Spontaneous Osseous Fusion after Remodeling Therapy for Chronic Atlantoaxial Rotatory Fixation and Recovery Mechanism of Rotatory Range of Motion of the Cervical Spine

by
Kazuya Kitamura
1,†,
Ken Ishii
2,3,4,*,†,
Narihito Nagoshi
5,
Kazuhiro Chiba
1,
Morio Matsumoto
5,
Masaya Nakamura
5 and
Kota Watanabe
5,*
1
Department of Orthopaedic Surgery, National Defense Medical College, Saitama 359-8513, Japan
2
Department of Orthopaedic Surgery, School of Medicine, International University of Health and Welfare (IUHW), Chiba 286-8520, Japan
3
Department of Orthopaedic Surgery, International University of Health and Welfare (IUHW) Narita Hospital, Chiba 286-8520, Japan
4
Department of Orthopaedic Surgery, International University of Health and Welfare (IUHW) Mita Hospital, Tokyo 108-8329, Japan
5
Department of Orthopaedic Surgery, Keio University School of Medicine, Tokyo 160-8582, Japan
*
Authors to whom correspondence should be addressed.
†
These authors contributed equally to this work.
J. Clin. Med. 2022, 11(6), 1504; https://doi.org/10.3390/jcm11061504
Submission received: 20 January 2022 / Revised: 7 March 2022 / Accepted: 8 March 2022 / Published: 9 March 2022
(This article belongs to the Special Issue Minimally Invasive Spinal Treatment: State of the Art)
Browse Figures
Review Reports Versions Notes

Abstract

:
We aimed to investigate the risk factors of spontaneous osseous fusion (SOF) of the atlantoaxial joint after closed reduction under general anesthesia followed by halo fixation (remodeling therapy) for chronic atlantoaxial rotatory fixation, and to elucidate the recovery mechanism of the rotatory range of motion (ROM) after halo removal. Twelve patients who underwent remodeling therapy were retrospectively reviewed. Five patients with SOF were categorized as the fusion group and seven patients without SOF as the non-fusion group. Three dimensional CT was used to detect direct osseous contact (DOC) of facet joints before and during halo fixation, while dynamic CT at neutral and maximally rotated head positions was performed to measure rotatory ROM after halo removal. The duration from onset to initial visit was significantly longer (3.2 vs. 5.7 months, p = 0.04), incidence of DOC during halo fixation was higher (0/7 [0%] vs. 4/5 [80%], p = 0.004), and segmental rotatory ROM of Occiput/C1 (Oc/C1) at final follow-up was larger (9.8 vs. 20.1 degrees, p = 0.003) in the fusion group. Long duration from the onset to the initial visit might induce irreversible damage to the articular surface of the affected facet, which was confirmed as DOC during halo fixation and resulted in SOF. Long duration from the onset to the initial visit and DOC during halo fixation could be used to suggest the risk for SOF. Nonetheless, rotatory ROM of Oc/C1 increased to compensate for SOF.

1. Introduction

Atlantoaxial rotatory fixation (AARF) is observed mainly in children. Patients suffer from neck pain and typically present a “cock-robin” position of the head and neck with limited range of motion (ROM) of the cervical spine. Acute AARF usually responds well to conservative treatment with a collar and traction if necessary. However, longer duration from the onset to the initial visit and delayed diagnosis can result in failure of conservative treatment and increase the requirement for more invasive treatment such as surgical reduction and fixation [1,2]. Fractures and congenital bone anomalies also need to be focused as a potential cause of AARF [3,4,5,6]. Accordingly, transition from acute to chronic or recurrent AARF needs to be prevented. Nonetheless, a recent systematic review concluded that there is a lack of high-quality data to determine the optimal nonsurgical treatment strategy [2].
The treatment strategy for chronic or recurrent AARF remains controversial. Surgical intervention used to be the mainstream treatment option for chronic AARF. Fielding and Hawkins [7] reported a series of 17 patients with chronic AARF and recommended surgery when the anterior displacement of the atlas is more than four millimeters. Parkih et al. [8] indicated surgical treatment when the duration from the onset to the initial visit is longer than three months. In subsequent clinical studies, several algorithms were advocated as the treatment of chronic AARF. Phillips and Hensinger [9] and Pang and Li [10] proposed halter or skull caliper tractions as an initial treatment, followed by halo fixation when reduction is achieved or surgical reduction and posterior fixation when the subluxation is irreducible or recurrent. Crossman et al. [11] proposed to start with a trial of halo traction to reduce subluxation. When reduced, the halo traction is converted to halo jacket fixation for three months. When not reduced, subluxation is surgically reduced followed by halo fixation, without surgical fixation of the atlantoaxial joint, to maintain the rotatory movement. However, surgical invasiveness and relatively high recurrence rate [9,10] were of concern in these treatment algorithms. Hence, even for chronic AARF, several studies have reported the efficacy of conservative treatments to reduce the invasiveness of the treatment, including rehabilitation [12], simple traction and bracing [13], halter traction and bracing [14,15,16,17], and closed manipulation under general anesthesia followed by external fixation [18,19,20,21,22,23].
We reported that chronic irreducible and recurrent unstable AARF can be managed successfully by “remodeling therapy,” a careful closed manipulation under general anesthesia followed by halo-vest fixation that obviates the need for surgical intervention [24,25]. Remodeling of C2 superior facet deformity is induced during halo fixation and can be detected on follow-up computed tomography (CT) images. It is a useful radiographic parameter to determine the appropriate period of halo fixation to prevent the recurrence of subluxation. However, we have experienced several cases in which occiput (Oc)-C1, C1-C2, or C2-C3 segment was osseously fused after remodeling therapy. It was hypothesized that there should be clinical (e.g., demographics of patients, duration from the onset, duration of halo fixation) and radiological findings (e.g., magnitude of sub-luxation, reduction during halo fixation) which suggest the risk of spontaneous osseous fusion (SOF). Interestingly, even when affected segments were osseously fused, rotatory range of motion (ROM) of the cervical spine recovered gradually after halo removal. The purpose of this study was to investigate the incidence and risk factors of SOF after remodeling therapy, and to reveal the mechanism to regain rotatory ROM of the cervical spine after the halo removal.

