Foods 2017, 6(6), 43; doi:10.3390/foods6060043

Article
Impact of Sweet Potato Starch-Based Nanocomposite Films Activated With Thyme Essential Oil on the Shelf-Life of Baby Spinach Leaves
Department of Family and Consumer Sciences, North Carolina Agricultural and Technical State University, Greensboro, NC 27411, USA
*
Author to whom correspondence should be addressed.
Academic Editors: Malik Altaf Hussain and Ravi Gooneratne
Received: 3 May 2017 / Accepted: 1 June 2017 / Published: 3 June 2017

Abstract

:
Salmonella Typhimurium (S. Typhi) and Escherichia coli (E. coli) have been responsible for an increasing number of outbreaks linked to fresh produce, such as baby spinach leaves, in the last two decades. More recently, antimicrobial biodegradable packaging systems have been attracting much attention in the food packaging industry as eco-friendly alternatives to conventional plastic packaging. The objective of this study was to evaluate the effect of antibacterial nanocomposite films on inoculated spinach leaves and on the sensory properties of these leaves during eight days of refrigerated storage. In this study, an antibacterial film comprised of sweet potato starch (SPS), montmorillonite (MMT) nanoclays and thyme essential oil (TEO) as a natural antimicrobial agent was developed. Our results showed that the incorporation of TEO in the film significantly (p < 0.05) reduced the population of E. coli and S. Typhi on fresh baby spinach leaves to below detectable levels within five days, whereas the control samples without essential oil maintained approximately 4.5 Log colony forming unit (CFU)/g. The sensory scores for spinach samples wrapped in films containing TEO were higher than those of the control. This study thus suggests that TEO has the potential to be directly incorporated into a SPS film to prepare antimicrobial nanocomposite films for food packaging applications.
Keywords:
antimicrobial films; sweet potato starch; Escherichia coli; Salmonella Typhimurium; baby spinach leaves

1. Introduction

The World Health Organization (WHO), the Food and Agriculture Organization of the United Nation (FAO), and the U.S. Department of Agriculture (USDA) all recommend produce consumption for consumers due to the presence of high levels of micronutrients and fibers that can reduce the risk of cardiovascular diseases and cancer [1]. However, the food safety of fresh produce is a matter of increasing concern because these foods usually receive minimal processing and are often consumed as a ready-to-eat product. In the U.S., there were more cases of foodborne illnesses associated with fresh produce than those involving seafood, poultry, beef, pork, or eggs [2]. Salmonella spp., Escherichia coli O157:H7, Listeria monocytogenes, and Shigella spp. have been frequently associated with illness outbreaks related to the consumption of fresh produce, respectively [2]. An analysis of outbreak data in the U.S. from 1988 to 2008 shows that there was an average of 6.3–13.2 illness outbreaks each year caused by produce. More recently, leafy greens have been responsible for one third of these same types of outbreaks [3].
Fresh-cut baby spinach leaves have a very high respiration rate and require high levels of O2 in their packaging in order to maintain their quality [4]. Commercially processed baby spinach leaves are currently packaged with perforated films to allow adequate O2. This practice, however, raises a food-safety concern that human pathogenic bacteria could transfer from the environment through the perforations and result in post-processing contamination of the produce [4]. Thereby, it is essential that a packaging system be developed to improve the safety, as well as to maintain the sensory properties, of fresh-cut baby spinach leaves.
The primary types of plastics that are currently used in all applications are derived from non-renewable petroleum resources and are non-biodegradable. The volume of plastics discarded annually creates a substantial waste disposal issue. In a 2005 report, 28.9 million tons of plastic packaging was generated in the U.S., and only approximately 5.7% of plastic was recycled or reused in some way. The remaining 94.3% was sent to landfills and discarded or combusted into the environment [5]. Therefore, alternative strategies such as the sustainable use of natural and renewable resources to reduce the quantity of persistent plastic waste are warranted.
Recently, biodegradable films made of biopolymers have become more attractive for food packaging as an alternative to typical commercial plastic packaging [6]. Many types of biopolymers such as corn starch, wheat gluten, chitosan, soy, and whey proteins have been used for biodegradable packaging. However, there is potential allergenicity if these compounds migrate onto edible products [7,8,9]. Sweet potato starch can be used to overcome this issue as there has been no report of allergenicity associated with sweet potatoes thus far. Sweet potato (Ipomoea batatas Lam) is an inexpensive and readily available vegetable that is cultivated extensively for its nutritious value across many regions of the world. Sweet potato starch (SPS) with a 58–76% starch content (on a dry basis), has properties that are similar or better than those of potato starch [10]. However, sweet potato does not have the mechanical and barrier properties matching those of plastics [11]. The addition of nano-scale particles into starch can change crystallization kinetics, crystalline morphology, crystal forms, and crystallite size. As a result, the addition of these particles may improve the mechanical and barrier properties of starch. By far the most promising nanoscale fillers for biodegradable packaging are montmorillonite (MMT) nanoclays. The popularity of MMT nanoclays in food contact applications derives from their low cost, effectiveness, and high stability [12]. The incorporation of MMT into starch matrices has been used to enhance mechanical and barrier properties [13].
Nanocomposite films are also excellent vehicles for incorporating a wide variety of additives such as antioxidants and antimicrobial agents. The effect of these additives may be an improvement in food quality and safety. The antibacterial activities of films are determined in part by the release rate of antibacterial agents. If the release is too slow and the microbial growth is not sufficiently inhibited, the release is too fast and the inhibition is not sustained [14]. MMT nanoclay is a compound that can potentially be used to control the release of antimicrobial agents from film materials.
Natural antimicrobial agents have attracted increasing attention as a replacement for synthetic ones in the food packaging industry. Several natural antimicrobials have been incorporated into food packaging such as plant essential oils (EO), nisin and chitosan (a natural biopolymer extracted from crustacean shells). However, nisin has a limited spectrum of activity, does not inhibit Gram-negative bacteria or fungi, and is only effective at a low pH [15]. In addition, there are concerns with the allergenicity of chitosan incorporated into food packaging [16]. Among EOs, thyme (Thymus vulgaris) EO (TEO) has received the most attention from researchers. Thymol, the major component of TEO, has been found to possess antimicrobial activity in vitro against a broad spectrum of bacteria, such as S. Typhimurium, L. monocytogenes [17] Escherichia coli, Pseudomonas fluorescens, Staphylococcus aureus, Lactobacillus plantarum, and Bacillus subtilis, as well as Shigella sonnei and Shigella flexneri [18]. Thymol is considered to present no risk to the health of consumers, has been registered by the European Commission [19], and is generally recognized as safe (GRAS) by the Food and Drug Administration (FDA) [3].
Studies related to SPS as a source of starch for film packaging are very limited. In addition, up to now, there is no published report related to the application of an antibacterial SPS-based bio-nanocomposite film to a real food system or fresh produce. Thus, the overall objective of this study was to develop biodegradable nanocomposite-based food packaging films which incorporate TEO and MMT nanofillers with SPS to address issues of food safety, the environmental impact, and agricultural sustainability. The specific objectives of the research were to: (1) Develop biodegradable MMT nanocomposite films with SPS by incorporating TEO, (2) Investigate the antibacterial activity of films on inoculated baby spinach leaves, and (3) Evaluate the sensory properties of baby spinach leaves during refrigerated storage.

