Search Results (9)

As aviation demand rises, fossil jet fuel consumption follows, thus increasing focus on sustainable aviation fuels to reduce aircraft greenhouse gas emissions. While advanced technologies and optimized operations play a role, alternative fuels, especially non-drop-in options like Liquefied Natural Gas (LNG) and methanol, offer promising potential for significant emission reductions if used in current aero-engines. LNG, a candidate near-term replacement of fossil jet fuel and methanol, even though a less conventional option in aviation, present advantages. Both fuels showcase the ability to generate the same thrust output by also achieving lower post-combustion temperatures, thereby enhancing component life and reducing emissions. Inversely, requesting equal post-combustion temperature as the baseline kerosene operation of the engine can produce greater thrust output, a much needed result for such fuels with low volumetric energy density, which causes greater take-off thrust demand mainly due to their larger tank requirements. This study uses advanced 0-D engine models coupled with detailed chemistry 1-D burner models and mission analysis tools to assess the aforementioned trends of LNG and methanol used to power a current geared turbofan engine. The aim of this work is to provide insights into the advantages, the limitations and the overall viability of the fuels in question as less polluting aviation fuels, addressing both environmental impact and operational feasibility in future aviation applications. According to findings of this article, when compared with Jet-A, LNG can reduce post-combustion temperature by an average of 1% or increase net-thrust by 3% while lowering $C{O}_2$, $N{O}_x$ and $CO$ emissions by 20%, 46% and 39%, respectively. Adversely, methanol is capable of lessening post-combustion temperature by 3% or enhancing thrust output by 10% while also reducing $C{O}_2$, $N{O}_x$ and $CO$ emissions by an average of 6%, 60% and 38%, respectively. Full article

A review of existing research on signatures of gas turbine faults is presented. Faults that influence the aerothermodynamic performance of compressors and turbines, such as fouling, tip clearance increase, erosion, variable geometry system malfunction, and object impact damage, are covered. The signatures of such faults, which are necessary for establishing efficient gas path diagnostic methods, are studied. They are expressed through mass flow capacity and efficiency deviations. The key characteristics of the ratio of such deviations are investigated in terms of knowledge existing in published research. Research based on experimental studies, field data, and results of detailed fluid dynamic computations that exist today is found to provide such information. It is shown that although such signatures may be believed to have a unique correspondence to the type of component fault, this is only true when a particular engine and fault type are considered. The choice of diagnostic methods by developers should, thus, be guided by such considerations instead of using values taken from the literature without considering the features of the problem at hand. Full article

Data from the steady-state operation of gas turbine engines are used in gas path diagnostic procedures. A method to identify steady-state operation is thus required. This paper initially explains and demonstrates the factors that cause a deviation in engine health when transient data are used for diagnosis and shows that there is a threshold in the slope of time traces, below which the variation in engine health parameters is acceptable. A methodology for deriving a criterion for steady-state operation based on actual flight data is then presented. The slope of the exhaust gas temperature variation with time and the size of its time-series window, from which this slope is determined, are the required parameters that must be specified when applying this criterion. It is found that the values of these parameters must be selected so that a sufficient number of steady-state points are available without compromising the accuracy of the diagnostic procedure. Full article

In a time when low emission solutions and technologies are of utmost importance regarding the sustainability of the aviation sector, this publication introduces a reduced-order physics-based model for combustion chambers of aeroengines, which is capable of reliably producing accurate pollutant emission and combustion efficiency estimations. The burner is subdivided into three volumes, with each represented by a single perfectly stirred reactor, thereby resulting in a simplified three-element serial chemical reactor network configuration, reducing complexity, and promoting the generality and ease of use of the model, without requiring the proprietary engine information needed by other such models. A tuning method is proposed to circumvent the limitations of its simplified configuration and the lack of detailed geometric data for combustors in literature. In contrast to most similar frameworks, this also provides the model with the ability to simultaneously predict the combustion efficiency and all pollutant emissions of interest ($N{O}_x$, $CO$ and unburnt hydrocarbons) more effectively by means of implementing a detailed chemical kinetics model. Validation against three correlation methods and actual aeroengine configurations demonstrates accurate performance and emission trend predictions. Integrated within two distinct combustion chamber low-emission preliminary design processes, the proposed model evaluates each new design, thereby displaying the ability to be employed in terms of optimizing a combustor’s overall performance given its sensitivity to geometric changes. Overall, the proposed model proves its worth as a reliable and valuable tool for use towards a greener future in aviation. Full article

An approach for preliminary aero-engine design, incorporating a mean-line code for the design of axial-flow, multi-stage compressors, is presented. The compressor mean-line code is developed and integrated within a framework for the preliminary design and assessment of aero-engine concepts. It is then combined with modules for compressor map generation, multi-point engine design, steady-state and transient engine off-design performance and aircraft mission analysis. Implementation examples are presented, demonstrating the determination of the optimal combination of compressor and engine design parameters for achieving minimum fuel burn over a specific aircraft mission, while obeying constraints that guarantee operability over the entire flight envelope. Constraints related to compressor stability during transient maneuvers between idle and static take-off conditions and engine temperature limits at maximum take-off are respected by the final design. The results demonstrate the potential for design trade-offs between engine performance at the aircraft mission level and compressor aerodynamic stability. Full article