2. Materials and Methods

2.1. Patient Population

The subjects consisted of consecutive 23 patients with chronic AARF who underwent remodeling therapy for chronic AARF [19,24,25] at Keio University Hospital from 2009 to 2016. Following approval from the institutional review board, we performed a retrospective review of clinical records of 12 patients (three boys and nine girls) who received dynamic CT images at the initial visit and during follow-ups. All patients were referred to our hospital due to persistent torticollis which had been resistant to the primary conservative treatment for more than 1.5 months. They presented with neck pain and exhibited a so-called “cock-robin” posture with the head rotated to one side and flexed laterally to the other side in addition to restricted neck motion. The onset date of torticollis was provided by the referral letter from the hospital or clinic of origin, and was also confirmed by interview to the patient at our hospital.

2.2. Diagnosis and Grading of AARF

All patients underwent plain cervical radiography and CT scanning at the initial visit to exclude underlying fractures and congenital deformities [3,4,5,6]. The diagnosis of chronic AARF was established in all cases by confirming the deformity of the C2 superior facet (C2 facet deformity) on three dimensional CT reconstructions (3D-CT). The C1 lateral inclination angle was measured on 3D CT as we reported previously [24]. AARF was classified according to Fielding’s classification [7] and Ishii’s grading system [24]. Ishii’s grading system is based on the magnitude of both C2 facet deformity and C1 lateral inclination observed on 3D-CT: Grade I, AARF without C2 facet deformity or C1 lateral inclination; Grade II, with C2 facet deformity and C1 lateral inclination <20°; Grade III, with C2 facet deformity and C1 lateral inclination ≥20° [24].

2.3. Remodeling Therapy of AARF and Imaging Analyses

All patients underwent the following remodeling therapy: (1) careful closed manipulation and reduction of the atlantoaxial joint under general anesthesia; (2) halo-vest fixation to maintain reduction; (3) halo removal when the remodeling of C2 facet deformity was confirmed on 3D-CT; (4) gentle neck rotation exercise in supine position for approximately 10 min, three times per day [15,20,21]. During and after the remodeling therapy, follow-up CT scans were performed right after closed reduction/halo fixation to confirm the reduction and at two and three months (if necessary) after halo fixation to confirm the remodeling of the C2 facet deformity. Presence or absence of direct osseous contact (DOC) of facet joints and SOF of vertebrae were evaluated using sagittal and coronal CT images at the initial visit and during and after halo fixation. DOC was defined as disappearance of facet joint space between the adjacent vertebrae (Figure 1B and Figure 2B,D). At some time points after halo removal, all patients underwent dynamic CT examination, which was examined in three different positions (i.e., the neutral position and maximally rotated positions to both sides) as proposed by Pang and Li [26,27]. Using the final follow-up dynamic CT images, the angles made by Oc, C1, C2, C3, and C4 with the vertical line (rotatory vertebra angle) were recorded respectively as vertebrae angles (Oc~C4 angle) on the maximum rotated head position to each side [26,27]. Separation angles (subtraction of the rotatory vertebra angles) between adjacent vertebrae were calculated at each segment on each head position, and the sum of the separation angles in each head position was defined as the segmental rotatory range of motion (rotatory ROM: Oc/C1~C3/C4) [26,27]. For all CT scans, low-dose (one-fifth) radiation exposure was used in all 12 patients (Canon Medical Systems, Otawara, Japan. Aquilione ONE, e.g., setting of 2 mm slice thickness, 80 kV, 100 mA, CT Dose Index [CTDI] 2.60 mGy, with a 0.35-s scan time). In addition to the CT measurements, macroscopic rotatory ROM of the cervical spine was measured at the initial visit, at two weeks after halo removal, and at the final follow-up as previously reported [25]. Outward rotatory ROM of the cervical spine was also measured. The angle by the midline with the line connecting occiput and nose was measured from overhead on the maximum rotated head position to each side in a sitting position. The sum of these angles on each head position was defined as macroscopic rotatory ROM.

2.4. Study Groups

Five patients (5/12, 41.7%) whose images showed SOF of the cervical spine after remodeling therapy were grouped in the SOF group. The other 7 patients (7/12, 58.3%) without SOF during the follow-up period were grouped in the Non-SOF group. Clinical (i.e., age, sex, cause of AARF, duration from onset to initial visit, duration of halo fixation, macroscopic rotatory ROM) and radiographic data including plain radiographs and plain and 3D CT (atlantodental interval [ADI], C1 lateral inclination, Fielding’s classification, Ishii’s grading, DOC, SOF, segmental rotatory ROM) were retrospectively reviewed in both groups.

2.5. Statistical Analyses

Continuous variables were presented as mean ± standard deviation (SD). A comparison of each independent continuous variable (i.e., age, duration from onset to initial visit, C1 lateral inclination, duration of halo fixation, Macroscopic cervical ROM, segmental rotatory ROM, time from reduction to final CT) between the two groups was performed using an independent t-test. A paired t-test was used to analyze the change in macroscopic ROM of the cervical spine from two weeks after halo removal to the final follow-up. The Fisher’s exact test and the chi-square test for independence were used to analyze discrete variables (i.e., sex distribution, cause of AARF, Fielding’s classification, Ishii’s grading, presence or absence of DOC of facet joints). Statistical Package for the Social Sciences (SPSS, version 24; IBM Corp., Armonk, NY, USA) was used for all statistical analyses. Probability values of less than 0.05 were used to denote statistical significance. Post hoc power analyses were performed for the variables with statistical significance (p < 0.05) by G*Power (Franz Faul, Kiel University, Kiel, Germany. Version 3.1.9.6).

2.6. Compliance with Ethical Standards

We certified that all applicable institutional and governmental regulations concerning the ethical use of human participants and the ethical standards in the 1964 Declaration of Helsinki and its later amendments were followed during the research. Informed consent was obtained from all participants in the study. This study was approved by the Institutional Review Board of Keio University School of Medicine (IRB No. 20110142).

3. Results

3.1. Patient Characteristics and Incidence of Spontaneous Osseous Fusion

The characteristics of the 12 patients included are summarized in Table 1. The mean age at the initial visit was 7.6 ± 2.0 years (range 4.3–11.6). The mean duration from the onset of torticollis to the initial visit to our institute was 4.3 ± 2.2 months (range 1.5–8.8). The mean follow-up period was 6.3 ± 2.4 years (range 1.8–8.9). The most frequent cause of torticollis was upper respiratory tract infection (4/12, 33.3%), followed by an incidental minor trauma (2/12, 16.7%) and lymphangitis (2/12, 16.7%). Out of the 12 patients, spontaneous osseous fusions of adjacent vertebrae were confirmed in five patients (SOF group, 41.7%) after remodeling therapy: one in Oc/C1 (case 10), one in Oc/C1/C2 (case 8), two in C1/C2 (case 9 and 11) and one in C2/C3 (case 12). In all five patients, osseous fusions were confirmed on follow-up CT after halo removal, and not at the initial visit or during halo fixation.

