Article

Development of a Loop-Mediated Isothermal Amplification (LAMP) Assay Targeting the Citrate Synthase Gene for Detection of Ehrlichia canis in Dogs

1
Department of Veterinary Paraclinical Sciences, College of Veterinary Medicine, University of the Philippines Los Baños, College, Laguna, Los Baños 4031, Philippines
2
Laboratory of Infectious Diseases, Joint Faculty of Veterinary Medicine, Kagoshima University, Korimoto 1-21-24, Kagoshima 890-0065, Japan
3
Center for Southeast Asian Studies, Kyoto University, Shimoadachi-cho 46, Yoshida, Sakyo-ku, Kyoto 606-8501, Japan
*
Authors to whom correspondence should be addressed.
Vet. Sci. 2020, 7(4), 156; https://doi.org/10.3390/vetsci7040156
Received: 8 September 2020 / Revised: 8 October 2020 / Accepted: 14 October 2020 / Published: 15 October 2020
(This article belongs to the Special Issue Trends in Tickborne Diseases)

Abstract

:
Canine monocytic ehrlichiosis caused by Ehrlichia canis is one of the leading tick-borne diseases of dogs, particularly in tropical countries. A highly sensitive and specific diagnostic method is essential for early detection to facilitate treatment. This study was conducted to develop E. canis loop-mediated isothermal amplification (LAMP) assay, a highly sensitive yet simple molecular technique, targeting the citrate synthase (gltA) gene of E. canis. Canine blood samples were subjected to conventional PCR targeting E. canis gltA. After analysis of the sequences of PCR amplicons, LAMP primers were generated. The optimum temperature and time for the LAMP assay were determined using eight samples—after which, the effectiveness and reproducibility of LAMP were verified by testing 40 samples, which included PCR-positive and negative samples. The detection limit was also established. The optimal condition for the assay was 61 °C for 60 min. Compared to PCR, the LAMP assay had a relative sensitivity and specificity of 92.5 and 100%, respectively. Statistical analysis using McNemar’s test showed that the E. canis LAMP assay has no significant difference with PCR. Therefore, the LAMP assay developed in this study may be used as an alternative to PCR in the detection of E. canis.

1. Introduction

Canine monocytic ehrlichiosis (CME) is caused by Ehrlichia canis, an obligate intracellular tick-borne pathogen of dogs primarily transmitted by the brown dog tick Rhipicephalus sanguineus [1,2]. CME is a multisystemic disease usually characterized by thrombocytopenia, which leads to hemorrhagic disorders, as well as lymphadenomegaly, splenomegaly, and ophthalmologic disorders [3]. In severe cases, bleeding tendencies, including petechiae and ecchymoses with pancytopenia, may occur and eventually lead to death [4]. The occurrence of CME in Southeast Asia has been long established [5]. Recent studies utilizing PCR showed that E. canis is a leading tick-borne pathogen of dogs in Southeast Asia [6,7,8,9] and has been associated with severe anemia [10,11].
Early diagnosis is crucial in prompt control of the disease since it can progress to a mild or severe chronic phase with a grave prognosis [12]. The clinical signs of CME are similar to that of other tick-borne diseases; hence, diagnostic tools that can specifically demonstrate the pathogen are necessary. Detection of E. canis is conventionally done by microscopic examination of blood smear. However, it is difficult to diagnose it in the acute phase of the infection due to the low number of morulae [3]. PCR is a highly sensitive molecular technique capable of detecting E. canis DNA as early as 4–10 days post-infection [13]. However, PCR is mostly applied in research since it is time-consuming, sophisticated, and labor-intensive [14]. In addition, it has limited use in clinical settings due to the need for expensive equipment and adequate skills.
The loop-mediated isothermal DNA amplification (LAMP) is also a highly sensitive molecular technique but is more rapid and more uncomplicated than PCR. In LAMP, a target gene is amplified using four to six primers under an isothermal condition within an hour or less [15]. LAMP reaction may be interpreted visually based on turbidity or fluorescence upon addition of intercalating dyes. LAMP products can also be subjected to gel electrophoresis to examine for the presence of multiple bands with a ladder-like appearance [16]. A colori-fluorometric indicator (CFI) developed by Hayashida et al. allows straightforward interpretation based on the visualization of a color change under white light or observation of fluorescence with the aid of ultraviolet light [17]. Some studies reported LAMP development for the detection of E. canis that targeted the heat shock operon groESL gene [18] and p30 gene [14,19]. The use of LAMP in the detection of E. canis in the Philippines has not been investigated. In this study, the development of a LAMP assay targeting the citrate synthase gene (gltA) for detecting E. canis in canine blood was investigated. The detection method mentioned may be possibly adapted in veterinary clinics in the Philippines and other countries.

