Open AccessArticle
Crystals 2018, 8(9), 363;

Mosaicity of Spin-Crossover Crystals

CNRS, University Bordeaux, ICMCB, UMR 5026, 87 Avenue du Dr A. Schweitzer, F-33608 Pessac, France
Institut Laue-Langevin, 71 Avenue des Martyrs, BP 156, F-38042 Grenoble, France
Author to whom correspondence should be addressed.
Received: 28 August 2018 / Revised: 11 September 2018 / Accepted: 11 September 2018 / Published: 13 September 2018
(This article belongs to the Special Issue Synthesis and Applications of New Spin Crossover Compounds)
Full-Text   |   PDF [1767 KB, uploaded 13 September 2018]   |


Real crystals are composed of a mosaic of domains whose misalignment is evaluated by their level of “mosaicity” using X-ray diffraction. In thermo-induced spin-crossover compounds, the crystal may be seen as a mixture of metal centres, some being in the high-spin (HS) state and others in the low spin (LS) state. Since the volume of HS and LS crystal packings are known to be very different, the assembly of domains within the crystal, i.e., its mosaicity, may be modified at the spin crossover. With little data available in the literature we propose an investigation into the temperature dependence of mosaicity in certain spin-crossover crystals. The study was preceded by the examination of instrumental factors, in order to establish a protocol for the measurement of mosaicity. The results show that crystal mosaicity appears to be strongly modified by thermal spin-crossover; however, the nature of the changes are probably sample dependent and driven, or masked, in most cases by the characteristics of the crystal (disorder, morphology …). No general relationship could be established between mosaicity and crystal properties. If, however, mosaicity studies in spin-crossover crystals are conducted and interpreted with great care, they could help to elucidate crucial crystal characteristics such as mechanical fatigability, and more generally to investigate systems where phase transition is associated with large volume changes. View Full-Text
Keywords: mosaicity; spin crossover; X-ray diffraction; fatigability; single crystal; phase transition; structural disorder mosaicity; spin crossover; X-ray diffraction; fatigability; single crystal; phase transition; structural disorder

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Supplementary material


Share & Cite This Article

MDPI and ACS Style

Lakhloufi, S.; Tailleur, E.; Guo, W.; Le Gac, F.; Marchivie, M.; Lemée-Cailleau, M.-H.; Chastanet, G.; Guionneau, P. Mosaicity of Spin-Crossover Crystals. Crystals 2018, 8, 363.
