Open AccessReview

Recent Advances in Lithiophilic Porous Framework toward Dendrite-Free Lithium Metal Anode

Department of Electrical Engineering and Computer Science, South Dakota State University, Brookings, SD 57007, USA
*
Authors to whom correspondence should be addressed.
Appl. Sci. 2020, 10(12), 4185; https://doi.org/10.3390/app10124185
Received: 31 May 2020 / Revised: 17 June 2020 / Accepted: 17 June 2020 / Published: 18 June 2020
Rechargeable lithium metal anode (LMA) based batteries have attracted great attention as next-generation high-energy-density storage systems to fuel the extensive practical applications in portable electronics and electric vehicles. However, the formation of unstable solid-electrolyte- interphase (SEI) and growth of lithium dendrite during plating/stripping cycles stimulate safety concern, poor coulombic efficiency (CE), and short lifespan of the lithium metal batteries (LMBs). To address these issues, the rational design of micro/nanostructured Li hosts are widely adopted in LMBs. The high surface area of the interconnected conductive framework can homogenize the Li-ion flux distribution, lower the effective current density, and provides sufficient space for Li accommodation. However, the poor lithiophilicity of the micro/nanostructure host cannot govern the initial lithium nucleation, which leads to the non-uniform/dendritic Li deposition and unstable SEI formation. As a result, the nucleation overpotential and voltage hysteresis increases, which eventually leads to poor battery cycling performance. Thus, it is imperative to decorate a micro/nanostructured Li host with lithiophilic coatings or seeds for serving as a homogeneous nucleation site to guide the uniform lithium deposition. In this review, we summarize research progress on porous metal and non-metal based lithiophilic micro/nanostructured Li hosts. We present the synthesis, structural properties, and the significance of lithiophilic decorated micro/nanostructured Li host in the LMBs. Finally, the perspectives and critical challenges needed to address for the further improvement of LMBs are concluded. View Full-Text
Keywords: lithium metal anode; lithiophilic; micro/nanostructure; low nucleation overpotential; dendrite-free Li deposition lithium metal anode; lithiophilic; micro/nanostructure; low nucleation overpotential; dendrite-free Li deposition
Show Figures

Figure 1

MDPI and ACS Style

Pathak, R.; Zhou, Y.; Qiao, Q. Recent Advances in Lithiophilic Porous Framework toward Dendrite-Free Lithium Metal Anode. Appl. Sci. 2020, 10, 4185.
