Search Results (13)

To enhance the understanding of the seismic behavior of reinforced concrete (RC) hollow piers, a sensitivity analysis of design parameters is conducted. A novel analytical model named the Axial–Flexure–Shear-Interaction-Membrane-Beam-Truss-Element-Model (AFSI-MBTEM) is proposed to account for the flexure–shear coupling. To avoid size effects, three full-scale rectangular RC hollow piers are simulated and validated using the AFSI-MBTEM. Based on a benchmark model, the influence of parameters on seismic responses is explored under cyclic loading, earthquakes, and different PGAs. The AFSI-MBTEM can efficiently and accurately capture the symmetric and asymmetric hysteretic curves of RC hollow piers. The influence of parameters under cyclic loading is generally consistent with that under strong earthquakes. The aspect ratio, width-to-depth ratio, wall thickness ratio, axial load ratio, and longitudinal rebar ratio have a significant influence under cyclic loading, earthquakes, and different PGAs. The influence of stirrup ratio, concrete strength, and longitudinal rebar strength becomes clear under earthquakes, especially for residual deformation. The suggested parameter values for hollow piers are as follows: aspect ratio of 4–6, width-to-depth ratio of 1.0–2.0, wall thickness ratio of 20–40%, axial load ratio of 0.05–0.10, longitudinal rebar ratio of 1.2–2.2%, stirrup ratio of 0.8–1.2%, concrete strength of C40, and longitudinal rebar strength of 400 MPa and 500 MPa. Full article

Following World War II, the swift economic growth in construction and the soaring demand in urban regions led to the excessive extraction of natural resources like fossil fuels, minerals, forests and land. To tackle significant global challenges, including the consumption of natural resources, air pollution and climate change, radical changes have been suggested over the past decades. As part of this strategic initiative, prioritizing sustainability in construction has emerged as a crucial focus in the design of all projects. In order to identify the most environmentally sustainable reinforced concrete (RC) slab system, this research investigates the carbon emissions associated with various slab systems, including solid, voided slabs and precast floor systems. The results demonstrate that beam and slab floor and solid slabs have the highest embodied carbon due to the significant use of concrete and related materials, whereas voided slabs and two-way joist floors exhibit lower carbon emissions. The results indicate that the two-way joist system is the most environmentally advantageous option. For precast floor systems, post-tensioned concrete and hollow-core slabs demonstrate the lowest embodied carbon levels. This research provides practical recommendations for architects and engineers aimed at enhancing sustainable design methodologies. It emphasizes the importance of incorporating low-carbon materials as well as pioneering flooring technologies in upcoming construction initiatives to support the achievement of global sustainability objectives. Full article

This study investigated the influence of CFRP composite wrapping techniques on the load–deflection and strain relationships of non-prismatic RC beams. A total of twelve non-prismatic beams with and without openings were tested in the present study. The length of the non-prismatic section was also varied to assess the effect on the behavior and load capacity of non-prismatic beams. The strengthening of beams was performed by using carbon fiber-reinforced polymer (CFRP) composites in the form of individual strips or full wraps. The linear variable differential transducers and strain gauges were installed at the steel bars to observe the load–deflection and strain responses of non-prismatic RC beams, respectively. The cracking behavior of unstrengthened beams was accompanied by excessive flexural and shear cracks. The influence of CFRP strips and full wraps was primarily observed in solid section beams without shear cracks, resulting in enhanced performance. In contrast, hollow section strengthened beams exhibited minor shear cracks alongside the primary flexural cracks within the constant moment region. The absence of shear cracks was reflected in the load–deflection curves of strengthened beams, which demonstrated a ductile behavior. The strengthened beams demonstrated 40% to 70% higher peak loads than control beams, whereas the ultimate deflection was increased up to 524.87% compared to that of the control beams. The improvement in the peak load was more prominent as the length of the non-prismatic section increased. A better improvement in ductility was achieved for the case of CFRP strips in the case of short non-prismatic lengths, whereas the efficiency of CFRP strips was reduced as the length of the non-prismatic section increased. Moreover, the load–strain capacity of CFRP-strengthened non-prismatic RC beams was higher than the control beams. Full article

