Case Report

RNA-seq and Mitochondrial DNA Analysis of Adrenal Gland Metastatic Tissue in a Patient with Renal Cell Carcinoma

Department of Clinical Pharmacology, Tokai University School of Medicine, Isehara 259-1193, Kanagawa, Japan
Department of Urology, Tokai University Hachioji Hospital, Tokyo 192-0032, Japan
Medical Science College Office, Tokai University, Isehara 259-1193, Kanagawa, Japan
Department of Urology, Tokai University School of Medicine, Isehara 259-1193, Kanagawa, Japan
Authors to whom correspondence should be addressed.
These authors contributed equally to this work.
Biology 2022, 11(4), 589;
Submission received: 16 February 2022 / Revised: 2 April 2022 / Accepted: 11 April 2022 / Published: 13 April 2022 / Corrected: 11 July 2022



Simple Summary

We performed mutation analysis of ribonucleic acid sequencing (RNA-seq) and whole mitochondrial genome data from tissues collected from metastatic lesions of a male patient in his 60s with metastatic renal cell carcinoma. We confirmed the common mutation sites of a mitochondrial gene containing the T3394Y, R11,807G, and G15,438R sites. Pathway analysis, using RNA-seq data, confirmed the common mutant pathway between renal cell carcinoma and metastatic adrenal carcinoma as cytokine–cytokine receptor (CCR) interaction. However, no common nuclear gene mutations were identified. The two similar sequences suggest that mtDNA-mutation-driven metastasis to the adrenal gland may affect CCR interactions and cause cancer cells to thrive.


This study aimed to clarify whether genetic mutations participate in renal cell carcinoma (RCC) metastasis to the adrenal gland (AG). Our study analyzed whole mitochondrial gene and ribonucleic acid sequencing (RNA-seq) data from a male patient in his 60s with metastatic RCC. We confirmed common mutation sites in the mitochondrial gene and carried out Kyoto Encyclopedia of Genes and Genomes (KEGG) analysis using RNA-seq data for RCC and adrenal carcinoma. Furthermore, we confirmed the common mutation sites of mitochondrial genes in which the T3394Y (p.H30Y) site transitioned from histidine (His.; H) to tyrosine (Tyr.; Y) in the NADH dehydrogenase subunit 1 (ND1) gene. The R11,807G (p.T350A) site transitioned from threonine (Thr.; T) to alanine (Ala.; A). Additionally, the G15,438R or A (p.G231D) site transitioned from glycine (Gly.; G) to aspartic acid (Asp.; D) in cytochrome b (CYTB). Furthermore, pathway analysis, using RNA-seq, confirmed the common mutant pathway between RCC and adrenal carcinoma as cytokine–cytokine receptor (CCR) interaction. Confirmation of the original mutation sites suggests that transfer to AG may be related to the CCR interaction. Thus, during metastasis to the AG, mitochondria DNA mutation may represent the initial origin of the metastasis, followed by the likely mutation of the nuclear genes.

Graphical Abstract

1. Introduction

We performed genetic analysis to investigate metastasis, using cancer tissues that had metastasized from the kidneys (renal cell carcinoma; RCC) to the adrenal gland (AG). This study aimed to clarify whether genetic mutations play a role in metastasis from RCC to the AG. To this end, we have been conducting research on both nuclear genes and mitochondrial DNA (mtDNA). Previously, we reported that mitochondrial DNA mutations are involved in the development and metastasis of RCC [1,2]. The kidney is rich in blood vessels; therefore, RCC is said to often metastasize to places with abundant blood flow, such as the lungs, bones, brain, liver, and AG [3,4,5]. However, RCC may also spread to the lymph nodes where lymphatic fluid is collected. Therefore, in this study, we focused on the relationship between metastasis and genetic mutations based on metastatic AG tissue.
The AG is an organ approximately 2–3 cm in size, located above the kidney, as shown in Figure 1 [6]. As such, the kidney is the most likely organ from which metastasis to the AG originates. Indeed, studies have reported RCC metastasis to the AG; however, these studies did not consider potential genetic involvement. Molecular-targeted drugs, such as angiogenesis inhibitors and mTOR inhibitors, have been developed for metastatic RCC, since the era of immunotherapy with interferon [7]. Furthermore, the development of immune checkpoint inhibitors has significantly improved survival rates.
Currently, drug treatments for metastatic RCC are diverse and stratified by risk factors using models such as those from the Memorial Sloan–Kettering Cancer Center and the International Metastatic RCC Database Consortium. However, it is difficult to select appropriate cases for study [8,9,10,11,12,13,14,15,16]. In addition, the effectiveness of therapeutic agents has been investigated primarily using nuclear gene information. However, for more appropriate case selection, it is necessary to not only collect information from the primary lesion of the metastatic RCC but also from molecules of the metastatic lesion. Furthermore, research on biomarkers specific to RCC metastasis, including various tumor mutations, has primarily included analysis of the nuclear genome. Meanwhile, the mutation burden and mutation profile of the mitochondrial genome has only recently been characterized. In fact, numerous genetic studies, including those identifying biomarkers related to the mechanism and treatment of RCC, have been conducted over the last 5 years [6,7,17,18,19,20,21,22,23,24,25,26,27,28,29].
Previously, our group analyzed the recurrence and survival of the D-loop and NADH dehydrogenase subunit 1 (ND1) regions of mitochondrial DNA in 62 patients [1,16,30,31]. We showed that adverse pathological tumor features in localized RCC are affected by high mutation rates in the mitochondrial D-loop region. Moreover, compared to patients with MT-ND1 or D-loop mutations, we found that RCC patients with both D-loop and MT-ND1 mutations exhibit more advanced cancer-specific survival. Thus, differences in nuclear gene expression and mitochondrial genome mutation profiles between primary and metastatic lesions may aid in the selection of various therapeutic agents. Therefore, we performed mutation analysis of RNA-seq and mitochondrial genome data using surgical specimens of tissues from patients with metastatic RCC collected from metastatic lesions. In the current study, we aimed to verify whether these genes are associated with metastasis. In addition, we sought to identify a more effective molecular-targeted drug for metastatic RCC by investigating pre-administration information, selected drugs, and their effects, as well as the prognosis relative to the administration method based on genomic analysis. We believe that these results provide valuable insights regarding the selection of effective drugs for the treatment of metastatic cancer, as well as the relationship between cancer-specific mutant genotypes and metastatic destinations.

