# On the Analytical and Numerical Study of a Two-Dimensional Nonlinear Heat Equation with a Source Term

^{1}

^{2}

^{*}

## Abstract

**:**

## 1. Introduction

## 2. The Existence and Uniqueness Theorem

**Theorem**

**1.**

- $b\left(t,-\mathsf{\pi}\right)=b\left(t,\mathsf{\pi}\right),b\left(t,\mathsf{\phi}\right)0$ and $\mathsf{\eta}\left(0\right)=0$.
- $b\left(t,\mathsf{\phi}\right)$ and $1/b\left(t,\mathsf{\phi}\right)$ are analytical with respect to $\mathsf{\phi}$ when $-\mathsf{\pi}\le \mathsf{\phi}\le \mathsf{\pi}$ and, in terms of $t$ in some neighborhood of the initial time $t=0$, $\mathsf{\eta}\left(u\right)$ is analytical with respect to $u$.

**Proof.**

**Stage**

**1.**

**Stage**

**2.**

- $g\left(\mathsf{\tau},\mathsf{\psi},s\right)$ is analytical in some neighborhood of $\mathsf{\tau}=0,s=0$ and at all $-\mathsf{\pi}\le \mathsf{\psi}\le \mathsf{\pi}$.
- ${G}_{i}$ and $i=1,2,3$ are quadratic polynomials with respect to the required function $v$ and its derivatives, whose coefficients are functions of the independent variables $\mathsf{\tau},\mathsf{\psi},s$, analytical in some neighborhood of $\mathsf{\tau}=0,s=0$ and at all $-\mathsf{\pi}\le \mathsf{\psi}\le \mathsf{\pi}$.

## 3. The BEM Solution Algorithm

- We assume ${u}^{\left(0\right)}\equiv 0$ as the initial iteration;
- Solving system (37), we determine the next, (n+1)-th, iteration of the nodal values of temperature and flux on the boundary ${S}^{\left(0\right)}$, ${u}_{m}^{\left(n+1\right)}$ and ${q}_{m}^{\left(n+1\right)}$;
- The determined nodal values give us the (n+1)-th iteration of the solution$$\begin{array}{ll}{u}^{\left(n+1\right)}\left(\xi \right)& ={\displaystyle \sum _{m=1}^{2N}\left({q}_{m}^{\left(n+1\right)}{\displaystyle \underset{{e}_{m}}{\int}{u}^{*}\left(\xi ,x\right)dS\left(x\right)}-{u}_{m}^{\left(n+1\right)}{\displaystyle \underset{{e}_{m}}{\int}{q}^{*}\left(\xi ,x\right)dS\left(x\right)}\right)}\\ & +{\displaystyle \sum _{i=1}^{K}{\mathsf{\alpha}}_{i}^{\left(n\right)}\left({\widehat{u}}_{i}\left(\xi \right)-{\displaystyle \sum _{m=1}^{2N}\left({\widehat{q}}_{i}\left({x}_{m}\right){\displaystyle \underset{{e}_{m}}{\int}{u}^{*}\left(\xi ,x\right)dS\left(x\right)}-{\widehat{u}}_{i}\left({x}_{m}\right){\displaystyle \underset{{e}_{m}}{\int}{q}^{*}\left(\xi ,x\right)dS\left(x\right)}\right)}\right)};\end{array}$$
- Solving system (35), we determine the coefficients ${\mathsf{\alpha}}_{i}^{(n+1)}$ for the next iteration;
- We go to the next iteration.

