Comparative Studies of Vertebrate Platelet Glycoprotein 4 (CD36)

1. Introduction

Platelet glycoprotein 4 (CD36) (cluster of differentiation 36) (or fatty acyl translocase [FAT]; and scavenger receptor class B, member 3 [SCARB3]) is one of at least three members of the CD36-like family that is an integral membrane protein of many tissues of the body which plays a role in fatty acyl translocation and as a multiple ligand cell surface receptor of oxidized LDL lipoproteins (ox-LDL), long chain fatty acids, aged neutrophils and Plasmodium falciparum-parasitized erythrocytes (PE) which has been implicated in several diseases including insulin resistance, diabetes, atherosclerosis and malaria [1,2,3,4,5,6,7,8,9,10]. CD36 has also been reported on the outer mitochondrial membrane of skeletal muscle and serves a long chain fatty acid transport role, as well as contributing to the regulation of fatty acid oxidation by muscle mitochondria [11]. In addition, CD36 contributes to cerebrovascular oxidative stress and neurovascular dysfunction induced by amyloid-beta in Alzeheimer’s dementia [12,13] and may serve a ‘lipid-sensing’ role in the body with a broad physiological role as a lipid-receptor protein which influences eating behavior and energy balance [14]. Moreover, a specific CD36-dependent signaling pathway has been proposed for platelet activation by ox-LDL [15].

SCARB1 (also called CLA1, SRB1 and CD36L1), a second member of the CD36-like family, is a homo-oligomeric plasma membrane cell surface glycoprotein receptor for high density lipoprotein cholesterol (HDL), other phospholipid ligands and chylomicron remnants [16,17,18,19,20]. SCARB2 (also called LIMP2 (lysosomal integral membrane protein), SRB2 and CD36L2) is a third member of the CD36 family predominantly integrated within lysosomal and endosomal membranes which contributes to lysosomal membrane organization and transport functions [21,22,23,24,25].

The gene encoding CD36 (CD36 in humans; Cd36 in mice) is localized on chromosome 7 q11.2 and is encoded by 15 exons, including 12 coding exons [26,27,28,29]. Human CD36 is expressed at very high levels in various cells and tissues of the body, including platelets, monocytes/macrophages, and microvascular endothelial cells, plays important roles in atherosclerosis, inflammation, thrombosis and angiogenesis [4,6,7,30,31,32], and is upregulated in human monocytes following statin administration [33]. Studies of Cd36¯/Cd36¯ knockout mice have shown that CD36-deficiency protects against Western-type diet related cardiac dysfunction [34,35,36] and contributes to a reduction in fatty acid oxidation by muscle mitochondria [11,37]. Human clinical studies have also examined CD36 polymorphisms associated with enhanced atherosclerotic cardiovascular diseases [38,39], type II diabetes [9], oral fat perception, fat preference and obesity in African-Americans [40] and protection from malaria [41,42]. In addition, hepatic CD36 upregulation has been shown to be associated with insulin resistance, hyperinsulinaemia, and increased steatosis in patients with non-alcoholic steatohepatitis and chronic hepatitis C [43]. Reviews of the role of macrophage human CD36 in atherosclerosis have been published [7,44].

This paper reports the predicted gene structures and amino acid sequences for several vertebrate CD36 genes and proteins, the secondary structures for vertebrate CD36 proteins, several potential sites for regulating human CD36 gene expression and the structural, phylogenetic and evolutionary relationships for these genes and enzymes with those for vertebrate CD36, SCARB1 and SCARB2 gene families.

2. Results and Discussion

2.1. Alignments of Vertebrate CD36 Amino Acid Sequences

The deduced amino acid sequences for cow (Bos taurus), opossum (Monodelphis domestica), chicken (Gallus gallus), frog (Xenopus tropicalis) and zebrafish (Danio rerio) CD36 are shown in Figure 1 together with previously reported sequences for human and mouse CD36 (Table 1) [45,46]. Alignments of human with other vertebrate CD36 sequences examined were 53–100% identical, suggesting that these are products of the same family of genes, whereas comparisons of sequence identities of vertebrate CD36 proteins with human SCARB1 and SCARB2 proteins exhibited lower levels of sequence identities (30–32%), indicating that these are members of distinct CD36-like gene families (

Supplementary Table 1. CD36, SCARB1 and SCARB2 proteins: subunit MWs and percentage identities. High % identities are in bold.

CD36 Gene	Species	Subunit MW	% Identity with human	% Identity with human	% Identity with human
			SCARB1	SCARB2	CD36
Human	Homo sapiens	53,053	31	30	100
Chimpanzee	Pan troglodytes	53,064	31	30	100
Orangutan	Pongo abelii	53,039	32	30	97
Gibbon	Nomascus leucogenys	53,161	32	30	96
Rhesus	Macaca mulatta	53,041	32	31	94
Mouse	Mus musculus	52,698	30	31	83
Rat	Rattus norvegicus	52,731	31	30	86
Guinea Pig	Cavia porcellus	53,085	32	32	81
Cow	Bos taurus	52,940	32	30	82
Dog	Canis familaris	52,549	31	30	82
Pig	Sus scrofa	53,085	31	30	82
Rabbit	Oryctolagus cuniculus	52,729	31	31	88
Horse	Equus caballus	52,789	31	31	83
Elephant	Loxodonta africana	52,873	31	31	80
Opossum	Monodelphis domestica	53,017	30	30	73
Platypus	Ornithorhynchus anatinus	52,807	31	30	73
Chicken	Gallus gallus	52,624	30	32	61
Lizard	Anolis carolinensis	52,890	31	31	61
Frog	Xenopus tropicalis	52,696	30	29	55
Zebrafish	Danio rerio	51,590	31	31	53
SCARB1 Gene	Species	Subunit MW	% Identity with human	% Identity with human	% Identity with human
			SCARB1	SCARB2	CD36
Human	Homo sapiens	56,973	100	29	31
Mouse	Mus musculus	56,754	79	29	29
Chicken	Gallus gallus	55,918	57	28	31
Zebrafish	Danio rerio	55,742	51	28	30
SCARB2 Gene
Human	Homo sapiens	54,290	29	100	30
Mouse	Mus musculus	54,044	29	85	31
Chicken	Gallus gallus	53,907	30	59	33
Zebrafish	Danio rerio	60,234	31	43	33
CD36 Gene
Lancelet	Branchiostoma floridae	54,141	34	35	35
Sea squirt	Ciona intestinalis	58,009	26	33	31
Nematode	Caenorhabditis elegans	60,182	21	26	24
Fruit fly	Drosophila melanogaster	58,663	20	23	26

)

The amino acid sequences for eutherian mammalian CD36 contained 472 residues, whereas opossum (Monodelphis domestica), platypus (Ornithorhynchus anatinus) and chicken (Gallus gallus) CD36 sequences contained 471 residues, while frog (Xenopus tropicalis) and zebrafish (Danio rerio) CD36 sequences contained 470 and 465 amino acids, respectively (Table 1; Figure 1). Previous studies have reported several key regions and residues for human and mouse CD36 proteins (human CD36 amino acid residues were identified in each case). These included cytoplasmic N-terminal and C-terminal residues: residues 2-6 and 462-472; N-terminal and C-terminal trans-membrane helical regions: residues 7-28 and 440-461 [32,45]; palmitoylated cysteine residues (Cys3; Cys7; Cys464; and Cys466) in the N- and C-terminal CD36 cytoplasmic tails [47]; exoplasmic Thr92, which is phosphorylated by protein kinase C alpha and contributes to the suppression of thrombospondin-1 binding in vitro [48]; His242 which contributes to the interaction of CD36-dependent endothelial cell adherence with Plasmodium falcurum [4]; and six exoplasmic disulfide bond forming residues: Cys243, Cys272, Cys311, Cys313, Cys322 and Cys333 [49].