2. Materials and Methods

2.1. Blood Samples and DNA Extraction

The canine blood samples used in this study have been previously collected from veterinary clinics in cities in Metropolitan Manila, the capital region of the Philippines, and tested using conventional PCR in a previous study [9]. A total of 46 E. canis-positive and 12 E. canis-negative samples based on PCR were identified. DNA was extracted from the blood samples using a commercial spin-column based extraction kit (GeneALL® ExgeneTM Blood SV mini GeneALL Biotechnology Co., Ltd., Seoul, Korea) following the manufacturer’s protocol. To confirm successful DNA extraction, amplification of the control actin gene was carried out as described previously [9] using the Tks Gflex DNA Polymerase (Takara, Kusatsu, Shiga, Japan).

2.2. Conventional PCR for E. canis and Sequence Analysis

DNA samples were subjected to a conventional PCR targeting the citrate synthase or gltA gene of E. canis following the conditions described by Inokuma et al. [20]. Table 1 depicts the primers utilized. The PCR products were separated by electrophoresis on 2% agarose gel in 1 x TAE buffer, followed by staining with ethidium bromide. Bands with a size of approximately 1251 bp were considered positive. Using Nucleospin® Gel and PCR clean up kit (Macherey-Nagel, Dueren, Germany), twelve positive amplicons were subjected to sequencing following purification according to the manufacturer’s protocol.
The sequences of the selected E. canis gltA amplicons were compared to that of reported isolates using the Standard Nucleotide Basic Local Alignment Search Tool (BLAST) program (http://blast.ncbi.nlm.nih.gov). Multiple alignments were accomplished to determine similarity among amplicons.

2.3. LAMP Primer Design and Optimization of LAMP Condition

The consensus sequence of E. canis gltA from selected samples was used to generate LAMP primers using the online LAMP primer designing software, Primer Explorer version 5 (http://primerexplorer.jp/e/) (Table 1).
LAMP reaction mixtures were prepared by mixing 2.5 µL (1×) 10× isothermal amplification buffer, 6 mM MgSO4, 1.4 mM dNTP mix, a primer mix containing 0.2 µM F3/B3 primers, 1.6 µM FIP/BIP primers, and 0.4 µM LF/LB primers, 8 U Bst 2.0 WarmStart® DNA Polymerase (New England Biolabs, Inc., Ipswich, MA, USA), 1 µL colori-fluorometric indicator (CFI), 2 µL DNA, and nuclease-free water to achieve a final volume of 25 µL. CFI contains 3 mM hydroxylnaphthol blue (HNB; MP Biomedicals, Aurora, OH, USA) and 0.35% v/v GelGreen (10 000 × Sol, Biotium, Hayward, CA, USA) dissolved in distilled water [17]. For optimizing LAMP condition, six PCR-positive and two PCR-negative samples were subjected to a LAMP assay for 60 min with varying temperatures between 60 °C to 65 °C. A negative control (nuclease-free water) was included in each run. The reaction was then terminated by heating at 80 °C for two minutes. After determining the optimum temperature, reaction time was varied to 30, 45, and 60 min.

