Sequential Use of CO2 Laser Prior to Nd:YAG and Dye Laser in the Management of Non-Facial Warts: A Retrospective Study

by
Luigi Bennardo
1,†,
Gaia Fasano
1,†,
Federica Tamburi
1,
Elena Zappia
1,
Francesco Rizzuto
1,
Steven Paul Nisticò
1,* and
Giovanni Cannarozzo
2
1
Department of Health Sciences, Magna Graecia University, 88100 Catanzaro, Italy
2
Department of Systems Medicine, Tor Vergata University, 00173 Rome, Italy
*
Author to whom correspondence should be addressed.
†
These authors contributed equally to this work.
Medicina 2022, 58(1), 115; https://doi.org/10.3390/medicina58010115
Submission received: 13 December 2021 / Revised: 6 January 2022 / Accepted: 11 January 2022 / Published: 12 January 2022
(This article belongs to the Special Issue Lasers, Lights and New Technologies in Medicine and Surgery)
Browse Figures
Versions Notes

Abstract

Background and Objectives: Warts are benign lesions of viral etiology characterized by a hyperkeratotic appearance tending to spread across the skin surface. Various treatments have been proposed to manage this condition, such as acids, imiquimod, photodynamic therapy, cryotherapy, and various lasers. Materials and Methods: In this paper, we describe a combination protocol using CO2 laser prior to Nd:YAG laser for lesions interesting the palmoplantar areas or dye laser for lesions on other skin surfaces in the management of non-facial warts resistant to traditional therapies. In total, 34 patients with 103 warts suffering from wart infection resistant to traditional therapies treated from 1 January 2019 to 1 June 2020 were retrospectively enrolled at the Dermatological Unit of Magna Graecia University (Catanzaro, Italy). Two dermatologists measured clinical results, classifying lesions with complete resolution, partial resolution, or non-responding. Patients at four months follow-up were asked to evaluate their degree of satisfaction with a visual analog scale (VAS). Results: Almost all patients reported the complete resolution of lesions, with no patient reporting scarring. Five patients reported hypopigmentation in the treated areas. The mean satisfaction level was high. Only three patients experienced a relapse of the condition. Conclusions: Using a vascular laser following a CO2 superficial ablation of warts may help reduce the risk of scarring and decrease the incidence of relapses for lesions resistant to traditional therapies. Therefore, more extensive studies will be necessary to confirm the obtained results.

1. Introduction

Warts (verrucae vulgaris) are benign lesions caused by several types of human papillomavirus (HPV), a DNA virus from the Papillomaviridae family, which affects about 10% of the population with a high prevalence in school-aged children. The infection may be localized in the squamous epithelium of the mucosa or the skin [1]. Transmission can be direct or indirect, especially in the interruption of the epithelial barrier, as in minor trauma. Common warts appear as an indurated papule with an irregular hyperkeratotic surface and vegetations; they can be single or multiple, small or large (several centimeters) [2].
Histological examination shows acanthosis, hyperplasia, papillomatosis, orthokeratosis, hypergranulosis, and thrombosed capillaries in dermal papillae; the presence of koilocytic cells is pathognomonic [3]. Different treatments can be used for the therapy of common warts; they must be adapted according to the number of warts, their size, localization, symptoms, the patient’s preference, cost, the status of the immune system, and previous treatment modalities. The cosmetic discomfort and the risk of translocation in other areas are the most frequent indication of treatment [4]. Therapies are not always effective, especially in immunocompromised patients, but it is necessary to start with the least painful and expensive treatment that leaves no scars reserving the most expensive and painful treatment in case of recurrent warts. Sometimes, warts resolve spontaneously in several months or years. First-line therapy is based on chemical topic agents such as salicylic acid, retinoic acid, podophyllin, topical 5-fluorouracil, and imiquimod; they require several weeks or months and can often be unsuccessful [5]. Cryotherapy, diathermocoagulation, and surgical curettage are more aggressive and can cause moderate/severe scars, tissue damage, and adverse effects [6]. The combination of lasers and conventional therapies such as immunomodulators, keratolytic agents, or photodynamic therapy is advantageous in cases of recalcitrant warts and immunosuppressed patients. Different types of laser therapy can be used, such as carbon dioxide (CO2) laser, neodymium-doped yttrium aluminum garnet (Nd:YAG) laser, pulsed dye laser (PDL), or a combination of them. Usually, these devices have been proposed alternatively and before surgery when all other local treatments failed [7,8]. In this paper, we report, for the first time, a combined therapy using a CO2 laser prior to Nd:YAG or dye laser in the management of recalcitrant warts.

