Search Results (8)

Excited state calculations are performed to predict the electronic structure and optical absorption characteristics of Cu-doped anatase Ti$O_2$ nanofilms, focusing on their (101) and (001) surface terminations. Using model structures that successfully represent the equilibrium positions of deposited Cu atoms on the Ti$O_2$ surface, a comprehensive analysis of the absorption spectra for each considered model is made. The proposed modeling reveals phenomena when photogenerated electrons from Ti$O_2$ tend to accumulate in the vicinity of the deposited Cu atoms exposed to photon energies surpassing the band gap of Ti$O_2$ (approximately 3.2 eV). The crucial transition states that are essential for the creation of potential photocatalytic materials are identified through detailed calculations of the excited states. These insights hold substantial promise for the strategic design of advanced photocatalytic materials. The obtained results provide a base for subsequent analyses, facilitating the determination of heightened surface reactivity, photostimulated water splitting, and antibacterial properties. Full article

Pure and Cu-doped NiO films were synthesized via a soft chemical process. They were deposited on glass substrates heated to 400 °C. Different atomic percentage ratios (2, 4, 6, 8, and 10%) of Cu-doping were used. The prepared samples were characterized by several techniques such as X-ray diffraction for crystallographic study, SEM and AFM for microstructural and morphological properties, and UV-Visible spectroscopy for optical and photocatalytical analysis. XRD results of pure and Cu-doped NiO films indicated the formation of NiO polycrystalline phases under a cubic structure with a favored orientation along the (200) plane noticed in all sprayed films. SEM images revealed the formation of NiO nanoparticles of spherical forms whose sizes increase and agglomerate with increasing Cu-doping. At 10% Cu-doping, NiO agglomeration was extended to the whole surface. AFM images showed a textured and rough surface composed of NiO nanoparticles of average size varying from 16 to 10 nm depending on Cu-doping concentration. UV-visible spectroscopy confirmed the transparency of NiO films and their semiconducting character with a band gap ranging from 3.4450 eV to 2.8648 eV. The photocatalytical properties of pure and Cu-NiO films were enhanced by Cu-doping particles as revealed by the degradation of methylene blue (MB) solution subjected to irradiation. Full article

CuO films, with their many features, attract special attention for applications in various optoelectronics. In their pristine form, CuO films suffer from low conductivity, which limits their application. Modification, especially by doping, is thus needed. The effects of tin (Sn) doping on the structure, morphology, and optical and, more importantly, electrical properties of multi-layered copper oxide (CuO) films deposited onto tin-doped indium oxide (ITO)/glass substrates by sol–gel spin coating are examined here. The multi-layered films were characterized with X-ray diffraction (XRD), atomic force microscopy (AFM), electronic absorption (UV-Visible) spectra, and four probe methods. The results confirmed the substitution of Cu²⁺ ions by Sn⁴⁺ ions in the CuO crystallites without altering their monoclinic structure. The measured crystallite size values decreased with increased doping concentration, indicating increased imperfection. This applies to both 5- and 10-layered CuO films. The doping concentration affected other film characteristics, namely, surface morphology and electrical conductivity, in each layered film. Among various systems, the 10-layered film, with 1.5 at% Sn, exhibited optimal properties in terms of higher uniformity (mean square root surface roughness 41 nm) and higher conductivity (50.3 × 10⁻³·Ω⁻¹·cm⁻¹). Full article

Pure and Li-doped CuO nanofilms were synthesized on heated glass substrates using the spray-pyrolysis technique. The deposited pure CuO nanofilms were achieved at a precursor molarity of 0.2 M using a solution prepared from copper nitrate trihydrate (Cu(NO₃)₂·3H₂O). Doped Li–CuO nanofilms were obtained using several doping concentrations (3, 6, 9, 12 and 15%) by adding a solution prepared from lithium nitrate (LiNO₃). The pure and Li–CuO samples were investigated by different techniques. XRD revealed three dominant peaks (-111), (111) and (211), which are the properties of monoclinic CuO. The increase in Li-doping concentration showed the appearance of other peaks of low intensities detected at 2θ ranging from 49 to 68°. AFM images showed a textured and inhomogeneous surface composed of spherical grains whose size decreased with increasing Li doping. UV–visible spectroscopy showed that the CuO samples were of low transparency; the transmittance was less than 50%. The band-gap energy determined from Tauc’s equation plot increased from 2.157 to 3.728 eV with the increase in Li doping. These values correspond well to the band gap of semiconducting CuO. The photocatalytic properties were accelerated by Li doping, as revealed by the discoloration of aqueous methylene-blue (MB) solution under ultraviolet irradiation. Full article

