Open AccessArticle
Energies 2019, 12(3), 518; https://doi.org/10.3390/en12030518

Numerical Analysis of Aerodynamic Characteristics of Hyperloop System

1
Departments of Mechanical Engineering, Chung-Ang University, Seoul 06911, Korea
2
Hyper Tube Express (HTX) Research Team, Korea Railroad Research Institute, Gyeonggi-do 16105, Korea
*
Author to whom correspondence should be addressed.
Received: 23 December 2018 / Revised: 30 January 2019 / Accepted: 2 February 2019 / Published: 6 February 2019
(This article belongs to the Special Issue Computational Fluid Dynamics (CFD) 2018)
Full-Text   |   PDF [6546 KB, uploaded 12 February 2019]   |

Abstract

The Hyperloop system is a new concept that allows a train to travel through a near-vacuum tunnel at transonic speeds. Aerodynamic drag is one of the most important factors in analyzing such systems. The blockage ratio (BR), pod speed/length, tube pressure, and temperature affect the aerodynamic drag, but the specific relationships between the drag and these parameters have not yet been comprehensively examined. In this study, we investigated the flow phenomena of a Hyperloop system, focusing on the effects of changes in the above parameters. Two-dimensional axisymmetric simulations were performed in a large parameter space covering various BR values (0.25, 0.36), pod lengths (10.75–86 m), pod speeds (50–350 m/s), tube pressures (~100–1000 Pa), and tube temperatures (275–325 K). As BR increased, the pressure drag was significantly affected. This is because of the smaller critical Mach number for a larger BR. As the pod length increased, the total drag and pressure drag did not change significantly, but there was a considerable influence on the friction drag. As the pod speed increased, strong shock waves occurred near the end of the pod. At this point, the flows around the pod were severely choked at both BR values, and the ratio of the pressure drag to the total drag converged to its saturation level. At tube pressures above 500 Pa, the friction drag increased significantly under the rapidly increased turbulence intensity near the pod surface. High tube temperatures increase the speed of sound, and this reduces the Mach number for the same pod speed, consequently delaying the onset of choking and reducing the aerodynamic drag. The results presented in this study are applicable to the fundamental design of the proposed Hyperloop system. View Full-Text
Keywords: Hyperloop; aerodynamic drag; compressible flow; choking; shock wave Hyperloop; aerodynamic drag; compressible flow; choking; shock wave
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