2. Materials and Methods

2.1. Case Description, Timeline, and Clinical Intervention

A male patient in his 60s with type 1 diabetes mellitus was referred to our hospital in July 2017. Chest and abdominal computed tomography showed a 3.5 cm left renal mass with hypervascularity, a bilateral adrenal mass (left was 3 cm in diameter; right was 1.2 cm in diameter; Figure 1), multiple lung nodules, and bone metastasis (T3, 10; L 3, 4 vertebrae). The findings of the bone lesion biopsy were compatible with features of clear cell RCC. In August 2017, the patient underwent cytoreductive left nephrectomy with ipsilateral adrenalectomy, without neoadjuvant therapy. The pathological findings of the kidney tumor revealed clear RCC, with a maximum diameter of approximately 40 mm, Fuhrman grade 2 tumor, v0, ly0 (sample number: K58-R). Pathological examination of the left AG (sample number: K58-M) revealed metastatic cancer foci with a pseudocapsule. Both DNA and RNA were extracted from the normal kidney tissue (sample number: K58-N), the primary RCC site, and the metastatic site of the left AG.
Following the guidelines of the Declaration of Helsinki, this study was conducted with approval from the institutional review board (ethics committee) of Tokai University, Japan (protocol code 15R065; date of approval: 12 August 2015). Informed consent was obtained from the patient.

2.1.1. DNA Extraction

The surgical specimens of the cancerous and normal kidney tissues were collected, immersed in RNAlater (Qiagen, Valencia, CA, USA), and stored at −80 °C. The cancerous and normal kidney tissues for study were then collected from the surgical specimens by macroscopic judgment. In addition, a blood sample was collected from the peripheral veins the day before surgery. DNA from blood sample was used as the control sequence.

2.1.2. Extraction of DNA and RNA

Total DNA and RNA were extracted from cancer tissues using TRIzol (Invitrogen, Carlsbad, CA, USA), followed by RNeasy (Qiagen, Valencia, CA, USA) (Table 1). The RNA preparation was assessed for degradation using an Agilent 2100 Bioanalyzer (Agilent Technologies, Palo Alto, CA, USA).

2.1.3. Extraction of Mitochondrial DNA

Tissue and blood samples were then incubated with 200 g of proteinase K in buffer (10 mM Tris-Cl (pH 8.0), 150 mM NaCl, 10 mM ethylenediaminetetraacetic acid (EDTA), 0.1% sodium dodecyl sulfate) at 60 °C overnight, and later extracted with phenol–chloroform (phenol–chloroform–isoamyl alcohol, 25:24:1) twice at 11,000 rpm for 10 min at room temperature (25 °C). DNA was precipitated by the addition of 0.1 volume of 3 M Na-AcOH and 2.5 volumes of ice-cold ethanol. Then, after centrifugation at 15,000 rpm at 4 °C for 20 min, the DNA pellets were rinsed with 70% cold ethanol, dried, and dissolved in TE buffer (10 mM Tris-HCl (pH 8.0) and 1 mM EDTA). The total mtDNA was then amplified by polymerase chain reaction (PCR) with the primer sets (Table S1), which cover the whole mtDNA region [32,33].

2.2. PCR Amplification Conditions

PCR was performed using KOD FX Neo (Toyobo, Osaka, Japan) under the following conditions: melting at 98 °C for 5 s, annealing at 63–66 °C for 15 s, and then extension at 68 °C for 20 s, for a total of 35 cycles. The PCR products were treated with EXOSAP-IT (Ametrix, Santa Clara, CA, USA) and immediately sequenced using a Big Dye Terminator v3.1 Reaction Kit (Applied Biosystems, Torrance, CA, USA) and an ABI 3500xL DNA sequencer (Life Technologies, Carlsbad, CA, USA).

2.3. Sequencing Analysis of Mitochondrial DNA

Complete mtDNA sequence data from the patient with localized RCC were assembled using Sequencher 5.0 software (Gene Codes Corporation, Ann Arbor, MI, USA). The mutation sites were determined using NC_012920.1 as the reference sequence.

2.4. RNA-seq Analysis: Mapping and Expression Analysis

The raw reads were obtained from the HiSeq 2500, and after completion of the run, data were base-called and demultiplexed (provided as Illumina FASTQ 1.8 files, Phred+33 encoding). FASTQ format files in Illumina 1.8 format were considered for downstream analysis (Illumina, San Diego, CA, USA).

2.4.1. Sequencing Libraries

Sequencing libraries were prepared using the TruSeq Stranded mRNA Library Prep Kit (Illumina), according to the manufacturer’s instructions [34,35].

2.4.2. Sequencing (HiSeq2500 PE100)

The libraries were sequenced on a HiSeq 2500 sequencing platform using HiSeq SBS Kit v4 reagents with 2 × 101 cycles.

2.4.3. Data Analysis (Human RNA-seq Tophat/Cufflinks)

The adapter sequences and low-quality regions were trimmed using Cutadapt (v1.1) (National Bioinformatics Infrastructure Sweden, Uppsala, Sweden) and Trimmomatic v0.32 (RWTH Aachen University, Aachen, Germany), respectively. After pre-processing, the reads were mapped to the human reference genome GRCh38 using TopHat (v2.0.14) (Johns Hopkins University, MD, USA) [36]. Differential gene expression analysis was performed using the Cufflinks package (v2.2.1)(University of Washington, Seattle, USA) [37,38].

2.5. RNA-seq Analysis and Gene Expression Analysis Based on DAVID

We created lists annotated to Homo sapiens genes by enrichment analysis. The listed genes were submitted to the DAVID functional annotation database ( (accessed on 7 December 2021), providing a broad and unguided test against primarily Gene Ontology (GO) groups as well as Kyoto Encyclopedia of Genes and Genomes (KEGG) pathways [30,33,39,40]. When GO gene groups and KEGG pathways were extracted, the expression levels increased four times. The results are considered statistically significant when the p-value is <0.05.