Disks in gas turbines are optimized for minimum weight, while satisfying both geometry and stress constraints, in order to minimize the engine production, operation, and maintenance costs. In the present paper, a tool is described for the preliminary mechanical design of gas turbine disks. A novel formulation is presented, where the disk weight minimization is achieved by maximizing the stresses developed in the disk. The latter are expressed in the form of appropriately defined design and burst margins. The computational capabilities of the tool developed are demonstrated through comparisons to calculations with a higher fidelity tool. The importance of accurately calculating thermal stresses is demonstrated and the ability of the tool for such calculations is discussed. The potential and efficiency of the tool are illustrated through a proposed re-design of the disks of a well-documented ten-stage compressor. Finally, the integration of the tool into an overall engine design framework is discussed. Full article

Objectives: Fibroids cause significant morbidity and are the most common indication for hysterectomies worldwide, delimiting a major public health problem. Uterine artery embolization (UAE) is an alternative therapy to surgical treatment of symptomatic fibroids; it has satisfactory long-time results and is no longer considered investigational for the treatment of symptomatic fibroids. This study was undertaken to evaluate changes in fibroid specific symptom severity and health-related quality of life (HRQOL) after UAE and to optimize the assessment of safety and outcomes measures for participants who receive UAE to objective compare UAE and surgical alternatives for therapy of symptomatic fibroids. Study design: The analysis was based on questionnaires completed by 270 pre-menopausal females with a mean age of 42 years (range, 38–50 years) who underwent UAE for uterine leiomyomas and/or adenomyosis from November 2013 through December 2019. Only symptomatic women were selected whose symptoms were not improving with medication and who did not wish to have children. The primary outcome measure was a change in fibroid symptoms and HRQOL (health related quality of life) after UAE. Secondary outcomes included the decrease in uterine volume after UAE. Results: Questionnaires were completed by 270 women (100%) at a mean of 12.1 months from UAE. The median follow-up period was two years. Uterine fibroid embolization led to a shrinkage at three months for the 90% of the participants. A reduction of bleeding symptoms, pain and bulk-related symptoms was observed in 89.7%, 88.9%, and 89.5% of the patients, respectively. In the long term, there was no significant difference in parameters assessed compared with the midterm follow-up findings. A total of 6 patients (2.3%) underwent fractional curettage an average of 32.1 months after intervention due to necrotic changes in submucosal fibroids. All participants continued to be satisfied with the intervention, and 240 patients (88.9%) answered that they would recommend uterine fibroid embolization to other patients. Conclusions: Women who undergo UAE have a significant decrease in symptom severity and increase in HRQOL which is associated with high levels of satisfaction with the procedure (even when subsequent therapies are pursued). Full article

A mean-line compressor performance calculation method is presented that covers the entire operating range, including the choked region of the map. It can be directly integrated into overall engine performance models, as it is developed in the same simulation environment. The code materializing the model can inherit the same interfaces, fluid models, and solvers, as the engine cycle model, allowing consistent, transparent, and robust simulations. In order to deal with convergence problems when the compressor operates close to or within the choked operation region, an approach to model choking conditions at blade row and overall compressor level is proposed. The choked portion of the compressor characteristics map is thus numerically established, allowing full knowledge and handling of inter-stage flow conditions. Such choking modelling capabilities are illustrated, for the first time in the open literature, for the case of multi-stage compressors. Integration capabilities of the 1D code within an overall engine model are demonstrated through steady state and transient simulations of a contemporary turbofan layout. Advantages offered by this approach are discussed, while comparison of using alternative approaches for representing compressor performance in overall engine models is discussed. Full article

This paper presents a modular, flexible, extendable and fast-computational framework that implements a multidisciplinary, varying fidelity, multi-system approach for the conceptual and preliminary design of novel aero-engines. In its current status, the framework includes modules for multi-point steady-state engine design, aerodynamic design, engine geometry and weight, aircraft mission analysis, Nitrogen Oxide (NOx) emissions, control system design and integrated controller-engine transient-performance analysis. All the modules have been developed in the same software environment, ensuring consistent and transparent modeling while facilitating code maintainability, extendibility and integration at modeling and simulation levels. Any simulation workflow can be defined by appropriately combining the relevant modules. Different types of analysis can be specified such as sensitivity, design of experiment and optimization. Any combination of engine parameters can be selected as design variables, and multi-disciplinary requirements and constraints at different operating points in the flight envelope can be specified. The framework implementation is exemplified through the optimization of an ultra-high bypass ratio geared turbofan engine with a variable area fan nozzle, for which specific aircraft requirements and technology limits apply. Although the optimum design resulted in double-digit fuel-burn benefits compared to current technology engines, it did not meet engine-response requirements, highlighting the need to include transient-performance assessments as early as possible in the preliminary engine design phase. Full article
