Non-destructive evaluation (NDE) is highly relevant to assessing micro- and macrostructural changes in ferritic and ferritic/martensitic steels subjected to high temperature loading. These materials are widely used in energy generation, where they undergo extreme thermal and mechanical loads. This study examines the feasibility of micromagnetic NDE techniques, i.e., micromagnetic measurements, supported by machine learning methods, to identify and characterize the micro- and macrostructural changes caused by the mechanical loading at high temperatures of power plant steels, i.e., ferritic/martensitic P91 and the high chromium ferritic steel HiperFer-17Cr2. While the P91 did not show any systematic changes in micromagnetic measurements, which generally correlate with the evolution of the microstructure and the mechanical properties, for the HiperFer-17Cr2, pronounced changes in the micromagnetic properties were observed. In correlation with the evolution of the hardness and cyclic deformation behavior, which are both mainly attributed to Laves phase precipitation, the micromagnetic measurements significantly changed depending on the temperature, number of load cycles and load amplitude applied. Thus, these NDE methods can be used for early diagnosis and preventive maintenance strategies for HiperFer-17Cr2, potentially extending the lifespan of the components and mitigating safety risks. Full article

Concentrating solar power (CSP) and thermal energy storage (TES) based on molten salts still lacks economic feasibility, with the material investment costs being a major drawback. Ferritic stainless steels are a comparatively cheap class of materials that could significantly contribute to cost reductions. The addition of aluminum to ferritic steel can result in self-passivation by forming a compact Al₂O₃ top layer, which exhibits significantly higher corrosion resistance to solar salt compared to the Cr₂O₃ surface layers typically formed on expensive structural alloys for CSP and TES, such as austenitic stainless steels and Ni-base super alloys. However, to date, no ferritic stainless steel combining Al₂O₃ formation and sufficient structural strength is available. For this reason, cyclic salt corrosion tests under flowing synthetic air were carried out on seven Laves phase-forming, ferritic model alloys (17Cr2-14Al0.6-1Nb2.6-4W0.25Si), using “solar salt” (60 wt. % NaNO₃ and 40 wt. % KNO₃). The Al content was varied to investigate the influence on the precipitation of the mechanically strengthening Laves phase, as well as the impact on the formation of the Al-oxide top layer. The W and Nb contents of the alloys were increased to examine their influence on the precipitation of the Laves phase. The salt corrosion experiments demonstrated that simultaneous self-passivation against a molten salt attack and mechanical strengthening by precipitation of fine Laves phase particles is possible in novel ferritic HiperFer^{SCR (salt corrosion-resistant)} steel. Microstructural examination unveiled the formation of a compact, continuous Al₂O₃ layer on the surface of the model alloys with Al contents of 5 wt. % and higher. Furthermore, a stable distribution of fine, strengthening Laves phase precipitates was achieved in the metal matrix, resulting in a combination of molten salt corrosion resistance and potentially high mechanical strength by a combination of solid solution and precipitation strengthening. These results show that high-strength ferritic alloys are suitable for use in CSP applications. Full article

High-performance Ferritic (HiperFer) steels are a novel class of heat-resistant, fully ferritic, Laves phase precipitation hardened materials. In comparison to conventional creep strength-enhanced 9–12 wt.% Cr ferritic–martensitic steels, HiperFer features increased mechanical strength, based on a thermodynamically stable distribution of small (Fe,Cr,Si)₂(Nb,W) Laves phase precipitates, and—owing to its increased chromium content of 17 wt.%—improved resistance to steam oxidation, resulting in superior temperature capability up to 650 °C. Previous publications focused on alloying, thermomechanical processing, and basic mechanical property evaluation. The current paper concentrates on the effect of heat treatment on microstructural features, especially Laves phase population, and the resulting creep performance. At 650 °C and a creep stress of 100 MPa, an increase in rupture time of about 100% was achieved in comparison to the solely thermomechanically processed state. Full article

High-chromium ferritic stainless HiperFer steels were developed for high-temperature applications in power conversion equipment. The presented research describes the precipitation behavior of the Laves phase after the thermomechanical treatment of Fe-17Cr-0.6Nb-2.4W HiperFer alloys with and without the addition of 55 ppm boron. The boron-alloyed variant was produced with the aim of enhancing grain boundary strengthening and consequently increasing creep resistance. The focus is set on the effect of boron on the thermomechanically induced precipitation of (Fe,Cr,Si)₂(Nb,W) Laves phase at grain boundaries. The addition of boron modifies the diffusion conditions in the area of grain boundaries. Consequently, the formation of Laves phase is promoted and the particle growth and coarsening process are suppressed. The impact of boron addition was validated by performing creep and thermomechanical fatigue testing in the standard processing state of HiperFer steel. In the B-alloyed variant, increased creep ductility through the modification of the particle-free zone widths at high-angle grain boundaries was encountered. Nevertheless, an optimized thermomechanical treatment is necessary to fully utilize the increased ductility effect for the creep strength optimization of the B-alloyed grade. Full article

High performance ferritic (HiperFer) stainless steels constitute a new class of low-cost, heat resistant, hardenable materials which combine high creep and fatigue strength with increased steam oxidation and wet corrosion resistance. The fundamental relationships regarding the alloy composition, microstructure, and resulting mechanical properties are largely known and already published, while relevant commercialization issues, such as the effect of processing on the microstructure, have not yet been addressed. The current paper outlines the impact of the forming parameters on the resulting microstructure and the achievable creep properties. Thermomechanical treatment is demonstrated as an effective method for increasing the creep strength for a given chemical composition. This may constitute a key enabler for cost savings in component production, e.g., for the simple machining of “drop-in” turbine blades or bolts from forged bar stock material. Full article