2. Materials and Methods

2.1. Bacterial Strains

Stock cultures of strains of E. coli K-12 (ATCC 25253) and S. Typhimurium (ATCC 53648) were obtained from the American Type Culture Collection. The microorganisms were kept frozen at −80 °C in tryptic soy broth (TSB) containing glycerol (10%, v/v). Before use, the stock cultures were resuscitated through two consecutive 24-h growth cycles in TSB at 37 °C to obtain working cultures containing approximately 105 colony forming unit (CFU)/mL, as determined by serial dilution and a plate count.

2.2. Antibacterial Activity of Thyme Essential Oil

The antibacterial properties of TEO were studied using the agar diffusion method as reported by [20]. Initially, the plates were seeded with 0.1 mL of inoculum by swab containing approximately 105 CFU/mL of the indicated bacteria. Then, an agar well (with 5 mm diameter) was created with a sterile core bore on the agar. Lastly, thirty µL of TEO was poured into the well. The plates were incubated at 37 °C for 24 h in an incubation chamber. The diameter of the resulting zone of inhibition was measured in mm.

2.3. Preparation of SPS/Clay-TEO Solution

The SPS/clay-TEO solution was prepared according to the previously described method with a slight modification [11]. An aqueous solution of SPS was prepared by dissolving 50 g of SPS in 1000 mL dH2O, moderately stirred at room temperature, and then heated to 80 °C for 30 min. After gelatinization, glycerol (Glycerol, Fisher Scientific, G33-1, Fair Lawn, New Jersey) was added as a plasticizer at a concentration of 30% (w/w, on dry basis of the weight of starch) and the resulting dispersion was subjected to further mixing for 5 min. MMT (Montmorillinite, Nanomer, St. Louis, MO, USA) powder (3% w/w of SPS) was separately dispersed into 60 mL of distilled water under magnetic stirring at 500 rpm for 48 h. Then, the resulting dispersion was added to the SPS-glycerol suspension solution and the mixture underwent high shear lab mixing at 5000 rpm for 10 min. Finally, the thyme essential oil (Thymus Vulgaris, New Direction Aromatics, Mississauga, ON, Canada), previously mixed with Tween 80 (Fisher Scientific, Fair Lawn, NJ, USA) (0.25 g/g of essential oil) to help create a uniform and stable distribution, was incorporated into the film forming solution at several concentrations (0, 2, 4, and 6% v/v on the basis of neat film solution). Samples were then homogenized at 20,000 rpm for 5 min using a laboratory homogenizer (Homogenizer, OMNI International, Kenneswa, GA, USA), after being degassed using an ultrasonic bath (Branson sonifier, Model 3800, Danbury, CT, USA).

2.4. Preparation of Nanocomposite Films

The films were developed by means of a casting process in which the dispersion solution (60 mL) was spread over a Teflon plate and then dried for 24 h at 23 ± 2 °C and 50 ± 5% relative humidity (RH). The dried films were peeled off the plates and stored in a desiccator containing a saturated magnesium nitrate solution at 25 °C and 52% RH until use. All films consisted of the same amounts of distilled water, SPS, MMT, and glycerol, but different proportions of TEO. One treatment without TEO and one treatment without TEO and MMT were considered as the control.

2.5. Antibacterial Activity of the Film

The antimicrobial test was carried out according to the method developed by [21]. An agar diffusion assay was used to determine the antibacterial activity of the SPS nanocomposite film. Mueller-Hinton agar (MHA) medium (Remel, Lenexa, KS, USA) was used to ensure better antimicrobial disk diffusion. Each culture of E. coli and S. Typhimurium was streaked onto an MHA medium. Circular discs (5 mm diameter) were cut from the nanocomposite films containing 0, 2, 4, and 6% (v/v) TEO. One circular disc obtained from each film was placed on top of the MHA medium inoculated with pathogenic bacteria, and the plates were incubated at 37 °C for 24 h. The film without TEO was used as a control. After incubation, the plates were examined to find the zone of inhibition of the film discs. The diameters of the inhibition zones were measured by subtracting the diameter of the entire inhibition zone (mm) from the diameter of the disc.