3.2. Comparison of Clinical and Radiological Findings

The comparison of clinical and imaging variables between the two groups are summarized in Table 2. There were no significant differences in the mean age at the initial visit (non-SOF vs. SOF: 8.1 [range 7–9] vs. 7.3 [range 4–11], p = 0.489), sex distribution (male percentage, 2/5 [40%] vs. 1/7 [14.3%], p = 0.523), and the causes of chronic AARF (p = 0.334). In the SOF group, the mean duration from the onset of torticollis to the initial visit was significantly longer than that in the non-SOF group (3.2 ± 1.4 [range 1.5–6.0] vs. 5.7 ± 2.3 [range 3.4–8.8] months, p = 0.040, statistical power 0.52) (Table 2). The mean duration of halo fixation was similar in both groups (2.5 ± 0.4 vs. 2.9 ± 0.7 months, p = 0.221).
The radiological classification of AARF at the initial visit assessed by Fielding’s classification (p = 0.180) and Ishii’s grading (p = 0.079) was similar in both groups, although the incidence of Ishii grade III was likely to be higher in the SOF group compared to the non-SOF group. The mean C1 lateral inclination angles (non-SOF vs. SOF: 15.6 ± 13.9 vs. 21.8 ± 5.3, p = 0.369) and the mean atlantodental intervals (ADI, 5.0 ± 3.6 vs. 7.3 ± 2.5, p = 0.260) were larger in the SOF group but without statistical significance.

3.3. Direct Osseous Contact of the Facet Joint before and during Halo Fixation

In the non-SOF group, DOCs of facet joints at the initial visit were assessed in five patients excluding two patients whose 3D CTs were not obtained. DOCs were detected at the C1/C2 facet joint of the dislocated side in three out of five patients (60%) at the initial visit. However, DOCs disappeared after reduction and were not found in any patients during halo fixation (0%) (Table 1 and Table 2, and Figure 1).
In the SOF group, excluding one patient whose 3D CTs were not obtained (case 8), four out of four patients (100%) showed DOCs at the initial visit (three patients [case 9, 11, and 12] at the unilateral C1/C2 facet of the dislocated side and another patient [case 10] at the C1/C2 facet of the dislocated side and at the Oc/C1 facet of the contralateral side, Table 1). After reduction, DOCs disappeared in one patient (case 10), disappeared but another DOC was detected at the caudal segment in the contralateral side in one patient (case 12), and persisted at the same segment in two patients (case 9 and 11) (Figure 2). Therefore, four out of five patients (80%), including one patient whose 3D CT at the initial visit was not obtained (case 8), showed DOCs during halo fixation. Case 10 was the only case that showed spontaneous osseous fusion at the segment where DOC was found only at the initial visit and disappeared after reduction and during halo fixation.
The incidence of DOCs of facet joints was similar at the initial visit in both groups (non-SOF vs. SOF: 3/5 [60%] vs. 4/4 [100%], p = 0.151), which might be biased due to the exclusion of two patients in the non-SOF group and one patient in the SOF group due to the unavailability of 3D CTs. However, the incidence was significantly higher in the SOF group during halo fixation (0/7 [0%] vs. 4/5 [80%], p = 0.004, statistical power 1.0) (Table 2). The sensitivity of DOC during halo fixation to predict SOF after halo removal was 80% (four out of five), the specificity was 100% (seven out of seven), the positive predictive value was 100% (four out of four), and the negative predictive value was 87.5% (seven out of eight). The percentage of SOF of the segments with DOC during halo fixation was likely to be higher than that of the segments with DOC at the initial visit (4/4 [100%] vs. 3/7 [42.9%], p = 0.058) (Table 1).

3.4. Recovery of Rotatory ROM after Halo Removal

All 12 patients showed gradual recovery of rotatory ROM of the cervical spine after halo removal and had no impairment in activities of daily living. Macroscopic rotatory ROM of the cervical spine was significantly smaller in the SOF group than in the non-SOF group at all three time points (i.e., at the initial visit, two weeks after halo removal, and at the final follow-up) (Table 2). Statistical power was 0.74, 1.0, and 0.99, respectively. Patients in the NF group showed almost full recovery of macroscopic rotatory ROM [28,29,30] within two weeks after halo removal (173.0 ± 5.9), which was maintained at the final follow-up (174.3 ± 3.8, p = 0.235). In contrast, patients in the SOF group showed almost no recovery within two weeks after halo removal (57.0 ± 4.1), followed by gradual but significant recovery until the final follow-up (118.3 ± 26.3, p = 0.018).
The mean duration from reduction to the final follow-up dynamic CT was significantly longer in the SOF group (37.8 ± 15.0 months) than in the non-SOF group (8.3 ± 3.6 months, p = 0.011). The segmental rotatory ROM of C1/C2 in the non-SOF group was 50.7 ± 9.9 degrees at the final follow-up. As shown in Table 2, on the final follow-up of dynamic CTs, patients in the SOF group were likely to show larger rotatory ROMs at caudal adjacent C2/C3 (non-SOF vs. SOF: 7.9 ± 3.2 degrees vs. 13.0 ± 3.4, p = 0.051) and C3/C4 (12.0 ± 2.8 vs. 15.4 ± 3.4, p = 0.115) than those in the non-SOF group. The segmental rotatory ROM at rostrally adjacent Oc/C1 was significantly larger in the SOF group than in the non-SOF group (9.8 ± 3.5 vs. 20.1 ± 2.3, p = 0.003, statistical power 0.99).

4. Discussion

In the current study, five out of the twelve patients (41.7%) exhibited SOF of the affected segments after remodeling therapy for chronic AARF. Longer duration from the onset of torticollis to the initial visit and DOCs of the facet joints during halo fixation were identified as potential risk factors for SOF. Additionally, for the first time, we revealed that rotatory ROM at the adjacent segments of the fused segment, specifically at Oc/C1, increased and contributed to the recovery of rotatory ROM of the cervical spine.

