Structural Analysis of Mo Thin Films on Sapphire Substrates for Epitaxial Growth of AlN
Abstract
1. Introduction
2. Experimental
3. Results and Discussion
4. Conclusions
Author Contributions
Funding
Data Availability Statement
Conflicts of Interest
References