## 4. Exact Solutions

## 5. Test Examples

## 6. Analysis of Using Radial Basis Functions

## 7. Conclusions

## Author Contributions

## Funding

## Acknowledgments

## Conflicts of Interest

## Appendix A. Calculation of Heat Flux on the Zero Front of a Heat Wave

## References

- Vazquez, J.L. The Porous Medium Equation: Mathematical Theory; Clarendon Press: Oxford, UK, 2007. [Google Scholar] [CrossRef]
- Evans, L.C. Partial Differential Equations, 2nd ed.; American Mathematical Society: Providence, RI, USA, 2010. [Google Scholar] [CrossRef] [Green Version]
- Barenblatt, G.I.; Entov, V.M.; Ryzhik, V.M. Theory of Fluid Flowsthrough Natural Rocks; Kluwer Academic Publishers: Dordrecht, The Netherlands; Boston, MA, USA, 1990. [Google Scholar]
- Sidorov, A.F. Analytic representations of solutions of nonlinear parabolic equations of time-dependent filtration (porous medium) type. Sov. Math. Dokl.
**1985**, 31, 40–44. [Google Scholar] - Filimonov, M.Y.; Korzunin, L.G.; Sidorov, A.F. Approximate methods for solving nonlinear initial boundary-value problems based on special construction of series. Russ. J. Numer. Anal. Math. Model.
**1993**, 8, 101–125. [Google Scholar] [CrossRef] - Sidorov, N.A.; Loginov, B.V.; Sinitsyn, A.V.; Falaleev, M.V. Lyapunov-Schmidt Methods in Nonlinear Analysis and Applications; Kluwer Academic Publishers: Dordrecht, The Netherlands, 2002. [Google Scholar] [CrossRef]
- Sidorov, N.A. Classic Solutions of Boundary Value Problems for Partial Differential Equations with Operator of Finite Index in the Main Part of Equation. Bull. Irkutsk State Univ. Ser. Math.
**2019**, 27, 55–70. [Google Scholar] [CrossRef] - Sidorov, D.N.; Sidorov, N.A. Generalized solutions in the problem of dynamical systems modeling by Volterra polynomials. Autom. Remote Control
**2011**, 72, 1258–1263. [Google Scholar] [CrossRef] - Wrobel, L.C.; Brebbia, C.A.; Nardini, D. The dual reciprocity boundary element formulation for transient heat conduction. In Finite Elements in Water Resources VI; Springer: Berlin, Germany, 1986; pp. 801–811. [Google Scholar]
- Tanaka, M.; Matsumoto, T.; Yang, Q.F. Time-stepping boundary element method applied to 2-D transient heat conduction problems. Appl. Math. Model.
**1994**, 18, 569–576. [Google Scholar] [CrossRef] - Tanaka, M.; Matsumoto, T.; Takakuwa, S. Dual reciprocity BEM for time-stepping approach to the transient heat conduction problem in nonlinear materials. Comput. Methods Appl. Mech. Eng.
**2006**, 195, 4953–4961. [Google Scholar] [CrossRef] - Divo, E.; Kassab, A.J. Transient non-linear heat conduction solution by a dual reciprocity boundary element method with an effective posteriori error estimator. Comput. Mater. Contin.
**2005**, 2, 277–288. [Google Scholar] [CrossRef] - Wrobel, L.C.; Brebbia, C.A. The dual reciprocity boundary element formulation for nonlinear diffusion problems. Comput. Methods Appl. Mech. Eng.
**1987**, 65, 147–164. [Google Scholar] [CrossRef] - Singh, K.M.; Tanaka, M. Dual reciprocity boundary element analysis of transient advection-diffusion. Int. J. Numer. Method H
**2003**, 13, 633–646. [Google Scholar] [CrossRef] - AL-Bayati, S.A.; Wrobel, L.C. A novel dual reciprocity boundary element formulation for two-dimensional transient convection–diffusion–reaction problems with variable velocity. Eng. Anal. Bound. Elem.
**2018**, 94, 60–68. [Google Scholar] [CrossRef] - Fendoglu, H.; Bozkaya, C.; Tezer-Sezgin, M. DBEM and DRBEM solutions to 2D transient convection-diffusion-reaction type equations. Eng. Anal. Bound. Elem.
**2018**, 93, 124–134. [Google Scholar] [CrossRef] - Powell, M.J.D. The Theory of Radial Basis Function Approximation. In Advances in Numerical Analysis; Light, W., Ed.; Oxford Science Publications: Oxford, UK, 1992; Volume 2. [Google Scholar]
- Golberg, M.A.; Chen, C.S.; Bowman, H. Some recent results and proposals for the use of radial basis functions in the BEM. Eng. Anal. Bound. Elem.
**1999**, 23, 285–296. [Google Scholar] [CrossRef] - Kazakov, A.L.; Spevak, L.F. Numerical and analytical studies of a nonlinear parabolic equation with boundary conditions of a special form. Appl. Math. Model.
**2013**, 37, 6918–6928. [Google Scholar] [CrossRef] - Kazakov, A.L.; Spevak, L.F. An analytical and numerical study of a nonlinear parabolic equation with degeneration for the cases of circular and spherical symmetry. Appl. Math. Model.
**2016**, 40, 1333–1343. [Google Scholar] [CrossRef] - Kazakov, A.L.; Lempert, A.A. Existence and uniqueness of the solution of the boundary-value problem for a parabolic equation of unsteady filtration. J. Appl. Mech. Tech. Phys.
**2013**, 54, 251–258. [Google Scholar] [CrossRef] - Polyanin, A.D.; Zaitsev, V.F. Handbook of Nonlinear Partial Differential Equations; Chapman and Hall/CRC Press: Boca Raton, FL, USA; London, UK; New York, NY, USA, 2012. [Google Scholar]
- Kosov, A.A.; Semenov, E.I. Exact Solutions of the Nonlinear Diffusion Equation. Sib. Math. J.
**2019**, 60, 93–107. [Google Scholar] [CrossRef] - Filimonov, M. Application of method of special series for solution of nonlinear partial differential equations. In AIP Conference Proceedings; American Institute of Physics: College Park, MD, USA, 2014; Volume 1631, p. 218. [Google Scholar] [CrossRef]
- Samarskii, A.A.; Galaktionov, V.A.; Kurdyumov, S.P.; Mikhailov, A.P. Blow-Up in Quasilinear Parabolic Equations; De Gruyte: Berlin, Germany; New York, NY, USA, 1995. [Google Scholar] [CrossRef]
- Kazakov, A.L.; Orlov, S.S.; Orlov, S.S. Construction and study of exact solutions to a nonlinear heat equation. Sib. Math. J.
**2018**, 59, 427–441. [Google Scholar] [CrossRef] - Sinelshchikov, D.I.; Kudryashov, N.A. Integrable Nonautonomous Liénard-Type Equations. Theor. Math. Phys.
**2018**, 196, 1230–1240. [Google Scholar] [CrossRef] - Guha, P.; Ghose-Choudhury, A. Nonlocal transformations of the generalized Liénard type equations and dissipative Ermakov-Milne-Pinney systems. Int. J. Geom. Methods Mod. Phys.
**2019**, 16, 1950107. [Google Scholar] [CrossRef] [Green Version] - Brebbia, C.A.; Telles, J.C.F.; Wrobel, L.C. Boundary Element Techniques; Springer: Berlin, Germany, 1984. [Google Scholar] [CrossRef]
- Fedotov, V.P.; Spevak, L.F. One approach to the derivation of exact integration formulae in the boundary element method. Eng. Anal. Bound. Elem.
**2008**, 32, 883–888. [Google Scholar] [CrossRef] - Hardy, R.L. Multiquadric equations of topography and other irregular surfaces. J. Geophys. Res.
**1971**, 76, 1905–1915. [Google Scholar] [CrossRef] - Franke, R. Scattered data interpolation: Tests of some methods. Math. Comput.
**1982**, 38, 181–200. [Google Scholar] [CrossRef]

