Application of a Terahertz System Combined with an X-Shaped Metamaterial Microfluidic Cartridge

1
Department of Power Mechanical Engineering, National Tsing Hua University, Hsinchu 30013, Taiwan
2
ACE BIOTEK Co. Ltd., Hsinchu 30261, Taiwan
3
Department of Material Science Engineering, National Tsing Hua University, Hsinchu 30013, Taiwan
4
Institute of NanoEngineering and MicroSystems, National Tsing Hua University, Hsinchu 30013, Taiwan
*
Author to whom correspondence should be addressed.
Micromachines 2020, 11(1), 74; https://doi.org/10.3390/mi11010074
Received: 17 December 2019 / Revised: 4 January 2020 / Accepted: 5 January 2020 / Published: 9 January 2020
(This article belongs to the Special Issue 10th Anniversary of Micromachines)
Terahertz (THz) radiation has attracted wide attention for its ability to sense molecular structure and chemical matter because of a label-free molecular fingerprint and nondestructive properties. When it comes to molecular recognition with terahertz radiation, our attention goes first towards the absorption spectrum, which is beyond the far infrared region. To enhance the sensitivity for similar species, however, it is necessary to apply an artificially designed metamaterial sensor for detection, which confines an electromagnetic field in an extremely sub-wavelength space and hence receives an electromagnetic response through resonance. Once the resonance is caused through the interaction between the THz radiation and the metamaterial, a minute variation might be observed in the frequency domain. For a geometric structure of a metamaterial, a novel design called an X-shaped plasmonic sensor (XPS) can create a quadrupole resonance and lead to sensitivity greater than in the dipole mode. A microfluidic system is able to consume reagents in small volumes for detection, to diminish noise from the environment, and to concentrate the sample into detection spots. A microfluidic device integrated with an X-shaped plasmonic sensor might thus achieve an effective and highly sensitive detection cartridge. Our tests involved not only measurements of liquid samples, but also the performance of a dry bio-sample coated on an XPS. View Full-Text
Keywords: terahertz radiation; metamaterials; microfluidics terahertz radiation; metamaterials; microfluidics
Show Figures

Figure 1

MDPI and ACS Style

Huang, S.-T.; Hsu, S.-F.; Tang, K.-Y.; Yen, T.-J.; Yao, D.-J. Application of a Terahertz System Combined with an X-Shaped Metamaterial Microfluidic Cartridge. Micromachines 2020, 11, 74.