Table 1. CD36, SCARB1 and SCARB2 genes and proteins. RefSeq: the reference amino acid sequence; ¹predicted Ensembl amino acid sequence; na-not available; GenBank IDs are derived from NCBI http://www.ncbi.nlm.nih.gov/genbank/; Ensembl ID was derived from Ensembl genome database http://www.ensembl.org; * designates scaffold; Un refers to unknown chromosome; UNIPROT refers to UniprotKB/Swiss-Prot IDs for individual CD36-like proteins (see http://kr.expasy.org); Un-refers to unknown chromosome; bps refers to base pairs of nucleotide sequences; the number of coding exons are listed; gene expression levels are in bold.

CD36 Gene	Species	RefSeq ID ¹Ensembl/NCBI	GenBank ID	UNIPROT ID	Amino acids	Chromosome location	Coding Exons (strand)	Gene Size bps	Gene Expression Level
Human	Homo sapiens	NM_001001547	BC008406	P16671	472	7:80,275,645-80,303,732	12 (+ve)	72,231	6.6
Chimpanzee	Pan troglodytes	¹XP_519573	na	na	472	7:81,142,402-81,169,764	12 (+ve)	#27,363	na
Orangutan	Pongo abelii	¹XP_002818343	na	na	472	7:95,750,733-95,779,630	12 (-ve)	#28,898	na
Gibbon	Nomascus leucogenys	¹XP_003252221	na	na	472	*GL397261:11,570,433-11,598,114	12 (+ve)	#27,682	na
Rhesus	Macaca mulatta	NP_001028085	na	na	472	3:136,626,102-136,653,066	12 (+ve)	#27,682	na
Mouse	Mus musculus	NM_001159555.1	BC010262	Q08857	472	5:17,291,543-17,334,712	12 (-ve)	43,170	4.2
Rat	Rattus norvegicus	NP_113749	L19658	Q07969	472	4:13,472,534-13,522,334	12 (+ve)	49,801	0.3
Guinea Pig	Cavia porcellus	¹XP_003469862	na	na	472	*31:20,074,611-20,098,210	12 (+ve)	#23,600	na
Cow	Bos taurus	NM_17410	BC103112	P26201	472	4:40,585,624-40,614,621	12 (-ve)	#28,998	na
Dog	Canis familaris	NM_001177734	ADE58431	na	472	18:23,334,171-23,360,045	12 (+ve)	#25,875	na
Pig	Sus scrofa	NP_001038087	AK400585	Q3HUX1	472	9:93,204,848-93,241,842	12 (-ve)	#36,995	na
Rabbit	Oryctolagus cuniculus	¹XP_002712062	na	na	472	7:35,303,111-35,333,630	12 (-ve)	#30,520	na
Horse	Equus caballus	¹XP_001487957	na	na	472	4:6730,96-698,607	12 (-ve)	#25,512	na
Elephant	Loxodonta africana	¹XP_003407226	na	na	472	5: 69,036,730-69,073,879	12 (-ve)	#37,150	na
Opossum	Monodelphis domestica	¹XP_001364375	na	na	471	8:149,041,138-149,075,533	12 (-ve)	#34,396	na
Platypus	Ornithorhynchus anatinus	¹XP_001506583	na	na	471	*Ultra5:3,505,963-3,536,963	12 (-ve)	#31,001	na
Chicken	Gallus gallus	¹ENSGALG8439	AJ719746	F1NER9	471	1:12,077,308-12,107,415	12 (-ve)	30,108	na
Lizard	Anolis carolinensis	¹XP_003221568	na	na	472	5:93,087,943-93,120,933	12 (-ve)	#32,991	na
Frog	Xenopus tropicalis	NP_001107151	na	na	470	*GL172681:663,550-679,762	12 (-ve)	#16,213	na
Zebrafish	Danio rerio	NP_001002363.1	BC076048	Q6DHC7	465	4:21,594,449-21,606,961	12 (-ve)	12,513	na
SCARB1 Gene	Species	RefSeq ID ¹Ensembl/NCBI	GenBank ID	UNIPROT ID	Amino acids	Chromosome location	Coding Exons (strand)	Gene Size bps	Gene Expression Level
Human	Homo sapiens	NM_00505	BC022087	Q8WVT0	509	12:125,267,232-125,348,266	12 (-ve)	81,035	13.7
Mouse	Mus musculus	NM_001205082.1	BC004656	Q61009	509	5:125,761,478-125,821,252	12 (-ve)	63,985	5.1
Chicken	Gallus gallus	¹XP_415106	na	na	503	15:4,543,054-4,558,954	12 (+ve)	15,901	na
Zebrafish	Danio rerio	NM_198121	BC044516	E7FB50	496	11:21,526,513-21,572,478	12 (-ve)	45,684	na
SCARB2 Gene
Human	Homo sapiens	NM_005506	BT006939	Q53Y63	478	4:77,084,378-77,134,696	12 (-ve)	50,316	3.2
Mouse	Mus musculus	NM_007644	BC029073	O35114	478	5:92,875,330-92,934,334	12 (-ve)	59,005	3.6
Chicken	Gallus gallus	¹XP_42093.1	BX931548	na	481	4:51,411,268-51,429,620	12 (+ve)	18,353	na
Zebrafish	Danio rerio	NM_173259.1	BC162407	Q8JQR8	531	5: 63,942,096-63,955,449	13 (+ve)	13,354	na
CD36 Gene
Lancelet	Branchiostoma floridae	¹XP_002609178.1	na	na	480	Un:534,334,234-534,343,082	12 (+ve)	8,849	na
Sea squirt	Ciona intestinalis	¹XP_002127015.1	na	na	523	09p:2,872,362-2,873,903	1 (-ve)	1,542	na
Nematode	Caenorhabditis elegans	NM_067224	na	Q9XTT3	534	III:12,453,609-12,456,726	8 (+ve)	3,118	4.6
Fruit fly	Drosophila melanogaster	NP_523859	na	na	520	2R:20,864,606-20,867,116	6 (-ve)	#2,511	na

Table 1. CD36, SCARB1 and SCARB2 genes and proteins. RefSeq: the reference amino acid sequence; ¹predicted Ensembl amino acid sequence; na-not available; GenBank IDs are derived from NCBI http://www.ncbi.nlm.nih.gov/genbank/; Ensembl ID was derived from Ensembl genome database http://www.ensembl.org; * designates scaffold; Un refers to unknown chromosome; UNIPROT refers to UniprotKB/Swiss-Prot IDs for individual CD36-like proteins (see http://kr.expasy.org); Un-refers to unknown chromosome; bps refers to base pairs of nucleotide sequences; the number of coding exons are listed; gene expression levels are in bold.