t | h | Relative Error | |||
---|---|---|---|---|---|

N = 150 | N = 250 | N = 300 | N = 350 | ||

0.3 | 0.1 | 0.00069 | 0.00047 | 0.00039 | 0.00035 |

0.6 | 0.1 | 0.00081 | 0.00058 | 0.00048 | 0.00043 |

1 | 0.1 | 0.00095 | 0.00071 | 0.00060 | 0.00052 |

0.3 | 0.05 | 0.00061 | 0.00041 | 0.00034 | 0.00029 |

0.6 | 0.05 | 0.00072 | 0.00051 | 0.00043 | 0.00037 |

1 | 0.05 | 0.00084 | 0.00062 | 0.00054 | 0.00045 |

t | h | Relative Error | ||||||
---|---|---|---|---|---|---|---|---|

${\mathit{f}}_{\mathit{i}}={\mathit{r}}_{\mathit{i}}$ | ${\mathit{f}}_{\mathit{i}}={\mathit{r}}_{\mathit{i}}^{3}$ | ${\mathit{f}}_{\mathit{i}}=1+{\mathit{r}}_{\mathit{i}}$ | ${\mathit{f}}_{\mathit{i}}=1+{\mathbf{\delta}}_{1}{\mathit{r}}_{\mathit{i}}$ | ${\mathit{f}}_{\mathit{i}}=1+{\mathbf{\delta}}_{2}{\mathit{r}}_{\mathit{i}}$ | ${\mathit{f}}_{\mathit{i}}=\sqrt{1+{\left({\mathbf{\delta}}_{1}{\mathit{r}}_{\mathit{i}}\right)}^{2}}$ | ${\mathit{f}}_{\mathit{i}}=\sqrt{1+{\left({\mathbf{\delta}}_{2}{\mathit{r}}_{\mathit{i}}\right)}^{2}}$ | ||

0.3 | 0.1 | 0.00064 | 0.00048 | 0.00035 | 0.00017 | 0.00015 | 0.00012 | 0.00011 |

0.6 | 0.1 | 0.00077 | 0.00060 | 0.00043 | 0.00020 | 0.00017 | 0.00016 | 0.00014 |

1 | 0.1 | 0.00094 | 0.00074 | 0.00052 | 0.00024 | 0.00021 | 0.00022 | 0.00019 |

0.3 | 0.05 | 0.00058 | 0.00040 | 0.00029 | 0.00016 | 0.00014 | 0.00010 | 0.00010 |

0.6 | 0.05 | 0.00072 | 0.00054 | 0.00037 | 0.00018 | 0.00015 | 0.00013 | 0.00012 |

1 | 0.05 | 0.00087 | 0.00067 | 0.00045 | 0.00023 | 0.00018 | 0.00019 | 0.00016 |