The advantages of using prestressed carbon fiber reinforced polymer (CFRP) for strengthening and retrofitting structures have been reported in recent years. In this regard, most of the studies on prestressed CFRP technique have been carried out in the laboratory test with small-scale and no damage (reinforced concrete) RC beam. However, the real structures that need to be retrofitted in service are often degraded or damaged due to early cracking. This paper aims at studying the effect of prestressed CFRP method on full-scale and damaged RC beams. The damaged levels of four full-scale damaged hollow RC beams taken from an old bridge were evaluated. One damaged beam was tested to check the residual capacity, and the other three were strengthened with prestressed composite strengthened CFRP and steel-carbon fiber reinforced polymer (SCFRP). The flexural behavior of non-strengthened and prestressed strengthened beams was investigated. During the experiments, the failure modes, deflection, yield and ultimate load, strains of concrete, steel reinforcements, and SCFRP were measured and analyzed. The results showed that the stiffness at the elastic stage was increased by 64.9%, 66.9%, and 67.1% after strengthened by SCFRP with 30%, 40%, and 60% prestressing level. Moreover, the ultimate load of damaged hollow RC beams were improved by 19.53%, 21.82%, and 31.9%, respectively. The flexural behavior of the severely damaged RC beam with strength reduction coefficient of 0.65 can be recovered after being strengthened by SCFRP with 40% prestressing levels. Meanwhile, SCFRP-concrete interface debonding failure occurred when the prestressing level exceed 60%, and the characteristics of brittle failure became more evident with increased prestressing level of the SCFRP. Full article

Non-prismatic reinforced concrete (RC) beams are widely used for various practical purposes, including enhancing architectural aesthetics and increasing the overall thickness in the support area above the column, which gives high assurance to services that this will not result in the distortion of construction features and can reduce heights. The hollow sections (recess) can also be used for the maintenance of large structural sections and the safe passage of utility lines of water, gas, telecommunications, electricity, etc. They are generally used in large and complex civil engineering works like bridges. This study conducted a numerical study using the commercial finite element software ANSYS version 15 for analysing RC beams, hollow longitudinally sectioned and retrofitted with carbon fibre reinforced polymers (CFRPs), which were subjected to concentrated vertical loads. The numerical analysis results on the simulated beam models were in excellent agreements with the previous experimental test results. This convergence was confirmed by a statistical analysis, which considered the correlation coefficients, individual arithmetic means and standard deviations for all the calculated deflections of the simulated beam models. A proposed numerical simulation model with the hypotheses can be considered suitable for modelling the behaviours of simple supported non-prismatic RC beams under vertical concentrated loads. The numerical results showed that altering the cross-section from solid to hollow could reduce the load carrying capacities of the beams by up to 53% and increase the corresponding deflections by up to 40%, respectively. Using steel pipes for making recesses could enhance the loading capacity by up to 56%, increase the ductility, and reduce the corresponding deflections by up to 30%, respectively. Finally, it was found that bonding the CFRP sheets in the lower middle tensile areas of the hollow beams could improve the resistance and reduce the deformations by up to 27%. The failure patterns for all the numerical models were shear failure. The cylinder compressive strength could be used as a mechanical parameter for modelling and assessing the structural behaviours of the beam models, as its increase could improve the load carrying capacities and reduce the deflections by 30–50%. Full article

An experimental program was conducted to ascertain the efficiency of Carbon Fiber Reinforced Polymer (CFRP) in enhancing the flexural response of hollow section reinforced concrete (RC) beams. Nine beams were tested under four-point bending in three groups. Beams were categorized to reflect the presence or configuration of the CFRP sheet. Each group consisted of three beams: one with a solid section, one with a square $50\times 50$ mm × mm opening and 1 with $100\times 100$ mm × mm opening. Beams in 1st group were tested in as-built conditions. Beams in the 2nd group were strengthened with a single CFRP sheet bonded to their bottom sides. Configuration of CFRP sheet was altered to U-shape applied to the tension side of 3rd group beams. The inclusion of openings, regardless of their size, did not result in degradation of ultimate load and corresponding deflections. However, cracking loads were found to decline as the opening size increased. Regardless of the opening size and CFRP configuration, ultimate loads of beams increased with the application of CFRP. However, this improvement was limited to the debonding and rupture of CFRP in group 2 and 3 beams, respectively. A comparison in the behavior of group 2 and 3 beams revealed that the application of the U-shape CFRP sheet yielded better flexural performance in comparison with the flat-CFRP sheet bonded to the bottom of beams. In the end, In order to further evaluate the economic and performance benefits of these beams, the cost-benefit analysis was also performed. The analysis showed that the feasibility of the hollow section RC beams is more than the solid section RC beams. Full article

