Open AccessArticle
Appl. Sci. 2017, 7(11), 1156; https://doi.org/10.3390/app7111156

Automated Defect Recognition as a Critical Element of a Three Dimensional X-ray Computed Tomography Imaging-Based Smart Non-Destructive Testing Technique in Additive Manufacturing of Near Net-Shape Parts

1
Brunel Innovation Centre, Brunel University London, Uxbridge, London UB8 3PH, UK
2
TWI Ltd, Granta Park, Great Abington CB21 6AL, UK
*
Author to whom correspondence should be addressed.
Received: 4 September 2017 / Revised: 2 November 2017 / Accepted: 3 November 2017 / Published: 10 November 2017
(This article belongs to the Section Materials)
Full-Text   |   PDF [6550 KB, uploaded 14 November 2017]   |

Abstract

In this paper, a state of the art automated defect recognition (ADR) system is presented that was developed specifically for Non-Destructive Testing (NDT) of powder metallurgy (PM) parts using three dimensional X-ray Computed Tomography (CT) imaging, towards enabling online quality assurance and enhanced integrity confidence. PM parts exhibit typical defects such as microscopic cracks, porosity, and voids, internal to components that without an effective detection system, limit the growth of industrial applications. Compared to typical testing methods (e.g., destructive such as metallography that is based on sampling, cutting, and polishing of parts), CT provides full coverage of defect detection. This paper establishes the importance and advantages of an automated NDT system for the PM industry applications with particular emphasis on image processing procedures for defect recognition. Moreover, the article describes how to establish a reference library based on real 3D X-ray CT images of net-shape parts. The paper follows the development of the ADR system from processing 2D image slices of a measured 3D X-ray image to processing the complete 3D X-ray image as a whole. The introduced technique is successfully integrated into an automated in-line quality control system highly sought by major industry sectors in Oil and Gas, Automotive, and Aerospace. View Full-Text
Keywords: Non-Destructive Testing; computed tomography; automated defect recognition; quality assurance; quality control; powder metallurgy; additive manufacturing; X-ray; net-shape manufacturing Non-Destructive Testing; computed tomography; automated defect recognition; quality assurance; quality control; powder metallurgy; additive manufacturing; X-ray; net-shape manufacturing
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