2.6. Antimicrobial Effects of Films on Inoculated Baby Spinach Leaves During Refrigerated Storage

2.6.1. Baby Spinach Leaves Preparation

Baby spinach leaves were purchased from a local grocery store one day before testing. Spinach leaves were surface sterilized by immersion in 70% methanol for 30 s, rinsed in sterile distilled water, and allowed to air-dry. Sterilized leaves were inoculated by pipetting 100 µL of ~105 CFU/mL bacterial suspension on to the surface of each leaf. The inoculated leaves were then held under a laminar flow biological hood at room temperature for 1 h to allow inoculum drying and attachment before further treatment [22]. After drying, the baby spinach leaves were wrapped with the film and stored at 4 °C for eight days. The populations of E. coli K-12 and S. Typhimurium bacteria in the samples were determined immediately following inoculation and periodically at two-day intervals during the storage period. All tests were done in triplicate.

2.6.2. Microbiological Analysis of Spinach Samples

Two controls were used: (1) An uninoculated, un-sterilized, and unwrapped control, to determine the background microflora (total viable count, yeast, and molds); and (2) An inoculated and unwrapped control for comparison with inoculated and wrapped spinach samples. Baby spinach samples (25 g each) in bio-nanocomposite films were aseptically placed in polyethylene stomacher bags (PE bags, Fisher Scientific Co., Fair Lawn, NJ, USA) and macerated with 225 mL of 0.1% (w/v) peptone water for 2 min. The macerated samples were filtered through sterile glass wool, serially diluted in peptone water, and surface plated onto the MHA medium. Plates were incubated at 35 °C for 24 to 48 h, and colonies of E. coli K-12 and S. Typhimurium were counted.

2.7. Sensory Evaluation of Baby Spinach Leaves

A sensory panel employed to test the acceptability of the uninoculated baby spinach leaves wrapped in nanocomposite films was conducted by a group of untrained panelists. The following sensory parameters were investigated: (a) odor, (b) color, and (c) overall acceptability. The descriptions for each score were as follows; 9 = like extremely or extremely high, 8 = like very much or very high, 7 = like moderately or high, 6 = like slightly or lightly high, 5 = neither like or dislike or neither high or low, 4 = dislike slightly or slightly low, 3 = dislike moderately or low, 2 = dislike very much or very low, and 1 = dislike extremely or extremely low. Testing was carried out in a sensory analysis laboratory with appropriate lighting conditions and a temperature of around 20 °C. The study was approved by the Institutional Review boards (IRB) at NC A&T State University.

2.8. Statistical Analysis

The data were presented as the mean ± standard deviation of each treatment. All samples were run in triplicate. The experiments were factorial with a completely randomized design using a two- way analysis of variance (ANOVA) using the SAS program (version 8.1; 2002, Statistical Analysis System Institute Inc., Cary, NC, USA). Differences between the mean values were compared using Tukey’s range test and a probability value of p < 0.05 was considered significant.

3. Results

3.1. Antimicrobial Activity of the Pure Thyme Essential Oil

The antimicrobial activity of pure thyme (Thymus vulgaris) essential oil (TEO) against the selected microorganisms, using the agar well diffusion test, is presented in Figure 1. The results indicated that both E. coli and S. Typhimurium were sensitive to TEO. TEO inhibited the growth of bacterial strains by producing inhibition zone diameters of 15 mm and 10 mm for E. coli and S. Typhimurium respectively.

3.2. Antimicrobial Activity of Films

The antimicrobial activities of SPS-based films are shown in Table 1 and Figure 2, Figure 3, Figure 4, Figure 5 and Figure 6. When antimicrobial agents are incorporated into food packaging films, these materials diffuse through the agar gel and this results in a clear zone around the film cuts. Our result indicated that a neat SPS film has no antibacterial properties. Additionally, MMT nanoclay did not exhibit any antibacterial activities in the agar diffusion test.
The incorporation of TEO in the bio-nanocomposite films at levels higher than 2% (v/v) exhibited a clear inhibitory zone, as evidenced by the absence of bacterial growth around the film cuts. The highest concentration of TEO (6%) resulted in the maximum bacterial growth inhibition.

3.3. The Effect of Films on Total Viable Count, Yeast and Mold Growth of Baby Spinach Leaves

Table 2 shows the changes in the total viable count (TVC), and yeast and mold counts of baby spinach leaves either unwrapped or wrapped with films containing 0, 2.0, 4.0, and 6.0% TEO over eight days of refrigerated storage. The initial number of TVC in baby spinach samples was 2.80 log CFU/g, which is an indication of the high quality of spinach used in this study. According to the literature, the bacterial counts of bagged cut spinach are around 7.0 log CFU/g, with a broad range of <4 to 8.3 log CFU/g [23]. Table 2 shows that the TVC and yeast/mold of all un-wrapped samples increased with storage time. The baby spinach samples wrapped in neat SPS films without TEO showed a decrease in bacterial, yeast, and mold populations. Films containing 2% TEO showed a lower number of microorganisms compared to the control samples after storage at 4 °C for two and eight days. However, when baby spinach samples were wrapped in films with 4 and 6% TEO, no bacterial or yeast and mold growth was detected during the storage period.