4.1. Spontaneous Osseous Fusion after Halo Traction/Fixation

Previous studies have reported that long-term subluxation of C1/C2 can result in the deformity and osseous/fibrous union of the segment that prevents successful reduction [10,24,27,31]. However, it remained unknown whether SOF can also occur after conservative treatment for chronic AARF [13,17], including remodeling therapy. Dove et al. [32] reported an SOF of the cervical spine as a complication after halo-pelvic traction for stiff spinal deformities (e.g., a tuberculous kyphosis and an idiopathic scoliosis). The duration of halo-pelvic traction was longer than 3 months, and most of the patients were older than 11 years. The fusion segments were found between C2 and C5. The authors hypothesized that the distraction force might have resulted in the disturbance of bony attachments of the cervical ligaments, causing local hemorrhage and later bone formation. This hypothesis may explain one potential mechanism of SOF induced by traumatic damage, though the ages of the patients, etiology, and duration of halo fixation were different from those in the current study. Krengel et al. [33] reported an SOF between Oc and C2 after closed reduction and halo fixation for chronic AARF in an 11-year-old boy. The duration from the onset to the initial visit was 6 months, and the duration of halo fixation was 3 months, which were similar to our study. Consistent with our series, the osseous fusion was confirmed after halo removal. The patient was found to be HLA-B27 positive, and the spontaneous fusion of the cervical spine has been reported to often occur in ankylosing spondyloarthropathy [34]. Accordingly, these authors suggested the possibility of pre-existing inflammatory condition caused by HLA-B27-related spondyloarthropathy, as well as ankylosis of C1/C2 at the initial visit and possible trauma to the joint during closed reduction, could have contributed to the development of osseous fusion.
In the current study, five out of the twelve patients (41.7%) exhibited SOF. Long duration from the onset to the initial visit and DOCs of the facet joints during halo fixation were identified as potential risk factors for SOF. DOC, which is the disappearance of joint space, may indicate damage to the articular cartilage. Damage to the articular cartilage leading to osteoarthritis of the affected facet joints may consequently result in SOF [11]. All patients in the non-SOF group showed DOC only at the initial visit, and DOC disappeared after reduction and during halo fixation (Figure 1, Table 1). On the other hand, in the SOF group, DOC at the initial visit persisted during halo fixation, even after subluxation was well reduced (Figure 2, Table 1). As shown in Case 10 (Table 1), the segment with DOC only at the initial visit also resulted in SOF, unlike the non-SOF group. Additionally, in terms of the recovery pattern of the macroscopic rotatory ROM of the cervical spine, the two groups showed obviously different processes after similar duration of halo fixation. The rotatory ROM was already significantly smaller in the SOF group than in the non-SOF group at the initial visit. Furthermore, patients in the SOF group showed almost no recovery at two weeks after halo removal, whereas those in the non-SOF group showed almost full recovery at the same time point (Table 2). These radiological and clinical findings seem to reflect one aspect of the severity of subluxation, which well-validated measures (i.e., Fielding’s classification and Ishii’s grading) cannot fully reflect due to the complexity in the pathophysiology of chronic AARF. It might be better to classify the severity of chronic AARF more comprehensively from the clinical as well as the morphologic perspective, as with the AO Spine Subaxial Cervical Spine Injury Classification System [35]. Therefore, we presume that DOC during halo fixation, limited rotatory ROM after halo removal, and resulting SOF might be dependent not on halo fixation itself, but on the severity of the damage of the affected facet joints that was already developed at the time of the initial visit. Significantly longer duration from the onset to the initial visit could have damaged the joint cartilage more severely in the SOF group than in the non-SOF group. It is hypothesized that, when the damage of the facet joint is already irreversible at the initial visit, DOC is likely to persist even after successful reduction and result in joint contracture and SOF. However, it was difficult to evaluate the damage using our CT images because we tried to minimize the radiation exposure using modalities just sufficient to recognize the obvious bony landmarks. Precise evaluation of the severity and area of the damage to joint cartilage is required to clarify this hypothesis. Magnetic resonance imaging (MRI) can be a safer alternative method regarding the issue of radiation exposure. Additionally, MRI is useful to evaluate the extent of inflammation at the atlantoaxial joint and its surrounding anatomical structures (e.g., retropharyngeal space, paranasal sinuses).
We previously revealed that a prominent lateral inclination of C1 is an impeding factor for reduction of chronic AARF and indicates an irreducible subluxation when greater than 20° [24]. Crockard, et al. reported that reduction is most likely to be prevented by the development of abundant fibrous tissue at C1/C2 [10,27,31]. Ishii’s grading also explains the severity of AARF according to a time-dependent process from the acute to the chronic phase of AARF [24]. Although there were no significant differences in the incidence of Ishii type 3 and C1 lateral inclination between the two groups at the initial visit, a significantly longer duration from the onset to the initial visit might have made the reduction more difficult in the SOF group, requiring over-correction of the atlas to the contralateral side, which might have induced another DOC on the contralateral side at the caudal adjacent segment, as seen in Case 12 (Table 1). Adjustment of the head position may be considered when a new DOC is found at the adjacent segment on the 3D-CT immediately after reduction.

4.2. Compensatory Mechanism to Gain Rotatory ROM after Halo Removal

A previous study reported that patients with chronic AARF showed reduced rotatory ROM of the cervical spine after open reduction and halo fixation but regained some rotatory ROM [11]. We reported that rotatory ROM of the cervical spine was limited after halo removal when C1/C2 fibrous contracture developed or the articular surface of the C1/C2 facet was damaged by traumatic events, but gradually improved during the follow-up [24,25]. However, the mechanism of the recovery remained unclear.
In the current study, it is noteworthy that patients in the SOF group showed gradual but significant recovery of rotatory ROM of the cervical spine until the final follow-up. Interestingly, those patients showed significantly increased segmental rotatory ROM at Oc/C1 and were likely to show larger rotatory ROM at the caudal adjacent segments (C2/C3 and C3/C4) than those in the non-SOF group at the final follow-up (Table 2). In contrast to the atlantoaxial joint which allows movements in all directions [36], the major motion at Oc/C1 is considered flexion and extension and the movement of rotation is a coupled motion [37], because of the cradle structure of the Oc/C1 joint and the lack of direct muscle involvement in the rotation [38]. The reported rotatory ROMs at the Oc/C1 segment to each side (i.e., right or left) are similar, ranging from 1.7° to 3.9°, measured by an MRI [20] or the CT [39,40,41] 3D reconstruction method and dual fluoroscopic imaging and model registration techniques [42,43] in healthy adults, and less than 3° in normal children younger than 12 years [26].Compared to these values in normal subjects, this study revealed markedly increased rotatory ROM of Oc/C1 in the SOF group (20.1 ± 2.3) as well as in the non-SOF group (9.8 ± 3.5). These findings suggest the possibility that rotatory ROM at adjacent segments increased to compensate for the C1/C2 segment, especially when the segment was osseously fused. Sternocleidomastoid (SCM) inserts into the mastoid process of the skull to allow for greater moment arm for head rotation than with rotator cervicis within the cervical spine, and work as a major rotator of the head on the cervical spine. This anatomical consideration might explain why the compensatory increase in the segmental rotatory ROM was predominant at rostrally adjacent Oc/C1 than caudally adjacent segments. Additionally, duration from reduction to the final follow-up of dynamic CT was significantly longer in the SOF group (27.7 ± 6.7 months) than in the non-SOF group (8.3 ± 3.6 months). We presume that rotatory ROM of Oc/C1, as well as caudally adjacent segments, might increase over time after halo removal to compensate for the affected C1/C2 joint as the natural history, regardless of the presence or absence of SOF.

