Energies 2018, 11(2), 271; https://doi.org/10.3390/en11020271

New Method for Shallow and Deep Trap Distribution Analysis in Oil Impregnated Insulation Paper Based on the Space Charge Detrapping

1
The State Key Laboratory of Power Transmission Equipment & System Security and New Technology, Chongqing University, Chongqing 400044, China
2
College of Power Engineering, Chongqing University, Chongqing 400044, China
*
Author to whom correspondence should be addressed.
Received: 12 November 2017 / Revised: 14 December 2017 / Accepted: 15 January 2018 / Published: 23 January 2018
(This article belongs to the Section Electrical Power and Energy System)
Full-Text   |   PDF [4922 KB, uploaded 23 January 2018]   |

Abstract

Space charge has close relation with the trap distribution in the insulation material. The phenomenon of charges trapping and detrapping has attracted significant attention in recent years. Space charge and trap parameters are effective parameters for assessing the ageing condition of the insulation material qualitatively. In this paper, a new method for calculating trap distribution based on the double exponential fitting analysis of charge decay process and its application on characterizing the trap distribution of oil impregnated insulation paper was investigated. When compared with the common first order exponential fitting analysis method, the improved dual-level trap method could obtain the energy level range and density of both shallow traps and deep traps, simultaneously. Space charge decay process analysis of the insulation paper immersed with new oil and aged oil shows that the improved trap distribution calculation method can distinguish the physical defects and chemical defects. The trap density shows an increasing trend with the oil ageing, especially for the deep traps mainly related to chemical defects. The greater the energy could be filled by the traps, the larger amount of charges could be trapped, especially under higher electric field strength. The deep trap energy level and trap density could be used to characterize ageing. When one evaluates the ageing condition of oil-paper insulation using trap distribution parameters, the influence of oil performance should not be ignored. View Full-Text
Keywords: space charge; trap distribution; oil impregnated insulation paper; charge detrapping; electrical field; oil ageing space charge; trap distribution; oil impregnated insulation paper; charge detrapping; electrical field; oil ageing
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
