Natural gas hydrates have great strategic potential as an energy source and have become a global energy research hotspot because of their large reserves and clean and pollution-free characteristics. Hydrate saturation affecting the electrical and acoustic properties of sediments significantly is one of the important parameters for the quantitative evaluation of natural gas hydrate reservoirs. The accurate calculation of hydrate saturation has guiding significance for hydrate exploration and development. In this paper, experiments regarding methane hydrate formation and dissociation in clay-bearing sediments were carried out based on the Ultrasound Combined with Electrical Impedance (UCEI) system, and the measurements of the joint electrical and acoustic parameters were collected. A machine learning (ML)-based model for evaluating hydrate saturation was established based on electrical–acoustic properties and a neural network ensemble. It was demonstrated that the average relative error of hydrate saturation calculated by the ML-based model is 0.48%, the average absolute error is 0.0005, and the root mean square error is 0.76%. The three errors of the ensemble network are lower than those of the Archie formula and Lee weight equation. The ML-based modeling method presented in this paper provides insights into developing new models for estimating the hydrate saturation of reservoirs. Full article

From December 2021 to January 2022, MH21-S conducted an exploratory drilling campaign using logging-while-drilling tools to confirm the methane hydrate concentrated zone (MHCZ) for future offshore production tests. In a preliminary screening study using seismic survey data, methane hydrate (MH) prospects have been extracted in The Hyuganada Sea, offshore Kyushu. In the exploration drilling site, a previous study had reported that MH prospects were inferred from four indices. We have selected two MH prospects: one with an anticlinal structure and another with a planus structure. As a result of drilling, a resistivity value higher than 3 Ω·m, which was a criterion for interpreting MHCZs from log data, was confirmed at a depth of 336–376 mBSF in the prospect with an anticlinal structure. The MH saturation calculated using Archie’s formula was 12–95% (average saturation of 70%). The average density porosity at the same depth was 52%. P-wave velocities were faster than the upper layers. Compared with those of the MHCZ at Daini Atsumi Knoll, the MH saturation is expected to be higher, the spread of some strong-amplitude reflectors has been interpreted from seismic survey data, and the potential MH resources in this area can be sufficiently expected. Full article

The conventional Archie formula struggles with the interpretation of water saturation from resistivity well log data due to the increasing complexity of exploration targets. This challenge has prompted researchers to explore alternative physical parameters, such as acoustic characteristics, for breakthroughs. Clarifying the influencing factors of porous media acoustic characteristics is one of the most important approaches to help understanding the mechanism of acoustic characteristics of carbonate reservoirs. The article uses digital rock technology to characterize the pore structure, quantitatively identify fractures and pore structures in carbonate rocks, and establish digital models. Through conventional acoustic testing, the pressure wave (P-wave) and shear wave (S-wave) velocities of rock samples at different water saturations are obtained, and the dynamic elastic modulus is calculated. A finite element calculation model is established using the digital rock computational model to provide a basis for fluid saturation calculation methods. Based on real digital rock models, different combinations of virtual fractures are constructed, and factors affecting acoustic parameters are analyzed. The study finds that as porosity increases, the velocity difference between porous cores and fractured cores also increases. These findings provide important technical support and a theoretical basis for interpreting acoustic well logging data and evaluating carbonate reservoirs with different pore and fracture types. Full article

The current techniques utilized for estimating seasonal fluctuations in earthing system resistance, including artificial neural networks (ANNs) and correlation/correction factors, rely on resistance records, soil resistivity measurements, and meteorological data collected across broad areas. However, they frequently fail to consider the impact of soil conditions and properties at the actual earthing location. As a solution, this research introduces a new method that models atmospheric conditions as soil suction and incorporates hydraulic soil properties (soil water retention characteristics and hydraulic conductivity) to estimate the seasonal changes in earthing resistance and performance. To illustrate this approach, this study constructs geometric models of vertical earthing rods for three homogeneous soil textures (clayey, silty, and sandy) utilizing COMSOL Multiphysics software. By coupling the differential equations governing electric current and water flow using Archie’s formula and solving numerically with the finite element method (FEM) for various soil suctions, this research reveals that soil water retention and resistivity variations are notably influenced by soil texture. Sandy soil displays higher variability, silt soil demonstrates moderate changes, while clayey soil exhibits lower fluctuation. By linking soil resistivity changes to soil suction and hydraulic properties, this innovative method predicts seasonal trends in earthing resistance and performance. Full article