4.3. Limitations

The present study has several limitations. First, this study is a retrospective comparative study that included only a small number of patients and can carry the risk of sample bias. The statistical power of the independent t test for the duration from onset to initial visit was small (0.52). Multivariate logistic regression analysis was not performed to investigate the independent predictors of SOF because of the small sample size. Univariate analysis was not performed because the incidence of DOC during halo fixation was 0% in the non-SOF group, and the odds ratio could not be calculated. Second, the dynamic behavior of the segments below C4 down to the thoracic spine after remodeling therapy remains unclear. Their contribution to the recovery of rotatory ROM of the cervical spine needs to be examined. Third, long term follow-up by dynamic CT is desired to examine the changes in the rotatory ROM at each segment as natural history after the remodeling therapy, and to identify the timing when the osseous fusion is completed. Due to the issue of radiation exposure, we had to limit the frequency and area of CT scans. Additionally, long term effects of the compensation in the ROMs of proximally and distally adjacent segments should be investigated, because the adjacent segments may result in osteoarthritis at earlier time point. Fourth, values of segmental rotatory ROMs of the cervical spine in healthy subjects were not examined in this study. These values may clarify the compensatory mechanism to regain rotatory ROM by assessing the changes in rotatory ROM at each segment after the remodeling therapy.

5. Conclusions

To the best of our knowledge, this is the first study to report the incidence of SOF after the remodeling therapy for chronic AARF, its risk factors, and a possible mechanism to regain rotatory ROM of the cervical spine after halo removal. Long duration from the onset to the initial visit and DOC during halo fixation could be used to suggest the risk for SOF. DOC during halo fixation, limited rotatory ROM after halo removal, and resulting SOF might be dependent not on halo fixation itself, but on the severity of the damage of the affected facet joints which had already developed at the time of the initial visit. The primary purpose of remodeling therapy is to prevent the recurrence of subluxation without fixing the C1/C2 joint thereby preserving the C1/C2 rotatory motion. Even if unfavorable SOF occurs after the remodeling therapy, recurrence of subluxation, the primary purpose, can still be achieved without causing any surgical impact to the patients. Even in such a case, limited rotatory ROM is compensated, at least in part, by increased motion in the adjacent segments, especially the rostral Oc/C1.
This study provides clinical insights that will help surgeons to understand the dynamic behavior of the cervical spine after remodeling therapy and to select a less invasive treatment for chronic AARF, obviating surgical invasiveness.

Author Contributions

Conceptualization, K.I. and K.K.; methodology, K.I. and K.K.; validation, K.I. and K.K.; formal analysis, K.K.; investigation, K.K.; resources, K.I., K.W., M.M., M.N. and K.C.; data curation, K.I. and K.K.; writing—original draft preparation, K.K.; writing—review and editing, K.I., K.K., N.N., K.W., M.M., M.N. and K.C.; visualization, K.I. and K.K.; supervision, K.I. and K.W.; project administration, K.I., K.W., M.M., M.N. and K.C. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Institutional Review Board Statement

The study was conducted in accordance with the Declaration of Helsinki, and approved by the Institutional Review Board of Keio University School of Medicine (protocol code 20110142).

Informed Consent Statement

Informed consent was obtained from all subjects involved in the study.

Data Availability Statement

The data presented in this study are available on request from the corresponding author. The data are not publicly available due to ethical and privacy restrictions.

Conflicts of Interest

The authors declare no conflict of interest.

Abbreviations and Terminology

AARFAtlantoaxial Rotatory Fixation
Chronic AARFPersistent or recurrent AARF which is resistant to the primary conservative treatment and exhibits C2 facet deformity on 3D CT images.
Remodeling therapyConservative treatment strategy for chronic AARF. By a careful closed reduction of atlantoaxial under general anesthesia followed by halo fixation, the remodeling of C2 facet deformity is obtained, preventing recurrence of subluxation.
SOFSpontaneous Osseous Fusion of affected vertebrae which is confirmed after remodeling therapy for chronic AARF
DOCDirect Osseous Contact of facet joints which is defined as disappearance of facet joint space between the adjacent vertebrae on sagittal or coronal CT images.
Segmental rotatory ROMRange of motion (ROM) of axial rotation at each segment (e.g., Oc/C1, C2/C3). ROM is measured using dynamic CT images examined in three different head positions (i.e., the neutral position and maximally rotated positions to both sides).
Macroscopic rotatory ROMOutward rotatory ROM of the cervical spine which is measured from overhead in a sitting position and is defined as the sum of the angles made by the midline with the line connecting occiput and nose on the maximum rotated head position to each side.