3. Results

3.1. Somatic Mutations in the Mitochondrial DNA Region

In two cancer tissues, a total of five site mutations were confirmed compared to those in normal cells (Table 2). The mutations occurred in the sites numbering 71; 1826; 3394; 11,807; and 15,438. Site 71 of the D-loop region changed to a gap (71delG). The G1826 site in normal cells was mutated to the G1826 R of 16S ribosomal RNA in both cancer cell lines. It was also found that the T3394C site of ND1 in normal cells was mutated to the heterosite of T3394Y (Y: Pyrimidine) in cancer cells. Site 15,438 changed from G in cytochrome b (CYTB) to R or A. In addition, site 11,807 of the NADH dehydrogenase subunit 4 (ND4) gene changed to G from the R heterosite (Table 2).
Moreover, the G15,438R or A (p.G231D) site transitioned from glycine (Gly.; G) to aspartic acid (Asp.; D), while the R11,807G (p.T350A) site transitioned from threonine (Thr.; T) to alanine (Ala.; A). Furthermore, the T3394Y (p.H30Y) site transitioned from histidine (His.; H) to tyrosine (Tyr.; Y) (Table 3). However, the signal of the T3394Y thymine (T) was lower than that of cytosine (C). Hence, it was confirmed that K58-R and K58-M have similar sequences.

3.2. RNA-seq Analysis and Gene Expression Analysis Based on DAVID

The KEGG pathways in which the expression and activity levels of adrenal cancer were more than doubled were primarily enriched in “Complement and coagulation cascades”, “Metabolic pathways”, and “Cytokine–cytokine receptor interaction” (Table 4). Additionally, pathways in which the expression and activity levels were more than doubled in RCC were primarily related to “Cell adhesion molecules (CAMs)”, “Antigen processing and presentation”, “Neuroactive ligand–receptor interaction”, “Cytokine”, and “cytokine receptor interaction” (Table 5). In particular, the cytokine–cytokine receptor interaction is of interest in this pathway. The expression level of this KEGG pathway was more than doubled in both cancer cell lines. However, there was a clear difference in the CXC subfamily pathways. That is, in adrenal cancer cells, the pathways of eight CXC subfamilies (CXCR1: CXCL1, 5, 6, and 8; CXCR2: CXCL2 and 3; CXCR3: CXCL4; and CXCL4L1) were affected (Figure 2, Figure S1 and Table S2). Meanwhile, in RCC, differences were observed in the expression levels of the four genes for CXCR3, which interacts with CXCL9, CXCL10, CXCL11, and CXCL13 (Figure 2 and Figure S2). Furthermore, the TGF-β family (BMPR1A and BMPR1B) was also impacted (Figure S2 and Table S2).

3.3. Clinical Course after Surgery

After surgery, sunitinib was administered at a dose of 37.5 mg in September 2017. Owing to the progression of the lumbar vertebral metastasis, the patient was administered nivolumab as second-line systemic therapy. Although the metastatic lesions showed a partial response to nivolumab, the agent was discontinued due to hypopituitary insufficiency (central adrenal insufficiency), and oral intake of steroids was initiated. Radiotherapy was administered for the bone metastases. As of October 2021, multiple lung metastases and a right adrenal metastasis-maintained shrinkage, as well as multiple bone metastases, were shown in osteosclerotic images.

4. Discussion

This study aimed to clarify the involvement of genetic mutations in the metastasis of RCC to the AG. We analyzed the total mitochondrial DNA and RNA sequences of the renal and adrenal cancer tissues in a patient with RCC metastasis to the AG. By analyzing mitochondrial and nuclear DNA from two cancer sequences (K58-R and K58-M), we were able to confirm whether a common gene for cancer metastasis exists. Specifically, three common mutation sites were identified: T3394Y, R11,807G, and G15,438. T3394C mutation is reportedly associated with colon cancer and leukemia [41,42]. However, it likely became heteroplasmic when it transitioned into a cancer cell type in this case study. Our previous studies have reported the involvement of mtDNA mutations in cancer metastasis [1,2]. Therefore, since they share a common mitochondrial sequence, it is considered that the mutation at this site had metastasized from the primary RCC to the AG. In addition, the other two mutations have not been confirmed in other cancer reports.
Regarding ND1, Hayashi et al. showed that mtDNA mutations are involved in cancer metastasis by creating cybrid cells via cytoplasmic transplantation using mouse cells [43]. Complex I is a mitochondrial respiratory enzyme complex that is the main source of reactive oxygen species (ROS) [44]. This confirmed that the occurrence of mitochondrial mutations induces a decrease in mitochondrial respiratory activity and an abnormality in glycolytic activity from the causal relationship of ROS production, leading to carcinogenesis. Thus, it is highly likely that this mutation in ND1 had metastasized from the primary RCC to the AG. Mitochondria are likely to be involved in adrenal metastasis, as RCC developed earlier in this patient. Furthermore, in our report, there was a correlation between the recurrence of ND1 and RCC (61 patients) and cancer-related death. These data are provided as part of our supplementary data.
Moreover, in the pathway analysis based on RNA-seq, the common mutant pathway cytokine–cytokine receptor interaction between RCC and adrenal carcinoma was confirmed. In particular, it strongly affected CXCL1-11 (excluding CXCL7), as well as 13 genes of the CXC subfamily. It was also determined that the CXC subfamily that comprises the pathway is affected by three genes: CXCR1, CXCR2, and CXCR3. Zeng et al. found that the transcriptional levels of CXCL1/2/5/6/9/10/11/16 in RCC tissues were reduced, while those of CXCL3/7/12/13 were elevated. CXC1/5/9/10/11/13 were shown to have a significant correlation with the pathological stage of RCC. RCC patients with low transcriptional levels of CXCL1/2/3/5/13 have a better prognosis [45]. Oldham et al. showed that CCR5, CXCR3, and CXCR6 are involved in selective recruitment of T cells into RCC tissues. These chemokine receptors, as well as CCR6, are involved in recruiting Tregs to the tumor site [46]. Furthermore, in RCC, in addition to the CXCR3 gene, the transforming growth factor (TGF)-β family (BMPR1A, BMPR1B, ACVR1) pathway is also impacted. Specifically, the expression levels of bone morphogenetic protein (BMP) receptors Acvr1, Bmpr1a, and Bmpr1b in the BMP signal transduction system were decreased. BMP signaling can promote tumor growth and suppress endometrial cancer. Fukuda et al. demonstrated the tumor-promoting effects of BMP signaling in endometrial cancer cells by inducing cancer stemness, EMT, and migration [47]. Several secreted proteins, including TWSG1 and Gremlin, antagonize BMP ligands [47].
TGF-β is a major inducer of the epithelial–mesenchymal transition (EMT) [48,49]. The TGF-β pathway is reportedly activated in the endothelial cells (ECs) [50,51,52], and TGF-β has tumor-promoting and tumor-suppressing effects in the EC. However, the effects of BMPs, members of the TGF-β family, on ECs are not well-known [53,54,55]. Complexes of type I and type II serine/threonine kinase receptors are induced by the cellular effects of BMP ligands [56,57,58]. ACVRL1 (ALK1), ACVR1 (ALK2), BMPR1A (ALK3), and BMPR1B (ALK6) are classified as type I receptors, and ACVR2A (ActRII), ACVR2B (ActRIIB), and BMPR2 (BMPRII) as type II receptors [47,59]. Following receptor activation, SMAD1/5/8 are phosphorylated and form complexes with SMAD4. They are translocated to the nucleus, where they regulate the transcription of several target genes, including ID1 [60,61,62,63,64,65,66]. In fact, we did not find the same gene or mutation site in our RNA-seq and mtDNA analyses using leukemia MOLT-3 cells. A mutation in mitochondrial DNA occurs in the background of metastasis. Subsequently, the mutated mitochondrial DNA is transferred to normal cells by interaction, and the pathway is affected by the mutation of each gene.
Molecular-targeted drugs are used to treat metastatic RCC. Improvements in survival rates have been reportedly compared, and treatment strategies for metastatic RCC are undergoing major changes. However, appropriate risk assessment, prognosis prediction, and optimal administration of molecular-targeted drugs for metastatic RCC in Japan have not yet been established. Therefore, it is necessary to consider information on a large number of patients to establish an effective treatment strategy.