This study aimed to study the cyclic behavior of two-side-connected precast-reinforced concrete infill panel (RCIP). A total of four RCIP specimens with different slit types and height-to-span ratios modeled at a one-third scale were tested subjected to cyclic lateral loads. The failure mode, hysteretic behavior, lateral strength, stiffness degradation, ductility, and energy dissipation capacity of each RCIP specimen were determined and analyzed. The specimens experienced a similar damage process, which involved concrete cracking, steel rebar yielding, concrete crushing, and plastic hinge formation. All the specimens showed pinched hysteretic curves, resulting in a small energy dissipation capacity and a maximum equivalent viscous damping ratio lower than 0.2. The specimens with penetrated slits experienced ductile failure, in which flexural hinges developed at both slit wall ends. The application of penetrated slits decreased the initial stiffness and lateral load-bearing capacity of the RC panel but increased the deformation capacity, the average ultimate drift ratios ranged from 1.41% to 1.99%, and the lowest average ductility ratio reached 2.48. The specimens with high-strength concrete resulted in a small slip no more than 1 mm between the RC panel and steel beam, and the channel shear connectors ensured that the RC infill panel developed a reliable assembly with the surrounding steel components. However, specimens with concealed vertical slits (CVSs) and concealed hollow slits (CHSs) achieved significantly higher lateral stiffness and lateral strength values. Generally, the specimens exhibited two-stage mechanical features. The concrete in the CVSs and CHSs was crushed, and flexural plastic hinges developed at both ends of the slit walls during the second stage. With increasing concrete strength, the initial lateral stiffness and lateral strength values of the RCIP specimens increased. With an increasing height-to-span ratio, the lateral stiffness and strength of the RC panels with slits decreased, but the failure mode remained unchanged. Full article

It is essential to make openings in structural concrete elements to accommodate mechanical and electrical needs. To study the effect of these openings on the performance of reinforced concrete (RC) elements, a numerical investigation was performed and validated using previous experimental work. The effect of the position and dimension of the opening and the beam length on the response of the beams, loads capacities, and failure modes was studied. The simulated RC beams showed different responses, loads capacities, and failure modes depending on the position and dimension of the opening. The transversal near support opening (TNSH) and longitudinal holes (LH) showed lower effects on the load capacities of the beams than the transversal near center opening (TNCH). The supreme reduction percentages of the load capacity (µ_u%) for beams with TNCH and TNSH were 37.21% and 30.34%, respectively (opening size = 150 × 150 mm²). In addition, the maximum µ_u% for beam with LH was 17.82% (opening size = 25% of the beam size). The TNSH with a width of less than 18.18% of the beam shear span (550 mm) had trivial effects on the beam’s load capacities (the maximum µ_u% = 1.26%). Although the beams with combined LH and TNCH or LH and TNSH showed different failure modes, they experienced nearly the same load reductions. Moreover, the length of the beam (solid or hollow) had a great effect on its failure mode and load capacity. Finally, equations were proposed and validated to calculate the yield load and post-cracking deflection for the concrete beams with a longitudinal opening. Full article

Reinforced concrete (RC) beams containing a longitudinal cavity have become an innovative development and advantage for economic purposes of light-weight members without largely affecting their resistance against the applied loads. This type of openings can also be used for maintenance purposes and usage space of communication lines, pipelines, etc. RC beams are primarily loaded in the plane of the members, which are two-dimensional in a plane stress state and the dominant structural behaviours include bending, shear, or combination of both. In the present study, six numerical models of RC beams with and without openings were simulated by using commercial finite element software ANSYS to evaluate the structural behaviours of those beam models under the partial uniformly distributed load. Different parameters were assessed, including opening dimensions and shear reinforcement ratios. The obtained numerical results were analysed and verified and were found very close to those obtained from the experimental investigations in the literature. The increase of shear reinforcement ratio could enhance the flexural and shear capacities of the RC beams, and the results also showed that some models sustained flexural failure while the others sustained failure of combined bending and shear. Full article

