Article

Electromechanical-Mode Coupling Model and Failure Prediction of CFRP under Three-Point Bending

1
School of Artificial Intelligence, Tiangong University, Tianjin 300387, China
2
School of Control Science and Engineering, Tiangong University, Tianjin 300387, China
3
School of Electrical and Electronic Engineering, University of Manchester, Manchester M13 9PL, UK
*
Author to whom correspondence should be addressed.
Academic Editors: Gabriele Grandi, José Matas, Carlos E. Ugalde-Loo and Fushuan Wen
Electronics 2021, 10(16), 2007; https://doi.org/10.3390/electronics10162007
Received: 20 July 2021 / Revised: 10 August 2021 / Accepted: 15 August 2021 / Published: 19 August 2021
(This article belongs to the Special Issue 10th Anniversary of Electronics: Recent Advances in Power Electronics)
Carbon fiber reinforced polymer materials (CFRP) cause CFRP to bend or fail when subjected to external loads or impacts. In the case of static three-point bending, using the conductive properties of the carbon fiber inside the CFRP, the overall damage detection and failure prediction can be carried out by electromagnetic methods. The eddy current coil is used to realize real-time monitoring of damage, and the measured voltage value can be mapped to obtain the load of the sample. This paper conducts theoretical analysis and experimental verification, and obtains the relationship between CFRP stress damage and spatial conductivity change, and proposes a CFRP electromechanical coupling model under quasistatic three-point bending. Combined with the theory of electrically ineffective length, the CFRP three-point bending electromechanical coupling model was revised. Experimental results prove that the revised model can describe the load-conductivity change trend of three-dimensional braided CFRP more accurately, which provides a theoretical basis for monitoring the structural health of CFRP through electromagnetic methods. View Full-Text
Keywords: electromagnetic testing; electromagnetic eddy current; three-dimensional angle interlocking woven structure of CFRP electromagnetic testing; electromagnetic eddy current; three-dimensional angle interlocking woven structure of CFRP
Show Figures

Figure 1