CD36 Gene	Species	RefSeq ID ¹Ensembl/NCBI	GenBank ID	UNIPROT ID	Amino acids	Chromosome location	Coding Exons (strand)	Gene Size bps	Gene Expression Level
Human	Homo sapiens	NM_001001547	BC008406	P16671	472	7:80,275,645-80,303,732	12 (+ve)	72,231	6.6
Chimpanzee	Pan troglodytes	¹XP_519573	na	na	472	7:81,142,402-81,169,764	12 (+ve)	#27,363	na
Orangutan	Pongo abelii	¹XP_002818343	na	na	472	7:95,750,733-95,779,630	12 (-ve)	#28,898	na
Gibbon	Nomascus leucogenys	¹XP_003252221	na	na	472	*GL397261:11,570,433-11,598,114	12 (+ve)	#27,682	na
Rhesus	Macaca mulatta	NP_001028085	na	na	472	3:136,626,102-136,653,066	12 (+ve)	#27,682	na
Mouse	Mus musculus	NM_001159555.1	BC010262	Q08857	472	5:17,291,543-17,334,712	12 (-ve)	43,170	4.2
Rat	Rattus norvegicus	NP_113749	L19658	Q07969	472	4:13,472,534-13,522,334	12 (+ve)	49,801	0.3
Guinea Pig	Cavia porcellus	¹XP_003469862	na	na	472	*31:20,074,611-20,098,210	12 (+ve)	#23,600	na
Cow	Bos taurus	NM_17410	BC103112	P26201	472	4:40,585,624-40,614,621	12 (-ve)	#28,998	na
Dog	Canis familaris	NM_001177734	ADE58431	na	472	18:23,334,171-23,360,045	12 (+ve)	#25,875	na
Pig	Sus scrofa	NP_001038087	AK400585	Q3HUX1	472	9:93,204,848-93,241,842	12 (-ve)	#36,995	na
Rabbit	Oryctolagus cuniculus	¹XP_002712062	na	na	472	7:35,303,111-35,333,630	12 (-ve)	#30,520	na
Horse	Equus caballus	¹XP_001487957	na	na	472	4:6730,96-698,607	12 (-ve)	#25,512	na
Elephant	Loxodonta africana	¹XP_003407226	na	na	472	5: 69,036,730-69,073,879	12 (-ve)	#37,150	na
Opossum	Monodelphis domestica	¹XP_001364375	na	na	471	8:149,041,138-149,075,533	12 (-ve)	#34,396	na
Platypus	Ornithorhynchus anatinus	¹XP_001506583	na	na	471	*Ultra5:3,505,963-3,536,963	12 (-ve)	#31,001	na
Chicken	Gallus gallus	¹ENSGALG8439	AJ719746	F1NER9	471	1:12,077,308-12,107,415	12 (-ve)	30,108	na
Lizard	Anolis carolinensis	¹XP_003221568	na	na	472	5:93,087,943-93,120,933	12 (-ve)	#32,991	na
Frog	Xenopus tropicalis	NP_001107151	na	na	470	*GL172681:663,550-679,762	12 (-ve)	#16,213	na
Zebrafish	Danio rerio	NP_001002363.1	BC076048	Q6DHC7	465	4:21,594,449-21,606,961	12 (-ve)	12,513	na
SCARB1 Gene	Species	RefSeq ID ¹Ensembl/NCBI	GenBank ID	UNIPROT ID	Amino acids	Chromosome location	Coding Exons (strand)	Gene Size bps	Gene Expression Level
Human	Homo sapiens	NM_00505	BC022087	Q8WVT0	509	12:125,267,232-125,348,266	12 (-ve)	81,035	13.7
Mouse	Mus musculus	NM_001205082.1	BC004656	Q61009	509	5:125,761,478-125,821,252	12 (-ve)	63,985	5.1
Chicken	Gallus gallus	¹XP_415106	na	na	503	15:4,543,054-4,558,954	12 (+ve)	15,901	na
Zebrafish	Danio rerio	NM_198121	BC044516	E7FB50	496	11:21,526,513-21,572,478	12 (-ve)	45,684	na
SCARB2 Gene
Human	Homo sapiens	NM_005506	BT006939	Q53Y63	478	4:77,084,378-77,134,696	12 (-ve)	50,316	3.2
Mouse	Mus musculus	NM_007644	BC029073	O35114	478	5:92,875,330-92,934,334	12 (-ve)	59,005	3.6
Chicken	Gallus gallus	¹XP_42093.1	BX931548	na	481	4:51,411,268-51,429,620	12 (+ve)	18,353	na
Zebrafish	Danio rerio	NM_173259.1	BC162407	Q8JQR8	531	5: 63,942,096-63,955,449	13 (+ve)	13,354	na
CD36 Gene
Lancelet	Branchiostoma floridae	¹XP_002609178.1	na	na	480	Un:534,334,234-534,343,082	12 (+ve)	8,849	na
Sea squirt	Ciona intestinalis	¹XP_002127015.1	na	na	523	09p:2,872,362-2,873,903	1 (-ve)	1,542	na
Nematode	Caenorhabditis elegans	NM_067224	na	Q9XTT3	534	III:12,453,609-12,456,726	8 (+ve)	3,118	4.6
Fruit fly	Drosophila melanogaster	NP_523859	na	na	520	2R:20,864,606-20,867,116	6 (-ve)	#2,511	na

Figure 1. Amino Acid Sequence Alignments for Vertebrate CD36 Sequences. See Table 1 for sources of CD36 sequences; Hu-human; Mo-mouse; Co-cow; Op-opossum; Ch-chicken; Fr-frog; Zf-zebrafish; * shows identical residues for CD36 subunits; : similar alternate residues; . dissimilar alternate residues; predicted cytoplasmic residues are shown in ; predicted transmembrane residues are shown in ; N-glycosylated and potential N-glycosylated Asn sites are in ; exoplasmic Thr92, which is phosphorylated by pyruvate kinase alpha, is shown in ; predicted disulfide bond Cys residues are shown in ; predicted α-helices for vertebrate CD36 are in and numbered in sequence from the start of the predicted exoplasmic domain; predicted β-sheets are in and also numbered in sequence; bold underlined font shows residues corresponding to known or predicted exon start sites; exon numbers refer to human CD36 gene exons; residues refer to conserved glycines in the N- and C-terminal oligomerisation domains of the trans-membrane sequence [49]; CD36 binding domains are identified: THP-refers to binding region for low-density lipoproteins [6,7,8]; neutrophil phagocytosis domain designated by [3,7]; PE binding refers to cytoadherence region of Plasmodium falciparum-parasitized erythrocytes (PE) to endothelial cells [4].

Figure 1. Amino Acid Sequence Alignments for Vertebrate CD36 Sequences. See Table 1 for sources of CD36 sequences; Hu-human; Mo-mouse; Co-cow; Op-opossum; Ch-chicken; Fr-frog; Zf-zebrafish; * shows identical residues for CD36 subunits; : similar alternate residues; . dissimilar alternate residues; predicted cytoplasmic residues are shown in ; predicted transmembrane residues are shown in ; N-glycosylated and potential N-glycosylated Asn sites are in ; exoplasmic Thr92, which is phosphorylated by pyruvate kinase alpha, is shown in ; predicted disulfide bond Cys residues are shown in ; predicted α-helices for vertebrate CD36 are in and numbered in sequence from the start of the predicted exoplasmic domain; predicted β-sheets are in and also numbered in sequence; bold underlined font shows residues corresponding to known or predicted exon start sites; exon numbers refer to human CD36 gene exons; residues refer to conserved glycines in the N- and C-terminal oligomerisation domains of the trans-membrane sequence [49]; CD36 binding domains are identified: THP-refers to binding region for low-density lipoproteins [6,7,8]; neutrophil phagocytosis domain designated by [3,7]; PE binding refers to cytoadherence region of Plasmodium falciparum-parasitized erythrocytes (PE) to endothelial cells [4].

2.2. Comparative Sequences for Vertebrate CD36 N-Glycosylation Sites

Ten exoplasmic N-glycosylation sites for human CD36 have been previously identified for this protein (Figure 1; Table 2) [50]. One of these sites (site 2) contained a proline residue at the second position and may not function as an N-glycosylation site due to proline-induced inaccessibility [51]. Eight of these sites were predominantly retained among the 19 vertebrate CD36 sequences examined (sites 4, 5, 10, 15, 19, 23 and 25) (Figure 1; Table 2). The sequence conservation observed for these residues among the vertebrate CD36 sequences examined suggests that they contribute significantly to the structure and function of vertebrate CD36 as a glycoprotein. The multiple N-glycosylation sites observed for vertebrate CD36 sequences suggest a role for N-proteoglycan residues exposed on the external surface of plasma membranes in the performance of CD36 functions in binding various lipid molecules, including long chain fatty acids. This is also supported by recent animal model studies examining the impacts of reduced N-glycosylation upon cardiac long chain fatty metabolism, which demonstrated a key role for N-glycosylation in the recruitment of CD36 into cardiac membranes [52].

2.3. Conserved Glycines in the N-Terminal Domain of the CD36 Trans-Membrane Sequence

The N-terminal region for vertebrate CD36 sequences (residues 1-29 for human CD36) contained cytoplasmic (residues 2-7) and trans-membrane (residues 8-29) motifs which underwent changes in amino acid sequence but retained predicted cytoplasmic and trans-membrane properties in each case, respectively (Figure 1). Vertebrate N-terminal trans-membrane sequences, in particular, were predominantly conserved, especially for CD36 Gly12, Gly16 and Gly24/Gly25 residues, which were observed among the vertebrate CD36 sequences examined (Figure 1). Site directed mutagenesis studies of the related human SCARB1 sequence have demonstrated key roles for N-terminus trans-membrane sequence glycine residues, by facilitating oligomerisation and selective lipid uptake by SCARB1 conserved glycine residues [53] and similar roles may apply to the conserved C-terminal domain CD36 glycine residues. A recent report has shown, however, that CD36 is capable of binding acetylated and oxidized low-density lipoproteins as a monomer, even though multiple homo- and hetero-protein interactions are formed in the plasma membrane [8]. A conserved glycine residue was also observed for the vertebrate C-terminal trans-membrane sequences (human CD36 Gly452) (Figure 1), however the role for this residue has not been investigated.