A large area of randomly distributed nanospike as nanostructured template was induced by femtosecond (fs) laser on a silicon substrate in water. Copper oxide (CuO) and palladium (Pd) heterostructured nanofilm were coated on the nanospikes by magnetron sputtering technology and vacuum thermal evaporation coating technology respectively for the construction of a p-type hydrogen sensor. Compared with the conventional gas sensor based on CuO working at high temperature, nanostructured CuO/Pd heterostructure exhibited promising detection capability to hydrogen at room temperature. The detection sensitivity to 1% H₂ was 10.8%, the response time was 198 s, and the detection limit was as low as 40 ppm, presenting an important application prospect in the clean energy field. The excellent reusability and selectivity of the CuO/Pd heterostructure sensor toward H₂ at room temperature were also demonstrated by a series of cyclic response characteristics. It is believed that our room-temperature hydrogen sensor fabricated with a waste-free green process, directly on silicon substrate, would greatly promote the future fabrication of a circuit-chip integrating hydrogen sensor. Full article

Properties of nanolayers can substantially differ from those of bulky materials, in part due to pronounced interface effects. It is known that combinations of layers of heavy and ferromagnetic metals leads to the appearance of specific spin textures induced by interface-induced Dzyaloshinskyi–Moria interaction (DMI), which attracts much interest and requires further studies. In this paper, we study magneto-optical effects in two- and three-layer films composed of a few nanometer thick Co layer adjacent to nanofilms of non-magnetic materials (Pt, W, Cu, Ta, MgO). For experimental studies of the interface magnetization-induced effects, we used the optical second harmonic generation (SHG) technique known for its high sensitivity to the symmetry breaking. We found that the structural asymmetry leads to the increase of the averaged SHG intensity, as well as to the magnetic field-induced effects in SHG. Moreover, by choosing the proper geometry of the experiment, we excluded the most studied linear in magnetization SHG contributions and, thus, succeeded in studying higher order in magnetization and non-local magnetic effects. We revealed odd in magnetization SHG effects consistent with the phenomenological description involving inhomogeneous (gradient) magnetization distribution at interfaces and found them quite pronounced, so that they should be necessarily taken into account when analyzing the non-linear magneto-optical response of nanostructures. Full article

Herein, the influence of the substrate in the formation of zirconium oxide monolayer, from an aqueous hexafluorozirconic acid solution, by chemical conversion and by electro-assisted deposition, has been approached. The nanoscale dimensions of the ZrO₂ film is affected by the substrate nature and roughness. This study evidenced that the mechanism of Zr-EAD is dependent on the potential applied and on the substrate composition, whereas conversion coating is uniquely dependent on the adsorption reaction time. The zirconium oxide based nanofilms were more homogenous in AA2024 substrates if compared to pure Al grade (AA1100). It was justified by the high content of Cu alloying element present in the grain boundaries of the latter. Such intermetallic active sites favor the obtaining of ZrO₂ films, as demonstrated by XPS and AFM results. From a mechanistic point of view, the electrochemical reactions take place simultaneously with the conventional chemical conversion process driven by ions diffusion. Such findings will bring new perspectives for the generation of controlled oxide coatings in modified electrodes used, as for example, in the construction of battery cells; in automotive and in aerospace industries, to replace micrometric layers of zinc phosphate by light-weight zirconium oxide nanometric ones. This study is particularly addressed for the reduction of industrial waste by applying green bath solutions without the need of auxiliary compounds and using lightweight ceramic materials. Full article

Aero-eutectic graphite can be defined as a new light material with hierarchically structured porosity. It is obtained from the solidification of gray cast irons, followed by the dissolution of the ferrous matrix by an acidic sequence. The result is a continuous and interconnected network of graphite sheets with varied dimensions randomly oriented. X-ray diffraction characterization has revealed graphite crystallographic planes (002), (100), (101), (102) and (004), while the surface area measured by BET and Langmuir methods has been determined in the order of 90 m² g⁻¹ and 336 m² g⁻¹, respectively. The process of obtaining eutectic aero-graphite also allows the deposit of Cu nanofilms and TiC particles. Aero-eutectic graphite has been tested as cathode in Li–O₂ batteries as it has been prepared, without the addition of binders or conductive carbons, showing an appropriate contact with the electrolyte, so that the oxygen reduction and evolution reactions may develop satisfactorily. In the discharge-charge galvanostatic tests, the battery accomplishes 20 complete cycles with area capacity limited to 1.2 mAh cm⁻². Full article
