The lake water surface temperature (LWST) is a critical parameter influencing lake ecosystem dynamics and addressing challenges posed by climate change. Traditional point measurement techniques exhibit limitations in providing comprehensive LWST data. However, the emergence of satellite remote sensing and unmanned aerial vehicle (UAV) Thermal Infrared (TIR) technology has opened new possibilities. This study presents an approach for retrieving plateau lake LWST (p-LWST) from UAV TIR data. The UAV TIR dataset, obtained from the DJI Zenmuse H20T sensor, was stitched together to form an image of brightness temperature (BT). Atmospheric parameters for atmospheric correction were acquired by combining the UAV dataset with the ERA5 reanalysis data and MODTRAN5.2. Lake Water Surface Emissivity (LWSE) spectral curves were derived using 102 hand-portable FT-IR spectrometer (102F) measurements, along with the sensor’s spectral response function, to obtain the corresponding LWSE. Using estimated atmospheric parameters, LWSE, and UAV BT, the un-calibrated LWST was calculated through the TIR radiative transfer model. To validate the LWST retrieval accuracy, the FLIR Infrared Thermal Imager T610 and the Fluke 51-II contact thermometer were utilized to estimate on-point LWST. This on-point data was employed for cross-calibration and verification. In the study area, the p-LWST method retrieved LWST ranging from 288 K to 295 K over Erhai Lake in the plateau region, with a final retrieval accuracy of 0.89 K. Results demonstrate that the proposed p-LWST method is effective for LWST retrieval, offering technical and theoretical support for monitoring climate change in plateau lakes. Full article

Thermal imaging cameras and infrared (IR) temperature measurement devices act as state-of-the-art techniques for non-contact temperature determination of the skin surface. The former is cost-intensive in many cases for widespread application, and the latter requires manual alignment to the measuring point. Due to this background, this paper proposes a new method for automated, non-contact, and area-specific temperature measurement of the facial skin surface. It is based on the combined use of a low-cost thermopile sensor matrix and a 2D image sensor. The temperature values as well as the 2D image data are fused using a parametric affine transformation. Based on face recognition, this allows temperature values to be assigned to selected facial regions and used specifically to determine the skin surface temperature. The advantages of the proposed method are described. It is demonstrated by means of a participant study that the temperature absolute values, which are achieved without manual alignment in an automated manner, are comparable to a commercially available IR-based forehead thermometer. Full article

The COVID-19 pandemic took valuable lives all around the world. The virus was so contagious and lethal that some of the doctors who worked with COVID-19 patients either were seriously infected or died, even after using personal protective equipment. Therefore, the challenge was not only to help communities recover from the pandemic, but also to protect the healthcare staff/professionals. In this regard, this paper presents a comprehensive design of a customized pseudo-humanoid robot to specifically deal with contagious patients by taking basic vitals through a healthcare staff member from a remote location amid the COVID-19 pandemic. The proposed design consists of two portions: (1) a complete design of mechanical, electrical/electronic, mechatronic, control, and communication parts along with complete assembly to make a complete multitask-performing robot that interacts with patients to take vitals, termed as RoboDoc, and (2) the design of the healthcare staff side (master/operator side) control of a joystick mechanism with haptic feedback. The proposed RoboDoc design can be majorly divided into three parts: (1) the locomotion part is composed of two-wheeled DC motors on a rover base and two omni wheels to support the movements of the robot; (2) the interaction part consists of a single degree-of-freedom (s-DOF) neck to have communication with different heights of patients and (3) two anthropomorphic arms with three degrees-of-freedom (3-DOF). These parts help RoboDoc to reach to patient’s location and take all of the vitals using relevant devices such as an IR temperature thermometer, pulse oximeter, and electronic stethoscope for taking live auscultations from the lungs and heart of the patient. The mechanical design was created using solid works, and the electronic control design was made via proteus 8.9. For haptic teleoperation, an XBOX 360 controller based on wireless communication is used at the master/operator side. For the convenience of the healthcare staff (operator), an interactive desktop-based GUI was developed for live monitoring of all the vital signs of patients. For the remote conversation between the healthcare staff and the patient, a tablet is mounted (that also serves as the robot’s face), and that tablet is controlled via a mobile application. For visual aid, a DSLR camera is integrated and controlled remotely, which helps the doctor monitor the patient’s location as well as examine the patient’s throat. Finally, successful experimental results of basic vitals of the remote patient such as temperature sensing, pulse oximeter, and heart rate (using haptic feedback) were obtained to show the significance of the proposed cost-effective RoboDoc design. Full article