Table 2. Predicted N-glycosylation sites for CD36 sequences. Numbers refer to amino acids in the acid sequences, including N-asparagine; K-lysine; I-isoleucine; H-histidine; S-serine; T-threonine; Q-glutamine; D-aspartate; Y-tyrosine; and V-valine. Note that there are 25 potential sites identified for vertebrate CD36 and other CD36-like sequences, including 10 sites for human CD36 (see [49]). N-glycosylation sites were identified using the NetNGlyc 1.0 web server (http://www.cbs.dtu.dk/services/NetNGlyc/). Higher probability N-glycosylation sites are in bold.

Vertebrate	Species	Site 1	Site 2*	Site 3	Site 4	Site 5	Site 6	Site 7	Site 8	Site 9	Site 10	Site 11	Site12	Site 13
CD36
Human	Homo sapiens				79NSSN	102NVTQ					134NFTV	163NKSK
Chimp	Pan troglodytes				79NSSN	102NVTQ					134NFTV	163NKSK
Orangutan	Pongo abelii				79NSSN	102NVTQ					134NFTV	163NKSK
Gibbon	Nomascus leucogenys				79NSSN	102NVTQ					134NFTV	163NKSK
Rhesus	Macaca mulatta				79NSSN	102NITQ					134NFTV	163NKSK
Marmoset	Callithrix jacchus				79NSSN	102NVTQ					134NFTV
Mouse	Mus musculus				79NSSK	102NITQ					134NFTV
Rat	Rattus norvegicus				79NSSK	102NITQ					134NFTV
Guinea Pig	Cavia porcellus				79NSSN	102NVTQ					132NDTF			172NRTL
Cow	Bos taurus				79NSSK	102NITQ								172NRTL
Horse	Equus caballus				79NSSK	102NITH	109NHTV				134NDTF
Dog	Canis familaris				79NSSK	102NITH								172NRTV
Pig	Sus scrofa				79NSSV	102NITQ					132NDTF
Rabbit	Oryctolagus cuniculus				79NSSN	102NVTQ					132NDTF
Elephant	Loxodonta africana				79NSSN	102NITQ					132NDTF
Panda	Ailuropoda melanoleuca				79NSSA	102NITH					132NDTL
Opossum	Monodelphis domestica				79NSTK	102NLTQ					131NDSF
Platypus	Ornithorhynchus anatinus				79NNSK	102NITK
Chicken	Gallus gallus	46NGTI	72NPSD			102NITE	108NGTI				131NDTI			171NRTV
Zebra finch	Taeniopygia guttata	46NGGT	72NPSE			102NVTE	108NGTI				131NDTL			171NRTV
Lizard	Anolis carolensis	46NGTI			79NGSQ	102NITH					131NDTF
Frog	Xenopus tropicalis					101NITQ	107NNTV						162NSSL
Zebrafish	Danio rerio	47NGTL				103NITF	109NNTV							168NRTV
Tetraodon	Tetraodon nigroviridis				77NGTT	100NVTY	105NDST						162NSSL
Sea squirt	Ciona intestinalis			74NVTN			120NKTY		143NGSE
Lancelet	Branchiostoma floridae					100NITF	106NGTV	122NMSF		129NDTF
Fruit fly	Drosophila melanogaster			80NVTN	90NGSK		118NGTL
Vertebrate	Species	Site 14	Site 15	Site 16	Site 17	Site 18	Site 19	Site 20	Site 21	Site 22	Site 23	Site 24	Site 25	No of
CD36														Sites
Human	Homo sapiens		205NNTA		220NISK		235NLSY		247NGTD		321NCTS		417NETG	10
Chimp	Pan troglodytes		205NNTA		220NISK		235NLSY		247NGTD		321NCTS		417NETG	10
Orangutan	Pongo abelii		205NNTA				235NLSY		247NGTD		321NCTS		417NETG	9
Gibbon	Nomascus leucogenys		205NNTA				235NLSY		247NGTD		321NCTS		417NETG	9
Rhesus	Macaca mulatta		205NNTA				235NLSY		247NGTD		321NCTS		417NETG	9
Marmoset	Callithrix jacchus		205NNTA				235NLSY		247NGTD		321NCTS		417NETG	9
Mouse	Mus musculus		205NDTV		220NISK		235NLSY		247NGTD		321NCTS		417NETG	9
Rat	Rattus norvegicus		205NNTV		220NISK		235NLSY		247NGTD		321NCTS		417NETG	9
Guinea Pig	Cavia porcellus		205NNTA		220NISK		235NLSY		247NGTD		321NCTS		417NETG	10
Cow	Bos taurus		205NNTA				235NLSY		247NGTD		321NCTS		417NETG	8
Horse	Equus caballus		205NNTV		220NISK		235NLSY		247NGTD		321NCTS		417NETG	10
Dog	Canis familaris		205NNTV		220NVSQ		235NLSY		247NGTD		321NCTS		417NETG	9
Pig	Sus scrofa		205NNTS	206NTSD			235NLSY		247NGTD		321NCTS		417NETG	9
Rabbit	Oryctolagus cuniculus		205NNTV		220NISK		235NLSY		247NGTD		321NCTS		417NETG	9
Elephant	Loxodonta africana		205NNTV				235NLSY		247NGTD		321NCTS		417NETG	8
Panda	Ailuropoda melanoleuca		208NNTA				238NLSY		250NGTD		324NCTS		420NETG	8
Opossum	Monodelphis domestica		204NNTV				234NLSF		246NGTD		320NCTS		416NETG	8
Platypus	Ornithorhynchus anatinus		204NNTA				234NLSY		246NGTD		320NCTS		416NETG	7
Chicken	Gallus gallus		204NGTS				234NLSY		246NGTD		320NCTL		416NETA	10
Zebra finch	Taeniopygia guttata		205NGTS						247NGTD		321NCTI		417NESA	9
Lizard	Anolis carolensis		205NETL				232NKSM		247NTGD		321NCTG		417NETA	9
Frog	Xenopus tropicalis		202NGTA						245NGTD		319NCTA		415NETA	7
Zebrafish	Danio rerio		194NGTV					229NDSY	237NGSD		311NCTL		406NETA	9
Tetraodon	Tetraodon nigroviridis		200NGTA					228NRTV	243NGTD		317NCTL		416NETA	9
Sea squirt	Ciona intestinalis		232NQSR			260NMSE			276NGTD	346NHTV				7
Lancelet	Branchiostoma floridae	182NDSL	211NGTD						255NGTD			333NISI	420NEST	9
Fruit fly	Drosophila melanogaster		223NGTS									347NVSL		5

Table 2. Predicted N-glycosylation sites for CD36 sequences. Numbers refer to amino acids in the acid sequences, including N-asparagine; K-lysine; I-isoleucine; H-histidine; S-serine; T-threonine; Q-glutamine; D-aspartate; Y-tyrosine; and V-valine. Note that there are 25 potential sites identified for vertebrate CD36 and other CD36-like sequences, including 10 sites for human CD36 (see [49]). N-glycosylation sites were identified using the NetNGlyc 1.0 web server (http://www.cbs.dtu.dk/services/NetNGlyc/). Higher probability N-glycosylation sites are in bold.