2.4. LAMP Reproducibility and Detection Limit

The remaining 40 E. canis PCR-positive samples and ten negative samples underwent LAMP assay using the optimized temperature and time. Analysis of LAMP products through gel electrophoresis was also performed similarly to what was described earlier after PCR. To determine the detection limit, a purified PCR amplicon of E. canis gltA (7.41 × 109 copies) was serially diluted 10-fold up to 7.41 × 104 copies being the lowest concentration, and was subjected to LAMP.

2.5. Data Analysis

To compare LAMP and PCR, Mc Nemar’s test was applied using a 2 × 2 contingency table. The relative sensitivity, specificity, accuracy, and positive and negative predictive values were calculated, of which all were expressed as a percentage. The significant difference between LAMP and conventional PCR was set at p < 0.05.

3. Results

3.1. PCR and Sequence Analysis

The targeted 1251 bp fragment of E. canis gltA was successfully amplified through conventional PCR. BLAST analysis showed that the selected amplicons shared 93–99% identity with E. canis gltA sequences stored in GenBank. Meanwhile, multiple alignments revealed a 96% sequence similarity among the amplicons. The LAMP primers were designed based on the consensus sequence of the PCR amplicons.

3.2. Optimum LAMP Temperature and Time

The results of LAMP in different temperatures were compared to that of the PCR (Table 2). LAMP at 60 °C, 61 °C, and 64 °C matched the PCR results of all tested samples. However, among those temperatures, an apparent distinction between the positive and negative reactions indicated by a blue and violet color, respectively, was most evident at 61 °C (Figure 1A). Visualization after gel electrophoresis of selected positive samples showed a ladder-like appearance while the negative sample and negative control showed no bands (Figure 1B). After establishing the optimum temperature, the duration of the LAMP reaction was varied. At various incubation times, all samples matched the PCR results with 60 min having the most evident color distinction between positive and negative results. Hence, the optimal condition for LAMP was set at 61 °C for 60 min.

3.3. LAMP Reproducibility and Detection Limit

The reproducibility and effectiveness of developed E. canis LAMP were tested by running 40 PCR positive and ten negative samples. Among the PCR-positive samples, 37 tested positive using LAMP, while three tested negative (Table 3). Meanwhile, all PCR negative samples were also negative in LAMP. Regarding the detection limit, a purified gltA fragment amplicon was serially diluted ten-fold, with the number of copies ranging from 7.41 × 109 being the highest and 7.41 × 104 being the lowest. All concentrations tested positive in LAMP (Figure 1C).

3.4. LAMP Sensitivity, Specificity, and Accuracy

Based on the obtained results, LAMP has 92.5% relative sensitivity, 100% relative specificity, and 94% accuracy compared to conventional PCR. Its positive and negative predictive values are 100 and 76.92%, respectively. Mc Nemar’s test showed no significant difference (p = 0.12411) between the two methods.