Quartz crystal microbalances are widely used sensors with applications for the detection of very-low-mass deposition in many different fields, from contamination monitoring in the high vacuum of deep space missions to the monitoring of biological activity or pollution using specifically designed active substrates. These sensors are very stable over time; nevertheless, their sensitivity to the temperature is well known, and different implementations have been devised to correct it, e.g., through compensation with a dual crystal. This paper deals with the effects of temperature on QCM but separates the case of uniform crystal temperature from the case of in-plane temperature gradients considering a QCM based on quartz crystals with deposited film resistors used as both RTDs and heaters. This configuration allows both an accurate temperature measurement and efficient thermal control, allowing the achievement of crystals temperatures in the order of 400 °C higher than the environment with a low power dissipation of the order of 1 W. The film resistors deposited around the electrodes allow directly measuring the average crystal temperature and directly delivering power to the crystal for thermal control. The localized delivery of the heat nevertheless also determines uncommon temperature fields on the crystal, and thus, an analysis of both the effects of temperature on the new microbalance was performed. The temperature gradient has strong effects on the frequency; therefore, along with the temperature, the thermal gradients have tobe compensated. The calibration of the QCM thermometers and the assessment of the achievable measurement accuracy were performed, as well as the determination of the frequency–temperature relationship. The comparison between frequency changes in the case of uniform temperature and those observed while using crystal heaters proved that temperature gradients have a strong effect on the crystal frequency. To identify the temperature field on the crystal surface of a QCM crystal, the gold coating of the deposited films was removed to achieve an emissivity acceptable for thermal imaging with an IR camera. Moreover, image processing for emissivity correction was developed. In order to correlate the temperature gradient with the frequency variation, a test campaign was performed to measure the frequency changes derived from different power levels delivered to the crystal heaters. From this test campaign and thermal analysis, the effect of the thermal gradient was assessed. Full article

There is a growing research interest in wireless non-invasive solutions for core temperature estimation and their application in clinical settings. This study aimed to investigate the use of a novel wireless non-invasive heat flux-based thermometer in acute stroke patients admitted to a stroke unit and compare the measurements with the currently used infrared (IR) tympanic temperature readings. The study encompassed 30 acute ischemic stroke patients who underwent continuous measurement (Tcore) with the novel wearable non-invasive CORE device. Paired measurements of Tcore and tympanic temperature (Ttym) by using a standard IR-device were performed 3–5 times/day, yielding a total of 305 measurements. The predicted core temperatures (Tcore) were significantly correlated with Ttym (r = 0.89, p < 0.001). The comparison of the Tcore and Ttym measurements by Bland–Altman analysis showed a good agreement between them, with a low mean difference of 0.11 ± 0.34 °C, and no proportional bias was observed (B = −0.003, p = 0.923). The Tcore measurements correctly predicted the presence or absence of Ttym hyperthermia or fever in 94.1% and 97.4% of cases, respectively. Temperature monitoring with a novel wireless non-invasive heat flux-based thermometer could be a reliable alternative to the Ttym method for assessing core temperature in acute ischemic stroke patients. Full article