Vertebrate	Species	Site 1	Site 2*	Site 3	Site 4	Site 5	Site 6	Site 7	Site 8	Site 9	Site 10	Site 11	Site12	Site 13
CD36
Human	Homo sapiens				79NSSN	102NVTQ					134NFTV	163NKSK
Chimp	Pan troglodytes				79NSSN	102NVTQ					134NFTV	163NKSK
Orangutan	Pongo abelii				79NSSN	102NVTQ					134NFTV	163NKSK
Gibbon	Nomascus leucogenys				79NSSN	102NVTQ					134NFTV	163NKSK
Rhesus	Macaca mulatta				79NSSN	102NITQ					134NFTV	163NKSK
Marmoset	Callithrix jacchus				79NSSN	102NVTQ					134NFTV
Mouse	Mus musculus				79NSSK	102NITQ					134NFTV
Rat	Rattus norvegicus				79NSSK	102NITQ					134NFTV
Guinea Pig	Cavia porcellus				79NSSN	102NVTQ					132NDTF			172NRTL
Cow	Bos taurus				79NSSK	102NITQ								172NRTL
Horse	Equus caballus				79NSSK	102NITH	109NHTV				134NDTF
Dog	Canis familaris				79NSSK	102NITH								172NRTV
Pig	Sus scrofa				79NSSV	102NITQ					132NDTF
Rabbit	Oryctolagus cuniculus				79NSSN	102NVTQ					132NDTF
Elephant	Loxodonta africana				79NSSN	102NITQ					132NDTF
Panda	Ailuropoda melanoleuca				79NSSA	102NITH					132NDTL
Opossum	Monodelphis domestica				79NSTK	102NLTQ					131NDSF
Platypus	Ornithorhynchus anatinus				79NNSK	102NITK
Chicken	Gallus gallus	46NGTI	72NPSD			102NITE	108NGTI				131NDTI			171NRTV
Zebra finch	Taeniopygia guttata	46NGGT	72NPSE			102NVTE	108NGTI				131NDTL			171NRTV
Lizard	Anolis carolensis	46NGTI			79NGSQ	102NITH					131NDTF
Frog	Xenopus tropicalis					101NITQ	107NNTV						162NSSL
Zebrafish	Danio rerio	47NGTL				103NITF	109NNTV							168NRTV
Tetraodon	Tetraodon nigroviridis				77NGTT	100NVTY	105NDST						162NSSL
Sea squirt	Ciona intestinalis			74NVTN			120NKTY		143NGSE
Lancelet	Branchiostoma floridae					100NITF	106NGTV	122NMSF		129NDTF
Fruit fly	Drosophila melanogaster			80NVTN	90NGSK		118NGTL
Vertebrate	Species	Site 14	Site 15	Site 16	Site 17	Site 18	Site 19	Site 20	Site 21	Site 22	Site 23	Site 24	Site 25	No of
CD36														Sites
Human	Homo sapiens		205NNTA		220NISK		235NLSY		247NGTD		321NCTS		417NETG	10
Chimp	Pan troglodytes		205NNTA		220NISK		235NLSY		247NGTD		321NCTS		417NETG	10
Orangutan	Pongo abelii		205NNTA				235NLSY		247NGTD		321NCTS		417NETG	9
Gibbon	Nomascus leucogenys		205NNTA				235NLSY		247NGTD		321NCTS		417NETG	9
Rhesus	Macaca mulatta		205NNTA				235NLSY		247NGTD		321NCTS		417NETG	9
Marmoset	Callithrix jacchus		205NNTA				235NLSY		247NGTD		321NCTS		417NETG	9
Mouse	Mus musculus		205NDTV		220NISK		235NLSY		247NGTD		321NCTS		417NETG	9
Rat	Rattus norvegicus		205NNTV		220NISK		235NLSY		247NGTD		321NCTS		417NETG	9
Guinea Pig	Cavia porcellus		205NNTA		220NISK		235NLSY		247NGTD		321NCTS		417NETG	10
Cow	Bos taurus		205NNTA				235NLSY		247NGTD		321NCTS		417NETG	8
Horse	Equus caballus		205NNTV		220NISK		235NLSY		247NGTD		321NCTS		417NETG	10
Dog	Canis familaris		205NNTV		220NVSQ		235NLSY		247NGTD		321NCTS		417NETG	9
Pig	Sus scrofa		205NNTS	206NTSD			235NLSY		247NGTD		321NCTS		417NETG	9
Rabbit	Oryctolagus cuniculus		205NNTV		220NISK		235NLSY		247NGTD		321NCTS		417NETG	9
Elephant	Loxodonta africana		205NNTV				235NLSY		247NGTD		321NCTS		417NETG	8
Panda	Ailuropoda melanoleuca		208NNTA				238NLSY		250NGTD		324NCTS		420NETG	8
Opossum	Monodelphis domestica		204NNTV				234NLSF		246NGTD		320NCTS		416NETG	8
Platypus	Ornithorhynchus anatinus		204NNTA				234NLSY		246NGTD		320NCTS		416NETG	7
Chicken	Gallus gallus		204NGTS				234NLSY		246NGTD		320NCTL		416NETA	10
Zebra finch	Taeniopygia guttata		205NGTS						247NGTD		321NCTI		417NESA	9
Lizard	Anolis carolensis		205NETL				232NKSM		247NTGD		321NCTG		417NETA	9
Frog	Xenopus tropicalis		202NGTA						245NGTD		319NCTA		415NETA	7
Zebrafish	Danio rerio		194NGTV					229NDSY	237NGSD		311NCTL		406NETA	9
Tetraodon	Tetraodon nigroviridis		200NGTA					228NRTV	243NGTD		317NCTL		416NETA	9
Sea squirt	Ciona intestinalis		232NQSR			260NMSE			276NGTD	346NHTV				7
Lancelet	Branchiostoma floridae	182NDSL	211NGTD						255NGTD			333NISI	420NEST	9
Fruit fly	Drosophila melanogaster		223NGTS									347NVSL		5

2.4. Conserved Vertebrate CD36 Cysteine Residues

Ten cysteine residues of the vertebrate CD36 sequences were conserved, including two within each of the N- (Cys3 and Cys7) and C-terminal (Cys464 and Cys466) cytoplasmic sequences, and six within the vertebrate exoplasmic sequences (Cys243; Cys272; Cys311; Cys313; Cys322; and Cys333) (Figure 1). The CD36 N- and C-terminal conserved cytoplasmic cysteine residues have been shown to be palmitoylated [47], which may contribute to protein-protein interactions, protein trafficking and membrane localization [54]. Comparative studies of vertebrate SCARB1 sequences have shown that N- and C-terminal cytoplasmic sequences lacked any conserved cysteine residues in this region [55]. The six conserved exoplasmic vertebrate CD36 cysteine residues participate in disulfide bridge formation for bovine CD36 (Cys243-Cys311; Cys272-Cys333; and Cys313-Cys322), resulting in a 1-3, 2-6 and 4-5 arrangement of the disulfide bridges [49]. In contrast, vertebrate SCARB1 exoplasmic sequences contain only four conserved cysteine residues forming disulfide bridges (Cys281; Cys321; Cys323; and Cys334); a fifth cysteine (Cys251) was not conserved among vertebrate SCARB1 sequences [55]; and a conserved sixth cysteine (not observed in the CD36 sequence) (human SCARB1 Cys384) which functions in lipid transfer activity [56,57].

2.5. Predicted Secondary Structures for Vertebrate CD36

Predicted secondary structures for vertebrate CD36 sequences were examined (Figure 1), particularly for the exoplasmic sequences. α-Helix and β-sheet structures were similar in each case, with a α-helix extending beyond the N-terminal and C-terminal trans-membrane regions, forming α1 and α7, respectively. A consistent sequence of predicted secondary structure was observed for each of the vertebrate CD36 sequences: N-terminal cytoplasmic sequence--N-terminal transmembrane sequence--α1--β1--α2--β2--β3--β4--β5--β6--α3--β7--α4--β8--β10--β11--β12--β13--β14--β15--α5--C-terminal trans-membrane sequence--C-terminal cytoplasmic sequence. Further description of the secondary and tertiary structures for CD36 must await the determination of the three dimensional structure for this protein, particularly for the exoplasmic region which directly binds oxidized LDL lipids and a wide range of other lipid-like structures, including long chain fatty acids [1,2,3,4,5,6,7,8,9,10].

