Parametric Amplification of Acoustically Actuated Micro Beams Using Fringing Electrostatic Fields
Abstract
1. Introduction
2. Methodology
2.1. Device Architecture
2.2. Model
3. Experiment
3.1. Experimental Setup
3.2. Experimental Results
4. Conclusions
Author Contributions
Funding
Data Availability Statement
Acknowledgments
Conflicts of Interest
References