This paper evaluates the feasibility of a method using a single hand-held infrared (IR) thermometer and a mini tower of wet and dry paper towels to psychometrically obtain surface layer temperature and moisture gradients and fluxes. Sling Psychrometers have long been standard measuring devices for quantifying the thermodynamics of near-surface atmospheric gas–vapor mixtures, specifically moisture parameters. However, these devices are generally only used to measure temperature and humidity at one near-surface level. Multiple self-aspirating psychrometers can be used in a vertical configuration to measure temperature and moisture gradients and fluxes in the first 1–2 m of the surface layer. This study explores a way to make multiple vertical psychrometric measurements with a single non-contact IR temperature sensor rather than using two in situ thermometers at each level. The surface layer dry- and wet-bulb temperatures obtained using an IR Thermometer are compared to Kestrel 4000 Weather Meter and Bacharach Sling Psychrometer measurements under various atmospheric conditions and surface types to test the viability of the method. To evaluate the results obtained using this new approach, standard meteorological surface data are collected during each experiment, and moisture parameters are derived via psychrometric equations. The results indicate that, not only is the method possible and practical, but they suggest that the IR Thermometer method may provide more surface layer temperature and moisture gradient and flux sensitivity than other single instrument methods. Full article

In veterinary medicine, the gold standard for assessing body temperature is rectal temperature assessment. Considering that this procedure is stressful for many species, in particular for cats, it could be clinically important to consider an alternative approach for the monitoring of core body temperature. The aim of this study was to test if cutaneous temperature measurements by means of different infrared thermometers are in agreement with the most commonly used method for body temperature measurement in cats. The cutaneous temperature was recorded in the jugular, shoulder, rib, flank, and inner thigh, using three different non-contact infrared thermometers (IR1, IR2, and IR3) in 20 cats. The cutaneous temperature was then compared to the rectal temperature, recorded by means of a digital thermometer. The obtained data indicated that the cutaneous temperature recorded by the infrared thermometers was not in agreement with the data recorded by the digital thermometer in the rectum. In cats, the use of non-contact infrared thermometers gave no reproducible or constant data to justify their application for the recording of body temperature instead of rectal temperature recording. In addition, the infrared temperature measurement devices generated results that were not in good agreement among themselves, providing a novel result of clinical importance. Full article

Biomedical measurements by specialized technological equipment have been used in farm animals to collect information about nutrition, behavior and welfare. This study investigates the relation of semen quality (CASA analysis, viability, morphology, membrane biochemical activity and DNA fragmentation) with boar behavior during ejaculation. Sensors were placed on the boar’s body. Movement features were collected using an inertial measurement unit (IMU), comprising an accelerometer, a gyroscope and a magnetometer. Boar, scrotal and dummy temperatures were measured by an infrared (IR) camera and an IR thermometer, while the face salivation of the boar was recorded by a moisture meter (also based on IR technology). All signals and images were logged on a mobile device (smartphone or tablet) using a Bluetooth connection and then transferred wirelessly to the cloud. The data files were then processed using scripts in MATLAB 2021a (MathWorks, Natick, Massachusetts) to derive the necessary indices. Ninety-four ejaculates from five boars were analyzed in this study. The statistical analysis was performed in the Statistics and Machine Learning Toolbox of MATLAB 2021a using a linear mixed effects model. Significant and strong negative correlations (R² > 0.5, p ≤ 0.05) were observed between boar, dummy and scrotal temperature with the progressive, rapid and slow movement of spermatozoa, VCL (curvilinear velocity), VSL (straight line velocity) and ALH (amplitude of lateral head displacement) kinematics. The volume of the ejaculate was correlated with the scrotal and dummy temperature. Dummy’s temperature was negatively correlated with BCF (beat/cross-frequency), viability and total time of ejaculation, while it was positively correlated with abnormal morphology. Body temperature was negatively correlated with BCF. Positive correlations were noticed between VAP (average path velocity) and total time of ejaculation with body acceleration features, as well as between the overall dynamic body acceleration (ODBA) and total time of ejaculation. In conclusion, the use of biomedical sensors can support the evaluation of boar sperm production capacity, providing valuable information about semen quality. Full article