3.4. The Antibacterial Effect of the Films on Baby Spinach Leaves Inoculated with E. coli and S. Typhimurium

The microbiological changes in baby spinach leaves stored at 4 °C are shown in Table 3. The initial population of E. coli and Salmonella in unwrapped baby spinach leaves increased substantially from the initial inoculation level of 2.9 to 4.8 and 2.3 to 6.8 log CFU/g, respectively, by the end of the experiment. The bacterial population of samples wrapped in the SPS-based nanocomposite with TEO either decreased or was not detectable by the end of the storage period. TEO was shown to be very effective at controlling the growth of Salmonella and E. coli in the highest concentration of TEO (6%), and a total inhibition of pathogen growth occurred during the storage period. In the presence of 4% TEO, a complete inhibition of microbial growth was observed during the entire time of storage, and this film reduced the population of E. coli and Salmonella by more than 4.5 log CFU/g compared to the control. Consequently, the nanocomposite containing TEO increased the shelf-life of the spinach leaves by about eight days as compared to the control.

3.5. Sensory Evaluation of Baby Spinach Leaves

A sensory evaluation (color, odor, and overall appearance) of the samples of wrapped spinach leaves was investigated in this study. The results for the sensory evaluation of baby spinach leaves wrapped in nanocomposite films at different days during the storage period are presented in Table 4. There was no significant difference in the overall appearance between the wrapped and unwrapped samples (p > 0.05). However, the overall appearance of wrapped samples with nanocomposite films incorporated with different concentrations of TEO was rated slightly higher than that of unwrapped samples. Samples wrapped with the highest TEO concentration (6%) had numerically higher appearance values compared to the control samples. With regard to odor and color, no significant differences (p > 0.05) were observed between wrapped samples and control samples. In general, wrapped samples had a better odor, color, and appearance than unwrapped samples, which could probably be attributed to the aromatic effect of thyme essential oil.

4. Discussion

4.1. Antimicrobial Activity of Pure Thyme Essential Oil

Various studies have shown variations in the antimicrobial properties of plant essential oils. These variations might be explained by the differences in the susceptibility of testing conditions, the culture media chosen for microbial growth, and the selected microorganisms chosen for the evaluation [24]. Additionally, there is a relationship between the chemical composition of the most abundant compounds in essential oil and the resultant antimicrobial activity. The major constituents of the T. vulgaris oil used in this study were thymol (57.7%), p-cymene (18.7%), and carvacrol (2.8%). Researchers [25] tested different species of thyme essential oil and determined that a greater efficacy was achieved when essential oils from T. hyemalis, followed by T. zygis and T. vulgaris, were used. This could be due to the fact that most of the antimicrobial activity in essential oils from the genus Thymus appears to be associated with phenolic compounds (thymol and carvacrol), since the contents of thymol and carvacrol in T. zygis and T. hyemalis were higher than those of T. vulgaris. This result agrees with those reported by other authors [26,27,28].

4.2. Antimicrobial Activity of the Films

The neat SPS film did not exhibit any antibacterial properties. These results correlate with the results of one similar study [11]. This effect may be related to the fact that SPS does not diffuse through the adjacent agar media in the agar diffusion test method; as a result, only microorganisms in direct contact with the active sites of SPS are inhibited. Additionally, MMT did not show antibacterial activity in the agar diffusion test and this result is in agreement with that of researchers [29] who tested MMT nanoclay in the well. They reported that MMT did not show any antibacterial activities.
Others [21] reported that the use of 2% thyme essential oil in a whey protein isolate film was the minimum inhibitory level against Staphylococcus aureus, Salmonella enteritidis, Listeria monocytogenes, Lactobacillus plantarum, and Escherichia coli O157:H7. This correlates with the results in our study. As previously discussed, the antimicrobial activity of thyme has been attributed to its essential oils, which contain the terpenes: carvacrol and thymol. According to a review [19], carvacrol and thymol break down the outer membrane of microorganisms, which leads to an excessive leakage of essential elements causing bacterial death. In general, in gram-negative bacteria, the outer membrane constitutes the outer surface of the cell wall, leading to a decrease in the effectiveness of antimicrobial agents. In addition, the effect of TEO refers to its ability to increase the permeability of the outer membrane of the cell, leading to a release of lipopolysaccharides and an increase in ATP loss [30].
In addition to the film preparation method, the source and concentration of active components of plant essential oils and basic film material have a crucial effect on the antimicrobial activity of films. The release of antimicrobial agents from the films is also dependent on many factors, including electrostatic interactions between the antimicrobial agent and the polymer chains, osmosis, structural changes induced by the presence of the antimicrobial, and environmental conditions [31].
In general, films containing TEO are very hydrophilic; thus, they absorb water quickly, which results in swelling. As a result, the active components in these films migrate very fast. As the concentration of essential oil increases, the zone of inhibition also increases. The largest inhibition zones were observed when 6% (v/v) of TEO was incorporated into the film. Of the bacteria examined, Salmonella showed a higher resistance, while E. coli was more sensitive to TEO containing films with an inhibition zone of 10 mm. These results correlate with the results of other studies [32,33], which indicated that the antibacterial effect of essential oils depended on the concentration of essential oil.