5. Conclusions

Based on mitochondrial gene analyses, we confirmed the common mutation sites between the original RCC and metastatic adrenal carcinoma. The three sites, G15,438R, R11,807G, and T3394Y, helped us confirm that K58-R and K58-M have similar sequences. Moreover, a common mutant pathway, CCR, was identified between RCC and adrenal carcinoma. However, no common nuclear gene mutations were identified. Furthermore, in this study, we were not able to identify specific genes associated with metastasis. Nevertheless, the two similar sequences suggest that mtDNA-mutation-driven metastasis to the AG may affect CCR interactions, allowing cancer cells to thrive.

Supplementary Materials

The following supporting information can be downloaded at: Table S1: Primer set used for amplifying the whole mitochondrial DNA region; Table S2. Gene expression analysis: list of genes; Figure S1: results of KEGG analysis of the adrenal gland metastatic lesion; K58-M FC ≥ 2 upregulated 2243 genes (2152 genes*); Figure S2: results of KEGG analysis of the renal cell carcinoma primary lesion; K58-R FC ≥ 2 upregulated 1897 genes (1810 genes*).

Author Contributions

Conceptualization, T.K. and H.K. (Hakushi Kim); investigation, T.K. and H.K. (Hakushi Kim); formal analysis, T.K., H.K. (Hakushi Kim), M.T., S.I. and K.Y.; validation, T.K., H.K. (Hakushi Kim), M.T., S.I. and K.Y.; data curation, T.K., M.T., S.I. and K.Y.; writing—original draft, T.K. and H.K. (Hakushi Kim); writing—review and editing, T.K. and H.K. (Hakushi Kim); supervision, H.K. (Hiroyuki Kobayashi) and A.M. All authors have read and agreed to the published version of the manuscript.


This research was funded by KAKENHI, grant number 18K09180. This work was supported by Tokai University General Research Organization Grant.

Institutional Review Board Statement

The study was conducted in accordance with the Declaration of Helsinki and approved by the Institutional Review Board for Medical Ethics of Tokai University, School of Medicine IRB (21R002 on 15 May 2021).

Informed Consent Statement

Informed consent was obtained from the subject involved in the study.

Data Availability Statement

The data presented in this study are available in the article and Supplementary Material.


We thank the Medical Science College Office of Tokai University for the technical assistance.

Conflicts of Interest

The authors declare no conflict of interest. The funders had no role in the design of the study; in the collection, analyses, or interpretation of data; in the writing of the manuscript; or in the decision to publish the results.