References

  1. Pitzen, T.; Ruf, M.; Meyer, C.; Drumm, J. Atlantoaxial Rotatory Dislocation: Delayed Diagnose Will Result in More Invasive Treatment Options. J. Neurol. Surg. Part A Cent. Eur. Neurosurg. 2021, 82, 1–8. [Google Scholar] [CrossRef] [PubMed]
  2. Sae-Huang, M.; Borg, A.; Hill, C.S. Systematic review of the nonsurgical management of atlantoaxial rotatory fixation in childhood. J. Neurosurg. Pediatrics 2021, 27, 108–119. [Google Scholar] [CrossRef] [PubMed]
  3. Perrini, P.; Montemurro, N. Congenital absence of a cervical spine pedicle. Neurol. India 2016, 64, 189. [Google Scholar] [CrossRef] [PubMed]
  4. Rodriguez-Romero, R.; Vargas-Serrano, B.; Carro-Martinez, A. Congenital absence of the neural arch in the cervical spine: An extreme form of pedicle absence. Eur. J. Radiol. 1995, 20, 100–104. [Google Scholar] [CrossRef]
  5. Smoker, W.R. Congenital anomalies of the cervical spine. Neuroimag. Clin. N. Am. 1995, 5, 427–449. [Google Scholar]
  6. Wiener, M.D.; Martinez, S.; Forsberg, D.A. Congenital absence of a cervical spine pedicle: Clinical and radiologic findings. Am. J. Roentgenol. 1990, 155, 1037–1041. [Google Scholar] [CrossRef]
  7. Fielding, J.; Hawkins, R. Atlanto-axial rotatory fixation. (Fixed rotatory subluxation of the atlanto-axial joint). J. Bone Jt. Surg. 1977, 59, 37–44. [Google Scholar] [CrossRef]
  8. Parikh, S.N.; Crone, K.R.; Crawford, A.H. Chronic Atlantoaxial Rotatory Fixation with Anterolisthesis: Case Report. J. Trauma Acute Care Surg. 2004, 57, 392–395. [Google Scholar] [CrossRef]
  9. Phillips, W.A.; Hensinger, R.N. The management of rotatory atlanto-axial subluxation in children. J. Bone Jt. Surg. 1989, 71, 664–668. [Google Scholar] [CrossRef]
  10. Pang, D.; Li, V. AtlantoAxial Rotatory Fixation: Part 3—A Prospective Study of the Clinical Manifestation, Diagnosis, Management, and Outcome of Children with AlantoAxial Rotatory Fixation. Neurosurgery 2005, 57, 954–972. [Google Scholar] [CrossRef]
  11. Crossman, J.E.; David, K.; Hayward, R.; Crockard, H.A. Open reduction of pediatric atlantoaxial rotatory fixation: Long-term outcome study with functional measurements. J. Neurosurg. Spine 2004, 100, 235–240. [Google Scholar] [CrossRef] [PubMed]
  12. Hsu, P.-T.; Chung, H.-Y.; Wang, J.-L.; Lew, H.L. Successful Conservative Treatment of Chronic Atlantoaxial Rotatory Fixation in a Child with Torticollis. Am. J. Phys. Med. Rehabil. 2010, 89, 776–778. [Google Scholar] [CrossRef] [PubMed]
  13. Burkus, J.K.; DePonte, R.J. Chronic Atlantoaxial Rotatory Fixation Correction by Cervical Traction, Manipulation, and Bracing. J. Pediatric Orthop. 1986, 6, 631–635. [Google Scholar] [CrossRef] [PubMed]
  14. Beier, A.D.; Vachhrajani, S.; Bayerl, S.H.; Aguilar, C.Y.D.; Lamberti-Pasculli, M.; Drake, J.M. Rotatory subluxation: Experience from the Hospital for Sick Children. J. Neurosurg. Pediatrics 2012, 9, 144–148. [Google Scholar] [CrossRef] [PubMed]
  15. Glotzbecker, M.P.; Wasser, A.M.; Hresko, M.T.; Karlin, L.I.; Emans, J.B.; Hedequist, D.J. Efficacy of Nonfusion Treatment for Subacute and Chronic Atlanto-Axial Rotatory Fixation in Children. J. Pediatric Orthop. 2014, 34, 490–495. [Google Scholar] [CrossRef] [PubMed]
  16. Ortiz, G.L.; Pratts, I.; Ramos, E. Grisel’s syndrome: An unusual cause of torticollis. J. Pediatric Rehabil. Med. 2013, 6, 175–180. [Google Scholar] [CrossRef]
  17. Park, S.W.; Cho, K.H.; Shin, Y.S.; Kim, S.H.; Ahn, Y.H.; Cho, K.G.; Huh, J.S.; Yoon, S.H. Successful reduction for a pediatric chronic atlantoaxial rotatory fixation (Grisel syndrome) with long-term halter traction: Case report. Spine 2005, 30, E444–E449. [Google Scholar] [CrossRef]
  18. Akbay, A.; Bilginer, B.; Akalan, N. Closed manual reduction maneuver of atlantoaxial rotatory dislocation in pediatric age. Child’s Nerv. Syst. 2014, 30, 1083–1089. [Google Scholar] [CrossRef]
  19. Ishii, K.; Toyama, Y.; Nakamura, M.; Chiba, K.; Matsumoto, M. Management of Chronic Atlantoaxial Rotatory Fixation. Spine 2012, 37, E278–E285. [Google Scholar] [CrossRef]
  20. Ishii, T.; Mukai, Y.; Hosono, N.; Sakaura, H.; Nakajima, Y.; Sato, Y.; Sugamoto, K.; Yoshikawa, H. Kinematics of the upper cervical spine in rotation: In vivo three-dimensional analysis. Spine 2004, 29, E139–E144. [Google Scholar] [CrossRef]
  21. Mifsud, M.; Abela, M.; Wilson, N.I. The delayed presentation of atlantoaxial rotatory fixation in children: A review of the management. Bone Jt. J. 2016, 98, 715–720. [Google Scholar] [CrossRef] [PubMed]
  22. Ozalp, H.; Hamzaoglu, V.; Avci, E.; Karatas, D.; Ismi, O.; Talas, D.U.; Bagdatoglu, C.; Dagtekin, A. Early diagnosis of Grisel’s syndrome in children with favorable outcome. Child’s Nerv. Syst. 2018, 35, 113–118. [Google Scholar] [CrossRef] [PubMed]
  23. Dahdaleh, N.S.; Dlouhy, B.J.; Menezes, A.H. One-Step Fixation of Atlantoaxial Rotatory Subluxation: Technical Note and Report of Three Cases. World Neurosurg. 2013, 80, e391–e395. [Google Scholar] [CrossRef] [PubMed]
  24. Ishii, K.; Chiba, K.; Maruiwa, H.; Nakamura, M.; Matsumoto, M.; Toyama, Y. Pathognomonic radiological signs for predicting prognosis in patients with chronic atlantoaxial rotatory fixation. J. Neurosurg. Spine 2006, 5, 385–391. [Google Scholar] [CrossRef]
  25. Ishii, K.; Matsumoto, M.; Momoshima, S.; Watanabe, K.; Tsuji, T.; Takaishi, H.; Nakamura, M.; Toyama, Y.; Chiba, K. Remodeling of C2 facet deformity prevents recurrent subluxation in patients with chronic atlantoaxial rotatory fixation: A novel strategy for treatment of chronic atlantoaxial rotatory fixation. Spine 2011, 36, E256–E262. [Google Scholar] [CrossRef]
  26. Pang, D.; Li, V. Atlantoaxial Rotatory Fixation: Part 1—Biomechanics OF Normal Rotation at the Atlantoaxial Joint in Children. Neurosurgery 2004, 55, 614–626. [Google Scholar] [CrossRef]
  27. Pang, D.; Li, V. Atlantoaxial Rotatory Fixation: Part 2—New Diagnostic Paradigm and a New Classification Based on Motion Analysis Using Computed Tomographic Imaging. Neurosurgery 2005, 57, 941–953. [Google Scholar] [CrossRef]
  28. Arbogast, K.B.; Gholve, P.A.; Friedman, J.E.; Maltese, M.R.; Tomasello, M.F.; Dormans, J.P. Normal Cervical Spine Range of Motion in Children 3–12 Years Old. Spine 2007, 32, E309–E315. [Google Scholar] [CrossRef]
  29. Castro, W.H.M.; Sautmann, A.; Schilgen, M.; Sautmann, M. Noninvasive Three-Dimensional Analysis of Cervical Spine Motion in Normal Subjects in Relation to Age and Sex. Spine 2000, 25, 443–449. [Google Scholar] [CrossRef]
  30. Dvorak, J.; Antinnes, J.A.; Panjabi, M.; Loustalot, D.; Bonomo, M. Age and Gender Related Normal Motion of the Cervical Spine. Spine 1992, 17, S393–S398. [Google Scholar] [CrossRef]
  31. Crockard, H.A.; Rogers, M.A. Open Reduction of Traumatic Atlanto-Axial Rotatory Dislocation with Use of the Extreme Lateral Approach. A Report of Two Cases. J. Bone Jt. Surg. 1996, 78, 431–436. [Google Scholar] [CrossRef] [PubMed]
  32. Dove, J.; Hsu, L.C.; Yau, A.C. The cervical spine after halo-pelvic traction. An analysis of the complications of 83 patients. J. Bone Jt. Surg. Br. 1980, 62, 158–161. [Google Scholar] [CrossRef] [PubMed]