Fever is a common symptom of many infections, e.g., in the ongoing COVID-19 pandemic, keeping monitoring devices such as thermometers in constant demand. Recent technological advancements have made infrared (IR) thermometers the choice for contactless screening of multiple individuals. Yet, even so, the measurement accuracy of such thermometers is affected by many factors including the distance from the volunteers’ forehead, impurities (such as sweat), and the location measured on the volunteers’ forehead. To overcome these factors, we describe the assembly of an Arduino-based digital IR thermometer with distance correction using the MLX90614 IR thermometer and HC-SR04 ultrasonic sensors. Coupled with some analysis of these factors, we also found ways to programme compensation methods for the final assembled digital IR thermometer to provide more accurate readings and measurements. Full article

The mean radiant temperature (MRT) is an indicator for evaluating the radiant heat environment near occupants and is determined by the radiant heat exchange between the occupants and their surroundings. To control various heating and cooling systems according to the occupants’ thermal comfort, it is essential to consider MRTs in the real-time evaluation of thermal environment. This study proposes a pan–tilt infrared (IR) scanning method to estimate the MRTs at multiple occupant locations in real buildings. The angle factor was calculated by defining the specific classification criteria for dividing the entire indoor surface into sub-surfaces. The coupling IR camera and pan–tilt motor were applied to enable storing data pairs of IR thermal image frame (IR image frame) and pan–tilt angle so each surface area taken by the IR camera can have its direction information. The measurement method of the mean surface temperature using the pan–tilt IR system was presented. The pan–tilt IR system hardware and MRT monitoring software were developed. An experiment was performed to verify the applicability of the proposed pan–tilt IR scanning method. By comparing the surface temperatures measured using a contact thermometer and the proposed IR system, the contact thermometer could cause inaccurate measurement of surfaces with a non-uniform distribution of temperature. The difference between surface temperatures increased by up to 15 °C and, accordingly, the MRT distributions differed by up to 6 °C within the same space. The proposed IR scanning method showed good applicability in various aspects. This paper reports that the MRT has a significant effect on the occupants’ thermal comfort and also suggests considering MRTs in the real-time evaluation of thermal environment to control various heating and cooling systems appropriately. Full article

Thermochromic urea (U) organogel immobilized with a thermochromic tricyanofuran hydrazone (TCFH) chromophore was developed. Thermochromic TCFH chromophore bearing two nitro functional groups on a hydrazone recognition unit was synthesized via an azo-coupling reaction of tricyanofuran (TCF) heterocyclic moiety containing an active methyl group with the diazonium chloride salt of 2,4-dinitroaniline comprising two strongly electron-withdrawing nitro groups. The molecular structure of both intermediates and TCFH dye were characterized by several analytical methods, including ¹H NMR, ¹³C NMR, IR, mass spectroscopy (MS), and elemental analysis. The thermochromic responsiveness could be attributed to the charge delocalization of TCFH as well as to the presence of an intramolecular charge transfer. The generated organogel displayed a thermoreversible sol–gel transition associated with color change. The origin of the monitored thermochromism is a conformational change of the tricyanofuran hydrazone backbone due to the temperature-driven deprotonation–protonation reversible process. The prepared urea–tricyanofuran hydrazone (UTCFH) thermometer acted as a diagnostic tool providing an instant color change between yellow, orange, red and purple upon changing the temperature of the UTCFH organogel in dimethyl sulfoxide (DMSO). This color change was proportionally correlated with increasing the temperature from 44 to 63 °C. The UTCFH organogel composed of urea and push-π-pull hydrazone type tricyanofuran chromophore immobilized physically in the urea organogel was found to function as a temperature-driven chromic thermometer. This chromogenic UTCFH organogel in DMSO displayed a phase transition at 41–48 °C. The morphological properties of the gel internal fibrous nanostructure (80–120 nm) were monitored by scanning electron microscopy (SEM). The colorimetric measurements were monitored by UV–Vis absorption spectroscopy. The chromogenic thermometer demonstrated a good reversibility without fatigue. The mechanism accounting for thermochromism of UTCFH organogel is proposed. Full article