4.3. The Effect of Films on Total Viable Count, Yeast and Mold Growth of Baby Spinach Leaves

The baby spinach samples wrapped in neat SPS films without TEO showed a decrease in bacterial, yeast, and mold populations. This might be due to the superior oxygen barrier properties of starch-based films, which limit the growth of aerobic bacteria on samples wrapped in films [11]. Films containing 2% TEO showed a lower number of microorganisms compared to the control samples after storage at 4 °C for two and eight days. However, when the baby spinach samples were wrapped in films with 4 and 6% TEO, no bacterial or yeast and mold growth was detected over the storage period. This indicates that TEO incorporated in SPS nanocomposite films can strongly inhibit the growth of the microorganisms. Researchers [34] reported a reduction in the initial total viable counts of Asian sea bass samples with the addition of 0.05% of oregano and/or thyme EO.

4.4. The Antibacterial Effect of Films on Baby Spinach Leaves Inoculated with E. coli and S. Typhimurim

The bacterial population of samples wrapped in the SPS-based nanocomposite with TEO either decreased or was undetectable by the end of the storage period. Similar results were obtained by others [29], who studied the effect of a bionanocomposite from chitosan and rosemary essential oil on sliver carp fillets. As previously discussed, the antimicrobial activity of thyme has been attributed to its EOs, which contain terpenes: carvacrol (2-methyl-5-(1-methylethyl) phenol) and thymol (5-methyl-2-(1-methylethyl) phenol), respectively. The antimicrobial activity of cinnamon, oregano, and thyme EOs against various Gram-negative bacteria (E. coli, Y. enterocolitica, P. aeruginosa, and Sal. choleraesuis), Gram-positive bacteria (L. monocytogenes, Staph. aureus, B. cereus, and E. faecalis), yeasts (C. albicans), and molds (A. flavus, P. islandicum) has been reported [33]. TEO was shown to be particularly effective against all bacteria during incubation. By comparison, the results of our study indicated that when TEO was incorporated into the film matrix, the antimicrobial activity of TEO was maintained, but exhibited less antibacterial activity in films in comparison with pure essential oil. This result might be the due to the lower amount of EO in the film solution in comparison with the well test for pure EO, as well as the partial loss of volatile compounds during film preparation [34]. Essential oils contain around 85–99% volatile and 1–15% non-volatile components [35].
It is notable that, as the storage time increased, the film effectiveness increased. As shown in Table 3, in all pathogens, growth was reduced by the end of the storage period. As previously discussed, the antibacterial activities of films are determined in part by the release rate of antibacterial agents. If the release is too slow, the microbial growth is not inhibited sufficiently; conversely, if the release is too fast, inhibition will not be sustained [14]. This effect could be due to the contribution of MMT nanoclay, which has the potential to control the release of antimicrobial agents in film materials.

4.5. Sensory Evaluation of Baby Spinach Leaves

A sensory evaluation consists of a set of techniques for the accurate measurement of human reaction to the odor, texture, and flavor of foods [36]. A sensory evaluation can provide useful information to product developers and food scientists about their products’ sensory appeal to consumers [37]. In general, wrapped samples had a better odor, color, and appearance than unwrapped samples, which was probably due to the aromatic effect of thyme essential oil.

5. Conclusions

A combination of sweet potato starch, MMT nanoclay, and thyme essential oil (TEO) was used to develop an active biodegradable nanocomposite film for food packaging. The extent to which this film enhanced the shelf life of baby spinach leaves stored at a refrigerated temperature during eight days was studied. The results confirmed that films containing TEO could effectively improve the acceptability of samples by around eight days compared with the control. Moreover, the film had no adverse effects on the sensory properties of the product. Consumer preferences were greater for films with higher TEO concentrations due to the more desirable odor, color, and overall acceptability of the spinach. Therefore, this study demonstrated the effectiveness of SPS/clay films containing TEO in controlling the growth of Escherichia coli and Salmonella Typhimurium and improving the microbiologcal quality of baby spinach leaves during refrigerated storage. Further studies should be directed towards underestanding how SPS-based films could impact the quality, safety and shelf-life of different fresh produce. In the near future, our group will report the results of the phyisco-mechancial aspects of SPS-based nanocomposites.

Acknowledgments

This research was funded through the National Institute for Food and Agriculture of the United States Department of Agricultural, Project No. NC.X-290-5-15-170-1, in the Agricultural Research Program, North Carolina Agricultural and Technical State University.

Author Contributions

R.T. conceived and designed the experiments. A.I. performed the experiments and analyzed the data. S.A.I. contributed materials and statistical analysis tools. R.T. and A.I. wrote the paper. All authors provided input into the interpretation of the results, contributed editorial comments, and read and approved the final manuscript.

Conflicts of Interest

The authors declare no conflict of interest. The founding sponsors had no role in the design of the study; in the collection, analyses, or interpretation of data; in the writing of the manuscript, and in the decision to publish the results.