2. Materials and Methods

Patients treated for recalcitrant non-facial warts not responding to traditional therapy with this new combined technique between 1 January 2019 and 1 June 2020 at the Unit of Dermatology of Magna Graecia University were retrospectively enrolled. Patients reporting hypersensitivity to light or reporting the use of sulfonamides, sulfonylureas, phenothiazines, and contraceptives, being pregnant, breastfeeding, or malignant tumors were excluded from the study. All patients signed informed consent on the risk of the procedure. The treatment consisted of the first session of CO2 laser (Smartxide Punto, DEKA M.E.L.A., Calenzano, Italy) in super-pulsed mode, with a focused beam of 0.1–0.2 mm diameter, power 0.3–0.8 W, frequency 10 Hz, with the intent to remove the superficial layer of the epidermis, exposing the superficial dermis but without causing bleeding. Then, a second session with long-pulsed Nd:YAG laser (Luxea, DEKA M.E.L.A., Calenzano, Italy) for lesions interesting the palmoplantar region (90–120 J/cm2, 5 mm spot size, slightly defocused, double pulse 5 ms–15 ms with a 10 ms interval performing multiple passes), and with a 595 nm dye laser (Synchro Vasq, DEKA M.E.L.A., Calenzano, Italy) for all other regions (10 mm size spot, fluence 9–10 J/cm2, and frequency 0.5/s, performing multiple passes) was performed on the treated spot, in order to reduce the vascularization to the treated area. The end-point of the treatment was the darkening of the lesion. Subcutaneous injection of lidocaine was proposed when patients suffered pain during the procedure. After the treatment session, topical fusidic acid was applied to the lesion twice a day for one week. From the second week, a 20% salicylic acid cream in the evening and 40% urea in the morning were applied for the other three weeks up to clinical follow-up. A clinical follow-up was performed one month after therapy to evaluate lesions’ disappearance. Four months after initial therapy, a second follow-up was performed to evaluate possible relapses. During both clinical follow-ups and before treatments, pictures of the lesions with the same ambient light and shooting parameters were taken. A visual analog scale (VAS) from 1 to 10 to measure patient satisfaction was administered to subjects during the last clinical follow-up. Statistica14.0 (TIBCO Software, Palo Alto, CA, USA) software was used for data analysis (mean, standard deviations, and rate calculations).

3. Results

In total, 34 patients, comprising 16 males and 18 females (mean age 44.24 ± 21.24), with a total number of 103 warts were enrolled in the study. Of those, 16 patients had warts on the palmoplantar region, 18 patients on other body areas. In addition, 26 patients suffered pain during the procedure, and local anesthesia was necessary, especially for the palmoplantar area. At one month follow-up, 32 patients reported complete resolution of the condition, with 2 patients from the palmoplantar group reporting partial resolution. No severe side effects were reported. At four months of follow-up, three patients experienced a relapse of the condition that was subsequently treated with the same protocol, reaching complete disappearance. Five patients reported hypopigmentation of the treated area. The reported VAS score for patients was very high (9.29 ± 0.97) (Figure 1, Figure 2, Figure 3, Figure 4 and Figure 5). Patient characteristics are reported in Table 1. A treatment protocol diagram is reported in Table 2.