  33. Krengel, W.F.; Kim, P.H.; Wiater, B. Spontaneous Ankylosis of Occiput to C2 following Closed Traction and Halo Treatment of Atlantoaxial Rotary Fixation. Glob. Spine J. 2015, 5, 233–238. [Google Scholar] [CrossRef] [Green Version]
  34. Brewerton, D.; Hart, F.; Nicholls, A.; Caffrey, M.; James, D.; Sturrock, R. Ankylosing spondylitis and HL-A 27. Lancet 1973, 301, 904–907. [Google Scholar] [CrossRef]
  35. Schroeder, G.D.; Canseco, J.A.; Patel, P.D.; Divi, S.N.; Karamian, B.A.; Kandziora, F.; Vialle, E.N.; Oner, F.C.; Schnake, K.J.; Dvorak, M.F.; et al. Establishing the Injury Severity of Subaxial Cervical Spine Trauma: Validating the Hierarchical Nature of the AO Spine Subaxial Cervical Spine Injury Classification System. Spine 2021, 46, 649–657. [Google Scholar] [CrossRef] [PubMed]
  36. Yanni, D.S.; Perin, N.I. Fixation of the Axis. Neurosurgery 2010, 66, A147–A152. [Google Scholar] [CrossRef]
  37. Tang, B.; Yao, H.; Wang, S.; Zhong, Y.; Cao, K.; Wan, Z. In vivo 3-Dimensional Kinematics Study of the Healthy Cervical Spine Based on CBCT Combined with 3D-3D Registration Technology. Spine 2021, 46, E1301–E1310. [Google Scholar] [CrossRef]
  38. Bogduk, N.; Mercer, S. Biomechanics of the cervical spine. I: Normal kinematics. Clin. Biomech. 2000, 15, 633–648. [Google Scholar] [CrossRef]
  39. Kang, J.; Chen, G.; Zhai, X.; He, X. In vivo three-dimensional kinematics of the cervical spine during maximal active head rotation. PLoS ONE 2019, 14, e0215357. [Google Scholar] [CrossRef]
  40. Salem, W.; Lenders, C.; Mathieu, J.; Hermanus, N.; Klein, P. In vivo three-dimensional kinematics of the cervical spine during maximal axial rotation. Man. Ther. 2013, 18, 339–344. [Google Scholar] [CrossRef]
  41. Zhao, X.; Wu, Z.-X.; Han, B.-J.; Yan, Y.-B.; Zhang, Y.; Lei, W. Three-dimensional analysis of cervical spine segmental motion in rotation. Arch. Med. Sci. 2013, 3, 515–520. [Google Scholar] [CrossRef] [PubMed] [Green Version]
  42. Guo, R.; Zhou, C.; Wang, C.; Tsai, T.-Y.; Yu, Y.; Wang, W.; Li, G.; Cha, T. In vivo primary and coupled segmental motions of the healthy female head-neck complex during dynamic head axial rotation. J. Biomech. 2021, 123, 110513. [Google Scholar] [CrossRef] [PubMed]
  43. Zhou, C.; Wang, H.; Wang, C.; Tsai, T.-Y.; Yu, Y.; Ostergaard, P.; Li, G.; Cha, T. Intervertebral range of motion characteristics of normal cervical spinal segments (C0-T1) during in vivo neck motions. J. Biomech. 2020, 98, 109418. [Google Scholar] [CrossRef] [PubMed]
Jcm 11 01504 g001 550
Figure 1. Representative non-fusion case (case 7) of 6-year-pld boy with Fielding type 3 and Ishii grade 3 (A). Direct osseous contact of C1/C2 facet on the dislocated side at initial visit (solid arrowhead in (B)), disappeared after reduction and during halo fixation (C), blank arrowhead in (D), and resulted in remodeling of facet deformity without osseous fusion at the final follow-up (E), open arrowhead in (F). Duration of halo fixation was 2.6 months.
Figure 1. Representative non-fusion case (case 7) of 6-year-pld boy with Fielding type 3 and Ishii grade 3 (A). Direct osseous contact of C1/C2 facet on the dislocated side at initial visit (solid arrowhead in (B)), disappeared after reduction and during halo fixation (C), blank arrowhead in (D), and resulted in remodeling of facet deformity without osseous fusion at the final follow-up (E), open arrowhead in (F). Duration of halo fixation was 2.6 months.
Jcm 11 01504 g001
Jcm 11 01504 g002 550
Figure 2. Representative osseous fusion case (Case 9) 7-year-old female patient with Fielding type 3 and Ishii grade 3 (A). Direct osseous contact of C1/C2 facet on the dislocated side at initial visit (solid arrowhead in (B)), persisted after reduction and during halo fixation (C), solid arrowhead in (D), and resulted in spontaneous osseous fusion at the final follow-up (E), solid arrowhead in (F). Duration of halo fixation was 2.9 months.
Figure 2. Representative osseous fusion case (Case 9) 7-year-old female patient with Fielding type 3 and Ishii grade 3 (A). Direct osseous contact of C1/C2 facet on the dislocated side at initial visit (solid arrowhead in (B)), persisted after reduction and during halo fixation (C), solid arrowhead in (D), and resulted in spontaneous osseous fusion at the final follow-up (E), solid arrowhead in (F). Duration of halo fixation was 2.9 months.
Jcm 11 01504 g002
Table
Table 1. Patient Characteristics.
Table 1. Patient Characteristics.
CaseAgeSexCause of AARFDuration from Onset to
Initial Visit (Months)		FCIGADI
(mm)		C1 LI
(Degree)		Duration of Halo
Fixation (Months)		Direct Osseous Contact of FacetOsseously Fused
Segment after Halo Removal
Initial VisitDuring Halo Fixation
Non-SOF group111FUpper RTI63213183.1Unknown *--
28FUnknown3.8223.6182.3Unknown *--
34FUpper RTI3.4234.2382.1C1/C2--
45FUpper RTI2.1123.5−32.1---
55FOtitis media2.622543---
69FLymphangitis1.51228.52.1C1/C2--
76FKawasaki disease3.2334262.6C1/C2--
SOF group87FUpper RTI5.4337283.8Unknown *Oc/C1, C1/C2Oc-C2
97FMinor trauma8.8338242.9C1/C2C1/C2C1-C2
109MMinor trauma3.93210.213.52.8Oc/C1, C1/C2-Oc-C2
118FMumps7.2333.322.81.9C1/C2C1/C2C1-C2
127MLymphangitis3.423820.93C1/C2C2/C3C2-C3
* Presence or absence of direct osseous contact of facet joint at initial visit was unknown in case 1, 2, and 8 because sagittal and coronal 3D reconstructions were not obtained. FC: Fielding Classification; IG: Ishii Grading; ADI: atlantodental intervals; C1 LI: C1 lateral inclination. RTI: respiratory tract infection.
Table
Table 2. Comparison of clinical and imaging variables.
Table 2. Comparison of clinical and imaging variables.
ParameterNon-SOF GroupSOF Groupp Value
Case 1–7Case 8–12
No. of patients75
Age (yrs)
  mean7.3 ± 2.68.1 ± 0.70.489
  range4–117–9
Sex
  male12
  female630.523
Duration from onset to initial visit (months)3.2 ± 1.45.7 ± 2.30.040
Causes (no. of cases)
  upper RTI31
  minor trauma02
  lymphangitis11
  otitis media10
  Kawasaki disease10
mumpus01
unknown100.334
Fielding classification (no. of cases)
  I20
  II31
  III240.180
Ishii grading (no. of cases)
  I00
  II51
  III240.079
C1 lateral inclination (degree)15.6 ± 13.921.8 ± 5.30.369
ADI (mm)5.0 ± 3.67.3 ± 2.50.260
Macroscopic cervical rotatory ROM (degree)
At initial visit66.5 ± 7.738.0 ± 22.20.018
Two weeks after halo removal173.0 ± 5.957.0 ± 4.1<0.001
At final follow-up174.3 ± 3.8118.3 ± 26.3<0.001
Duration of halo fixation (months)2.5 ± 0.42.9 ± 0.70.221
Direct osseous contact of facet joints (no. of cases)
  At initial visit *  Present34
           Absent200.151
  During halo fixation Present04
            Absent710.004
Segmental rotatory ROM on final follow-up CT
  Oc/C19.8 ± 3.520.1 ± 2.3 †0.003
  C1/C250.7 ± 9.9--
  C2/C37.9 ± 3.213.0 ± 3.4 ‡0.051
  C3/C412.0 ± 2.815.4 ± 3.40.115
Time from reduction to final CT (mos)8.3 ± 3.637.8 ± 14.90.011
* Two patients in the non-SOF group (Case 1, 2) and one patient in the SOF group (Case 8) were excluded because their 3D-CT reconstructions at initial visit were not obtained. † Case 8 and Case 10 were excluded from the calculation because Oc/C1 segment was fused. ‡ Case 12 was excluded from the calculation because C2/C3 segment was fused. RTI: respiratory tract infection.
Publisher’s Note: MDPI stays neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Share and Cite