  1. Kim, H.; Komiyama, T.; Inomoto, C.; Kamiguchi, H.; Kajiwara, H.; Kobayashi, H.; Nakamura, N.; Terachi, T.J. Mutations in the mitochondrial ND1 gene are associated with postoperative prognosis of localized renal cell carcinoma. Int. J. Mol. Sci. 2016, 17, 2049. [Google Scholar] [CrossRef] [PubMed]
  2. Kim, H.; Komiyama, T.; Nitta, M.; Kawamura, Y.; Hasegawa, M.; Shoji, S.; Orihashi, Y.; Inomoto, C.; Kajiwara, H.; Nakamura, N.; et al. D-loop mutations in renal cell carcinoma improve predictive accuracy for cancer-related death by integrating with mutations in the NADH dehydrogenase subunit 1 gene. Genes 2019, 10, 998. [Google Scholar] [CrossRef] [PubMed]
  3. Torchalla, P.; Czesak, M.; Osuch-Wójcikiewicz, E.J. Metastasis of clear cell renal cell carcinoma to the organs of the head and neck–an ongoing problem. Otolaryngol. Pol. 2021, 10, 42–48. [Google Scholar]
  4. Augustin, H.G.; Koh, G.Y. Organotypic vasculature: From descriptive heterogeneity to functional pathophysiology. Science 2017, 357, eaal2379. [Google Scholar] [CrossRef] [PubMed]
  5. Langley, R.R.; Fidler, I.J. Tumor cell-organ microenvironment interactions in the pathogenesis of cancer metastasis. Endocr. Rev. 2007, 28, 297–321. [Google Scholar] [CrossRef]
  6. Li, Y.; Ji, Z.; Wang, D.; Xie, Y. Bilateral adrenal metastasis of renal cell carcinoma 4 years after radical nephrectomy: A case report and review of literature. Medicine 2021, 100, e26838. [Google Scholar] [CrossRef]
  7. Roskoski, R., Jr. Vascular endothelial growth factor (VEGF) and VEGF receptor inhibitors in the treatment of renal cell carcinomas. Pharmacol. Res. 2017, 120, 116–132. [Google Scholar] [CrossRef]
  8. Graham, J.; Heng, D.Y. Real-world evidence in metastatic renal cell carcinoma. Tumori J. 2018, 104, 76–82. [Google Scholar] [CrossRef]
  9. Biles, M.J.; Patel, H.D.; Allaf, M.E. Cytoreductive nephrectomy in the era of tyrosine kinase and immuno-oncology checkpoint inhibitors. Urol. Clin. N. Am. 2020, 47, 359–370. [Google Scholar] [CrossRef]
  10. Goebell, P.J.; Ivanyi, P.; Bedke, J.; Bergmann, L.; Berthold, D.; Boegemann, M.; Busch, J.; Doehn, C.; Krege, S.; Retz, M.; et al. Consensus paper: Current state of first-and second-line therapy in advanced clear-cell renal cell carcinoma. Future Oncol. 2020, 16, 2307–2328. [Google Scholar] [CrossRef]
  11. Schmid, T.A.; Gore, M.E. Sunitinib in the treatment of metastatic renal cell carcinoma. Ther. Adv. Urol. 2016, 8, 348–371. [Google Scholar] [CrossRef] [PubMed]
  12. Janisch, F.; Klotzbücher, T.; Marks, P.; Kienapfel, C.; Meyer, C.P.; Yu, H.; Fühner, C.; Hillemacher, T.; Mori, K.; Mostafei, H.; et al. Predictive value of De Ritis ratio in metastatic renal cell carcinoma treated with tyrosine-kinase inhibitors. World J. Urol. 2021, 39, 2977–2985. [Google Scholar] [CrossRef] [PubMed]
  13. Vitale, M.G.; Bracarda, S.; Cosmai, L.; Crocetti, E.; Di Lorenzo, G.; Lapini, A.; Mandressi, A.; Martorana, G.; Masini, C.; Montironi, R.; et al. Management of kidney cancer patients: 2018 guidelines of the Italian Medical Oncology Association (AIOM). Tumori J. 2019, 105, 3–12. [Google Scholar] [CrossRef] [PubMed]
  14. Wong, S.E.; Quinn, D.I.; Bjarnason, G.A.; North, S.A.; Sridhar, S.S. Eligibility criteria and endpoints in metastatic renal cell carcinoma trials. Am. J. Clin. Oncol. 2020, 43, 559. [Google Scholar] [CrossRef]
  15. Arasaratnam, M.; Gurney, H. Nivolumab in the treatment of advanced renal cell carcinoma. Future Oncol. 2018, 14, 1679–1689. [Google Scholar] [CrossRef]
  16. Kim, H.; Inomoto, C.; Uchida, T.; Kajiwara, H.; Komiyama, T.; Kobayashi, H.; Nakamura, N.; Miyajima, A. Impact of rhabdoid differentiation on postoperative outcome for patients with N0M0 renal cell carcinoma. Urol. Oncol. 2019, 37, 711–720. [Google Scholar] [CrossRef]
  17. van der Mijn, J.C.; Mier, J.W.; Broxterman, H.J.; Verheul, H.M. Predictive biomarkers in renal cell cancer: Insights in drug resistance mechanisms. Drug Resist. Updates 2014, 17, 77–88. [Google Scholar] [CrossRef]
  18. Noon, A.P.; Vlatković, N.; Polański, R.; Maguire, M.; Shawki, H.; Parsons, K.; Boyd, M. p53 and MDM2 in renal cell carcinoma: Biomarkers for disease progression and future therapeutic targets? Cancer 2010, 116, 780–790. [Google Scholar] [CrossRef]
  19. Gossage, L.; Eisen, T. Alterations in VHL as potential biomarkers in renal-cell carcinoma. Nat. Rev. Clin. Oncol. 2010, 7, 277–288. [Google Scholar] [CrossRef]
  20. Braga, E.A.; Fridman, M.V.; Loginov, V.I.; Dmitriev, A.A.; Morozov, S. Molecular mechanisms in clear cell renal cell carcinoma: Role of miRNAs and hypermethylated miRNA genes in crucial oncogenic pathways and processes. Front. Genet. 2019, 10, 320. [Google Scholar] [CrossRef]
  21. Motzer, R.J.; Hutson, T.E.; Hudes, G.R.; Figlin, R.A.; Martini, J.-F.; English, P.A.; Huang, X.; Valota, O.; Williams, J. Investigation of novel circulating proteins, germ line single-nucleotide polymorphisms, and molecular tumor markers as potential efficacy biomarkers of first-line sunitinib therapy for advanced renal cell carcinoma. Cancer Chemother. Pharmacol. 2014, 74, 739–750. [Google Scholar] [CrossRef] [PubMed]