4. Discussion

The CO2 laser is an ablative laser that uses water as a chromophore target [9,10]. It was the first laser used for warts treatment [11].
The CO2 laser can be used in focused mode or non-focused mode with stimulation of immunity of infected keratinocytes [12].
It is necessary to gradually vaporize layer by layer and remove the burned tissues with a cotton-containing physiological solution during the procedure. The treatment can be repeated at intervals of 30–45 days [13].
The advantages of using the CO2 laser are the precision in the depth of ablation that does not damage the adjacent tissues, the quickness in case of multiple lesions, and the absence of bleeding [14].
Adverse effects are pain, edema, infections, hyperpigmentation, scars, and dystrophy in the treatment of periungual warts [7].
Takac investigated the efficacy of surgical laser, compared with other conventional treatments; a CO2 surgical laser has been used with high efficacy to vaporize and resect the root of warts. No significant side effects were reported; healing occurred painlessly and without scarring, suggesting this method has numerous advantages over conventional therapies [15]. Different authors reported the use of CO2 laser in immunocompetent patients with good results [16,17].
The CO2 laser can also be used to treat challenging recalcitrant warts in immunosuppressed patients. In immunocompromised patients, HPV is a risk factor implicated in the onset of non-melanoma skin cancer. Specifically, squamous cell carcinoma has been linked with this infection [18,19]; these patients often present with multiple warts that are unresponsive to conventional treatments and often persist and spread. The presence of 10 or more warts is a high-risk factor for the onset of squamous cell carcinoma (SCC) [20]. The duration of immunosuppression also increases the incidence of these tumors; on average, 25% of patients with a previous kidney transplant develop SCC after about 10 years from the start of immunosuppressive therapy [21].
Läuchli et al. treated 13 immunocompromised patients with multiple relapsing warts; they used a CO2 laser with fluences of 3–10 W in super pulsed mode. Response rates were in line with those of non-immunocompromised patients undergoing the same CO2 laser treatment [21]. Additionally, fractional laser, generating columns of heat in the epidermis [22], has been proposed to enhance drug penetration, as already experimented with for other conditions [23].
We propose that CO2 laser may be used to substitute keratolytic therapies to expose superficial dermis, and then vascular lasers, according to the interested area, may be used to isolate the area, reduce the blood flow, and lower the risk of relapses. The use of keratolytic creams in the weeks following the procedures may help eliminate the necrotic debris following the action of vascular lasers on the exposed lesions. For this reason, it is fundamental to expose the superficial dermis with the CO2 laser without causing bleeding during this procedure, in order to hit the small vessels with vascular lasers safely. Given the longer wavelength of Nd:YAG laser, we used it on thicker areas, such as palmoplantar regions, while PDL, with a shorter wavelength and a minor ability to penetrate through the skin, was used in all the other areas.
PDL produces pulses of visible light at a 585 or 595 nm wavelength. The PDL using the wavelength of 585 nm can hit the capillaries, so the vaporization and coagulation should block the replication of warts and promote their healing, but hyperpigmentation is a possible adverse side effect [24].
The mechanism of action of the PDL is the selective photothermolysis of dermal blood vessels without damaging the surrounding structure, reducing the risk of scar formation [25].
Photothermolysis of dermal blood vessels stimulates the release of inflammatory cytokines and enhances a cellular immune system response, which contributes to the elimination of the virus; the immunomodulating properties also support the wart’s healing [26,27].
To avoid the onset of side effects such as scars and pigment changes, it is necessary to use the PDL with low fluences and as few impulses as possible. On the contrary, the palmar and plantar areas have a high healing capacity and can be treated with higher fluences and more impulses. The cycle is repeated every 15–20 days until complete resolution. [28].