Temperature is a key parameter in many fields and luminescence-based temperature sensing is a solution for those applications in which traditional (mechanical, electrical, or IR-based) thermometers struggle. Amongst the indicator dyes for luminescence thermometry, Ru(II) polyazaheteroaromatic complexes are an appealing option to profit from the widespread commercial technologies for oxygen optosensing based on them. Six ruthenium dyes have been studied, engineering their structure for both photostability and highest temperature sensitivity of their luminescence. The most apt Ru(II) complex turned out to be bis(1,10-phenanthroline)(4-chloro-1,10-phenanthroline)ruthenium(II), due to the combination of two strong-field chelating ligands (phen) and a substituent with electron withdrawing effect on a conjugated position of the third ligand (4-Clphen). In order to produce functional sensors, the dye has been best embedded into poly(ethyl cyanoacrylate), due to its low permeability to O₂, high temperature sensitivity of the indicator dye incorporated into this polymer, ease of fabrication, and excellent optical quality. Thermosensitive elements have been fabricated thereof as optical fiber tips for macroscopic applications (water courses monitoring) and thin spots for microscopic uses (temperature measurements in cell culture-on-a-chip). With such dye/polymer combination, temperature sensing based on luminescence lifetime measurements allows 0.05 °C resolution with linear response in the range of interest (0–40 °C). Full article

In this study, we have studied the effects of temperature and X-ray energy variations on the light output signals from two different fiber-optic sensors, a fiber-optic dosimeter (FOD) based on a BCF-12 as a plastic scintillating fiber (PSF) and a fiber-optic thermometer (FOT) using a silver halide optical fiber as an infrared optical fiber (IR fiber). During X-ray beam irradiation, the scintillating light and IR signals were measured simultaneously using a dosimeter probe of the FOD and a thermometer probe of the FOT. The probes were placed in a beaker with water on the center of a hotplate, under variation of the tube potential of a digital radiography system or the temperature of the water in the beaker. From the experimental results, in the case of the PSF, the scintillator light output at the given tube potential decreased as the temperature increased in the temperature range from 25 to 60 °C. We demonstrated that commonly used BCF-12 has a significant temperature dependence of −0.263 ± 0.028%/°C in the clinical temperature range. Next, in the case of the IR fiber, the intensity of the IR signal was almost uniform at each temperature regardless of the tube potential range from 50 to 150 kVp. Therefore, we also demonstrated that the X-ray beam with an energy range used in diagnostic radiology does not affect the IR signals transmitted via a silver halide optical fiber. Full article

The temperature of the flue-gas in the post combustion zone of a waste to energy (WTE) plant has to be maintained within a fairly narrow range of values, the minimum of which is prescribed by the European Waste Directive 2000/76/CE, whereas the maximum value must be such as to ensure the preservation of the materials and the energy efficiency of the plant. A high degree of accuracy in measuring and controlling the aforementioned temperature is therefore required. In almost the totality of WTE plants this measurement process is carried out by using practical industrial thermometers, such as bare thermocouples and infrared radiation (IR) pyrometers, even if affected by different physical contributions which can make the gas temperature measurements incorrect. The objective of this paper is to analyze errors and uncertainties that can arise when using a bare thermocouple or an IR pyrometer in a WTE plant and to provide a method for the in situ calibration of these industrial sensors through the use of suction pyrometers. The paper describes principle of operation, design, and uncertainty contributions of suction pyrometers, it also provides the best estimation of the flue-gas temperature in the post combustion zone of a WTE plant and the estimation of its expanded uncertainty. Full article

Infrared temperature sensors, simple device for temperature measurement, have been modified for the measurement of temperature distribution on the metal surface in a way of nondestructive detection of defects of the object. In this study, the IR sensor system is utilized for the defect detection in a cylinder with one point heating, and the performance of the system is examined with an aluminum cylinder having a simulated defect. In addition, a 3-D conduction equation is numerically solved to compare the computed temperature profile with the measured one. The experimental outcome indicates that the defect detection is readily available with the proposed device and the point heating is practical for the applications of the defect detection. It is also found that the measured temperature distribution is comparable to the computed result from the conduction equation. Full article