  22. Mihai, S.; Codrici, E.; Popescu, I.D.; Enciu, A.-M.; Albulescu, L.; Necula, L.G.; Mambet, C.; Anton, G.; Tanase, C. Inflammation-related mechanisms in chronic kidney disease prediction, progression, and outcome. J. Immunoll Res. 2018, 2018, 16. [Google Scholar] [CrossRef] [PubMed]
  23. Joosten, S.C.; Smits, K.M.; Aarts, M.J.; Melotte, V.; Koch, A.; Tjan-Heijnen, V.C.; van Engeland, M. Epigenetics in renal cell cancer: Mechanisms and clinical applications. Nat. Rev. Urol. 2018, 15, 430–451. [Google Scholar] [CrossRef] [PubMed]
  24. Reese, B.; Silwal, A.; Daugherity, E.; Daugherity, M.; Arabi, M.; Daly, P.; Paterson, Y.; Woolford, L.; Christie, A.; Elias, R. Complement as prognostic biomarker and potential therapeutic target in renal cell carcinoma. J. Immunol. 2020, 205, 3218–3229. [Google Scholar] [CrossRef]
  25. Rodriguez-Vida, A.; Strijbos, M.; Hutson, T. Predictive and prognostic biomarkers of targeted agents and modern immunotherapy in renal cell carcinoma. ESMO Open 2016, 1, e000013. [Google Scholar] [CrossRef]
  26. Jonasch, E.; Futreal, P.A.; Davis, I.J.; Bailey, S.T.; Kim, W.Y.; Brugarolas, J.; Giaccia, A.J.; Kurban, G.; Pause, A.; Frydman, J. State of the science: An update on renal cell carcinoma. Mol. Cancer Res. 2012, 10, 859–880. [Google Scholar] [CrossRef]
  27. Cowey, C.L.; Rathmell, W. VHL gene mutations in renal cell carcinoma: Role as a biomarker of disease outcome and drug efficacy. Curr. Oncol. Rep. 2009, 11, 94–101. [Google Scholar] [CrossRef]
  28. Topalian, S.L.; Taube, J.M.; Anders, R.A.; Pardoll, D. Mechanism-driven biomarkers to guide immune checkpoint blockade in cancer therapy. Nat. Rev. Cancer 2016, 16, 275–287. [Google Scholar] [CrossRef]
  29. Hsieh, J.J.; Purdue, M.P.; Signoretti, S.; Swanton, C.; Albiges, L.; Schmidinger, M.; Heng, D.Y.; Larkin, J.; Ficarra, V. Renal cell carcinoma. Nat. Rev. Dis. Primers 2017, 3, 1–19. [Google Scholar] [CrossRef]
  30. Tanaka, M.; Makiuchi, T.; Komiyama, T.; Shiina, T.; Osaki, K.; Tachibana, H. Whole genome sequencing of Entamoeba nuttalli reveals mammalian host-related molecular signatures and a novel octapeptide-repeat surface protein. PLoS Negl. Trop. Dis. 2019, 13, e0007923. [Google Scholar] [CrossRef]
  31. Kim, H.; Inomoto, C.; Uchida, T.; Furuya, H.; Komiyama, T.; Kajiwara, H.; Kobayashi, H.; Nakamura, N.; Miyajima, A. Verification of the International Society of Urological Pathology recommendations in Japanese patients with clear cell renal cell carcinoma. Int. J. Oncol. 2018, 52, 1139–1148. [Google Scholar] [CrossRef] [PubMed]
  32. Komiyama, T.; Ogura, A.; Hirokawa, T.; Zhijing, M.; Kamiguchi, H.; Asai, S.; Miyachi, H.; Kobayashi, H. Analysis to estimate genetic variations in the idarubicin-resistant derivative MOLT-3. Int. J. Mol. Sci. 2016, 18, 12. [Google Scholar] [CrossRef] [PubMed]
  33. Komiyama, T.; Ogura, A.; Kajiwara, T.; Okada, Y.; Kobayashi, H.J.G. Analysis of candidate idarubicin drug resistance genes in MOLT-3 cells using exome nuclear DNA. Genes 2018, 9, 390. [Google Scholar] [CrossRef] [PubMed]
  34. Hou, Z.; Jiang, P.; Swanson, S.A.; Elwell, A.L.; Nguyen, B.K.S.; Bolin, J.M.; Stewart, R.; Thomson, J. A cost-effective RNA sequencing protocol for large-scale gene expression studies. Sci. Rep. 2015, 5, 9570. [Google Scholar] [CrossRef]
  35. Chao, H.-P.; Chen, Y.; Takata, Y.; Tomida, M.W.; Lin, K.; Kirk, J.S.; Simper, M.S.; Mikulec, C.D.; Rundhaug, J.E.; Fischer, S. Systematic evaluation of RNA-seq preparation protocol performance. BMC Genom. 2019, 20, 571. [Google Scholar] [CrossRef] [PubMed]
  36. Trapnell, C.; Pachter, L.; Salzberg, S. TopHat: Discovering splice junctions with RNA-seq. Bioinformatics 2009, 25, 1105–1111. [Google Scholar] [CrossRef]
  37. Trapnell, C.; Roberts, A.; Goff, L.; Pertea, G.; Kim, D.; Kelley, D.R.; Pimentel, H.; Salzberg, S.L.; Rinn, J.L.; Pachter, L. Differential gene and transcript expression analysis of RNA-seq experiments with TopHat and Cufflinks. Nat. Protoc. 2012, 7, 562–578. [Google Scholar] [CrossRef]
  38. Ghosh, S.; Chan, C.-K.K. Analysis of RNA-seq data using TopHat and Cufflinks. Methods Mol. Biol. 2016, 1374, 339–361. [Google Scholar]
  39. Murakami, T.; Komiyama, T.; Matsumoto, S.; Kajiwara, H.; Kobayashi, H.; Ikari, Y. Examination of gender differences in patients with takotsubo syndrome according to left ventricular biopsy: Two case reports. J. Med. Case Rep. 2021, 15, 281. [Google Scholar] [CrossRef]
  40. Kanehisa, M.; Goto, S. KEGG: Kyoto Encyclopedia of Genes and Genomes. Nucleic Acids Res. 2000, 28, 27–30. [Google Scholar] [CrossRef]
  41. Koshikawa, N.; Akimoto, M.; Hayashi, J.-I.; Nagase, H.; Takenaga, K. Association of predicted pathogenic mutations in mitochondrial ND genes with distant metastasis in NSCLC and colon cancer. Sci. Rep. 2017, 7, 15535. [Google Scholar] [CrossRef] [PubMed]
  42. Linnartz, B.; Anglmayer, R.; Zanssen, S. Comprehensive scanning of somatic mitochondrial DNA alterations in acute leukemia developing from myelodysplastic syndromes. Cancer Res. 2004, 64, 1966–1971. [Google Scholar] [CrossRef] [PubMed]
  43. Hayashi, M.; Thomas, L.; Moriya, R.; Rettner, C.; Parkin, S. Current-controlled magnetic domain-wall nanowire shift register. Science 2008, 320, 209–211. [Google Scholar] [CrossRef] [PubMed]
  44. Ishikawa, K.; Takenaga, K.; Akimoto, M.; Koshikawa, N.; Yamaguchi, A.; Imanishi, H.; Nakada, K.; Honma, Y.; Hayashi, J.-I. ROS-generating mitochondrial DNA mutations can regulate tumor cell metastasis. Science 2008, 320, 661–664. [Google Scholar] [CrossRef]