The advantages of using the PDL are rapid healing and the absence of pain, and nail dystrophy in periungual warts. PDL can be used to treat recalcitrant warts in children [29].
Currently, the most used treatment by pediatricians for warts in children is cryotherapy, which has a response rate of 40–82%. In case of recurrences, different therapies are available: topical or systemic immunotherapy, intralesional bleomycin, surgical excision, curettage, and cautery or lasers, especially carbon dioxide (CO2) and pulsed dye laser (PDL) [30,31].
Sethuraman et al. described 61 children treated with PDL. A 5–7 mm spot was used at 7 J/cm2, and an average of three pulses per wart. Follow-up lasted 1–5 years, and the overall clearance rate was 75%, with only 25% partial responses; most patients required about three treatments, while 13% needed only one treatment. Side effects were minimal (hypopigmentation, hyperpigmentation, itching, scars), compared with a CO2 laser (postoperative pain, bleeding, scarring, and hypopigmentation) [32,33]. Therefore, PDL is a safer, more effective, and well-tolerated treatment for children than cryotherapy and CO2 laser [34].
In contrast, as described in other studies, Huilgol et al. reported that PDL treatment in their patients resulted in partial remission and symptom reduction without complete resolution. Different factors could explain this result (immune status, warts’ number, location, and persistence, number of laser sessions performed) [35].
Nd:YAG is a crystal used as a laser medium for solid-state lasers; it has a wavelength of 1064 nm and a deeper penetration level of skin tissue than other types of lasers [36,37].
In Q-switched mode, Nd:YAG produces two wavelengths—one in the infrared range (1064 nm) and the second beam of 532 nm wavelength, which is helpful for superficial skin lesions [38,39].
Hemoglobin has two absorption peaks: one greater at the wavelength of 585–595 nm and another smaller in the wavelengths between 800 and 1000 nm [40].
By modulating the pulse duration and energy density, it is possible to obtain two different effects on the target tissue: coagulation (photothermal effect) and destruction (photomechanical effect). Monochromatic light is absorbed by hemoglobin (targeted tissue chromophores) and converted to thermal energy; this determines the destruction of the tissue [41,42]. The 1064 nm Nd:YAG laser can target the red structures such as hemoglobin in blood vessels, targeting the capillaries present inside warts [43].
In the days following the treatment, it is possible to observe the changes through a microscopic evaluation: Separation of the dermal–epidermal junction, epidermal necrosis, RBC extravasation, and destroyed blood vessels with dense inflammatory infiltrate in the dermis will be obtained [44].
The mechanism of Nd:YAG laser’s function is probably due to an interruption of the supply of vital substances for the wart, or it is linked to the destruction of the epidermal cells that contain HPV. An advantage of using Nd:YAG laser vs. conventional therapies such as cryotherapy is the greater ability to eliminate HPV DNA after treatment [45].
Unlike the PDL, its target does not include the melanin of the dermal–epidermal junction, so there is no hyperpigmentation as a side effect but can cause blood vessel rupture with purpura 5–7 days after the treatment [46].
In Han’s study, 348 patients with untreated or relapsed warts were treated with Nd:YAG laser. The parameters used were spot size 5 mm, pulse duration 20 ms, fluence 200 J/cm2. Biopsy after treatment showed destruction of blood vessels. After the first treatment, 64% of warts were wholly cleared, while 96% were cleared after four treatment sessions. The average number of treatments required for clearance was 1.49. Verruca Vulgaris had a better response than deep palmoplantar warts, while only 3.27% of warts relapsed over the next 2–10 months. The most frequent side effects were pain (82%), transient numbness (15%), hemorrhagic bullae (7%), hyperpigmentation (5%), and hypopigmentation (4%). Han et al. concluded that the long-pulsed Nd:YAG laser is a safe and effective treatment for removing or reducing warts and does not depend on patient compliance [46]. El-Mohamady et al. compared the use of the PDL and Nd:YAG laser to treat plantar warts. In their study, 46 patients with multiple and relapsing warts were treated after topical or local anesthesia and a surgical curettage with a scalped blade [47].