As an important unconventional oil and gas resource, the tight gas reservoir faces many technical challenges due to its low porosity, low permeability, and strong heterogeneity. Among them, the accurate definition of effective reservoirs and ineffective reservoirs in tight gas reservoirs directly affects the formulation and adjustment of subsequent development plans. This paper proposes a reservoir effectiveness identification method based on double factors based on conventional geophysical logging data and core experimental data. The double factors considered are based on the logging response and physical parameters of the reservoir. The identification factor $F_1$ is obtained by using the difference in the logging response values of the natural gamma logging curve, compensated density logging curve, and acoustic time difference logging curve in different reservoirs combined with mathematical operation, and the identification factor $F_2$ is calculated by using porosity parameters combined with Archie’s formula. The validity of the reservoir can be judged by the intersection of the above double factors. This method is applied to the Shihezi Formation in the L block, and the applicability of the double factors is compared and analyzed using the traditional method. The results show that the method has strong applicability in tight gas reservoirs and that the accuracy rate reaches 96%. Compared with the direct use of the porosity lower limit method, the accuracy of the judgment is significantly improved, and the calculation is simple, easy to implement, and unaffected by mud invasion. For study areas with different geological backgrounds, the process of this method can also be used to determine the effectiveness of the reservoir. The reservoir effectiveness identification method proposed in this paper has practical engineering significance and lays a solid foundation for subsequent fluid property identification, production calculation, and development plan formulation and adjustment. Full article

To investigate the impact of geothermal gradient on the distribution and reserves of hydrate in permafrost regions, it is crucial to utilize the Archie formula to compute hydrate saturation and adjust parameters to enhance the model’s precision under varying temperature gradient conditions. This study formed methane hydrate under four temperature gradients of 0.02 °C/cm, 0.07 °C/cm, 0.11 °C/cm and 0.18 °C/cm, and two sand particle ratios. The values of porosity index (m) and saturation index (n) were fitted according to different conditions. The water saturation and hydrate saturation were then calculated and contrasted with experimental results. Findings indicate that the influence of temperature gradient on the values of m and n is intricate, with n decreasing gradually and m fluctuating with an increase in temperature gradient. The discrepancies between the optimized Archie model and the actual calculated hydrate saturation values ranged from 0.8% to 2.5%, with average errors of less than 3%, proving its applicability. Finally, the optimized Archie model was used to investigate the hydrate saturation and its distribution in different layers, which confirmed the significant effect of temperature gradient on the assessment of hydrate storage and distribution by Archie’s equation. Full article

To study the evolution of geological hazard sources of waste dump slopes under rainfall conditions, a physical model of a rainfall-affected slope was designed. The apparent resistivity of the slope rock and soil mass at different rainfall times was measured via the high-density resistivity method, and the formation process of internal disaster sources of the rainfall-affected slope was obtained. The variation characteristics of the resistivity of the rain-affected slope were analyzed when it had a weak surface and crack development. Based on the three-water model and Maxwell conductivity formula, the evolution process of geological hazard sources of the rainfall-affected slope was summarized. A resistivity response mechanism equation for rainfall-induced slope hazard sources was derived and compared to the Archie formula, verifying the model rationality. The test results showed that the behavior of the rainfall-affected slope conforms to the saturated–unsaturated dynamic cycle process. The apparent resistivity was positively correlated with the development of slope pores and cracks and negatively correlated with the water content in the slope. The apparent resistivity increased during fracture development and decreased during water seepage. In the slope failure and disaster process, the apparent resistivity varies under the coupling effect of crack development and water seepage. During the formation of geological hazard sources, the apparent resistivity abruptly changes and fluctuates. Therefore, according to the abrupt changes and abnormal fluctuations in the apparent resistivity detected, the development of geological hazard sources of slopes can be determined. Full article