References

  1. Su, L.J.; Arab, L. Salad and raw vegetable consumption and nutritional status in the adult US population: Results from the Third National Health and Nutrition Examination Survey. J. Am. Diet. Assoc. 2006, 106, 1394–1404. [Google Scholar] [CrossRef] [PubMed]
  2. Warriner, K.; Huber, A.; Namvar, A.; Fan, W.; Dunfield, K. Recent advances in the microbial safety of fresh fruits and vegetables. Adv. Food Nutr. Res. 2009, 57, 155–208. [Google Scholar] [PubMed]
  3. Food and Drug Administration (FDA). Guidance for Industry: Guide to Minimize Microbial Food Safety Hazards of Leafy Greens. 2009. Available online: http://www.fda.gov/Food/GuidanceComplianceRegulatoryInformation/GuidanceDocuments/ProduceandPlanProducts/ucm174200.htm#intro (accessed on 25 April 2017). [Google Scholar]
  4. Jacxsens, L.; Devlieghere, F.; Van der Steen, C.; Debevere, J. Effect of high oxygen modified atmosphere packaging on packaging on microbial growth and sensorial qualities of fresh-cut produce. Int. J. Food Microbiol. 2001, 71, 197–210. [Google Scholar] [CrossRef]
  5. Marsh, K.; Bugusu, B. Food Packaging–Roles, Materials, and Environmental Issues. J. Food Sci. 2007, 72, 39–55. [Google Scholar] [CrossRef] [PubMed]
  6. Castro-Rosas, J.; Cruz-Galvez, A.M.; Gomez-Aldapa, C.A.; Falfan-Cortes, R.N.; Guzman-Ortiz, F.A.; Rodríguez-Marín, M.L. Biopolymer films and the effects of added lipids, nanoparticles and antimicrobials on their mechanical and barrier properties: A review. Int. J. Food Sci. Technol. 2016, 51, 1967–1978. [Google Scholar] [CrossRef]
  7. Battis, F.; Pineau, F.; Popineau, Y.; Aparicio, C.; Kanny, G.; Guerin, L.; Moneret-Vautrin, D.A.; Denery-Papini, S. Food allergy to wheat: Identification of immunogloglin E and immunoglobulin G-binding proteins with sequential extracts and purified proteins from wheat flour. Clin. Exp. Allergy 2003, 33, 962–970. [Google Scholar] [CrossRef]
  8. Cordle, C.T. Soy Protein Allergy: Incidence and Relative Severity. J. Nutr. 2004, 134, 1213–1219. [Google Scholar]
  9. Bu, G.; Luo, Y.; Zheng, Z.; Zheng, H. Effect of heat treatment on the antigenicity of bovine α-lactalbumin and β-lactoglobulin in whey protein isolate. Food Agric. Immunol. 2009, 20, 195–206. [Google Scholar] [CrossRef]
  10. Bertuzzi, M.A.; Armada, M.; Gottifredi, J.C. Physicochemical characterization of starch based films. J. Food Eng. 2007, 82, 17–25. [Google Scholar] [CrossRef]
  11. Shen, X.L.; Wu, J.M.; Chen, Y.; Zhao, G. Antimicrobial and physical properties of sweet potato starch films incorporated with potassium sorbate or chitosan. Food Hydrocoll. 2010, 24, 285–290. [Google Scholar] [CrossRef]
  12. Issa, A.; Ibrahim, S.A.; Tahergorabi, R. Sweet potato starch/clay nanocomposite film: New material for emerging biodegradable food packaging. MOJ Food Process. Technol. 2016, 3, 00073. [Google Scholar] [CrossRef]
  13. McGlashan, S.A.; Halley, P.J. Preparation and characterization of biodegradable starch-based nanocomposite materials. Polym. Int. 2003, 52, 1767–1773. [Google Scholar] [CrossRef]
  14. Li, B.; Rozas, J.; Haynie, D.T. Structural stability of polypeptide nanofilms under extreme conditions. Biotechnol. Prog. 2006, 22, 111–117. [Google Scholar] [CrossRef] [PubMed]
  15. Tiwari, B.K.; Valdramidis, V.P.; Donnell, C.P.O.; Muthukumarappan, K.; Bourke, P.; Cullen, P.J. Application of Natural Antimicrobials for Food Preservation. J. Agric. Food Chem. 2009, 57, 5987–6000. [Google Scholar] [CrossRef] [PubMed]
  16. Nguyen, M. Characterization of Allergenic and Antimicrobial Properties of Chitin and Chitosan and Formulation of Chitosan-Based Edible Film for Instant Food Casing. Ph.D. Thesis, Applied Sciences, RMIT University, Melbourne, Australia, March 2012. [Google Scholar]
  17. Singh, N.; Sing, R.K.; Bhunia, A.K. Sequential disinfection of Escherichia coli O157:H7 inoculated alfalfa seeds before and during sprouting using aqueous chlorine dioxide, ozonated water, and thyme essential oil. LWT-Food Sci. Technol. 2003, 36, 235–243. [Google Scholar] [CrossRef]
  18. Bagamboula, C.F.; Uyttendaele, M.; Debevere, J. Inhibitory effect of thyme and basil essential oils, carvacrol, thymol, estragol, linalool and p-cymene towards Shigella sonnei and S. flexneri. Food Microbiol. 2004, 21, 33–42. [Google Scholar] [CrossRef]
  19. Burt, S. Essential oils: Their antibacterial properties and potential applications in foods—A review. Int. J. Food Microbiol. 2004, 94, 223–253. [Google Scholar] [CrossRef] [PubMed]
  20. Gómez-Estaca, J.; De Lacey, A.L.; López-Caballero, M.E.; Gómez-Guillén, M.C.; Montero, P. Biodegradable gelatin–chitosan films incorporated with essential oils as antimicrobial agents for fish preservation. Food Microbiol. 2010, 27, 889–896. [Google Scholar] [CrossRef] [PubMed]