In each patient, half of the warts were treated with PDL, using a spot size of 7 mm, 8 J, and a pulse duration of 0.5 ms, while the other half were treated with Nd:YAG laser using a spot size of 7 mm, 100 J, and a pulse duration of 20 ms. With PDL, 73.9% of patients achieved a complete remission rate (34 patients), while with Nd:YAG laser, 78.3% (36 patients) [47].
The incidence of side effects was higher in patients treated with Nd:YAG laser (43.5%) than in patients treated with PDL (8.7%); specifically, hematoma (28.3% vs. 2.2%), bacterial infections (10.9% vs. 4.3%), and erythema (4.3% vs. 2.2%) incidence rates were higher (20). On the contrary, the number of relapses was higher in patients treated with PDL (13% vs. 8.7%) (20). Therefore, PDL is safe and associated with fewer side effects but requires a greater number of treatments for the complete resolution of the lesions; on the contrary, Nd:YAG laser is more effective and requires fewer treatments but is associated with more pain and a greater incidence of side effects [47].
Zorman et al. used the Nd:YAG laser without anesthesia to treat warts on 85 patients. The treatment is safe and effective using alternative techniques such as ice cubes every 3–4 laser pulses or cold air to reduce pain and thermal damage of the surrounding tissues. None of the patients experienced significant side effects following the procedure; 4 patients had blisters, and 14 patients reported slight pain in the following days; no patient reported hypo/hyperpigmentation or scarring. Patients reported that the perceived pain was similar to cryotherapy’s procedures, with minor discomfort in the following days. In their experiences, topical anesthesia did not reduce the pain significantly more than placebo, with response rates similar or higher than those obtained with conventional therapies [48].
Khattab et al. described the combined treatment with long-pulsed Nd:YAG laser and potassium hydroxide (KOH) to treat recalcitrant warts. In total, 38 patients with 132 lesions were recruited, from which 66 lesions were treated with a long-pulsed Nd:YAG laser every four weeks, while the other 66 also added a 10% KOH application once daily at night. In both groups, after the first treatment, there was a reduction in wart size, with no statistically significant difference; after the second treatment, LP Nd:YAG laser plus KOH showed higher effectiveness. The mechanism of action is due to the ability of KOH to reduce hyperkeratosis of warts by favoring laser penetration [49].
Only a few cases of combined laser therapies for the treatment of warts have been reported in the literature. The first description of a successful technique with the combination of PDL and CO2 laser in treating recalcitrant warts was proposed by Mixer et al. [50]. Based on Geronemus et al.’s data trial, the use of the PDL alone has fewer side effects than the combination with the CO2 laser as described by Mixter et al. [50,51]. The combined use of the two lasers requires a prolonged healing time with the possibility of pain and scarring in the following days. The main side effect of using PDL is the appearance of a purpuric area that resolves within 7–10 days.
According to Geronemus et al., the treatment with PDL is effective only if fluences of about 7 J/cm2 are used [51]. To date, no further studies described the combined use of multiple lasers for wart’s treatment. The efficacy of combined laser therapies has been described to treat various pathologies.
The combined use of the Nd:YAG laser in association with PDL has been described for the treatment of melasma [52], tattoo removal [53], hypertrophic scar [54], capillary malformation [55], infantile hemangiomas [56], port-wine stains [57], PHACES syndrome [58], Mibelli’s angiokeratoma [59] and cutaneous symptoms of connective tissue disease [60]. The combined use of the CO2 laser in association with PDL has been described for the treatment of flap necrosis after surgery [61], keloids [62], and giant epidermal nevus [63].
The ablative CO2 laser requires fewer treatments to achieve complete healing than non-ablative lasers such as PDL and Nd:YAG laser. Among non-ablative lasers, Nd:YAG laser requires fewer sessions than PDL. The Nd:YAG laser is more effective in treating plantar warts [64]. PDL treatment has fewer side effects than Nd:YAG laser treatment, but it is less effective. The combination of topical or keratolytic therapies may be helpful before laser treatment to achieve a better response [4].

