This paper demonstrates the sorting and detection of near-infrared vortex light using a nonlinear Dammann vortex grating. By incorporating a forked structure into the nonlinear Dammann grating, the resulting nonlinear Dammann vortex grating is capable of converting near-infrared Gaussian light into a visible vortex array. The array comprises 49 independent detection channels, each of which can precisely control the inherent topological charge values. When the topological charge value of a detection channel’s vortex light matches that of the incident vortex, the vortex degenerates into a Gaussian spot, thereby enabling the detection of the incident vortex’s topological charge. Our experimental results show that this grating, with its 49 independent detection channels, can detect the topological charge values of vortex light in the near-infrared range from l = −12 to +12 in real-time. Compared to existing solutions, this grating offers enhanced versatility and has potential applications in optical communication systems for the transmission, reception, and multiplexing of OV beams. Full article

The generation of optical beam arrays with prospective uses within the realms of microscopy, photonics, non-linear optics, and material processing often requires Dammann gratings. Here, we report the direct fabrication of one- and two-dimensional Dammann grating-like structures on soda lime glass using a nanosecond pulsed laser beam with a 1064 nm wavelength. Using the fabricated grating, an axicon lens, and an optical magnification system, we propose a scheme of generation of a diverging array of zero-order Bessel beams with a sub-micron-size central core, extending longitudinally over several hundred microns. Two different grating fabrication strategies are also proposed to control the number of Bessel beams in an array. It was demonstrated that Bessel beams of 12 degrees conical half-angle in an array of up to [5 × 5] dimensions can be generated using a suitable combination of Dammann grating, axicon lens and focusing optics. Full article

The use of array generators has become ubiquitous in various applications such as laser fabrication, face identification, and motion sensing. The Dammann grating, a diffractive optical element, is the mainstream approach for generating uniform spot arrays. However, its limited capability and the contradiction between the performance and the complexity of fabrication hinder its application. To address this issue, an all-in-one collimating splitter based on metasurfaces is theoretically proposed by synthesizing the phase of an inverse-optimized Dammann grating and a collimating lens. Leveraging both the diffraction effect of Dammann grating and the Fourier transformation of the collimating lens, the number of spot arrays can be largely increased with a single lenslet. The proposed design shows a large field of view of 62° × 62° and a high uniformity of 1.29% in generating a spot array of 3 × 3 on a single-fiber platform, confirmed by both the scalar and full-wave simulation. Further, a larger spot array up to 15 × 15 is also derived in the far field by integrating the proposed metasurface on a 5 × 5 fiber array platform, confirmed by the scalar simulation. Our design may be transplanted to the vertical-cavity surface-emitting laser platform, and shows great potential in various applications including face identification and motion sensing. Full article

The structured light projection (SLP) method occupies a crucial position in three-dimensional (3D) imaging technology. Different working wavelengths of structured light can be employed depending on the situation. However, there are few structured lights that can be modulated based on wavelength at present. Therefore, we have comprehensively investigated and designed a Dammann grating (DG) based on metasurface, which can be controlled through multi-beam interference (MBI) to achieve a change of the working wavelength. In this work, we can convert the straight waveguide to the helical waveguide by fine-tuning the related parameters of the incident lights and generate 5 × 5 diffraction spot arrays in the wavelength range of 480–510 nm and 950–1020 nm, respectively. Furthermore, the metasurfaces exhibit good performance. For example, their spread angles can be up to 44° × 44° and they can reach a conversion efficiency of over ≥50% while maintaining a contrast ratio of roughly 40%. Compared with traditional structured light, it can be used in different working wavelengths and has a broader application range in 3D sensing systems. Full article

In our research, we propose a novel asymmetric multiple-image encryption method using a conjugate Dammann grating (CDG), which is based on the coherent beam combining (CBC) principle. The phase generated by the Dammann grating (DG) beam splitting system is processed and added to the image to be encrypted, and then, the ciphertexts and keys are generated by equal modulus decomposition (EMD). Decryption is to combine the beams through the CDG and collect the combined images in the far field. The proposed encryption scheme is flexible and thus extendable. CDG structure parameters, such as one period length of CDG, can be used as encryption key for the increase of the complexity. The Fresnel diffraction distance can also be used as an encryption key. The power of the combined beam is stronger than that of the single beam system, which is convenient for long-distance transmission and also easy to detect. Simulation results show that the proposed method is effective and efficient for asymmetric multiple-image encryption. Sensitivity analysis of CDG alignment has also been performed showing the robustness of the system. The influence of occlusion attack and noise attack on decryption are also discussed, which proves the stability of the system. Full article