  21. Seydim, A.C.; Sarikus, G. Antimicrobial activity of whey protein based edible films incorporated with oregano, rosemary and garlic essential oils. Food Res. Int. 2006, 39, 639–644. [Google Scholar] [CrossRef]
  22. Mahmoud, B.S.M.; Linton, R.H. Inactivation kinetics of inoculated Escherichia coli O157:H7 and Salmonella enterica on lettuce by chlorine dioxide gas. Food Microbiol. 2008, 25, 244–252. [Google Scholar] [CrossRef] [PubMed]
  23. Valentin-Bon, I.; Jacobson, A.; Monday, S.R.; Feng, P.C. Microbiological quality of bagged cut spinach and lettuce mixes. Appl. Environ. Microbiol. 2008, 74, 1240–1242. [Google Scholar] [CrossRef] [PubMed]
  24. Rodríguez Calleja, J.M.; Cruz-Romero, M.C.; García-López, M.L.; Kerry, J.P. Antimicrobial and antioxidant activities of commercially available essential oils and their oleoresins. J. Herb. Sci. 2015, 3, 1–16. [Google Scholar]
  25. Rota, M.C.; Herrera, A.; Martínez, R.M.; Sotomayor, J.A.; Jordán, M.J. Antimicrobial activity and chemical composition of Thymus vulgaris, Thymus zygis and Thymus hyemalis essential oils. Food Control 2008, 19, 681–687. [Google Scholar] [CrossRef]
  26. Consentino, S.; Tuberoso, C.I.G.; Pisano, B.; Satta, M.; Arzedi, E.; Palmas, F. In vitro antimicrobial activity and chemical composition of sardinian Thymus essential oils. Lett. Appl. Microbiol. 1999, 29, 130–135. [Google Scholar] [CrossRef]
  27. Davidson, P.M.; Naidu, A.S. Phyto-Phenol in Natural Food Antimicrobial Systems; Naidu, A.S, Ed.; CRC Press: Boca Raton, FL, USA, 2000; pp. 265–294. [Google Scholar]
  28. Skocibusic, M.; Bezic, N.; Dunkic, V. Phytochemical composition and antimicrobial activities of essential oils from Satureja subspicata Vis. growing in Croatia. Food Chem. 2006, 96, 20–28. [Google Scholar] [CrossRef]
  29. Abdollahi, M.; Rezaei, M.; Farzi, G. A novel active bionanocomposite film incorporating rosemary essential oil and nanoclay into chitosan. J. Food Eng. 2012, 111, 343–350. [Google Scholar] [CrossRef]
  30. Hosseini, M.H.; Razavi, S.H.; Mousavi, M.A. Antimicrobial, physical and mechanical properties of chitosan-based films incorporated with thyme, clove and cinnamon essential oils. J. Food Process. Preserv. 2009, 33, 727–743. [Google Scholar] [CrossRef]
  31. Avila-Sosa, R.; Palou, E.; Munguía, M.T.J.; Nevárez-Moorillón, G.V.; Cruz, A.R.N.; López-Malo, A. Antifungal activity by vapor contact of essential oils added to amaranth, chitosan, or starch edible films. Int. J. Food Microbiol. 2012, 153, 66–72. [Google Scholar] [CrossRef] [PubMed]
  32. Valderrama, N.; Albarracín, W.; Algecira, N. Physical and Microbiological Evaluation of Chitosan Films: Effect of Essential Oils and Storage. World Acad. Sci. Eng. Technol. Int. J. Chem. Mol. Nucl. Mater. Metall. Eng. 2015, 9, 262–269. [Google Scholar]
  33. Zivanovic, S.; Chi, S.; Draughon, A.F. Antimicrobial activity of chitosan films enriched with essential oils. J. Food Sci. 2005, 70, M45–M51. [Google Scholar] [CrossRef]
  34. Harpaz, S.; Glatman, L.; Drabkin, V.; Gelman, A. Effects of herbal essential oils used to extend the shelf life of freshwater-reared Asian sea bass fish (Lates calcarifer). J. Food Prot. 2003, 66, 410–417. [Google Scholar] [CrossRef] [PubMed]
  35. Goni, P.; López, P.; Sánchez, C.; Gómez-Lus, R.; Becerril, R.; Nerín, C. Antimicrobial activity in the vapour phase of a combination of cinnamon and clove essential oils. Food Chem. 2009, 116, 982–989. [Google Scholar] [CrossRef]
  36. Lawless, H.T.; Heymann, H. Sensory Evaluation of Food: Principles and Practices, 1st ed.; Springer: New York, NY, USA, 2010; p. 2. [Google Scholar]
  37. Meilgaard, M.; Civille, G.V.; Carr, B.T. Sensory Evaluation Techniques, 4th ed.; CRC Press: Boca Raton, FL, USA, 2007. [Google Scholar]
Figure 1. Antibacterial activity of pure thyme essential oil (TEO) against (A) Escherichia coli, (B) Salmonella Typhimurium.
Figure 1. Antibacterial activity of pure thyme essential oil (TEO) against (A) Escherichia coli, (B) Salmonella Typhimurium.
Foods 06 00043 g001
Figure 2. Antibacterial activity of the neat sweet potato starch-based films against Escherichia coli and Salmonella Typhimurium.
Figure 2. Antibacterial activity of the neat sweet potato starch-based films against Escherichia coli and Salmonella Typhimurium.
Foods 06 00043 g002
Figure 3. Antibacterial activity of sweet potato starch-based nanocomposite films with montmorillonite nanoclay and without thyme essential oil, agaisnt (A) Escherichia coli (B) Salmonella Typhimurium.
Figure 3. Antibacterial activity of sweet potato starch-based nanocomposite films with montmorillonite nanoclay and without thyme essential oil, agaisnt (A) Escherichia coli (B) Salmonella Typhimurium.