In the Middle East, there remain many technical challenges in the water saturation evaluation of carbonate rocks and the effective identification of reservoir fluid properties. The traditional Archie equation is not applicable to carbonate reservoirs with complex pore structures and varying reservoir space distribution, as there are obvious “non-Archie” phenomena. In this paper, by analyzing the experimental data on the rock resistivity of the target formation in the study area and analyzing the relationship between stratigraphic factors and porosity, the previous fitting method was modified as a result of using the actual data while avoiding the cementation index as a way to improve Archie’s formula to evaluate the water saturation. Based on the improved Archie formula, the mathematical differential operation of water saturation and porosity was carried out using the formation resistivity. The calculation results of irreducible water saturation were used to calibrate the oil layer, and the water layer was calibrated when the water saturation was 100%, allowing for a novel reservoir fluid property identification method. This total differential method can effectively identify the oil-down-to (ODT) and water-up-to (WUT) levels in an oil–water system and then accurately divide the transition zone of the oil–water layer. When this method was applied, the identification results were in good agreement with production conclusions and test data with an accuracy rate of 89.95%. Although the use of geophysical logging data from open-hole wells combined with the total differential method is only applicable to wells with similar logging time and production time, it is possible to compare geophysical logging data from different periods to construct oil–water profiles to observe the changes in ODT over time to guide development and adjust production plans. The proposed reservoir fluid property identification method and the improved water saturation calculation formula can meet the requirements of water saturation evaluation in the target block with low calculation cost and easy implementation, which provides a new method for water saturation evaluation and rapid identification of reservoir fluid properties. Full article

This study aims to apply geophysical methods to determine the Specific Yield (Sy) and Groundwater Level (GWL) in an unconfined aquifer of the Pingtung Plain in South Taiwan. Sy is an important hydraulic parameter for assessing groundwater potential. Obtaining specific yield for a large area is impractical due to the limited coverage and the high cost of the pumping test, which limits the potential evaluation of regional groundwater. Therefore, we used time-lapse Electrical Resistivity Imaging (ERI) to determine the Sy and GWL. Seasonal variations were considered when measuring time-lapse resistivity for five different months in 2019. We calculated the Sy and GWL from inverted resistivity data using empirical formulas and the soil–water characteristic curve (SWCC). We first used Archie’s law to calculate the relative saturation change with depth for each ERI profile, and then we used the Van Genuchten (VG) and Brooks–Corey (BC) empirical equations to estimate Sy and GWL. Finally, we compared the obtained GWL to the existing observation well to verify the findings of our study. The results showed that the VG and BC are able to predict Sy and GWL; however, the BC result is less consistent with the observation well result. In the study area, the dry season GWL ranged from 24.5 m to 35.2 m for the VG results and from 25.7 m to 35.5 m for the BC results. The wet season GWL ranged from 26.5 m to 38.9 m for the VG and from 26.4 m to 38.2 m for the BC results. The spatial distribution of the GWL shows a high gradient of GWL in the northeastern region, induced by significant proximal fan recharge. The determined spatial distribution of Sy varies from 0.15 to 0.21 for the VG and 0.14 to 0.20 for the BC results, indicating the study area has significant potential for groundwater resources. Therefore, nondestructive resistivity imaging can be used to aid in the determination of hydraulic parameters. Full article