4. Discussion

CME due to E. canis is widespread, most likely due to its vector tick’s worldwide distribution [21]. Our recent study suggested that CME is the leading TBD of dogs in the Philippines [7]. Aside from causing significant morbidities and fatalities in dogs, E. canis is recognized as a potential zoonotic pathogen after being reported in some cases in humans [22,23,24]. Early diagnosis is crucial to control the progress of infection promptly. Being superior to microscopic examination in terms of sensitivity and a better indicator of active disease than antibody detection, PCR is useful in early detection of E. canis infection [25]. However, the time requirement and sophistication hinder its use in the veterinary clinic setting as a routine diagnostic tool, particularly in developing countries like the Philippines. Thus, the development of a LAMP assay for E. canis detection due to its simplicity, shorter time requirement, and lower cost compared to PCR was further explored.
In this study, LAMP primers were designed based on an amplified fragment of the E. canis gltA gene using conventional PCR. Previous studies that developed LAMP assay for E. canis targeted groESL [18] and p30 [14,19]. gltA is an ideal target because of the lower level of similarity among Ehrlichia species and related genera compared to groESL and 16sr RNA genes [20,26]. Therefore, the use of this gene is beneficial in the detection of specific species.
The use of CFI with HNB as a dye enabled the immediate and easy visual interpretation of LAMP results in this study without requiring any equipment. In the case of a positive reaction, the color change from violet to blue occurs due to the decrease in Mg2+ ion concentration upon chelation by dNTPs [27]. The presence of multiple bands with a ladder-like appearance after gel electrophoresis of positive samples supports the visual interpretation. In this study, several temperatures and reaction times yielded similar results. However, the optimal reaction condition, 61 °C for 60 min, was decided based on the distinct difference in the color of the positive samples from the negative samples. Using LAMP, the total testing time from DNA extraction to the visualization of results was accomplished in only two hours and 20 min compared to that of PCR, which took more than four hours. Although a thermal cycler was used to carry-out the LAMP reactions, a heat block may be used as a substitute to simplify the equipment requirement. Moreover, with the use of CFI, lysed blood can be utilized as starting material without DNA extraction [17] to simplify further and shorten the process.
Among the 40 PCR positive samples, three samples were negative in LAMP. The false-negative result may be due to the sequence variation in the DNA target. Since more primers were used in a LAMP reaction, accurate hybridization at nucleotide to nucleotide bases is needed to facilitate strand displacement DNA amplification [19]. The LAMP primers were designed based on the consensus sequence of twelve amplicons. Those three samples may have some differences in the nucleotide sequence compared to that of the other samples. The sequence variation may be due to differences among strains of E. canis [28,29]. Another possible reason proposed by Pinhanelli et al. [14] could be the inhibitory effect of the DNA components of the samples.
Compared with conventional E. canis PCR, the LAMP reaction in this study had a 92.5% relative sensitivity and 100% relative specificity. It also has a 94% (47/50) accuracy. These values were higher than those obtained in the study of Pinhanelli et al. [14] and comparable to that of Muangchuen et al. [19], which used LAMP targeting p30 gene. Mc Nemar’s test revealed that the difference between conventional PCR and LAMP was statistically insignificant. This implies that the LAMP is comparable with PCR in the detection of E. canis, and thus the LAMP assay targeting gltA can be used as an alternative to PCR for the detection of E. canis. In studies on the detection of other members of Anaplasmataceae, the LAMP assay was also found to have displayed superior performance over PCR [30,31,32].
To summarize, a LAMP assay targeting the gltA gene was developed for the detection of E. canis. The LAMP primers, designed based on the sequences of selected PCR positive amplicons, were proven to be effective, with an optimum reaction condition at 61 °C for 60 min. The use of CFI allowed a rapid and straightforward interpretation of results. Based on the statistical analysis, there was no significant difference between the two molecular techniques, making LAMP a comparable diagnostic tool to conventional PCR. Therefore, this assay may be done as an alternative to PCR in the detection of E. canis and can be adapted for use in veterinary clinics to aid in the accurate diagnosis of CME. Future investigation should be aimed at increasing the sensitivity of this assay to avoid having false-negative results. The sequences of PCR-positive samples that turned negative in LAMP should be examined for variations, and the primer sequences should be redesigned accordingly to ensure the detection of multiple strains of E. canis. The testing of a large number of clinical samples is recommended to assess its effectiveness. Further comparative study of LAMP and PCR may look into the earliest time the pathogen is detectable during the disease onset. A heat block or a regular laboratory water bath can be substituted for a thermal cycler to simplify the material requirement. Lastly, the use of lysed blood samples as starting material may be considered to shorten the time required.

