In the digital 3D reconstruction of the shapes and surface reflectance of ancient paintings and drawings using Photometric Stereo (PS) techniques, normal integration is a key step. However, difficulties in locating light sources, non-Lambertian surfaces, and shadows make the results of this step inaccurate for such artworks. This paper presents a solution for PS to overcome this problem based on some enhancement of the normal integration process and the accurate measurement of Points of Interest (PoIs). The mutual positions of the LED lights, the camera sensor, and the acquisition plane in two custom-designed stands, are measured in laboratory as a system calibration of the 3D acquisition workflow. After an introduction to the requirements and critical issues arising from the practical application of PS techniques to artworks, and a description of the newly developed PS solution, the measurement process is explained in detail. Finally, results are presented showing how the normal maps and 3D meshes generated using the measured PoIs’ positions, and further minimized using image processing techniques, which significantly limits outliers and improves the visual fidelity of digitized artworks. Full article

Line structured light (LSL) measurement systems can obtain high accuracy profiles, but the overall clarity relies greatly on the sampling interval of the scanning process. Photometric stereo (PS), on the other hand, is sensitive to tiny features but has poor geometrical accuracy. Cooperative measurement with these two methods is an effective way to ensure precision and clarity results. In this paper, an LSL-PS cooperative measurement system is brought out. The calibration methods used in the LSL and PS measurement system are given. Then, a data fusion algorithm with adaptive weights is proposed, where an error function that contains the 3D point cloud matching error and normal vector error is established. The weights, which are based on the angles of adjacent normal vectors, are also added to the error function. Afterward, the fusion results can be obtained by solving linear equations. From the experimental results, it can be seen that the proposed method has the advantages of both the LSL and PS methods. The 3D reconstruction results have the merits of high accuracy and high clarity. Full article

Predicting accurate normal maps of objects from two-dimensional images in regions of complex structure and spatial material variations is challenging using photometric stereo methods due to the influence of surface reflection properties caused by variations in object geometry and surface materials. To address this issue, we propose a photometric stereo network called a RMAFF-PSN that uses residual multiscale attentional feature fusion to handle the “difficult” regions of the object. Unlike previous approaches that only use stacked convolutional layers to extract deep features from the input image, our method integrates feature information from different resolution stages and scales of the image. This approach preserves more physical information, such as texture and geometry of the object in complex regions, through shallow-deep stage feature extraction, double branching enhancement, and attention optimization. To test the network structure under real-world conditions, we propose a new real dataset called Simple PS data, which contains multiple objects with varying structures and materials. Experimental results on a publicly available benchmark dataset demonstrate that our method outperforms most existing calibrated photometric stereo methods for the same number of input images, especially in the case of highly non-convex object structures. Our method also obtains good results under sparse lighting conditions. Full article

We investigated optimal implementation strategies for industrial inspection systems aiming to detect cracks on ground steel billets’ surfaces by combining state-of-the-art AI-based methods and classical computational imaging techniques. In 2D texture images, the interesting patterns of surface irregularities are often surrounded by visual clutter, which is to be ignored, e.g., grinding patterns. Even neural networks struggle to reliably distinguish between actual surface disruptions and irrelevant background patterns. Consequently, the image acquisition procedure already has to be optimised to the specific application. In our case, we use photometric stereo (PS) imaging to generate 3D surface models of steel billets using multiple illumination units. However, we demonstrate that the neural networks, especially in high-speed scenarios, still suffer from recognition deficiencies when using raw photometric stereo camera data, and are unable to generalise to new billets and image acquisition conditions. Only the additional application of adequate state-of-the-art image processing algorithms guarantees the best results in both aspects. The neural networks benefit when appropriate image acquisition methods together with image processing algorithms emphasise relevant surface structures and reduce overall pattern variation. Our proposed combined strategy shows a 9.25% better detection rate on validation data and is 14.7% better on test data, displaying the best generalisation. Full article

This paper presents a photometric stereo (PS) method based on the dichromatic reflectance model (DRM) using colour images. The proposed method estimates surface orientations for surfaces with non-Lambertian reflectance using diffuse-specular separation and contains two steps. The first step, referred to as diffuse-specular separation, initialises surface orientations in a specular invariant colour subspace and further separates the diffuse and specular components in the RGB space. In the second step, the surface orientations are refined by first initialising specular parameters via solving a log-linear regression problem owing to the separation and then fitting the DRM using Levenburg-Marquardt algorithm. Since reliable information from diffuse reflection free from specularities is adopted in the initialisations, the proposed method is robust and feasible with less observations. At pixels where dense non-Lambertian reflectances appear, signals from specularities are exploited to refine the surface orientations and the additionally acquired specular parameters are potentially valuable for more applications, such as digital relighting. The effectiveness of the newly proposed surface normal refinement step was evaluated and the accuracy in estimating surface orientations was enhanced around $30\%$ on average by including this step. The proposed method was also proven effective in an experiment using synthetic input images comprised of twenty-four different reflectances of dielectric materals. A comparison with nine other PS methods on five representative datasets further prove the validity of the proposed method. Full article

As a classical method widely used in 3D reconstruction tasks, the multi-source Photometric Stereo can obtain more accurate 3D reconstruction results compared with the basic Photometric Stereo, but its complex calibration and solution process reduces the efficiency of this algorithm. In this paper, we propose a multi-source Photometric Stereo 3D reconstruction method based on the fully convolutional network (FCN). We first represent the 3D shape of the object as a depth value corresponding to each pixel as the optimized object. After training in an end-to-end manner, our network can efficiently obtain 3D information on the object surface. In addition, we added two regularization constraints to the general loss function, which can effectively help the network to optimize. Under the same light source configuration, our method can obtain a higher accuracy than the classic multi-source Photometric Stereo. At the same time, our new loss function can help the deep learning method to get a more realistic 3D reconstruction result. We have also used our own real dataset to experimentally verify our method. The experimental results show that our method has a good effect on solving the main problems faced by the classical method. Full article

Visual inspections of nuclear power plant (NPP) reactors are important for understanding current NPP conditions. Unfortunately, the existing visual inspection methods only provide limited two-dimensional (2D) information due to a loss of depth information, which can lead to errors identifying defects. However, the high cost of developing new equipment can be avoided by using advanced data processing technology with existing equipment. In this study, a three-dimensional (3D) photometric stereo (PS) reconstruction technique is introduced to recover the lost depth information in NPP images. The system uses conventional inspection equipment, equipped with a camera and four light-emitting diodes (LEDs). The 3D data of the object surface are obtained by capturing images under multiple light sources oriented in different directions. The proposed method estimates the light directions and intensities for various image pixels in order to reduce the limitation of light calibration, which results in improved performance. This novel technique is employed to test specimens with various defects under laboratory conditions, revealing promising results. This study provides a new visual inspection method for NPP reactors. Full article
