24 pages, 10269 KiB
Article
Design of a Misalignment-Tolerant Inductor–Capacitor–Capacitor-Compensated Wireless Charger for Roadway-Powered Electric Vehicles
by Mustafa Abdulhameed, Eiman ElGhanam, Ahmed H. Osman and Mohamed S. Hassan
Sustainability 2024, 16(2), 567; https://doi.org/10.3390/su16020567 - 9 Jan 2024
Cited by 7 | Viewed by 2055
Abstract
Dynamic wireless charging (DWC) systems enable electric vehicles (EVs) to receive energy on the move, without stopping at charging stations. Nonetheless, the energy efficiency of DWC systems is affected by the inherent misalignments of the mobile EVs, causing fluctuations in the amount of [...] Read more.
Dynamic wireless charging (DWC) systems enable electric vehicles (EVs) to receive energy on the move, without stopping at charging stations. Nonetheless, the energy efficiency of DWC systems is affected by the inherent misalignments of the mobile EVs, causing fluctuations in the amount of energy transmitted to the EVs. In this work, a multi-coil secondary-side inductive link (IL) design is proposed with independent double-D (DD) and quadrature coils to reduce the effect of coupling fluctuations on the power received during misalignments. Dual-sided inductor–capacitor–capacitor (LCC) compensation networks are utilized with power and current control circuits to provide a load-independent, constant current output at different misalignment conditions. The LCC compensation components are tuned to maximize the power transferred at the minimum acceptable coupling point, kmin. This compensates for the leaked energy during misalignments and minimizes variations in the operating frequency during zero-phase angle (ZPA) operation. Simulations reveal an almost constant output power for different lateral misalignment (LTMA) values up to ±200 mm for a 25 kW system, with a power transfer efficiency of 90%. A close correlation between simulation and experimental results is observed. Full article
(This article belongs to the Topic Advanced Electric Vehicle Technology)
Show Figures

Figure 1

14 pages, 3721 KiB
Article
A Wireless Power Transfer System Using a Double DD Quadrature Coil Structure
by Jure Domajnko and Nataša Prosen
Electronics 2023, 12(4), 890; https://doi.org/10.3390/electronics12040890 - 9 Feb 2023
Cited by 8 | Viewed by 3149
Abstract
This paper presents the evolution of an inductive wireless power transfer using a multicoil system. The double DD coil structure on the transmitter and the receiver side using two perpendicular bipolar DD coils is upgraded with an additional nonpolar quadrature coil. The proposed [...] Read more.
This paper presents the evolution of an inductive wireless power transfer using a multicoil system. The double DD coil structure on the transmitter and the receiver side using two perpendicular bipolar DD coils is upgraded with an additional nonpolar quadrature coil. The proposed structure can be called the double DDQ coil structure. All three coils are not coupled, due to the nature of the directional double DD coil. If the transmitter and the receiver are not misaligned to one another, the system behaves as three separate, uncoupled IPT systems. The main advantage of the proposed coil topology is additionally increased power density and increased misalignment tolerance. Additionally, when the transmitter and the receiver coil are perfectly aligned, the proposed pad structure can transmit three different voltages and can be excited with different frequencies. In the case of this paper, the three coils on the transmitter side were excited by the same frequency. The proposed coil was evaluated experimentally and compared to the system using double DD coil structure. Full article
Show Figures

Figure 1

23 pages, 6807 KiB
Article
On-Line Foreign Object Detection Using Double DD Coils in an Inductive Wireless Power Transfer System
by Nataša Prosen, Miro Milanovič and Jure Domajnko
Sensors 2022, 22(4), 1637; https://doi.org/10.3390/s22041637 - 19 Feb 2022
Cited by 4 | Viewed by 2424
Abstract
This paper proposes an on-line method for foreign object detection in a double DD coil system. The foreign object is detected by real-time measurement of the mutual inductance between the transfer pads. Measurement of the mutual inductance between coils can be performed at [...] Read more.
This paper proposes an on-line method for foreign object detection in a double DD coil system. The foreign object is detected by real-time measurement of the mutual inductance between the transfer pads. Measurement of the mutual inductance between coils can be performed at the start, during initialisation, or during the wireless power transfer. The coils in the double DD coil structure can be used separately; one coil can be used for power transfer and the other can be used for the mutual inductance measurement. The mutual inductance measurement is based on the voltage measurement across the open circuit receiver coil. The measured value of mutual inductance between the transmitter and the receiver pad can be used in a control algorithm and in a foreign object detection algorithm. Additionally, a 2DDq coil structure can be used as a replacement for the double DD coil structure, which increases the power transfer density. The DD coils in the double DD coil structure can also be driven using two phase-shifted voltages, which enables better location and detection of foreign objects. The method also helps to differentiate the mutual inductance change due to the distance change from the mutual inductance change due to the presence of a foreign object. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

19 pages, 992 KiB
Article
Design and Performance Analysis of Misalignment Tolerant Charging Coils for Wireless Electric Vehicle Charging Systems
by Eiman ElGhanam, Mohamed Hassan, Ahmed Osman and Hanin Kabalan
World Electr. Veh. J. 2021, 12(3), 89; https://doi.org/10.3390/wevj12030089 - 24 Jun 2021
Cited by 36 | Viewed by 6066
Abstract
In order to design a high efficiency Wireless Electric Vehicle Charging (WEVC) system, the design of the different system components needs to be optimized, particularly the design of a high-coupling, misalignment-tolerant inductive link (IL), comprising primary and secondary charging coils. Different coil geometries [...] Read more.
In order to design a high efficiency Wireless Electric Vehicle Charging (WEVC) system, the design of the different system components needs to be optimized, particularly the design of a high-coupling, misalignment-tolerant inductive link (IL), comprising primary and secondary charging coils. Different coil geometries can be utilized for the primary and the secondary sides, each with a set of advantages and drawbacks in terms of weight, cost, coupling at perfect alignment and coupling at lateral misalignments. In this work, a Finite Element Method (FEM)-based systematic approach for the design of double-D (DD) charging coils is presented in detail. In particular, this paper studies the effect of different coil parameters, namely the number of turns and the turn-to-turn spacing, on the coupling performance of the IL at perfect alignment and at ±200 mm lateral misalignment, given a set of space constraints. The proposed design is verified by an experimental prototype to validate the accuracy of the FEM model and the simulation results. Accordingly, FEM simulations are utilized to compare the performance of rectangular, DD and DDQ coils. The FEM results prove the importance of utilizing an additional quadrature coil on the secondary side, despite the added weight and cost, to further improve the misalignment tolerance of the proposed inductive link design. Full article
(This article belongs to the Special Issue Electric Vehicles Integrated with Green Energy Sources)
Show Figures

Figure 1
