Enhanced Control Scheme for a Three-Phase Grid-Connected PV Inverter under Unbalanced Fault Conditions
Abstract
:1. Introduction
2. PV System Modeling
2.1. FLL Synchronization System
2.2. MPPT Method
2.3. Current Controller
2.3.1. Type I: Ideal PR Controller
2.3.2. Type II: Non-Ideal PR Controller
2.3.3. Type III: Non-Ideal PR Controller with a Harmonic Compensators
3. Proposed Power Control Method
3.1. PNSC
3.2. IARC
3.3. Controller Design Using Bode Frequency Analysis
4. Simulation Results
4.1. Conventional Current Control Method
4.2. PNSC Method Performance Using the Type II PR Controller
4.3. IARC Method Performance Using the Type III PR Controller
5. Conclusions
Author Contributions
Funding
Conflicts of Interest
Abbreviations
transfer function of ideal PR controller | |
proportional gain | |
integral gain | |
grid frequency | |
transfer function of non-ideal PR controller | |
bandwidth of controller | |
damping factor | |
transfer function of non-ideal PR controller with harmonic compensators | |
orthogonal voltage | |
constant components of active and reactive power | |
oscillatory components of active and reactive power | |
reference current | |
norm of the grid voltage vector signal | |
instantaneous conductance | |
instantaneous susceptance | |
DC-link capacitance | |
criteria value of proportional gain | |
criteria value of integral gain | |
d component of continuous switching vector | |
sampling frequency | |
switching frequency | |
transfer function of current control loop |