2.6. Conserved Proline, Glycine and Charged Amino Acid Residues within the CD36 Exoplasmic Domain

Supplementary Figure 1 shows the alignment of 7 vertebrate CD36 amino acid sequences for the exoplasmic domain with colors depicting the properties of individual amino acids and conservation observed for some of these protein sequences. In addition to the key vertebrate CD36 amino acids detailed previously, others were also conserved, including 17 proline residues. A human CD36 genetic deficiency of one of these conserved prolines (Pro90→Ser) confirmed the significance of this residue, which lacked platelet CD36 [56]. Human CD36 deficiency has been shown to cause systemic metabolic changes in glucose and long chain fatty acid metabolism [59]. Prolines play a major role in protein folding and protein-protein interactions, involving the cyclic pyrrolidine amino acid side chain, which may introduce turns (or kinks) in the polypeptide chain as well as having destabilizing effects on α-helix and β-strand conformations [60]. In addition, the presence of sequential prolines within a protein sequence may confer further restriction in folding conformation and create a distinctive structure, such as that reported for the mammalian Na⁺/H⁺ exchanger, which plays a major role in cation transport [61]. Sequential prolines (Pro258-Pro259) were conserved for 6 of 7 vertebrate CD36 sequences examined and these may confer a distinctive conformation in this region supporting the lipid receptor functions for this protein. Moreover, regions of water exposed proteins with high levels of proline residues are often sites for protein-protein interactions [62] and these residues may significantly contribute to the binding of lipoproteins by the exoplasmic region of CD36. Similar results have been recently reported for the vertebrate SCARB1 exoplasmic region, however in this case, 30 conserved proline residues were observed [55].

Supplementary Figure 1 also shows conservation of 14 glycine residues for vertebrate CD36 exoplasmic domains, which due to their small size, may be essential for static turns, bends or close packing in the domain, or required for conformational dynamics during long chain fatty acid receptor on-off switching, as in the case of the aspartate receptor protein [63]. Both proline and glycine residues are frequently found in turn and loop structures of proteins, and usually influence short loop formation within proteins containing between 2 and 10 amino acids [61]. Evidence for these short loop structures within vertebrate CD36 exoplasmic sequences was evident from the predicted secondary structures for vertebrate CD36 (Figure 1), with proline and/or glycine residues found at the start of the following structures: α1 (Pro28; Gly30), β1 (Gly58), α2 (Pro73), β3 (Gly89-Pro90), β8 (Gly210), β12 (Gly287) and α5 (Gly420; Gly423). Moreover, CD36 sequential proline residues (Pro255-Pro256) were located in a region with no predicted secondary structure (between β9 and β10) but with disulfide bonds, which suggests that this is a region of conformational significance for CD36.

In addition to the prolines and glycine residues for the vertebrate exoplasmic CD36 sequences, there are several conserved charged amino acid residue positions, including positively charged Lys40/Lys41 located within the first predicted exoplasmic helix (α1); Arg/Lys89, Arg95; Arg97 and Lys101 within or near the predicted strand-β3/strand β4 THP-binding domain region; Lys233/Lys235/Arg236 near the PE-binding domain; Lys263 located near the β10 strand; Arg276 within the β11 strand and adjacent to a disulphide bond; Lys288 which lies between predicted β11 and β12 strands; Lys337 and Arg/Lys340 near a disulphide bond; Lys388/Arg389 near the predicted β15 strand; and Lys401/Lys409 within the last exoplasmic helix (α5). Two domains of the exoplasmic CD36 sequence have been potentially implicated in the binding and endocytosis of apoptotic neutrophils: residues 155-183; and 93-120 (see [7]) The latter domain is called CLESH (for CD36 LIMP-II Emp [erythrocyte membrane protein] sequence homology) which is predominantly conserved, particularly near Thr92, which is phosphorylated by protein kinase C alpha and contributes to the suppression of thrombospondin-1 binding in vitro [48]. One or more of these positively charged CD36 exoplasmic regions may contribute to long chain fatty acid binding prior to the translocation of fatty acids inside the cell membrane. There are also several conserved acidic amino acid regions, particularly a sequence of three acidic amino acids (367Asp/68Asp/369Asp) near the β13 predicted strand. The conserved nature of these CD36 charged residues suggests that play key functional roles for this cell membrane protein, which may include serving as the long chain fatty acid CD36 receptor site.

2.7. Alignments of Human CD36, SCARB1 and SCARB2

The amino acid sequences for human CD36, SCARB1 and SCARB2 (see Table 1) are aligned in Figure 2. The sequences were 30-33% identical and showed similarities in several key features and residues, including cytoplasmic N-terminal and C-terminal residues; N-terminal and C-terminal trans-membrane helical regions; exoplasmic disulfide bond forming residues, previously identified for bovine CD36: Cys243-Cys311; Cys272-Cys333; and Cys313-Cys322 [47]; several predicted N-glycosylation sites for human CD36 (10 sites), SCARB1 (9 sites) and SCARB2 (9 sites), of which only two are shared between these sequences (N-glycosylation sites 15 and 21 (Table 2); and similar predicted secondary structures previously identified for SCARB1 [55] (Figure 1). The Cys384 residue, for which the free-SH group plays a major role in SCARB1-mediated lipid transport [57], was unique to SCARB1, being replaced by other residues for the corresponding CD36 and SCARB2 proteins (Phe383 and Ala379, respectively). N-terminal trans-membrane glycine residues, which play a role in the formation of SCARB1 oligomers [53], were also observed for the human CD36 sequence, with twin-glycines (Gly23-Gly24) conserved for the vertebrate CD36 sequences (Figure 1). In contrast, only one of these glycines (Gly10) was observed for the human SCARB2 sequence. These results suggest that human CD36, SCARB1 and SCARB2 proteins share several important properties, features and conserved residues, including being membrane-bound with cytoplasmic and transmembrane regions, having similar secondary structures, but being significantly different to serve distinct functions.

Alignments were also prepared for the predicted lancelet (Branchiostoma floridae) and sea squirt (Ciona intestinalis) CD36-like sequences and a major epithelial membrane protein (EMP) from fruit fly (Drosophila melanogaster) (FBpp0072309) with the human CD36, SCARB1 and SCARB2 sequences (Figure 2). The lancelet, sea squirt and fruit fly sequences examined shared many features with the CD36-like human sequences, including the N- and C-terminal cytoplasmic and transmembrane sequences; similarities in predicted secondary structures; positional identities for five conserved cysteine residues, indicating conservation of at least 2 disulfide bridges for these proteins; predicted N-glycosylation sites, including one which is shared across all 6 CD-like sequences (site 15 in Table 2); and trans-membrane glycine residues, which were observed in both the N- and C-terminal sequences.

2.8. Gene Locations and Exonic Structures for Vertebrate CD36 Genes

Table 1 summarizes the predicted locations for vertebrate CD36 genes based upon BLAT interrogations of several vertebrate genomes using the reported human CD36 sequence [45] and the predicted sequences for other vertebrate CD36 genes and the UC Santa Cruz genome browser [64]. Vertebrate CD36 genes were transcribed on either the positive strand (e.g., human, chimpanzee, gibbon, rhesus, rat and dog genomes) or the negative strand (e.g., mouse, cow, pig, opossum, chicken, frog and zebrafish genomes). Figure 1 summarizes the predicted exonic start sites for human, mouse, cow, opossum, chicken, frog and zebrafish CD36 genes with each having 12 coding exons, in identical or similar positions to those reported for the human CD36 gene [28].

Figure 2. Amino Acid Sequence Alignments for Human CD36, SCARB1, and SCARB2; and Lancelet, Sea Squirt and Fruit Fly CD36-like Sequences. See Table 1 for sources of CD36-like sequences; HuCD36-human CD36; HuSCA1-human SCARB1; HuSCA2-human SCARB2; LaCD36-lancelet CD36; SsCD36- sea squirt CD36; DmEMP1-fruit fly endothelial membrane protein; * shows identical residues for subunits; : similar alternate residues; . dissimilar alternate residues; predicted cytoplasmic residues are shown in ; predicted trans-membrane residues are shown in ; N-glycosylated and potential N-glycosylated Asn sites are shown in ; free-SH Cys involved in lipid transfer for human SCARB1 is shown in ; predicted disulfide bond Cys residues are shown in ; predicted α-helices for CD36-like sequences are in and numbered in sequence from the start of the predicted exoplasmic domain; predicted β-sheets are in and also numbered in sequence; bold underlined font shows residues corresponding to known or predicted exon start sites; exon numbers are shown; residues refer to conserved glycines in the N- and C-terminal oligomerisation domains of the trans-membrane sequence [49]; C-terminal SCARB1 residues refer to PDZ-binding domain sequences [18,19].