5. Conclusions

This article proposed a combined treatment using a first pass of CO2 laser to expose the viral lesions, followed by a second pass of vascular laser to reduce the vascular afflux to the area, necrotize viral warts, and reduce the relapse rate. Pulsed dye laser was used in the area where the skin was thin, and Nd:YAG in the areas with thicker skin, with an optimal result; the response rate was very high, and the relapse rate was very low, suggesting this combined treatment as a valid alternative in recalcitrant and treatment-resistant warts. It was fundamental to associate keratolytic creams in the weeks following the procedure to eliminate any necrotic debris following vascular laser treatment. Limitations of this study included the relatively low number of participants and the absence of a control group using only salicylic acid and urea to manage warts.
Vascular lasers are a very operator-dependent procedure, so it is fundamental for the physician to be adequately trained to improve the results and reduce side effects. In addition, further studies and trials are necessary to confirm the findings of this study, and a prospective trial comparing this new combination with single techniques will be required to validate the results obtained by this paper.

Author Contributions

Conceptualization, G.C., F.T. and L.B.; methodology, S.P.N., F.R. and E.Z.; software, G.F.; validation, L.B., S.P.N. and G.F.; formal analysis, L.B.; investigation, S.P.N.; data curation, G.C.; writing—original draft preparation, L.B. and G.F.; writing—review and editing, L.B.; supervision, L.B.; L.B. and G.F. equally contributed to the paper. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Institutional Review Board Statement

The study was conducted according to the guidelines of the Declaration of Helsinki and approved by the Calabrian Institutional Review Board (Protocol Code 2019/373; date of approval 17 December 2019).

Informed Consent Statement

Informed consent was obtained from all subjects involved in the study.