Author Contributions

Conceptualization, R.L.G. and T.T.; methodology, R.L.G., T.T., and W.Y.; investigation, A.P.B.C. and R.L.G.; formal analysis, A.P.B.C. and R.L.G.; writing—original draft preparation, A.P.B.C. and R.L.G.; writing—review and editing, R.L.G., T.T., and W.Y.; supervision, R.L.G.; project administration, R.L.G. and T.T.; funding acquisition, R.L.G. and T.T. All authors have read and agreed to the published version of the manuscript.

Funding

This research was funded by the University of the Philippines Balik PhD (Foreign-trained PhD) grant, and the Japan Society for Promotion of Science, Grant No. 15H05264.

Acknowledgments

The authors are thankful to John Michael G. Bernardo and Kristina Andrea C. Sandalo, research associates at the Department of Veterinary Paraclinical Sciences, College of Veterinary Medicine, University of the Philippines Los Baños, for their assistance in the conduct of experiments, Billy P. Divina and Rey B. Oronan, faculty members of College of Veterinary Medicine, University of the Philippines Los Baños, for their suggestions in the improvement of the original manuscript, and Junelle L. Paller for language editing.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Fourie, J.J.; Stanneck, D.; Luus, H.G.; Beugnet, F.; Wijnveld, M.; Jongejan, F. Transmission of Ehrlichia canis by Rhipicephalus sanguineus ticks feeding on dogs and on artificial membranes. Vet. Parasitol. 2013, 197, 595–603. [Google Scholar] [CrossRef] [PubMed]
  2. Dantas-Torres, F.; Otranto, D. Further thoughts on the taxonomy and vector role of Rhipicephalus sanguineus group ticks. Vet. Parasitol. 2015, 208, 9–13. [Google Scholar] [CrossRef] [PubMed]
  3. Harrus, S.; Waner, T. Diagnosis of canine monocytotropic ehrlichiosis (Ehrlichia canis): An overview. Vet. J. 2011, 187, 292–296. [Google Scholar] [CrossRef] [PubMed]
  4. Shipov, A.; Klement, E.; Reuveni-Tager, L.; Waner, T.; Harrus, S. Prognostic indicators for canine monocytic ehrlichiosis. Vet. Parasitol. 2008, 153, 131–138. [Google Scholar] [CrossRef]
  5. Irwin, P.J.; Jefferies, R. Arthropod-transmitted diseases of companion animals in Southeast Asia. Trends Parasitol. 2004, 20, 27–34. [Google Scholar] [CrossRef]
  6. Piratae, S.; Pimpjong, K.; Vaisusuk, K.; Chatan, W. Molecular detection of Ehrlichia canis, Hepatozoon canis and Babesia canis vogeli in stray dogs in Mahasarakham province, Thailand. Ann. Parasitol. 2015, 61, 183–187. [Google Scholar] [PubMed]
  7. Koh, F.X.; Panchadcharam, C.; Tay, S.T. Vector-Borne Diseases in Stray Dogs in Peninsular Malaysia and Molecular Detection of Anaplasma and Ehrlichia spp. from Rhipicephalus sanguineus (Acari: Ixodidae) Ticks. J. Med. Entomol. 2016, 53, 183–187. [Google Scholar] [CrossRef]
  8. Inpankaew, T.; Hii, S.F.; Chimnoi, W.; Traub, R.J. Canine vector-borne pathogens in semi-domesticated dogs residing in northern Cambodia. Parasit. Vectors 2016, 9, 253. [Google Scholar] [CrossRef][Green Version]