  45. Zeng, Q.; Sun, S.; Li, Y.; Li, X.; Li, Z.; Liang, H. Identification of therapeutic targets and prognostic biomarkers among CXC chemokines in the renal cell carcinoma microenvironment. Front. Oncol. 2020, 9, 1555. [Google Scholar] [CrossRef] [PubMed]
  46. Oldham, K.A.; Parsonage, G.; Bhatt, R.I.; Wallace, D.M.A.; Deshmukh, N.; Chaudhri, S.; Adams, D.H.; Lee, S. T lymphocyte recruitment into renal cell carcinoma tissue: A role for chemokine receptors CXCR3, CXCR6, CCR5, and CCR6. Eur. Urol. 2012, 61, 385–394. [Google Scholar] [CrossRef]
  47. Fukuda, T.; Fukuda, R.; Miyazono, K.; Heldin, C.-H. Tumor promoting effect of BMP signaling in endometrial cancer. Int. J. Mol. Sci. 2021, 22, 7882. [Google Scholar] [CrossRef]
  48. Xu, J.; Lamouille, S.; Derynck, R. TGF-β-induced epithelial to mesenchymal transition. Cell Res. 2009, 19, 156–172. [Google Scholar] [CrossRef]
  49. Zhang, J.; Tian, X.-J.; Zhang, H.; Teng, Y.; Li, R.; Bai, F.; Elankumaran, S.; Xing, J. TGF-β-induced epithelial-to-mesenchymal transition proceeds through stepwise activation of multiple feedback loops. Sci. Signal. 2014, 7, ra91. [Google Scholar] [CrossRef]
  50. Lebrin, F.; Deckers, M.; Bertolino, P.; Ten Dijke, P. TGF-β receptor function in the endothelium. Cardiovasc. Res. 2005, 65, 599–608. [Google Scholar] [CrossRef]
  51. Lebrin, F.; Goumans, M.J.; Jonker, L.; Carvalho, R.L.; Valdimarsdottir, G.; Thorikay, M.; Mummery, C.; Arthur, H.M.; Dijke, P. Endoglin promotes endothelial cell proliferation and TGF-β/ALK1 signal transduction. EMBO J. 2004, 23, 4018–4028. [Google Scholar] [CrossRef] [PubMed]
  52. Goumans, M.-J.; Lebrin, F.; Valdimarsdottir, G. Controlling the angiogenic switch: A balance between two distinct TGF-b receptor signaling pathways. Trends Cardiovasc. Med. 2003, 13, 301–307. [Google Scholar] [CrossRef]
  53. Pardali, E.; Goumans, M.-J.; ten Dijke, P. Signaling by members of the TGF-β family in vascular morphogenesis and disease. Trends Cell Biol. 2010, 20, 556–567. [Google Scholar] [CrossRef] [PubMed]
  54. Mi, L.-Z.; Brown, C.T.; Gao, Y.; Tian, Y.; Le, V.Q.; Walz, T.; Springer, T. Structure of bone morphogenetic protein 9 procomplex. Proc. Natl. Acad. Sci. USA 2015, 112, 3710–3715. [Google Scholar] [CrossRef] [PubMed]
  55. Wang, R.N.; Green, J.; Wang, Z.; Deng, Y.; Qiao, M.; Peabody, M.; Zhang, Q.; Ye, J.; Yan, Z.; Denduluri, S.; et al. Bone Morphogenetic Protein (BMP) signaling in development and human diseases. Genes Dis. 2014, 1, 87–105. [Google Scholar] [CrossRef] [PubMed]
  56. Groppe, J.; Hinck, C.S.; Samavarchi-Tehrani, P.; Zubieta, C.; Schuermann, J.P.; Taylor, A.B.; Schwarz, P.M.; Wrana, J.L.; Hinck, A. Cooperative assembly of TGF-β superfamily signaling complexes is mediated by two disparate mechanisms and distinct modes of receptor binding. Mol. Cell 2008, 29, 157–168. [Google Scholar] [CrossRef]
  57. Heldin, C.-H.; Landström, M.; Moustakas, A. Mechanism of TGF-β signaling to growth arrest, apoptosis, and epithelial–mesenchymal transition. Curr. Opin. Cell Biol. 2009, 21, 166–176. [Google Scholar] [CrossRef]
  58. Kawabata, M.; Imamura, T.; Miyazono, K. Signal transduction by bone morphogenetic proteins. Cytokine Growth Factor Rev. 1998, 9, 49–61. [Google Scholar] [CrossRef]
  59. Weiss, A.; Attisano, L. The TGFbeta superfamily signaling pathway. Wiley Interdiscip. Rev. Dev. Biol. 2013, 2, 47–63. [Google Scholar] [CrossRef]
  60. Miyazono, K.; Kamiya, Y.; Morikawa, M. Bone morphogenetic protein receptors and signal transduction. J. Biochem. 2010, 147, 35–51. [Google Scholar] [CrossRef]
  61. Meynard, D.; Kautz, L.; Darnaud, V.; Canonne-Hergaux, F.; Coppin, H.; Roth, M.-P. Lack of the bone morphogenetic protein BMP6 induces massive iron overload. Nat. Genet. 2009, 41, 478–481. [Google Scholar] [CrossRef] [PubMed]
  62. Yamazaki, M.; Fukushima, H.; Shin, M.; Katagiri, T.; Doi, T.; Takahashi, T.; Jimi, E. Tumor necrosis factor α represses bone morphogenetic protein (BMP) signaling by interfering with the DNA binding of Smads through the activation of NF-κB. J. Biol. Chem. 2009, 284, 35987–35995. [Google Scholar] [CrossRef] [PubMed]
  63. Sieber, C.; Kopf, J.; Hiepen, C.; Knaus, P. Recent advances in BMP receptor signaling. Cytokine Growth Factor Rev. 2009, 20, 343–355. [Google Scholar] [CrossRef] [PubMed]
  64. Kautz, L.; Meynard, D.; Monnier, A.; Darnaud, V.; Bouvet, R.; Wang, R.-H.; Deng, C.; Vaulont, S.; Mosser, J.; Coppin, H.; et al. Iron regulates phosphorylation of Smad1/5/8 and gene expression of Bmp6, Smad7, Id1, and Atoh8 in the mouse liver. Blood 2008, 112, 1503–1509. [Google Scholar] [CrossRef]
  65. Ono, Y.; Calhabeu, F.; Morgan, J.E.; Katagiri, T.; Amthor, H.; Zammit, P.S. BMP signalling permits population expansion by preventing premature myogenic differentiation in muscle satellite cells. Cell Death Differ. 2011, 18, 222–234. [Google Scholar] [CrossRef]
  66. Sheng, N.; Xie, Z.; Wang, C.; Bai, G.; Zhang, K.; Zhu, Q.; Song, J.; Guillemot, F.; Chen, Y.-G.; Lin, A.; et al. Retinoic acid regulates bone morphogenic protein signal duration by promoting the degradation of phosphorylated Smad1. Proc. Natl. Acad. Sci. USA 2010, 107, 18886–18891. [Google Scholar] [CrossRef]
