A sol–gel deposition approach was applied for obtaining nanostructured Li-doped ZnO thin films. ZnO:Li films were successfully spin-coated on quartz and silicon substrates. The evolution of their structural, vibrational, and optical properties with annealing temperature (300–600 °C) was studied by X-ray diffraction (XRD), Fourier Transform Infrared (FTIR), UV-VIS spectroscopic, and field emission scanning electron microscopic (FESEM) characterization techniques. It was found that lithium doping maintains the wurtzite arrangement of ZnO, with increasing crystallite sizes when increasing the annealing temperature. Analysis of the FTIR spectra revealed a broad main absorption band (around 404 cm⁻¹) for Li-doped films, implying the inclusion of Li into the ZnO lattice. The ZnO:Li films were transparent, with slightly decreased transmittance after the use of higher annealing temperatures. The porous network of undoped ZnO films was transformed to a denser, grained, packed structure, induced by lithium doping. Full article

This review addresses the importance of Zn for obtaining multifunctional materials with interesting properties by following certain preparation strategies: choosing the appropriate synthesis route, doping and co-doping of ZnO films to achieve conductive oxide materials with p- or n-type conductivity, and finally adding polymers in the oxide systems for piezoelectricity enhancement. We mainly followed the results of studies of the last ten years through chemical routes, especially by sol-gel and hydrothermal synthesis. Zinc is an essential element that has a special importance for developing multifunctional materials with various applications. ZnO can be used for the deposition of thin films or for obtaining mixed layers by combining ZnO with other oxides (ZnO-SnO₂, ZnO-CuO). Also, composite films can be achieved by mixing ZnO with polymers. It can be doped with metals (Li, Na, Mg, Al) or non-metals (B, N, P). Zn is easily incorporated in a matrix and therefore it can be used as a dopant for other oxidic materials, such as: ITO, CuO, BiFeO_3, and NiO. ZnO can be very useful as a seed layer, for good adherence of the main layer to the substrate, generating nucleation sites for nanowires growth. Thanks to its interesting properties, ZnO is a material with multiple applications in various fields: sensing technology, piezoelectric devices, transparent conductive oxides, solar cells, and photoluminescence applications. Its versatility is the main message of this review. Full article

The fabrication of NiO films by different routes is important to extend and improve their applications as hole-transporting layers in organic and inorganic optoelectronic devices. Here, an automated ultrasonic pyrolysis spray method was used to fabricate NiO and Li-doped NiO thin films using nickel acetylacetonate and lithium acetate dihydrate as metal precursor and dimethylformamide as solvent. The effect of the amount of lithium in the precursor solution on the structural, morphological, optical, and electrical properties were studied. XRD results reveal that all the samples are polycrystalline with cubic structure and crystallite sizes in the range of 21 to 25 nm, without any clear trend with the Li doping level. AFM analysis shows that the crystallites form round-shaped aggregates and all the films have low roughness. The optical transmittance of the films reaches values of 60% to 77% with tendency upward as Li content is increased. The electrical study shows that the films are p-type, with the carrier concentration, resistivity, and carrier mobility depending on the lithium doping. NiO:Li (10%) films were successfully incorporated into inorganic light emitting diodes together with Mn-doped ZnS and ZnO:Al films, all deposited on ITO by the same ultrasonic spray pyrolysis technique. Full article

In this study, a Pt/Ag/LZO/Pt resistive random access memory (RRAM), doped by different Li-doping concentrations was designed and fabricated by using a magnetron sputtering method. To determine how the Li-doping concentration affects the crystal lattice structure in the composite ZnO thin films, X-ray diffraction (XRD) and X-ray photoelectron spectroscopy (XPS) tests were carried out. The resistive switching behaviors of the resulting Pt/Ag/LZO/Pt devices, with different Li-doping contents, were studied under direct current (DC) and pulse voltages. The experimental results showed that compared with the devices doped with Li-8% and -10%, the ZnO based RRAM device doped by 5% Li-doping presented stable bipolar resistive switching behaviors with DC voltage, including a low switching voltage (<1.0 V), a high endurance (>10³ cycles), long retention time (>10⁴ s), and a large resistive switching window. In addition, quick switching between a high-resistance state (HRS) and a low-resistance state (LRS) was achieved at a pulse voltage. To investigate the resistive switching mechanism of the device, a conduction model was installed based on Ag conducting filament transmission. The study of the resulting Pt/Ag/LZO/Pt devices makes it possible to further improve the performance of RRAM devices. Full article

