ISPRS Int. J. Geo-Inf. 2018, 7(11), 434; https://doi.org/10.3390/ijgi7110434

An Automatic Recognition and Positioning Method for Point Source Targets on Satellite Images

1
Zhengzhou Institute of Surveying and Mapping, Zhengzhou 450001, China
2
Faculty of Geo-Information Science and Earth Observation (ITC), University of Twente, 7514 AE Enschede, The Netherlands
*
Author to whom correspondence should be addressed.
Received: 17 September 2018 / Revised: 2 November 2018 / Accepted: 4 November 2018 / Published: 7 November 2018
Full-Text   |   PDF [2458 KB, uploaded 7 November 2018]   |

Abstract

Currently, the geometric and radiometric calibration of on-board satellite sensors utilizes different ground targets using some form of manual intervention. Point source targets provide high precision geometric and radiometric information and have the potential to become a new tool for joint geometric and radiometric calibration. In this paper, an automatic recognition and positioning method for point source target images is proposed. First, the template matching method was used to effectively reduce nonpoint source target image pixels in the satellite imagery. The point source target images were then identified using particular feature parameters. Using the template matching method, the weighted centroid method, and the Gaussian fitting method, the positions of the centroid of the point source target images were calculated. The maximum position detection error obtained using the three methods was 0.07 pixels, which is comparably better than artificial targets currently in use. The experimental results show point source targets provide high precision geometric information, which can become a suitable alternative for automatic joint geometric and radiometric calibration of spaceborne optical sensors. View Full-Text
Keywords: point source targets; automatic recognition and positioning; Point Spread Function; feature parameter; joint geometric and radiometric calibration point source targets; automatic recognition and positioning; Point Spread Function; feature parameter; joint geometric and radiometric calibration
Figures

Figure 1