Diffractive multi-beams based on 1 × 5 and 2 × 2 binary Dammann gratings applied to a spatial light modulator (SLM) combined with a nanostructured S-wave plate have been used to generate uniform multiple cylindrical vector beams with radial and azimuthal polarizations. The vector quality factor (concurrence) of the single vector vortex beam was found to be C = 0.95 ± 0.02, hence showing a high degree of vector purity. The multi-beams have been used to ablate polished metal samples (Ti-6Al-4V) with laser-induced periodic surface structures (LIPSS), which confirm the polarization states unambiguously. The measured ablation thresholds of the ring mode radial and azimuthal polarizations are close to those of a Gaussian mode when allowance is made for the expected absolute intensity distribution of a ring beam generated from a Gaussian. In addition, ring mode vortex beams with varying orbital angular momentum (OAM) exhibit the same ablation threshold on titanium alloy. Beam scanning with ring modes for surface LIPSS formation can increase micro-structuring throughput by optimizing fluence over a larger effective beam diameter. The comparison of each machined spot was analysed with a machine learning method—cosine similarity—which confirmed the degree of spatial uniformity achieved, reaching cosθ > 0.96 and 0.92 for the 1 × 5 and 2 × 2 arrays, respectively. Scanning electron microscopy (SEM), optical microscopy and white light surface profiling were used to characterize and quantify the effects of surface modification. Full article

The Maxwellian view offers a promising approach to overcome the vergence-accommodation conflict in near-eye displays, however, its pinhole-like imaging naturally limits the eyebox size. Here, a liquid crystal polymer-based Dammann grating with evenly distributed energy among different diffraction orders is developed to enlarge the eyebox of Maxwellian view displays via pupil replication. In the experiment, a 3-by-3 Dammann grating is designed and fabricated, which exhibits good efficiency and high brightness uniformity. We further construct a proof-of-concept Maxwellian view display breadboard by inserting the Dammann grating into the optical system. The prototype successfully demonstrates the enlarged eyebox and full-color operation. Our work provides a promising route of eyebox expansion in Maxwellian view displays while maintaining full-color operation, simple system configuration, compactness, and lightweight. Full article

Photoalignment of liquid crystals by using azo dye molecules is a commonly proposed alternative to traditional rubbing alignment methods. Photoalignment mechanism can be well described in terms of rotational diffusion of azo dye molecules exposed by ultraviolet polarized light. A specific feature of the irradiated light is the intensity dependent change of azimuthal anchoring of liquid crystals. While there are various mechanisms of azo dye photoalignment, photo-reorientation occurs when dye molecules orient themselves perpendicular to the polarization of incident light. In this review, we describe both recent achievements in applications of photoaligned liquid crystal cells and its simulation. A variety of display and photonic devices with azo dye aligned nematic and ferroelectric liquid crystals are presented: q-plates, optically rewritable flexible e-paper (monochromatic and color), and Dammann gratings. Some theoretical aspects of the alignment process and display simulation are also considered. Full article

As one of the diffractive optical elements, circular Dammann grating has shown its excellent versatility in practical applications. The electrically switchable Dammann grating has been extensively investigated; however, the research on the optically tunable circular Dammann grating has received less attention and reports on this subject have been insufficient in the past decade. In this paper, three-order and eight-order binary-phase liquid crystal circular Dammann gratings with two mutually orthogonal photo-induced alignments in every two adjacent alignment domains, fabricated by a micro-patterned liquid crystal polymer phase mask, are proposed to generate annular uniform-intensity patterns in the far field. A simple maskless optical tuning of an eight-order liquid crystal circular Dammann grating is demonstrated by controlling the polarization of an ultraviolet light as well as the energy dose. The proposed liquid crystal circular Dammann gratings with high efficiencies and desirable uniformities exhibit outstanding optical as well as electrical tunabilities, enabling the widespread prospective applications in adaptive photonic chips stimulated flexibly by only light or by the combination of light and electric field. Full article

In this article, a ferroelectric liquid crystal (FLC) dammann grating (DG) is demonstrated based on the patterned photoalignment technology. By applying low electric field (10 V) on the FLC DG, the grating can switch between a diffractive state with 7 × 7 optical spots array and a non-diffractive state, depending on the polarity of electric field. The FLC DG shows very fast switching speed with switching on time and off time to be only 81 μs and 59 μs respectively. Comparing with other fast LC DGs such as the ones based on blue phase LC or dual-frequency LC, the switching speed of the proposed FLC DG is about one order faster, which provides great potential and perspective for the FLC DG to be applied in a broad range of optical applications such as optical communication and beam shaping. Full article
