On the Sensitivity of Local Flexibility Markets to Forecast Error: A Bi-Level Optimization Approach

1
Environmental Technology, Wageningen University and Research, Bornse Weilanden 9, 6700 AA Wageningen, The Netherlands
2
Flemish Institute for Technological Research (VITO), 2400 Mol, Belgium
3
EnergyVille, 3600 Genk, Belgium
4
Mathematical and Statistical Methods—Biometris, Wageningen University, Droevendaalsesteeg 1, 6708 PB Wageningen, The Netherlands
5
Energy and Resources, Copernicus Institute of Sustainable Development, Utrecht University, Vening Meinesz building 8.94, Princetonlaan 8a, 3584 CB Utrecht, The Netherlands
*
Author to whom correspondence should be addressed.
Energies 2020, 13(8), 1959; https://doi.org/10.3390/en13081959
Received: 24 February 2020 / Revised: 29 March 2020 / Accepted: 7 April 2020 / Published: 16 April 2020
(This article belongs to the Special Issue Design Optimization of Local Energy Markets)
The large-scale integration of intermittent distributed energy resources has led to increased uncertainty in the planning and operation of distribution networks. The optimal flexibility dispatch is a recently introduced, power flow-based method that a distribution system operator can use to effectively determine the amount of flexibility it needs to procure from the controllable resources available on the demand side. However, the drawback of this method is that the optimal flexibility dispatch is inexact due to the relaxation error inherent in the second-order cone formulation. In this paper we propose a novel bi-level optimization problem, where the upper level problem seeks to minimize the relaxation error and the lower level solves the earlier introduced convex second-order cone optimal flexibility dispatch (SOC-OFD) problem. To make the problem tractable, we introduce an innovative reformulation to recast the bi-level problem as a non-linear, single level optimization problem which results in no loss of accuracy. We subsequently investigate the sensitivity of the optimal flexibility schedules and the locational flexibility prices with respect to uncertainty in load forecast and flexibility ranges of the demand response providers which are input parameters to the problem. The sensitivity analysis is performed based on the perturbed Karush–Kuhn–Tucker (KKT) conditions. We investigate the feasibility and scalability of the proposed method in three case studies of standardized 9-bus, 30-bus, and 300-bus test systems. Simulation results in terms of local flexibility prices are interpreted in economic terms and show the effectiveness of the proposed approach. View Full-Text
Keywords: optimal flexibility dispatch; bi-level optimization; sensitivity analysis; transactive energy optimal flexibility dispatch; bi-level optimization; sensitivity analysis; transactive energy
Show Figures

Figure 1
