As the core components of geophysical dynamic system, oceans and atmospheres are dominated by the Coriolis force, which governs complex dynamic phenomena such as internal waves, gravity currents, vortices, and others involving multi-scale spatiotemporal coupling. Due to the limitations of in situ observations, large-scale rotating tanks have emerged as critical experimental platforms for simulating Earth’s rotational effects. This review summarizes recent advancements in rotating tank applications for studying oceanic flow phenomena, including mesoscale eddies, internal waves, Ekman flows, Rossby waves, gravity currents, and bottom boundary layer dynamics. Advanced measurement techniques, such as particle image velocimetry (PIV) and planar laser-induced fluorescence (PLIF), have enabled quantitative analyses of internal wave breaking-induced mixing and refined investigations of vortex merging dynamics. The findings demonstrate that large-scale rotating tanks provide a controllable experimental framework for unraveling the physical essence of geophysical fluid motions. Such laboratory experimental endeavors in a rotating tank can be applied to more extensive scientific topics, in which the rotation and stratification play important roles, offering crucial support for climate model parameterization and coupled ocean–land–atmosphere mechanisms. Full article

A detailed experimental study of ethanol spray swirling flames was performed in an axial bluff body stabilized burner. The characteristics of the non-reacting and reacting sprays were recorded by particle imaging velocimetry (PIV) and planar laser-induced fluorescence (PLIF) of the OH radical. A few typical flames with different structures (outer-side-flame-lifting, stable, and near-blow-off) were compared and analyzed. The parameters of the spray, including the spray half-angle (α) and droplet number density (n_d), are quantified, and it has been found the flame structure and stability were strongly correlated with the droplet distribution. Several parameters of the flow field, such as velocity magnitude ($\left|U\right|$ vorticity (ω_z), and turbulent kinetic energy (TKE), are quantitively analyzed, and it is observed that the local strain rate rose as the air flow rate increased, which is not conducive to local flame stability. Regarding the flame, quantities such as progress variable (<c>), flame height (L_f), lift–off height (h_lf), and symmetry factor (S_nd and S_<c>) are calculated, and it can be observed that the flame symmetry keeps worsening when approaching blow–off, and the inner flame branch exhibits a worse stabilization than the outer one. Our comprehensive investigations offer a deeper understanding of stable combustion in such two–phase flames. Full article

The present paper reports on the combined stereoscopic particle image velocimetry (PIV) and planar laser induced fluorescence (PLIF) measurements of turbulent transport for model swirl burners without combustion. Two flow types were considered, namely the mixing of a free jet with surrounding air for different swirl rates of the jet (Re = 5 × 10³) and the mixing of a pilot jet (Re = 2 × 10⁴) with a high-swirl co-flow of a generic gas turbine burner (Re = 3 × 10⁴). The measured spatial distributions of the turbulent Reynolds stresses and fluxes were compared with their predictions by gradient turbulent transport models. The local values of the turbulent viscosity and turbulent diffusivity coefficients were evaluated based on Boussinesq’s and gradient diffusion hypotheses. The studied flows with high swirl were characterized by a vortex core breakdown and intensive coherent flow fluctuations associated with large-scale vortex structures. Therefore, the contribution of the coherent flow fluctuations to the turbulent transport was evaluated based on proper orthogonal decomposition (POD). The turbulent viscosity and diffusion coefficients were also evaluated for the stochastic (residual) component of the velocity fluctuations. The high-swirl flows with vortex breakdown for the free jet and for the combustion chamber were characterized by intensive turbulent fluctuations, which contributed substantially to the local turbulent transport of mass and momentum. Moreover, the high-swirl flows were characterized by counter-gradient transport for one Reynolds shear stress component near the jet axis and in the outer region of the mixing layer. Full article

The experimental and numerical results on the flow structure and heat transfer in a bubbly polydispersed upward duct flow in a backward-facing step are presented. Measurements of the carrier fluid phase velocity and gas bubbles motion are carried out using the PIV/PLIF system. The set of RANS equations is used for modeling the two-phase bubbly flow. Turbulence of the carrier fluid phase is predicted using the Reynolds stress model. The effect of bubble addition on the mean and turbulent flow structure is taken into account. The motion and heat transfer in a dispersed phase is modeled using the Eulerian approach taking into account bubble break-up and coalescence. The method of delta-functions is employed for simulation of distributions of polydispersed gas bubbles. Small bubbles are presented over the entire duct cross-section and the larger bubbles mainly observed in the shear mixing layer and flow core. The recirculation length in the two-phase bubbly flow is up to two times shorter than in the single-phase flow. The position of the heat transfer maximum is located after the reattachment point. The effect of the gas volumetric flow rate ratios on the flow patterns and maximal value of heat transfer in the two-phase flow is studied numerically. The addition of air bubbles results in a significant increase in heat transfer (up to 75%). Full article

