On the Hole Injection for III-Nitride Based Deep Ultraviolet Light-Emitting Diodes
Abstract
:1. Introduction
2. Increase the Hole Injection Efficiency from the p-Type Ohmic Contact into the Hole Supplier
3. Enhance the Hole Transport within the Hole Supplier
4. Reduce the Hole Blocking Effect by the p-EBL
5. Increase the Hole Concentration in the MQW Region
6. Summary
Acknowledgments
Conflicts of Interest
References
