Elastic Analysis of Three-Layer Concrete Slab Based on Numerical Homogenization with an Analytical Shear Correction Factor
Abstract
:1. Introduction
2. Materials and Methods
2.1. Basic Assumptions
2.2. Finite Difference in Variational Form
2.3. Numerical Homogenization
3. Results
4. Discussion
5. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