Figure 2. Amino Acid Sequence Alignments for Human CD36, SCARB1, and SCARB2; and Lancelet, Sea Squirt and Fruit Fly CD36-like Sequences. See Table 1 for sources of CD36-like sequences; HuCD36-human CD36; HuSCA1-human SCARB1; HuSCA2-human SCARB2; LaCD36-lancelet CD36; SsCD36- sea squirt CD36; DmEMP1-fruit fly endothelial membrane protein; * shows identical residues for subunits; : similar alternate residues; . dissimilar alternate residues; predicted cytoplasmic residues are shown in ; predicted trans-membrane residues are shown in ; N-glycosylated and potential N-glycosylated Asn sites are shown in ; free-SH Cys involved in lipid transfer for human SCARB1 is shown in ; predicted disulfide bond Cys residues are shown in ; predicted α-helices for CD36-like sequences are in and numbered in sequence from the start of the predicted exoplasmic domain; predicted β-sheets are in and also numbered in sequence; bold underlined font shows residues corresponding to known or predicted exon start sites; exon numbers are shown; residues refer to conserved glycines in the N- and C-terminal oligomerisation domains of the trans-membrane sequence [49]; C-terminal SCARB1 residues refer to PDZ-binding domain sequences [18,19].

Figure 3 shows the predicted structures of mRNAs for two major human CD36 transcripts and the major Cd36 transcripts for mouse and rat Cd36 genes [46,65,66]. The human transcripts were ~2 kbs in length with 14 (isoform c) or 15 (isoform e) introns present for these CD36 mRNA transcripts and in each case, a 3’-untranslated region (UTR) was observed. The human CD36 genome sequence contained a number of predicted transcription factor binding sites (TFBS), including the dual promoter structure of PPARA (peroxisome proliferator-activated receptor-α) and PPARG (peroxisome proliferator-activated receptor-γ) sites [67,68]. Moreover, the mouse Cd36 gene is regulated in a tissue specific manner by PPARA in liver and by PPARG in adipose tissues [69]. Other TFBS sites predicted for the human CD36 5’ promoter region included RSRFC4, a myocyte enhancer factor 2A found in muscle-specific and ‘immediate early’ genes [70]; CART1, a paired-class homeodomain transcription factor [71]; FOXJ2, a fork head transcriptional activator which is active during early development [72]; XBP1, a transcription factor which is critical for cell fate determination in response to endoplasmic reticulum stress [73]; and CDC5, a transcription activator and cell cycle regulator [74]. Hepatic upregulation of CD36 transcription in human patients has been recently shown to be significantly associated with insulin resistance, hyperinsulinaemia and increased steatosis in non-alcoholic steatohepatitis and chronic hepatitis C [43].

Figure 3. Gene Structures and Major Splicing Transcripts for the Human, Mouse and Rat CD36 Genes. Derived from the AceView website http://www.ncbi.nlm.nih.gov/IEB/Research/Acembly/ mature isoform variants are shown with capped 5’- and 3’- ends for the predicted mRNA sequences [62]; NM refers to the NCBI reference sequence; exons are in pink; the directions for transcription are shown as 5’ → 3’; sizes of mRNA sequences are shown in kilobases (kb); predicted transcription factor binding sites (TFBS) for human Cd36 are shown: CART1- a paired-class homeodomain transcription factor [71]; RSRFC4-myocyte enhancement factor 2A transcription factor [70]; XBP1-transcription factor [73]; FOXJ2-fork-head transcription factor [72]; CDC5-transcription activator and cell cycle regulator; [74]; PPARA-peroxisome proliferator-activated receptor alpha; and PPARG-peroxisome proliferator-activated receptor gamma [67,68].

Figure 3. Gene Structures and Major Splicing Transcripts for the Human, Mouse and Rat CD36 Genes. Derived from the AceView website http://www.ncbi.nlm.nih.gov/IEB/Research/Acembly/ mature isoform variants are shown with capped 5’- and 3’- ends for the predicted mRNA sequences [62]; NM refers to the NCBI reference sequence; exons are in pink; the directions for transcription are shown as 5’ → 3’; sizes of mRNA sequences are shown in kilobases (kb); predicted transcription factor binding sites (TFBS) for human Cd36 are shown: CART1- a paired-class homeodomain transcription factor [71]; RSRFC4-myocyte enhancement factor 2A transcription factor [70]; XBP1-transcription factor [73]; FOXJ2-fork-head transcription factor [72]; CDC5-transcription activator and cell cycle regulator; [74]; PPARA-peroxisome proliferator-activated receptor alpha; and PPARG-peroxisome proliferator-activated receptor gamma [67,68].

2.9. Comparative Human and Mouse CD36 Tissue Expression

Figure 4 presents ‘heat maps’ showing comparative gene expression for various human and mouse tissues obtained from GNF Expression Atlas Data using the U133A and GNF1H (human) and GNF1M (mouse) chips (http://genome.ucsc.edu; http://biogps.gnf.org) [75]. These data supported a broad and high level of tissue expression for human and mouse CD36, particularly for adipose tissue, heart, skeletal muscle and liver, which is consistent with previous reports for these genes [11,32,66]. Overall, human and mouse CD36 tissue expressions levels were 4-6 times the average level of gene expression which supports the key role played by this enzyme in fatty acid metabolism, especially in liver, muscle and adipose tissue.

Figure 4. Comparative Tissue Expression for Human and Mouse CD36 Genes. Expression ‘heat maps’ (GNF Expression Atlas 2 data) (http://biogps.gnf.org) were examined for comparative gene expression levels among human and mouse tissues for CD36 genes showing high (red); intermediate (black); and low (green) expression levels [75]. Derived from human and mouse genome browsers (http://genome.ucsc.edu) [64].

Figure 4. Comparative Tissue Expression for Human and Mouse CD36 Genes. Expression ‘heat maps’ (GNF Expression Atlas 2 data) (http://biogps.gnf.org) were examined for comparative gene expression levels among human and mouse tissues for CD36 genes showing high (red); intermediate (black); and low (green) expression levels [75]. Derived from human and mouse genome browsers (http://genome.ucsc.edu) [64].

The broad tissue and high level of gene expression reported for human and mouse CD36 reflects key roles for this major cell membrane and muscle outer mitochondrial membrane glycoprotein in fatty acyl translocation and as a multiple ligand cell surface receptor of oxidized LDL lipoproteins (ox-LDL) and long chain fatty acids [7,11,33,66]. CD36 has also been described as a lipid ‘sensor’ playing a lipid receptor role for cells and tissues of the body [8,40]. Moreover, CD36 upregulation is associated with insulin resistance and hyperinsulinaemia, leading to liver pathology and increased steatosis [43]. In addition, cardiomyocyte CD36 cell surface recruitment is induced by insulin, AMP-dependent protein kinase (AMPK) activity or contraction, and is regulated in its vesicular trafficking by the RabGAP-AS160 substrate and AS160-Rab8a GTPase activating protein (GAP) [76,77,78]. These features provide a link between cell membrane CD36 and the reported insulin-stimulated phosphorylation of AS160 involved with the translocation of the glucose transporter GLUT4 to the plasma membrane [79,80]. It is also relevant to report that plasma levels of soluble CD36 are increased in type 2 diabetic patients [81].

Significant levels of CD36 expression have also been described in brain tissues, where CD36 contributes to cerebrovascular oxidative stress and neurovascular dysfunction induced by amyloid-beta in Alzeheimer’s dementia [12,13], and in transporting long chain fatty acids across the blood-brain barrier [82].

