Open AccessArticle
Membranes 2019, 9(1), 14; https://doi.org/10.3390/membranes9010014

Integrated Design and Control of Various Hydrogen Production Flowsheet Configurations via Membrane Based Methane Steam Reforming

1
Chemical Process and Energy Resources Institute (C.P.E.R.I.), Centre for Research and Technology Hellas (CE.R.T.H.), P.O. Box 60361, 57001 Thermi-Thessaloniki, Greece
2
Department of Mechanical Engineering, Aristotle University of Thessaloniki, P.O. Box 484, 54124 Thessaloniki, Greece
3
Department of Automation Engineering, Alexander Technological Educational Institute of Thessaloniki, P.O. Box 141, 57400 Thessaloniki, Greece
*
Author to whom correspondence should be addressed.
Received: 17 October 2018 / Revised: 29 December 2018 / Accepted: 8 January 2019 / Published: 15 January 2019
(This article belongs to the Special Issue Modeling and Design of Membrane Reactors)
  |
PDF [2372 KB, uploaded 15 January 2019]
  |

Abstract

This work focuses on the development and implementation of an integrated process design and control framework for a membrane-based hydrogen production system based on low temperature methane steam reforming. Several alternative flowsheet configurations consisted of either integrated membrane reactor modules or successive reactor and membrane separation modules are designed and assessed by considering economic and controller dynamic performance criteria simultaneously. The design problem is expressed as a non-linear dynamic optimization problem incorporating a nonlinear dynamic model for the process system and a linear model predictive controller aiming to maintain the process targets despite the effect of disturbances. The large dimensionality of the disturbance space is effectively addressed by focusing on disturbances along the direction that causes the maximum process variability revealed by the analysis of local sensitivity information for the process system. Design results from a multi-objective optimization study, where only the annualized equipment and operational costs are minimized, are used as reference case in order to evaluate the proposed design framework. Optimization results demonstrate the controller’s ability to track the imposed setpoint changes and alleviate the effects of multiple simultaneous disturbances. Also, significant economic improvements are observed by the implementation of the integrated design and control framework compared to the traditional design methodology, where process and controller design are performed sequentially. View Full-Text
Keywords: hydrogen production; reactor modeling; dynamic process simulation; process optimization; low temperature methane steam reforming; multi-objective optimization; Integrated process design and control hydrogen production; reactor modeling; dynamic process simulation; process optimization; low temperature methane steam reforming; multi-objective optimization; Integrated process design and control
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Kyriakides, A.-S.; Voutetakis, S.; Papadopoulou, S.; Seferlis, P. Integrated Design and Control of Various Hydrogen Production Flowsheet Configurations via Membrane Based Methane Steam Reforming. Membranes 2019, 9, 14.