Data Availability Statement

Data available upon request from the corresponding author due to privacy issues.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Al Aboud, A.M.; Nigam, P.K. Wart; StatPearls Publishing: Treasure Island, FL, USA, 2021. [Google Scholar]
  2. Vlahovic, T.C.; Khan, M.T. The Human Papillomavirus and Its Role in Plantar Warts: A Comprehensive Review of Diagnosis and Management. Clin. Podiatr. Med. Surg. 2016, 33, 337–353. [Google Scholar] [CrossRef] [Scilit]
  3. Loo, S.K.; Tang, W.Y. Warts (non-genital). BMJ Clin. Evid. 2014, 2014, 1710. [Google Scholar] [PubMed]
  4. Iranmanesh, B.; Khalili, M.; Zartab, H.; Amiri, R.; Aflatoonian, M. Laser therapy in cutaneous and genital warts: A review article. Dermatol. Ther. 2021, 34, e14671. [Google Scholar] [CrossRef] [Scilit]
  5. García-Oreja, S.; Álvaro-Afonso, F.J.; García-Álvarez, Y.; García-Morales, E.; Sanz-Corbalán, I.; Lázaro Martínez, J.L. Topical treatment for plantar warts: A systematic review. Dermatol. Ther. 2021, 34, e14621. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  6. Soenjoyo, K.R.; Chua, B.W.B.; Wee, L.W.Y.; Koh, M.J.A.; Ang, S.B. Treatment of cutaneous viral warts in children: A review. Dermatol. Ther. 2020, 33, e14034. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  7. Nguyen, J.; Korta, D.Z.; Chapman, L.W.; Kelly, K.M. Laser Treatment of Nongenital Verrucae: A Systematic Review. JAMA Dermatol. 2016, 152, 1025–1034. [Google Scholar] [CrossRef] [Scilit]
  8. Bennardo, L.; Del Duca, E.; Dattola, A.; Cannarozzo, G.; Nistico, S.P. Management of laser treatments during the coronavirus disease 2019 pandemic: The Italian experience. Clin. Dermatol. 2021, 39, 521–522. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  9. Fazia, G.; Cannarozzo, G.; Bennardo, L.; Nisticò, S.P. CO2 laser in the management of eccrine hidrocystomas: A retrospective study. Lasers Med. Sci. 2021, 1–5. [Google Scholar] [CrossRef] [Scilit]
  10. Cannarozzo, G.; Bennardo, L.; Negosanti, F.; Nisticò, S.P. CO2 Laser Treatment in Idiopathic Scrotal Calcinosis: A Case Series. J. Lasers Med. Sci. 2020, 11, 500–501. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  11. Dmovsek-Olup, B.; Vedlin, B. Use of Er:YAG laser for benign skin disorders. Lasers Surg. Med. 1997, 21, 13–19. [Google Scholar] [CrossRef] [Scilit]
  12. Kwok, C.S.; Gibbs, S.; Bennett, C.; Holland, R.; Abbott, R. Topical treatments for cutaneous warts. Cochrane Database Syst. Rev. 2012, 2012, CD001781. [Google Scholar] [CrossRef] [Scilit]
  13. Hruza, G.J. Laser treatment of warts and other epidermal and dermal lesions. Dermatol. Clin. 1997, 15, 487–506. [Google Scholar] [CrossRef] [Scilit]
  14. Mercuri, S.R.; Brianti, P.; Dattola, A.; Bennardo, L.; Silvestri, M.; Schipani, G.; Nisticò, S.P. CO2 laser and photodynamic therapy: Study of efficacy in periocular BCC. Dermatol. Ther. 2018, 31, e12616. [Google Scholar] [CrossRef] [Scilit]
  15. Takac, S. CO2 laser i Verruca vulgaris [The CO2 laser and Verruca vulgaris]. Med. Pregl. 2000, 53, 389–393. [Google Scholar]
  16. Serour, F.; Somekh, E. Successful treatment of recalcitrant warts in pediatric patients with carbon dioxide laser. Eur. J. Pediatr. Surg. 2003, 13, 219–223. [Google Scholar] [CrossRef] [Scilit]
  17. Boroujeni, N.H.; Handjani, F.; Saki, N. CO2 laser treatment for plantar warts in children: A case series. Dermatol. Ther. 2020, 33, e13414. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  18. Bennardo, L.; Bennardo, F.; Giudice, A.; Passante, M.; Dastoli, S.; Morrone, P.; Provenzano, E.; Patruno, C.; Nisticò, S.P. Local Chemotherapy as an Adjuvant Treatment in Unresectable Squamous Cell Carcinoma: What Do We Know So Far? Curr. Oncol. 2021, 28, 213. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  19. Pentangelo, G.; Nisticò, S.P.; Provenzano, E.; Cisale, G.Y.; Bennardo, L. Topical 5% Imiquimod Sequential to Surgery for HPV-Related Squamous Cell Carcinoma of the Lip. Medicina (Kaunas) 2021, 57, 563. [Google Scholar] [CrossRef] [Scilit]