Cage-based aquaculture has been growing rapidly in recent years. In some locations, cage-based aquaculture has resulted in the clustering of large quantities of cages in fish farms located in inland lakes or reservoirs and coastal embayments or fjords, significantly affecting flow and mass transport in the surrounding waters. Existing studies have focused primarily on the macro-scale flow blockage effects of fish cages, and the complex wake flow and associated near-field mass transport in the presence of the cages remain largely unclear. As a first step toward resolving this knowledge gap, this study employed the combined Particle Image Velocimetry and Planar Laser Induced Fluorescence (PIV-PLIF) flow imaging technique to measure turbulence characteristics and associated mass transport in the near wake of a steady current through an aquaculture cage net panel in parametric flume experiments. In the near-wake region, defined as ~3M (mesh size) downstream of the net, the flow turbulence was observed to be highly inhomogeneous and anisotropic in nature. Further downstream, the turbulent intensity followed a power-law decay after the turbulence production region, albeit with a decay exponent much smaller than reported values for analogous grid-generated turbulence. Overall, the presence of the net panel slightly enhanced the lateral spreading of the scalar plume, but the lateral distribution of the scalar concentration, concentration fluctuation and transverse turbulent scalar flux exhibited self-similarity from the near-wake region where the flow was still strongly inhomogeneous. The apparent turbulent diffusivity estimated from the gross plume parameters was found to be in reasonable agreement with the Taylor diffusivity calculated as the product of the transverse velocity fluctuation and integral length scale, even when the plume development was still transitioning from a turbulent-convective to turbulent-diffusive regime. The findings of this study provide references to the near-field scalar transport of fish cages, which has important implications in the assessment of the environmental impacts and environmental carrying capacity of cage-based aquaculture. Full article

A customized particle image velocimetry/planar laser induced fluorescence (PIV/PLIF) experimental method, aiming to capture transient hydrodynamics of solitary waves of inertia-dominated falling liquid films, is presented in this paper. A novel PIV/PLIF technique, which only uses one camera to capture simultaneously both particle image and fluorescence, and meanwhile a post-processing imaging method is also developed, which is able to simultaneously measure both internal velocity field in film and its topology. To validate the fidelity of the novel PIV/PLIF technique, a comparison between experimental results of streamwise velocity profile and film thickness and that of the Nusselt’s prediction at low Reynold number is carried out, and in addition, integral continuity is checked for transient wavy film, both of which shows that they are in good agreement. Based on experimental velocity fields and film topology, pressure distribution inside film is derived with the Poisson equation. Considering characteristics of traveling waves, the experimental results are presented respectively in spatial mode and temporal mode. In spatial mode, capillary wave dynamics are demonstrated out of velocity field, film topology and pressure distribution, which reveals that flow reversal occurs at capillary troughs. In temporal mode, the mechanism of flow reversal at capillary troughs is scrutinized on the basis of high-frequency velocity sampling and the derived pressure gradient. It is shown that flow reversal at capillary troughs is triggered due to occurrence of positive pressure gradient at the back side of the capillary wave crest, rather than the trough upstream as stated by the previous researchers. By elucidating the dynamics of flow reversal, mechanisms for the upper limit of Reynold number with respect to flow reversal underneath capillary wave trough were proposed, which might be the gradually saturated deceleration from the capillary curvature and shorten deceleration duration determined by the wave speed and capillary wave length. Our results should be of interest for optimization of the mass transport model of falling liquid films and shed light on the revealing of flow reversal mechanism. Full article

Although the turbulent intensity is suppressed in the drag-reducing channel flow by viscoelastic additives, the mean velocity distribution in the channel flow is symmetrical and tends to be similar to the laminar flow. In the study of near-wall modulation of the drag-reducing flow with an injected ultrathin water layer, an asymmetrical mean velocity distribution was found. To further investigate this phenomenon and the underlying cause, an experiment was carried out with the water injected from a porous channel wall at a small velocity (~10⁻⁴ m/s) into the drag-reducing flow of surfactant solution. The instantaneous concentration and flow fields were measured by using planar laser-induced fluorescence (PLIF) and particle imaging velocimetry (PIV) techniques, respectively. Moreover, analyses on turbulent statistical characteristics and spatial distribution of viscoelastic structures were carried out on the basis of comparison among various flow cases. The results showed that the injected ultrathin water layer under present experimental conditions affected the anisotropy of the drag-reducing flow. The characteristics, such as turbulence intensity, showed the zonal feature in the wall-normal direction. The Reynolds shear stress was enhanced in the near-wall region, and the viscoelastic structure was modified severely due to the redistributed stress. These results may provide experimental supports for the near-wall modulation of turbulence and the exploration of the drag-reducing mechanism by viscoelastic additives. Full article

The recent growing attention to energy saving and environmental protection issues has brought attention to the possibility of exploiting syngas from gasification of biomass and coal for the firing of industrial plants included in the, so called, Integrated Gasification Combined Cycle power plants. In order to improve knowledge on the employ of syngas in lean premixed turbulent flames, a large scale swirl stabilized gas-turbine burner has been operated with a simplified model of H₂ enriched syngas from coal gasification. The experimental campaign has been performed at atmospheric pressure, with operating conditions derived from scaling the real gas turbines. The results are reported here and consist of OH-PLIF (OH Planar Laser Induced Fluorescence) measurements, carried out at decreasing equivalence of air/fuel ratio conditions and analysed together with the mean aerodynamic characterisation of the burner flow field in isothermal conditions obtained through LDV (Laser Doppler Velocimetry) and PIV (Particle Image Velocimetry) measurements. The OH concentration distributions have been analysed statistically in order to obtain information about the location of the most reactive zones, and an algorithm has been applied to the data in order to identify the flame fronts. In addition, the flame front locations have been successively interpreted statistically to obtain information about their main features and their dependence on the air to fuel ratio behaviour. Full article