The new international outlook for the gas sector suggests evaluating exploitable reserves in previously unconsidered areas including hydraulic fracturing technology. In order to estimate the amount of gas in the Jaca Flysch formation, the analysis of geological and geophysical logs and the volumetric method have been used. It has been taking into account the part of the formation likely to contain gas, the porosity (2.65%) calculated from sonic logs with Wyllie’s equation, the water saturation (35.3%) with Archie’s formula, and the initial gas formation volume factor (Bgi), estimated with MHA-P3 software with the reservoir pressure/temperature data 3600 psi/90 °C. The economic analysis of each well has been carried out based on three options, without stimulation, with 50% and 100% stimulation by fracking, and five possible construction costs (7.5–15 MM€). The impact of the use of the fracking technology on the production of the well is about 48%. The production rate and the economic impact that its exploitation would have on the domestic demand for natural gas has been analyzed, resulting in a significant contribution to the national energy mix of between 10–20% of consumption for several years. Full article

Recently, drilling wells have encountered rich gas hydrates in fine-grained sediments in the northern South China Sea. Gas hydrate in fine-grained sediments is very heterogeneous, and its physical properties are different from those of oil and gas reservoirs. The reliability of the classical logging saturation evaluation models established for diagenetic reservoirs is questionable. This study used four wells in GMGS3 and GMGS4 to evaluate the effects of the application of three typical methods for evaluating saturation with different principles in the unconsolidated fine-grained sediments: nuclear magnetic logging, sigma logging, and the Archie formula. It was found that the value of the lithologic capture cross-section in sigma logging and the rock’s electrical parameters in the Archie formula affect the accuracy of the model. Therefore, to obtain a reliable saturation value for fine-grained sediments, an innovative method for the calculation of resistivity and acoustic time is proposed to estimate gas hydrate saturation based on logging data, which is most consistent with the results of core analysis. The overall relative error of the verification well was 5.87%, whereas that of the density NMR logging method was 56%, showing that the accuracy of the newly proposed resistivity DT logging method’s saturation formula was significantly improved. Finally, a new model-based cross chart was developed, which can rapidly differentiate gas saturation during drilling. Full article

Oil–water relative permeability is an important parameter that affects fluid flow in porous media. It is usually obtained in a laboratory. Since rock resistivity and relative permeability are both effects of water saturation, they should theoretically have a relationship. Based on the parallel conduction principle of fluid and skeleton in porous media, the pore structure and fluid distribution can be simplified using the Kozeny–Carman permeability correction equation and the Archie formula, and the relative permeability model of the water phase can be deduced under different wetting conditions. In this study, the resistivity and relative permeability experimental data of 20 rock samples from four inspection wells were compared and verified. The results show that the proposed oil–water relative permeability model agrees well with a reservoir having a porosity range of 17.6–30.7% and an air permeability of 0.16–973 × 10⁻³ μm, and it may explain why the relative permeability of the water phase decreases as water saturation increases. This model could provide a new technique to construct the relative permeability curves of sandstone reservoirs. Full article

Natural gas hydrate is widely spread in marine environments around the world. It has great energy potential due to its high methane gas content. High-precision exploration and evaluation of marine gas hydrate still face great challenges as it is affected by the complex reservoir control mechanisms and distribution characteristics. Resistivity is widely used in geophysical logging and theoretical research on gas hydrate-bearing reservoirs by utilizing the high sensitivity electrical response. In this paper, based on the examination of the global marine gas hydrate occurrences, resistivity logging results are summarized. Then the key remaining gas hydrate resistivity experimental concerns are reviewed. In summary, resistivity properties are a reliable means to derive the gas hydrate reservoir characteristics, despite the effect induced by the anisotropic properties of hydrate reservoirs and drilling technology. The overall resistivity change associated with the occurrence of pore filling gas hydrate in reservoirs are relatively small, and the specific value is affected by sediment lithology and hydrate saturation. On the other hand, fracture filling hydrate reservoirs have strong anisotropy, and massive hydrate occurrences (i.e., layers of gas hydrate with no sediment) section shows very high resistivity variation. Clay minerals are an important factor restricting the accurate estimation of gas hydrate saturations from in situ resistivity measurements. Many experimental studies have proposed the correction of Archie empirical formula, but widely representative models have not yet been developed. It is worth noting that more complex resistivity measurements may be able to provide additional electrical response information on various gas hydrate systems. Full article