Foods 06 00043 g003
Figure 4. Antibacterial activity of sweet potato starch-based nanocomposite films with montmorillonite nanoclay and 2% (v/v) thyme essential oil against Escherichia coli and Salmonella Typhimurium.
Figure 4. Antibacterial activity of sweet potato starch-based nanocomposite films with montmorillonite nanoclay and 2% (v/v) thyme essential oil against Escherichia coli and Salmonella Typhimurium.
Foods 06 00043 g004
Figure 5. Antibacterial activity of sweet potato starch-based nanocomposite films with montmorillonite nanoclay and 4% (v/v) thyme essential oil against Escherichia coli and Salmonella Typhimurium.
Figure 5. Antibacterial activity of sweet potato starch-based nanocomposite films with montmorillonite nanoclay and 4% (v/v) thyme essential oil against Escherichia coli and Salmonella Typhimurium.
Foods 06 00043 g005
Figure 6. Antibacterial activity of sweet potato starch-based nanocomposite films with montmorillonite nanoclay and 6% (v/v) thyme essential oil against Escherichia coli and Salmonella Typhimurium.
Figure 6. Antibacterial activity of sweet potato starch-based nanocomposite films with montmorillonite nanoclay and 6% (v/v) thyme essential oil against Escherichia coli and Salmonella Typhimurium.
Foods 06 00043 g006
Table 1. Antibacterial activity of sweet potato starch-based (SPS-MMT) nanocomposites activated by thyme essential oil (TEO) at different levels against Escherichia coli and Salmonella Typhimurium.
Table 1. Antibacterial activity of sweet potato starch-based (SPS-MMT) nanocomposites activated by thyme essential oil (TEO) at different levels against Escherichia coli and Salmonella Typhimurium.
TreatmentMMT
(%)
TEO
(%)
Inhibition Zone (mm)
E. coliS. Typhymurium
10000
23000
33233
43455
536107
Table 2. Antimicrobial effect of sweet potato starch-based nanocomposites activated by thyme essential oil at different levels on the total viable count (TVC), and yeast and molds during eight days of refrigerated storage.
Table 2. Antimicrobial effect of sweet potato starch-based nanocomposites activated by thyme essential oil at different levels on the total viable count (TVC), and yeast and molds during eight days of refrigerated storage.
DayMicroorganismsUnwrappedTreatment
12345
Log Colony Forming Unit (CFU)/g
Day 2TVC2.802.502.341.001.000.69
Yeast/Mold1.701.630.5NDNDND
Day 8TVC3.002.041.00NDNDND
Yeast/Mold1.801.75NDNDNDND
TVC—Total viable count, ND—Non detectable.
Table 3. Antibacterial activity of sweet potato starch-based nanocomposites activated by thyme essential oil at different levels on innoculated baby spinach leaves with Escherichia coli and Salmonella Typhimurium during eight days of refrigerated storage.
Table 3. Antibacterial activity of sweet potato starch-based nanocomposites activated by thyme essential oil at different levels on innoculated baby spinach leaves with Escherichia coli and Salmonella Typhimurium during eight days of refrigerated storage.
TreatmentMicroorganismLog CFU/g
Day 2Day 4Day 6Day 8
1E. coliUnwrapped1.601.602.473.00
wrapped1.201.201.151.10
SalmonellaUnwrapped2.042.952.256.80
wrapped1.08NDNDND
2E. coliUnwrapped2.002.903.603.75
wrapped1.30NDNDND
SalmonellaUnwrapped1.692.602.803.00
wrapped1.601.00NDND
3E. coliUnwrapped2.071.004.004.30
wrapped1.30NDDNDN
SalmonellaUnwrapped1.301.003.003.69
wrappedDNDNDNDN
4E. coliUnwrapped2.842.903.003.00
wrappedDNDNDNDN
SalmonellaUnwrapped2.843.233.964.30
wrappedDNDNDNDN
5E. coliUnwrapped2.902.953.074.84
wrappedDNNDDNDN
SalmonellaUnwrapped2.302.474.004.90
wrappedNDNDDNDN
ND—Non detectable.
Table 4. Sensory properties of baby spinach leaves wrapped in sweet potato starch-based nanocomposites activated by thyme essential oil at different levels during eight days of refrigerated storage.
Table 4. Sensory properties of baby spinach leaves wrapped in sweet potato starch-based nanocomposites activated by thyme essential oil at different levels during eight days of refrigerated storage.
DaysUnwrappedTreatment
12345
color
18.0 ± 0.00 a8.0 ± 0.00 a8.0 ± 0.00 a9.0 ± 1.00 a8.0 ± 0.00 a8.5± 0.70 a
87.0 ± 0.01 a7.0 ± 0.03 a7.0 ± 0.82 a7.0 ± 0.96 a7.0 ± 0.5 a7.5 ± 0.58 a
Odor
17.0 ± 0.02 a7.5 ± 0.00 a7.5 ± 0.00 a8.0 ± 0.50 a8.0 ± 0.70 a8.0 ± 0.70 a
87.0 ± 0.01 a7.0 ± 0.00 a7.0 ± 0.00 a7.0 ± 0.00 a7.5 ± 0.70 a7.5 ± 0.70 a
Overall appearance
18.0 ± 0.00 a8.0 ± 0.01 a8.0 ± 0.00 a8.0 ± 0.01 a8.5 ± 0.05 a8.0 ± 0.04 a
88.0 ± 0.00 a7.0 ± 0.00 a7.0 ± 0.00 a8.0 ± 0.00 a8.0 ± 0.70 a8.5 ± 0.70 a
Data are given as mean values ± standard deviation (n = 3). Different letters within the same row indicate significant differences (Tukey’s Test, p < 0.05) between mean values.
