An Over-Deterministic Method for Mode III SIF Calculation Using Full-Field Experimental Displacement Fields
Abstract
:1. Introduction
2. Literature Review
2.1. Theoretical Background
2.2. Plausible Effects of Ignoring KIII on CP and Keq
3. Proposed Scheme for Mode III Estimation
4. Materials and Methods
5. Results and Discussion
5.1. Results for Non-Proportional (45° Out-of-Phase Tension and Torsion) Loading
5.2. Results for Non-Proportional (90° Out-of-Phase Tension and Torsion) Loading
5.3. Results for Proportional (In-Phase Tension and Torsion) Loading
5.4. Discussion
6. Conclusions
Supplementary Materials
Author Contributions
Funding
Data Availability Statement
Acknowledgments
Conflicts of Interest
Nomenclature
COD | Crack Opening Displacement |
DIC | Digital Image Correlation |
E | Young’s modulus |
G | Shear modulus |
K, SIF | Stress Intensity Factor |
RL | Axial load reversal ratio |
RT | Torsional load reversal ratio |
u | Displacement in the X direction |
v | Displacement in the Y direction |
w | Displacement in the Z direction |
X | X direction, parallel to the crack |
Y | Y direction, perpendicular to the crack |
Z | Z direction, out of plane displacement |
ν | Poisson modulus |
θ | Crack growth angular direction |
θR3D | Crack propagation angle according to Richard model |
r | radius |
k | Kolosov’s constant |
Ti | rigid body displacement in the i direction |
Ri | rigid body rotation around the i axis |
[h] | concatenated vector of measured displacements |
[Δ] | vector of unknown coefficients in Williams’ series |
[b] | form function in Williams’ series |