In this paper, a double piezoelectric layer acceleration sensor based on Li-doped ZnO (LZO) thin film is presented. It is constituted by Pt/LZO/Pt/LZO/Pt/Ti functional layers and a Si cantilever beam with a proof mass. The LZO thin films were prepared by radio frequency (RF) magnetron sputtering. The composition, chemical structure, surface morphology, and thickness of the LZO thin film were analyzed. In order to study the effect of double piezoelectric layers on the sensitivity of the acceleration sensor, we designed two structural models (single and double piezoelectric layers) and fabricated them by using micro-electro-mechanical system (MEMS) technology. The test results show that the resonance frequency of the acceleration sensor was 1363 Hz. The sensitivity of the double piezoelectric layer was 33.1 mV/g, which is higher than the 26.1 mV/g of single piezoelectric layer sensitivity, both at a resonance frequency of 1363 Hz. Full article

A kind of devices Pt/Ag/ZnO:Li/Pt/Ti with high resistive switching behaviors were prepared on a SiO₂/Si substrate by using magnetron sputtering method and mask technology, composed of a bottom electrode (BE) of Pt/Ti, a resistive switching layer of ZnO:Li thin film and a top electrode (TE) of Pt/Ag. To determine the crystal lattice structure and the Li-doped concentration in the resulted ZnO thin films, X-ray diffraction (XRD) and X-ray photoelectron spectroscopy (XPS) tests were carried out. Resistive switching behaviors of the devices with different thicknesses of Li-doped ZnO thin films were studied at different set and reset voltages based on analog and digital resistive switching characteristics. At room temperature, the fabricated devices represent stable bipolar resistive switching behaviors with a low set voltage, a high switching current ratio and a long retention up to 10⁴ s. In addition, the device can sustain an excellent endurance more than 10³ cycles at an applied pulse voltage. The mechanism on how the thicknesses of the Li-doped ZnO thin films affect the resistive switching behaviors was investigated by installing conduction mechanism models. This study provides a new strategy for fabricating the resistive random access memory (ReRAM) device used in practice. Full article

A novel piezoelectric energy harvester with multi-resonant frequencies based on Li-doped ZnO (LZO) thin films is proposed in this paper, consisting of an elastic element with three (or more) different length cantilever beam arrays and a piezoelectric structure (Al/Li-doped ZnO/Pt/Ti). The LZO thin films of piezoelectric structure were prepared on Pt/Ti/SiO₂/Si by using a radio frequency (RF) magnetron sputtering method under certain process conditions. When the LZO thin films were deposited with an LZO target concentration of 5 wt%, the piezoelectric coefficient d₃₃ was 9.86 pm/V. Based on this, the energy harvester chips were fabricated on a <100> silicon substrate using micro-electromechanical systems (MEMS) technology, and its performance can be measured by fixing it to a printed circuit board (PCB) test substrate. The experimental results show that, when exerting an external vibration acceleration of 2.2 g and a vibration frequency of 999 Hz, the energy harvester can achieve a big load voltage of 1.02 V at a load resistance of 600 kΩ, and a high load power of 2.3 µW at a load resistance of 200 kΩ. Full article

An acceleration sensor based on piezoelectric thin films is proposed in this paper, which comprises the elastic element of a silicon cantilever beam and a piezoelectric structure with Li-doped ZnO piezoelectric thin films. The Li-doped ZnO piezoelectric thin films were prepared on SiO₂/Si by radio frequency (RF) magnetron sputtering method. The microstructure and micrograph of ZnO piezoelectric thin films is analysed by a X-ray diffractometer (XRD), scanning electron microscope (SEM), X-ray photoelectron spectroscopy (XPS), and piezoresponse force microscopy (PFM), respectively. When the sputtering power of 220 W and Li-doped concentration of 5%, ZnO piezoelectric thin films have a preferred (002) orientation. The chips of the sensor were fabricated on the <100> silicon substrate by micro-electromechanical systems (MEMS) technology, meanwhile, the proposed sensor was packaged on the printed circuit board (PCB). The experimental results show the sensitivity of the proposed sensor is 29.48 mV/g at resonant frequency (1479.8 Hz). Full article