Figure 1. Position of metastatic and primary cancers. (a) Primary tumor in the left kidney (arrow) and metastatic tumor in the left adrenal gland (arrowhead). (b) Metastatic tumor in the left adrenal gland (arrowhead). (c) Renal cell carcinoma in the upper pole of the left kidney (arrowhead).
Figure 1. Position of metastatic and primary cancers. (a) Primary tumor in the left kidney (arrow) and metastatic tumor in the left adrenal gland (arrowhead). (b) Metastatic tumor in the left adrenal gland (arrowhead). (c) Renal cell carcinoma in the upper pole of the left kidney (arrowhead).
Biology 11 00589 g001
Figure 2. Association of CXC subfamily pathways in renal cell carcinoma (adrenal cancer cells). (a) Adrenal cancer cells. (b) Renal cell carcinoma. Red star: Expression-variable genes on the pathway.
Figure 2. Association of CXC subfamily pathways in renal cell carcinoma (adrenal cancer cells). (a) Adrenal cancer cells. (b) Renal cell carcinoma. Red star: Expression-variable genes on the pathway.
Biology 11 00589 g002
Table 1. Results of the RNA sample quality test.
Table 1. Results of the RNA sample quality test.
No.Sample NameNanodropBioanalyzer
1RCC: K58-R2.002.143991.21.29.23088.1
2AG: K58-M1.992.063298.01.59.42692.7
Table 2. Mitochondrial DNA mutation sites of three samples.
Table 2. Mitochondrial DNA mutation sites of three samples.
PositionReferenceNormal CellsCancer CellsMetastatic CellsGene NamedbSNP (Build 154v2)
73AGGG rs869183622
153AGGG rs370716192
263AGGG rs2853515
489TCCC rs28625645
750AGGG rs2853518
1041AGGG rs58327546
1438AGGG rs2001030
2706AGGG rs2854128
16,223CTTT rs2853513
16,234CTTT rs368259300
16,300AGGG rs879082592
16,316AGGG rs1556424861
16,362TCCC rs62581341
Total differences384141
Y: pyrimidine (T or C), R: purine (G or A).
Table 3. Amino acid substitution sites from the three sequenced samples.
Table 3. Amino acid substitution sites from the three sequenced samples.
Nucleotide PositionReferenceK58-NK58-RK58-MAmino Acid
Gene Name
NC_012920Amino Acid Substitution Site/Abbreviation1-Letter AbbreviationCodon1-Letter AbbreviationCodon1-Letter AbbreviationCodon1-Letter Abbreviation
Table 4. K58-M using the Kyoto Encyclopedia of Genes and Genomes (KEGG) analysis; K58-M: fold change ≥2 upregulated 2243 genes (2152 genes*). * Number of genes corresponds to DAIVID.
Table 4. K58-M using the Kyoto Encyclopedia of Genes and Genomes (KEGG) analysis; K58-M: fold change ≥2 upregulated 2243 genes (2152 genes*). * Number of genes corresponds to DAIVID.
Pathway NameCount% Countp-ValueBenjamini
Complement and coagulation cascades281.301115243.48 × 10−119.84 × 109
Metabolic pathways1587.342007431.07 × 10−50.00151811
Cytokine–cytokine receptor interaction431.998141267.99 × 10−50.00753899
Glycine, serine, and threonine metabolism130.604089221.70 × 10−40.01082157
Tryptophan metabolism130.604089222.23 × 10−40.01082157
Retinol metabolism170.789962832.29 × 10−40.01082157
Chemical carcinogenesis190.882899633.93 × 10−40.0158922
Phenylalanine metabolism80.371747215.59 × 10−40.01977878
Systemic lupus erythematosus261.208178447.05 × 10−40.0221624
Steroid hormone biosynthesis150.697026028.17 × 10−40.02310869
PPAR signaling pathway160.743494420.001242540.03173786
Arachidonic acid metabolism150.697026020.001387280.03173786
Drug metabolism—cytochrome P450160.743494420.001457920.03173786
Table 5. K58-R using the Kyoto Encyclopedia of Genes and Genomes (KEGG) analysis; K58-R: fold change ≥ 2 upregulated1897 genes (1810 genes*). * Number of genes corresponds to DAIVID.
Table 5. K58-R using the Kyoto Encyclopedia of Genes and Genomes (KEGG) analysis; K58-R: fold change ≥ 2 upregulated1897 genes (1810 genes*). * Number of genes corresponds to DAIVID.
Pathway NameCount% Countp-ValueBenjamini
Cell adhesion molecules (CAMs)281.546961331.18 × 10−73.02 × 10−5
Antigen processing and presentation191.049723765.56 × 10−77.14 × 10−5
Type I diabetes mellitus130.718232045.49 × 10−64.70 × 10−4
Cytokine–cytokine receptor interaction341.878453041.38 × 10−57.76 × 10−4
Neuroactive ligand–receptor interaction372.04419891.51 × 10−57.76 × 10−4
Graft-versus-host disease110.607734811.90 × 10−58.14 × 10−4
Allograft rejection110.607734815.71 × 10−50.00209757
Primary immunodeficiency90.497237578.80 × 10−40.02827813
Calcium signaling pathway231.270718230.001490720.0425683
Dilated cardiomyopathy140.773480660.001811140.04654619
Publisher’s Note: MDPI stays neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Share and Cite

MDPI and ACS Style

Komiyama, T.; Kim, H.; Tanaka, M.; Isaki, S.; Yokoyama, K.; Miyajima, A.; Kobayashi, H. RNA-seq and Mitochondrial DNA Analysis of Adrenal Gland Metastatic Tissue in a Patient with Renal Cell Carcinoma. Biology 2022, 11, 589.

AMA Style

Komiyama T, Kim H, Tanaka M, Isaki S, Yokoyama K, Miyajima A, Kobayashi H. RNA-seq and Mitochondrial DNA Analysis of Adrenal Gland Metastatic Tissue in a Patient with Renal Cell Carcinoma. Biology. 2022; 11(4):589.

Chicago/Turabian Style

Komiyama, Tomoyoshi, Hakushi Kim, Masayuki Tanaka, Sanae Isaki, Keiko Yokoyama, Akira Miyajima, and Hiroyuki Kobayashi. 2022. "RNA-seq and Mitochondrial DNA Analysis of Adrenal Gland Metastatic Tissue in a Patient with Renal Cell Carcinoma" Biology 11, no. 4: 589.

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