MDPI and ACS Style

Kitamura, K.; Ishii, K.; Nagoshi, N.; Chiba, K.; Matsumoto, M.; Nakamura, M.; Watanabe, K. Spontaneous Osseous Fusion after Remodeling Therapy for Chronic Atlantoaxial Rotatory Fixation and Recovery Mechanism of Rotatory Range of Motion of the Cervical Spine. J. Clin. Med. 2022, 11, 1504. https://doi.org/10.3390/jcm11061504

AMA Style

Kitamura K, Ishii K, Nagoshi N, Chiba K, Matsumoto M, Nakamura M, Watanabe K. Spontaneous Osseous Fusion after Remodeling Therapy for Chronic Atlantoaxial Rotatory Fixation and Recovery Mechanism of Rotatory Range of Motion of the Cervical Spine. Journal of Clinical Medicine. 2022; 11(6):1504. https://doi.org/10.3390/jcm11061504

Chicago/Turabian Style

Kitamura, Kazuya, Ken Ishii, Narihito Nagoshi, Kazuhiro Chiba, Morio Matsumoto, Masaya Nakamura, and Kota Watanabe. 2022. "Spontaneous Osseous Fusion after Remodeling Therapy for Chronic Atlantoaxial Rotatory Fixation and Recovery Mechanism of Rotatory Range of Motion of the Cervical Spine" Journal of Clinical Medicine 11, no. 6: 1504. https://doi.org/10.3390/jcm11061504

APA Style

Kitamura, K., Ishii, K., Nagoshi, N., Chiba, K., Matsumoto, M., Nakamura, M., & Watanabe, K. (2022). Spontaneous Osseous Fusion after Remodeling Therapy for Chronic Atlantoaxial Rotatory Fixation and Recovery Mechanism of Rotatory Range of Motion of the Cervical Spine. Journal of Clinical Medicine, 11(6), 1504. https://doi.org/10.3390/jcm11061504

Note that from the first issue of 2016, this journal uses article numbers instead of page numbers. See further details here.

Article Metrics

Back to TopTop