  9. Galay, R.L.; Manalo, A.A.L.; Dolores, S.L.D.; Aguilar, I.P.M.; Sandalo, K.A.C.; Cruz, K.B.; Divina, B.P.; Andoh, M.; Masatani, T.; Tanaka, T. Molecular detection of tick-borne pathogens in canine population and Rhipicephalus sanguineus (sensu lato) ticks from southern Metro Manila and Laguna, Philippines. Parasit. Vectors 2018, 11, 643. [Google Scholar] [CrossRef]
  10. Kaewmongkol, G.; Lukkana, N.; Yangtara, S.; Kaewmongkol, S.; Thengchaisri, N.; Sirinarumitr, T.; Jittapalapong, S.; Fenwick, S.G. Association of Ehrlichia canis, Hemotropic Mycoplasma spp. and Anaplasma platys and severe anemia in dogs in Thailand. Vet. Microbiol. 2017, 201, 195–200. [Google Scholar] [CrossRef]
  11. Piratae, S.; Senawong, P.; Chalermchat, P.; Harnarsa, W.; Sae-Chue, B. Molecular evidence of Ehrlichia canis and Anaplasma platys and the association of infections with hematological responses in naturally infected dogs in Kalasin, Thailand. Vet. World 2019, 12, 131–135. [Google Scholar] [CrossRef] [PubMed][Green Version]
  12. Harrus, S.; Kass, P.H.; Klement, E.; Waner, T. Canine monocytic ehrlichiosis: A retrospective study of 100 cases, and an epidemiological investigation of prognostic indicators for the disease. Vet. Rec. 1997, 141, 360–363. [Google Scholar] [CrossRef] [PubMed]
  13. Iqbal, Z.; Chaichanasiriwithaya, W.; Rikihisa, Y. Comparison of PCR with other tests for early diagnosis of canine ehrlichiosis. J. Clin. Microbiol. 1994, 32, 1658–1662. [Google Scholar] [CrossRef][Green Version]
  14. Pinhanelli, V.C.; Costa, P.N.M.; Silva, G.; Aguiar, D.M.; Silva, C.M.L.; Fachin, A.L.; Marins, M. Development and evaluation of a loop-mediated isothermal amplification assay for detection of Ehrlichia canis DNA in naturally infected dogs using the p30 gene. Genet. Mol. Res. 2015, 14, 17885–17892. [Google Scholar] [CrossRef]
  15. Notomi, T.; Okayama, H.; Masubuchi, H.; Yonekawa, T.; Watanabe, K.; Amino, N.; Hase, T. Loop-mediated isothermal amplification of DNA. Nucleic Acids Res. 2000, 28, E63. [Google Scholar] [CrossRef] [PubMed][Green Version]
  16. Wong, Y.P.; Othman, S.; Lau, Y.L.; Radu, S.; Chee, H.Y. Loop-mediated isothermal amplification (LAMP): A versatile technique for detection of micro-organisms. J. Appl. Microbiol. 2018, 124, 626–643. [Google Scholar] [CrossRef] [PubMed][Green Version]
  17. Hayashida, K.; Kajino, K.; Hachaambwa, L.; Namangala, B.; Sugimoto, C. Direct blood dry LAMP: A rapid, stable, and easy diagnostic tool for Human African Trypanosomiasis. PLoS Negl. Trop. Dis. 2015, 9, e0003578. [Google Scholar] [CrossRef]
  18. Faggion, S.A.; Salvador, A.R.; Jacobino, K.; Bortolotto, L.; Lopes, M.B.; Silva, M.; Santos, E.V.; Fachin, A.L.; Franca, S.C.; Marins, M. Loop-mediated isothermal amplification assay for the detection of Ehrlichia canis DNA in blood samples from dogs. Arch. de Med. 2013, 45, 197–201. [Google Scholar] [CrossRef][Green Version]
  19. Muangchuen, A.; Chaumpluk, P.; Suriyasomboon, A.; Ekgasit, S. Colorimetric detection of Ehrlichia canis via nucleic acid hybridization in gold nano-colloids. Sensors 2014, 14, 14472–14487. [Google Scholar] [CrossRef] [PubMed][Green Version]
  20. Inokuma, H.; Brouqui, P.; Drancourt, M.; Raoult, D. Citrate synthase gene sequence: A new tool for phylogenetic analysis and identification of Ehrlichia. J. Clin. Microbiol. 2001, 39, 3031–3039. [Google Scholar] [CrossRef][Green Version]