In this study, the generalized softened variable angle truss-model (GSVATM) is used to predict the response of reinforced concrete (RC) beams under torsion at the early loading stages, namely the transition from the uncracked to the cracked stage. Being a 3-dimensional smeared truss model, the GSVATM must incorporate smeared constitutive laws for the materials, namely for the tensile concrete. Different smeared constitutive laws for tensile concrete can be found in the literature, which could lead to different predictions for the torsional response of RC beams at the earlier stages. Hence, the GSVATM is used to check several smeared constitutive laws for tensile concrete proposed in previous studies. The studied parameters are the cracking torque and the corresponding twist. The predictions of these parameters from the GSVATM are compared with the experimental results from several reported tests on RC beams under torsion. From the obtained results and the performed comparative analyses, one of the checked smeared constitutive laws for tensile concrete was found to lead to good predictions for the cracking torque of the RC beams regardless of the cross-section type (plain or hollow). Such a result could be useful to help with choosing the best constitutive laws to be incorporated into the smeared truss models to predict the response of RC beams under torsion. Full article

The system reliability evaluation of a bridge structure is a complicated problem. Previous studies have commonly used approximate estimation methods, such as the wide bounds method and the narrow bounds method, but neither could obtain an accurate result. In recent years, the copula theory has been introduced into the system reliability evaluation, which can obtain more accurate results than the approximate methods. However, most studies simply construct binary copula functions to consider the joint failure of two failure modes. For a complex bridge structure composed of multiple components and failure modes, the joint failure of multiple failure modes needs to be considered. Before evaluating the system reliability, it is necessary to determine the failure criteria of the system. Different failure criteria for simply supported beam bridges have been proposed. However, there is no standard available to determine which failure criterion to choose, and the selection of failure criteria is ambiguous. In this paper, a novel method is proposed to evaluate the system reliability of a simply supported beam bridge by considering multiple failure criteria based on multivariate copulas and the analytic hierarchy process entropy weight (AHP–EW) method. The method first considers multiple failure criteria comprehensively and constructs multivariate copulas for the joint failure of multiple components in a bridge system reliability evaluation. The AHP–EW method is a comprehensive weighting method combining the analytic hierarchy process and entropy weight methods, which is used to establish the hierarchical analysis model between system reliability and multiple failure criteria. By considering the joint failure of multiple failure modes in the system reliability evaluation under a single failure criterion, multivariate copula functions were constructed. In order to verify the applicability of the proposed bridge system reliability method, a simply supported reinforced concrete (RC) hollow slab bridge composed of nine slab segments was selected as the numerical example. The results indicate that the method proposed in this paper could evaluate the bridge system reliability more comprehensively and reasonably. Full article

In recent studies, a new softened truss model called Generalized Softened Variable Angle Truss Model (GSVATM) has been proposed to compute the full torsional response of reinforced concrete (RC) rectangular solid beams under pure torsion. In this article, the GSVATM is extended to cover RC hollow beams under torsion. The modification of the calculation procedure, in order to account for the specific behavior of RC hollow beams for low loading levels, as well as the final solution procedure, is presented. The theoretical predictions from the extended GSVATM are compared with experimental results of RC hollow beams under torsion found in the literature. Good agreement is observed between the experimental and theoretical results, for both high and low loading levels. Full article

Increasing importance is being attached to materials in the life-cycle of a building. In the Netherlands, material life-cycle assessments (LCA) are now mandatory for almost all new buildings, on which basis the building is then awarded a building environmental performance or MPG [Milieuprestatie Gebouwen] score. The objective of this study is to reduce the environmental–economic (shadow) costs of precast reinforced concrete (RC) beams in a conventional Dutch office building, thereby improving its MPG score. Two main optimizations are introduced: first, the amount of concrete is reduced, designing a cavity in the cross-section of the beam; second, part of the reinforcement is replaced with a fibre reinforced polymer (FRP) tube. The structural calculations draw from a combination of several codes and FRP recommendations. Hollow FRP-RC beams (with an elongated oval cavity), and flax, glass, and kenaf fibre tubes yielded the lowest shadow costs. In particular, the flax tube obtained shadow costs that were 39% lower than those of the hollow RC beam (with an elongated oval cavity); which also contributed to decreasing the shadow costs of other building components (e.g., facade), thereby reducing the MPG score of the building. However, this study also shows that it is important to select the right type of FRP as hemp fibre tubes resulted in a 98% increase in shadow costs. Full article
