Micromachines 2018, 9(8), 407; https://doi.org/10.3390/mi9080407

Effects of Embedded TiO2−x Nanoparticles on Triboelectric Nanogenerator Performance

1
Department of Mechanical Engineering, Kyung Hee University, 1732 Deogyeong-daero, Giheung-gu, Yongin-Si, Gyeonggi-do 446-701, Korea
2
Department of Physics and Semiconductor Science, Dongguk University, Seoul 100-715, Korea
These authors are equally contributed.
*
Authors to whom correspondence should be addressed.
Received: 23 July 2018 / Revised: 10 August 2018 / Accepted: 14 August 2018 / Published: 17 August 2018
(This article belongs to the Special Issue Nanogenerators in Korea)
Full-Text   |   PDF [4262 KB, uploaded 17 August 2018]   |

Abstract

Triboelectric nanogenerators (TENGs) are used as self-power sources for various types of devices by converting external waves, wind, or other mechanical energies into electric power. However, obtaining a high-output performance is still of major concern for many applications. In this study, to enhance the output performance of polydimethylsiloxane (PDMS)-based TENGs, highly dielectric TiO2−x nanoparticles (NPs) were embedded as a function of weight ratio. TiO2−x NPs embedded in PDMS at 5% showed the highest output voltage and current. The improved output performance at 5% is strongly related to the change of oxygen vacancies on the PDMS surface, as well as the increased dielectric constant. Specifically, oxygen vacancies in the oxide nanoparticles are electrically positive charges, which is an important factor that can contribute to the exchange and trapping of electrons when driving a TENG. However, in TiO2−x NPs containing over 5%, the output performance was significantly degraded because of the increased leakage characteristics of the PDMS layer due to TiO2−x NPs aggregation, which formed an electron path. View Full-Text
Keywords: TiO2−x nanoparticle; high dielectric constant; triboelectric nanogenerators; oxygen vacancy TiO2−x nanoparticle; high dielectric constant; triboelectric nanogenerators; oxygen vacancy
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Supplementary material

SciFeed

Share & Cite This Article

MDPI and ACS Style

Park, H.-W.; Huynh, N.D.; Kim, W.; Hwang, H.J.; Hong, H.; Choi, K.; Song, A.; Chung, K.-B.; Choi, D. Effects of Embedded TiO2−x Nanoparticles on Triboelectric Nanogenerator Performance. Micromachines 2018, 9, 407.