  21. Dantas-Torres, F. Biology and ecology of the brown dog tick, Rhipicephalus sanguineus. Parasit. Vectors 2010, 3, 26. [Google Scholar] [CrossRef] [PubMed][Green Version]
  22. Perez, M.; Bodor, M.; Zhang, C.; Xiong, Q.; Rikihisa, Y. Human infection with Ehrlichia canis accompanied by clinical signs in Venezuela. Ann. N. Y. Acad. Sci. 2006, 1078, 110–117. [Google Scholar] [CrossRef] [PubMed]
  23. Garcia-Baena, C.; Cárdenas, M.F.; Ramón, J.F. Cerebral haemorrhage as a clinical manifestation of human ehrlichiosis. BMJ Case Rep. 2017. [Google Scholar] [CrossRef] [PubMed]
  24. Bouza-Mora, L.; Dolz, G.; Solórzano-Morales, A.; Romero-Zuñiga, J.J.; Salazar-Sánchez, L.; Labruna, M.B.; Aguiar, D.M. Novel genotype of Ehrlichia canis detected in samples of human blood bank donors in Costa Rica. Ticks Tick Borne Dis. 2017, 8, 36–40. [Google Scholar] [CrossRef]
  25. Sainz, Á.; Roura, X.; Miró, G.; Estrada-Peña, A.; Kohn, B.; Harrus, S.; Solano-Gallego, L. Guideline for veterinary practitioners on canine ehrlichiosis and anaplasmosis in Europe. Parasit. Vectors 2015, 8, 75. [Google Scholar] [CrossRef] [PubMed][Green Version]
  26. Marsilio, F.; Di Martino, B.; Meridiani, I.; Bianciardi, P. Direct identification of Ehrlichia canis by a novel polymerase chain reaction method and molecular analysis of the citrate synthase (gltA) gene from various Italian strains. J. Vet. Diagn. Investig. 2006, 18, 215–217. [Google Scholar] [CrossRef][Green Version]
  27. Goto, M.; Honda, E.; Ogura, A.; Nomoto, A.; Hanaki, K.-I. Colorimetric detection of loop-mediated isothermal amplification reaction by using hydroxy naphthol blue. BioTechniques 2009, 46, 167–172. [Google Scholar] [CrossRef]
  28. Nambooppha, B.; Rittipornlertrak, A.; Tattiyapong, M.; Tangtrongsup, S.; Tiwananthagorn, S.; Chung, Y.-T.; Sthitmatee, N. Two different genogroups of Ehrlichia canis from dogs in Thailand using immunodominant protein genes. Infect. Genet. Evol. 2018, 63, 116–125. [Google Scholar] [CrossRef]
  29. Zhang, X.; Luo, T.; Keysary, A.; Baneth, G.; Miyashiro, S.; Strenger, C.; Waner, T.; McBride, J.W. Genetic and antigenic diversities of major immunoreactive proteins in globally distributed Ehrlichia canis strains. Clin. Vaccine Immunol. 2008, 15, 1080–1088. [Google Scholar] [CrossRef][Green Version]
  30. Nakao, R.; Stromdahl, E.Y.; Magona, J.W.; Faburay, B.; Namangala, B.; Malele, I.; Inoue, N.; Geysen, D.; Kajino, K.; Jongejan, F.; et al. Development of loop-mediated isothermal amplification (LAMP) assays for rapid detection of Ehrlichia ruminantium. BMC Microbiol. 2010, 10, 296. [Google Scholar] [CrossRef][Green Version]
  31. Ma, M.; Liu, Z.; Sun, M.; Yang, J.; Guan, G.; Li, Y.; Luo, J.; Yin, H. Development and evaluation of a loop-mediated isothermal amplification method for rapid detection of Anaplasma ovis. J. Clin. Microbiol. 2011, 49, 2143–2146. [Google Scholar] [CrossRef] [PubMed][Green Version]
  32. Wen, X.B.; Jiang, H.T.; Zhang, Y.L.; Lang, X.Y.; Liu, J.; Ni, H.B. Rapid and sensitive diagnosis of cattle anaplasmosis by loop-mediated isothermal amplification (LAMP). Pak. Vet. J. 2016, 36, 174–178. [Google Scholar]
