmentation rate. The findings of this paper can provide a reliable theoretical basis for the optimal design of a UDVRT cutter. Full article

This study investigates the potential of hyperbolic paraboloid (hypar) shapes for enhancing wave attenuation and structural efficiency in Free-Surface Breakwaters (FSBW). A decoupled approach combining Smoothed Particle Hydrodynamics (SPH) and Finite Element Method (FEM) is employed to analyze hypar-faced FSBW performance across varying hypar warping values and wave characteristics. SPH simulations, validated through experiments, determine wave attenuation performance and extract pressure values for subsequent FEM analysis. Results indicate that hypar-faced FSBW produces increased wave attenuation compared to traditional flat-faced designs, particularly for shorter wave periods and smaller drafts. Furthermore, hypar surfaces exhibit up to three times lower principal stresses under wave loading compared to the flat counterpart, potentially allowing for thinner surfaces. The study also shows that peak-load static stress values provide a reasonable approximation for preliminary design, with less than 6% average difference compared to dynamic analysis results. In summary, this research presents hypar-faced FSBW as a promising alternative in coastal defense strategies, offering effective wave attenuation and structural efficiency in the context of rising sea levels and increasing storm intensities. Full article

The authors of this study focused their research on developing cap geometries for the FibroScan^® elastograph (FibroScan, EchoSens, Paris, France) measuring head aimed at a non-invasive assessment of liver condition for transplantation using a pig animal model. Numerical models were created to simulate the propagation of a mechanical wave through a biological medium induced by the FibroScan^® elastograph measuring head. The designed caps were intended to replicate the skin–muscle–rib–liver structures to minimize the risk of damage caused by mechanical wave excitation when directly applied to liver tissue. The construction process of numerical models for the liver and surrounding tissues is presented, along with simulations reflecting the mechanical and acoustic properties of the wave propagation process. The results obtained from in vivo measurements on pigs were validated through a numerical analysis, confirming a high level of agreement between the test results and the numerical model. Full article

Given the significantly large deformation and high strain exhibited by explosively formed projectiles (EFP) in penetration, their penetration performance into multi-layer targets differs from that of ordinary bullets or rigid projectiles. Therefore, it is necessary to investigate the ballistic performance and the damage mechanism of target deformation when an EFP penetrates a multi-layer target. This study conducted high-velocity impact tests of EFPs on four types of multi-layer steel targets, analyzing the damage morphology and deformation characteristics of multi-layer steel targets subjected to EFP penetration from both macro and micro levels. To investigate the anti-penetration performance of more target combinations at different EFP velocities, an accurate symmetrical finite element model of EFP penetration into multi-layer targets was established using Autodyn 16.0 finite element software and the SPH-FEM algorithm based on the symmetrical characteristics of the EFP and target structure. The experimental and simulation results showed that for a three-layer composite target, when the thickness of the middle layer remained constant, using the target layers with a front–rear target thickness ratio of less than one was beneficial for enhancing the anti-penetration performance of the targets against EFPs; when the EFP velocity was low and the residual velocity for penetrating a single-layer target was no more than 200 m/s, the anti-penetration performance of the two-layer target was optimal. When the EFP velocity exceeded 1500 m/s, the single-layer target exhibited the best anti-penetration performance to the EFP, and the more layers, the smaller the ballistic resistance. When the number of layers was more than six, the ballistic resistance of the multi-layer targets gradually tended to remain constant. Full article

Burst morphology is a crucial indicator for evaluating the effectiveness of blasting, as it directly reflects the actual state of the blasting results. The results of rock displacement following blasting partially reflect the effectiveness of throw blasting, while the rock ejection process serves as the macroscopic manifestation of the blasting method. To accurately assess the impact of different delay times on burst formation, this study addressed the issues of rock movement and ejection in underground blasting. Using three-dimensional modeling, we constructed a FEM–SPH model and utilized LS-DYNA numerical simulation software to investigate the movement patterns of rock in precise delayed blasting scenarios underground. This study explored the spatiotemporal evolution characteristics of rock movement post-blasting. Digital electronic detonators were used to set precise inter-row delay times of 25 ms, 50 ms, and 75 ms. The results revealed that the ejection distance of blasted rock in underground mining increased with longer inter-row delay times, while the slope angle of the blasted muck pile decreased as the delay time increased. Furthermore, at a micro level, the study found that a 75 ms delay created new free surfaces, providing effective compensation space for subsequent blasts, thereby improving blasting outcomes. Analysis of the 25 ms and 50 ms delay periods indicated a clamping effect on rock movement. Field comparisons of blasting results were conducted to validate the influence of precise delay times on the movement patterns and spatiotemporal evolution characteristics of blasted rock. Full article

The natural caving method, as a new technique in underground mining, has been promoted and applied in several countries worldwide. The destruction of the bottom rock mass structure directly impacts the structural stability of underground engineering, resulting in damage and collapse of underground tunnels. Therefore, based on the principles of explosion theory and field monitoring data, a scaled three-dimensional numerical simulation model of underground blasting was constructed using LS-DYNA19.0 software to investigate the attenuation patterns of underground blasting vibrations and their impact on nearby tunnels. The results show that the relative error range between the simulated blasting vibration velocities based on the FEM-SPH (Finite Element Method–Smoothed Particle Hydrodynamics) algorithm and the measured values is between 7.75% and 9.85%, validating the feasibility of this method. Significant fluctuations in blasting vibration velocities occur when the blast center increases to within a range of 10–20 m. As the blast center distance exceeds 25 m, the vibration velocities are increasingly influenced by the surrounding stress. Additionally, greater stress results in higher blasting vibration velocities and stress wave intensities. Fitting the blasting vibration velocities of various measurement points using the Sadovsky formula yields fitting correlation coefficients ranging between 0.92 and 0.97, enabling the prediction of on-site blasting vibration velocities based on research findings. Changes in propagation paths lead to localized fluctuations in the numerical values of stress waves. These research findings are crucial for a deeper understanding of underground blasting vibration patterns and for enhancing blasting safety. Full article

To address the impact of layered ice and seawater on polar vessels navigating in icy waters, this study employs a coupled finite element method (FEM) and smoothed particle hydrodynamics (SPH) algorithm to simulate the collision dynamics between the bow and stern of a designated icebreaker and the ice layers. The foundational principles and deployment strategies of the coupling algorithm have been meticulously delineated, with a subsequent simulation conducted to model the trajectory of icebreakers navigating through stratified ice conditions. The ice load on the hull, the movement of broken ice bodies, and the temporal variation of ice resistance during collision were analyzed. The method’s applicability and precision were substantiated through a comparative analysis between the simulated ice resistance outcomes and the ice load estimations derived from the Lindqvist formula. Finally, the differences between the bow and stern icebreaking methods were compared. The research findings indicate that the coupling algorithm demonstrates high precision in simulating the navigation of icebreakers under layered ice conditions, aligning with actual scenarios. This provides a solid foundation for further exploration of the ice load on polar vessels. Furthermore, at equivalent speeds and ice thicknesses, stern icebreaking was observed to induce greater oscillations in ice load and yield a higher mean resistance compared to bow icebreaking. Full article