2.10. Phylogeny of Vertebrate CD36-Like Sequences

A phylogenetic tree (Figure 5) was calculated by the progressive alignment of 21 vertebrate CD36 amino acid sequences with human, mouse, chicken and zebrafish SCARB1 and SCARB2 sequences. The phylogenetic tree was ‘rooted’ with the lancelet (Branchiostoma floridae) CD36 sequence (see Table 1). The phylogenetic tree showed clustering of the CD36 sequences into groups which were consistent with their evolutionary relatedness as well as groups for human, mouse, chicken and zebrafish SCARB1 and SCARB2 sequences, which were distinct from the lancelet CD36 sequence. These groups were significantly different from each other (with bootstrap values of ~100/100) with the clustering observed supporting a closer phylogenetic relationship between CD36 and SCARB2, with the SCARB1 gene being more distantly related. This is suggestive of a sequence of CD36-like gene duplication events: ancestral CD36 gene duplication → SCARB1 and CD36 genes; followed by a further CD36 duplication, generating the SCARB2 and CD36 genes found in all vertebrate species examined (Figure 5). It is apparent from this study of vertebrate CD36-like genes and proteins that this is an ancient protein for which a proposed common ancestor for the CD36, SCARB1 and SCARB2 genes may have predated the appearance of fish > 500 million years ago [83]. In parallel with the evolution of CD36 and other CD36-like proteins (SCARB1 and SCARB2), thrombospondins (TSPs) are also undergoing evolutionary changes in their structures and functions [84], with gene duplication events proposed at the origin of deuterostomes.

3. Methods

3.1. Vertebrate CD36 Gene and Protein Identification

BLAST (Basic Local Alignment Search Tool) studies were undertaken using web tools from the National Center for Biotechnology Information (NCBI) (http://blast.ncbi.nlm.nih.gov/Blast.cgi) [85]. Protein BLAST analyses used vertebrate CD36 amino acid sequences previously described [8,45] (Table 1). Non-redundant protein sequence databases for several vertebrate genomes were examined using the blastp algorithm from sources previously described [55]. This procedure produced multiple BLAST ‘hits’ for each of the protein databases which were individually examined and retained in FASTA format, and a record kept of the sequences for predicted mRNAs and encoded CD36-like proteins. Predicted CD36-like protein sequences were obtained in each case and subjected to analyses of predicted protein and gene structures.

Figure 5. Phylogenetic Tree of Vertebrate CD36 Amino Acid Sequences with Human, Mouse, Chicken and Zebrafish SCARB1 and SCARB2 Sequences. The tree is labeled with the CD36-like gene name and the name of the animal and is ‘rooted’ with the lancelet CD36 sequence. Note the 3 major clusters corresponding to the CD36, SCARB1 and SCARB2 gene families. A genetic distance scale is shown. The number of times a clade (sequences common to a node or branch) occurred in the bootstrap replicates are shown. Only highly significant replicate values of 95 or more are shown with 100 bootstrap replicates performed in each case. A proposed sequence of CD36 gene duplication events is shown.

Figure 5. Phylogenetic Tree of Vertebrate CD36 Amino Acid Sequences with Human, Mouse, Chicken and Zebrafish SCARB1 and SCARB2 Sequences. The tree is labeled with the CD36-like gene name and the name of the animal and is ‘rooted’ with the lancelet CD36 sequence. Note the 3 major clusters corresponding to the CD36, SCARB1 and SCARB2 gene families. A genetic distance scale is shown. The number of times a clade (sequences common to a node or branch) occurred in the bootstrap replicates are shown. Only highly significant replicate values of 95 or more are shown with 100 bootstrap replicates performed in each case. A proposed sequence of CD36 gene duplication events is shown.

BLAT (Blast-like Alignment Tool) analyses were subsequently undertaken for each of the predicted CD36 amino acid sequences using the UC Santa Cruz Genome Browser [64] with the default settings to obtain the predicted locations for each of the vertebrate CD36 genes, including predicted exon boundary locations and gene sizes. BLAT analyses were similarly undertaken for vertebrate SCARB1 and SCARB2 genes using previously reported sequences in each case (see Table 1). Structures for human and mouse isoforms (splicing variants) for human CD36, mouse Cd36 and rat Cd36 were obtained using the AceView website to examine predicted gene and protein structures [66].

3.2. Predicted Structures and Properties of Vertebrate CD36

Predicted secondary structures for vertebrate CD36 proteins, human SCARB1 and SCARB2, lancelet (Branchiostoma floridae) CD36, sea squirt (Ciona intestinalis) CD36 and a fruit fly (Drosophila melanogaster) epithelial membrane protein (FBpp0072309) were obtained using the PSIPRED v2.5 web site tools provided by Brunel University [86]. Molecular weights, N-glycosylation sites [49] and predicted trans-membrane, cytosolic and exocellular sequences for vertebrate SCARB1 proteins were obtained using Expasy web tools (http://au.expasy.org/tools/pi_tool.html).

3.3. Comparative Human and Mouse CD36 Gene Expression

The genome browser (http://genome.ucsc.edu) [62] was used to examine GNF Expression Atlas 2 data using various expression chips for human and mouse CD36 genes (http://biogps.gnf.org) [74]. Gene array expression ‘heat maps’ were examined for comparative gene expression levels among human and mouse tissues showing high (red); intermediate (black); and low (green) expression levels.

3.4. Phylogeny Studies and Sequence Divergence

Alignments of vertebrate CD36, SCARB1 and SCARB2 sequences were assembled using BioEdit v.5.0.1 and the default settings [87]. Alignment ambiguous regions, including the amino and carboxyl termini, were excluded prior to phylogenetic analysis yielding alignments of 431 residues for comparisons of vertebrate CD36 sequences with human, mouse, chicken and zebra-fish SCARB1 and SCARB2 sequences with the lancelet (Branchiostoma floridae) CD36 sequence (Table 1). Evolutionary distances and phylogenetic trees were calculated as previously described [85]. Tree topology was reexamined by the boot-strap method (100 bootstraps were applied) of resampling and only values that were highly significant (≥95) are shown [88].

4. Conclusions

The results of this study indicate that vertebrate CD36 genes and encoded proteins represent a distinct gene and protein family of CD36-like proteins which share key conserved sequences that have been reported for other CD36-like proteins (SCARB1 and SCARB2) previously studied [16,17,18,19,20,21,22,23,24]. CD36 has a unique property among these proteins in serving a major role in fatty acyl translocation and as a multiple ligand cell surface receptor of oxidized LDL lipoproteins (ox-LDL), long chain fatty acids, aged neutrophils and Plasmodium falciparum-parasitized erythrocytes [3,4,5,6,7,8,9,10]. CD36 is encoded by a single gene among the vertebrate genomes studied and is highly expressed in human and mouse tissues, particularly in adipose tissue, heart, skeletal muscle and liver, and usually contain 12 coding exons. Predicted secondary structures for vertebrate CD36 proteins showed strong similarities with other CD36-like proteins, SCARB1 and SCARB2. Three major structural domains were observed for vertebrate CD36 sequences, including N- and C-terminal cytoplasmic domains; N- and C-terminal trans-membrane domains; and an exoplasmic domain, which serves as the ‘receptor’ for long chain fatty acids and thrombospondins [5,6,7,8,14,32]. The latter domain contained three disulfide bridges [49]; several N-glycosylation sites for glycan binding (7–10 sites), which are essential for membrane recruitment [52]; 17 conserved proline and 14 glycine residues, which may contribute to short loop structures for the CD36 exoplasmic structure; and several conserved basic amino acid sites, which may promote long chain fatty acid binding. Phylogenetic studies using 21 vertebrate CD36 sequences with human, mouse, chicken and zebrafish SCARB1 and SCARB2 sequences indicated that the CD36 gene appeared early in evolution, prior to the appearance of bony fish more that 500 million years ago, and has undergone at least two gene duplication events: ancestral CD36 → vertebrate SCARB1 and CD36; with the latter gene undergoing a further gene duplication generating vertebrate CD36 and SCARB2 genes.