In the present study, the first tailored steel based on HiperFer (high-performance ferrite) was developed specifically for the additive manufacturing process. This steel demonstrates its full performance potential when produced via additive manufacturing, e.g., through a high cooling rate, an in-build heat treatment, a tailored microstructure and counteracts potential process-induced defects (e.g. pores and cavities) via “active” crack-inhibiting mechanisms, such as thermomechanically induced precipitation of intermetallic (Fe,Cr,Si)₂(W,Nb) Laves phase particles. Two governing mechanisms can be used to accomplish this: (I) “in-build heat treatment” by utilizing the “temper bead effect” during additive manufacturing and (II) “dynamic strengthening” under cyclic, plastic deformation at high temperature. To achieve this, the first HiperFer^AM (additive manufacturing) model alloy with high precipitation kinetics was developed. Initial mechanical tests indicated great potential in terms of the tensile strength, elongation at rupture and minimum creep rate. During the thermomechanical loading, global sub-grain formation occurred in the HiperFer^AM, which refined the grain structure and allowed for higher plastic deformation, and consequently, increased the elongation at rupture. The additive manufacturing process also enabled the reduction of grain size to a region, which has not been accessible by conventional processing routes (casting, rolling, heat treatment) so far. Full article

Fully ferritic stainless steels, strengthened by Laves phase precipitates, were developed for high-temperature application in the next generation of ultra-super-critical thermal power plants. Based on the rapid occurrence of thermomechanically induced precipitation in strengthening Laves phase particles, a novel thermomechanical process route for this class of steels was developed. A controlled precipitation of particles, in a desired morphology and quantity, and an optimization of the corresponding forging parameters was achieved on a laboratory scale. This article outlines the very first up-scaling experiment with these optimized forging parameters from the laboratory scale to the industrial scale. The precipitation behavior was analyzed, utilizing digital particle analysis of scanning electron microscopy (SEM) images, to estimate and compare the phase fraction of the precipitated Laves phase, as well as the particle size and distribution. Due to the up-scaling in the forging process, the behavior of the precipitation changed and the precipitation strengthening effect was decreased, in comparison with the laboratory scale. Full article

The combined addition of Nb and W provides increased solid solution and precipitation strengthening by (Fe,Cr,Si)₂(Nb,W)-Laves phase particles of ferritic, 17 wt.% Cr stainless high-performance ferritic (HiperFer) steel. Based on alloy modifications and the obtained hardness, tensile, and creep testing results; a new high alloying variant is proposed as a candidate steel for future structural application up to approximately 680 °C in power engineering and the process industry. Full article

Novel high-performance fully ferritic (HiperFer) stainless steels were developed to meet the demands of next-generation thermal power-conversion equipment and to feature a uniquely balanced combination of resistance to fatigue, creep, and corrosion. Typical conventional multistep processing and heat treatment were applied to achieve optimized mechanical properties for this alloy. This paper outlines the feasibility of thermomechanical processing for goal-oriented alteration of the mechanical properties of this new type of steel, applying an economically more efficient approach. The impact of treatment parameter variation on alloy microstructure and the resulting mechanical properties were investigated in detail. Furthermore, initial optimization steps were undertaken. Full article

Strong efforts are made internationally to optimize the process control of laser additive manufacturing processes. For this purpose, advanced detectors and monitoring software are being developed to control the quality of production. However, commercial suppliers of metal powders and part manufacturers are essentially focused on well-established materials. This article demonstrates the potential of optimized process control. Furthermore, we outline the development of a new high temperature structural steel, tailored to best utilize the advantages of additive manufacturing techniques. In this context, the impact of production-induced porosity on fatigue strength of austenitic 316L is presented. Additionally, we discuss the first conceptual results of a novel ferritic steel, named HiperFer (High Performance Ferrite), which was designed for increased fatigue strength. This ferritic, Laves phase-strengthened, stainless steel could be used for a wide range of structural components in power and (petro)chemical engineering at maximum temperatures ranging from about 580 to 650 °C. This material benefits from in situ heat treatment and counteracts process-related defects by “reactive” crack obstruction mechanisms, hampering both crack initiation and crack propagation. In this way, increased fatigue resistance and safety can be achieved. Full article

High-chromium ferritic stainless steels strengthened by Laves phase precipitates were developed for a high-temperature application in steam power plants. The impact of tungsten content on the precipitation of the intermetallic Laves phase during the newly developed thermomechanical process route was investigated. Due to rapid thermomechanically induced precipitation, a considerable reduction in processing time in comparison to the conventional solely thermal two-step processing of high chromium ferritic steels was achieved. Nevertheless, comparable mechanical properties at room temperature, i.e., the ultimate tensile strength of 712 MPa and the yield strength of 434 MPa, were obtained. The microstructure was analyzed by scanning electron microscopy (SEM) in combination with digital particle analysis, to estimate the particle size and the phase fraction of the Laves phase. The mean particle size of 52 nm and the volume fraction of 4.11% were achieved. Due to the tungsten content, an increase in the volume fraction and particle size was observed, giving rise to the higher strengthening effect. Full article

Future, flexible thermal energy conversion systems require new, demand-optimized high-performance materials. The High performance Ferritic (HiperFer) stainless steels, under development at the Institute of Microstructure and Properties of Materials (IEK-2) at Forschungszentrum Jülich GmbH in Germany, provide a balanced combination of fatigue, creep and corrosion resistance at reasonable price. This paper outlines the scientific background of alloy performance development, which resulted in an age-hardening ferritic, stainless steel grade. Furthermore, technological properties are addressed and the potential concerning application is estimated by benchmarking versus conventional state of the art materials. Full article