Figure 1. Representative results of LAMP assay targeting E. canis gltA by direct visualization and after gel electrophoresis. (A) shows the results of selected samples under the established optimal condition through direct visualization wherein Tubes 1 and 2 show a blue color indicative of a positive reaction. In contrast, Tube 3 shows a violet color indicative of a negative reaction similar to the negative control (Tube 4). In (B), the same samples were subjected to gel electrophoresis and viewed over a UV transilluminator. Lanes 1 and 2 display multiple bands with a ladder-like appearance, similar to the DNA marker (L), whereas Lane 3 shows the absence of bands, similar to the negative control in Lane 4. (C) shows the test results for the detection limit using a purified PCR amplicon of E. canis gltA that was serially diluted 10-fold. Tube 1 has the highest number of template copies at 7.41 × 109 while tube 5 has the lowest with 7.41 × 104 copies. Tube 6 is the negative control.
Figure 1. Representative results of LAMP assay targeting E. canis gltA by direct visualization and after gel electrophoresis. (A) shows the results of selected samples under the established optimal condition through direct visualization wherein Tubes 1 and 2 show a blue color indicative of a positive reaction. In contrast, Tube 3 shows a violet color indicative of a negative reaction similar to the negative control (Tube 4). In (B), the same samples were subjected to gel electrophoresis and viewed over a UV transilluminator. Lanes 1 and 2 display multiple bands with a ladder-like appearance, similar to the DNA marker (L), whereas Lane 3 shows the absence of bands, similar to the negative control in Lane 4. (C) shows the test results for the detection limit using a purified PCR amplicon of E. canis gltA that was serially diluted 10-fold. Tube 1 has the highest number of template copies at 7.41 × 109 while tube 5 has the lowest with 7.41 × 104 copies. Tube 6 is the negative control.
Vetsci 07 00156 g001
Table 1. List of primers targeting Ehrlichia canis gltA used in PCR and LAMP.
Table 1. List of primers targeting Ehrlichia canis gltA used in PCR and LAMP.
MethodPrimer NameSequence (5′ → 3′)Reference
PCREcanis FwTTATCTGTTTGTGTTATATAAGC[20]
Ecanis RevCAGTACCTATGCATATCAATCC
LAMPEcanis F3GCTGATCATGAGCAAAATGCThis study
Ecanis B3GCCTCGTACTTTTATTACCATCT
Ecanis FIPTCCCTGCTACCAAACAAGCAAGCTACTGTTAGGTTGGCTG
Ecanis BIPAGCTCATGGTGGTGCTAATGAATTGAATAAACTGCTTTACGTTAC
Ecanis LFATAAGTCAGCACCAGAAGAAC
Ecanis LBGCTGTGATTAATATGTTAATGGCA
Table 2. Result of LAMP assay for E. canis using different temperatures.
Table 2. Result of LAMP assay for E. canis using different temperatures.
Sample IDPCR ResultLAMP Temperature (°C)
606162636465
1BESC5++++++
2BBV3++++++
3PSY20++++++
4D8++++++
5D25+++++++
6D26++++++
7BHK2
8D45++
9Neg Control
Table 3. Contingency table for the comparison of LAMP and PCR in the detection of E. canis.
Table 3. Contingency table for the comparison of LAMP and PCR in the detection of E. canis.
PCR PositivePCR NegativeTotal
LAMP positive37037
LAMP negative31013
Total401050