  20. Ramsay, H.M.; Fryer, A.A.; Reece, S.; Smith, A.G.; Harden, P.N. Clinical risk factors associated with nonmelanoma skin cancer in renal transplant recipients. Am. J. Kidney Dis. 2000, 36, 167–176. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  21. Läuchli, S.; Kempf, W.; Dragieva, G.; Burg, G.; Hafner, J. CO2 laser treatment of warts in immunosuppressed patients. Dermatology 2003, 206, 148–152. [Google Scholar] [CrossRef] [Scilit]
  22. Nistico, S.P.; Silvestri, M.; Zingoni, T.; Tamburi, F.; Bennardo, L.; Cannarozzo, G. Combination of Fractional CO2 Laser and Rhodamine-Intense Pulsed Light in Facial Rejuvenation: A Randomized Controlled Trial. Photobiomodul. Photomed. Laser Surg. 2021, 39, 113–117. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  23. Lodi, G.; Sannino, M.; Caterino, P.; Cannarozzo, G.; Bennardo, L.; Nisticò, S.P. Fractional CO2 laser-assisted topical rifamycin drug delivery in the treatment of pediatric cutaneous leishmaniasis. Pediatr. Dermatol. 2021, 38, 717–720. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  24. Forbat, E.; Al-Niaimi, F. Nonvascular uses of pulsed dye laser in clinical dermatology. J. Cosmet. Dermatol. 2019. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  25. Kenton-Smith, J.; Tan, S.T. Pulsed dye laser therapy for viral warts. Br. J. Plast. Surg. 1999, 52, 554–558. [Google Scholar] [CrossRef] [Scilit]
  26. Robson, K.J.; Cunningham, N.M.; Kruzan, K.L.; Patel, D.S.; Kreiter, C.D.; O’Donnell, M.J.; Arpey, C.J. Pulsed-dye laser versus conventional therapy in the treatment of warts: A prospective randomized trial. J. Am. Acad. Dermatol. 2000, 43 Pt 1, 275–280. [Google Scholar] [CrossRef] [Scilit]
  27. Akhyani, M.; Ehsani, A.H.; Noormohammadpour, P.; Shamsodini, R.; Azizahari, S.; Sayanjali, S. Comparing Pulsed-dye Laser with Cryotherapy in the Treatment of Common Warts. J. Lasers Med. Sci. 2011, 1, 14–19. Available online: https://journals.sbmu.ac.ir/jlms/article/view/2132 (accessed on 15 November 2021).
  28. Snast, I.; Kaftory, R.; Lapidoth, M.; Mazor, S.; Hodak, E.; Mimouni, D.; Davidovici, B.; Levi, A. Combined pulsed dye laser and systemic retinoids for the treatment of hypertrophic resistant warts among organ transplant patients. Lasers Med. Sci. 2020, 35, 1653–1657. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  29. Elmaadawy, E.H.; Shams, S.S.; Hegab, D.S.; Zaki, R.A. Pulsed-dye laser versus intralesional Candida albicans antigen injection in treatment of genital warts. Acta Dermatovenerol. Alp. Pannonica Adriat. 2019, 28, 21–26. [Google Scholar] [PubMed]
  30. Focht, D.R., 3rd; Spicer, C.; Fairchok, M.P. The efficacy of duct tape vs. cryotherapy in the treatment of Verruca vulgaris (the common wart). Arch. Pediatrics Adolesc. Med. 2002, 156, 971–974. [Google Scholar] [CrossRef] [Scilit]
  31. Gibbs, S.; Harvey, I. Topical treatments for cutaneous warts. Cochrane Database Syst. Rev. 2006, CD001781. [Google Scholar] [CrossRef] [Scilit]
  32. Lipke, M.M. An armamentarium of wart treatments. Clin. Med. Res. 2006, 4, 273–293. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  33. Baleg, S.M.; Bidin, N.; Suan, L.P.; Ahmad, M.F.; Krishnan, G.; Johari, A.R.; Hamid, A. The effect of CO2 laser treatment on skin tissue. J Cosmet Dermatol. 2015, 14, 246–253. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  34. Sethuraman, G.; Richards, K.A.; Hiremagalore, R.N.; Wagner, A. Effectiveness of pulsed dye laser in the treatment of recalcitrant warts in children. Dermatol. Surg. 2010, 36, 58–65. [Google Scholar] [CrossRef] [Scilit]
  35. Huilgol, S.C.; Barlow, R.J.; Markey, A.C. Failure of pulsed dye laser therapy for resistant verrucae. Clin. Exp. Dermatol. 1996, 21, 93–95. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  36. Del Duca, E.; Zingoni, T.; Bennardo, L.; di Raimondo, C.; Garofalo, V.; Sannino, M.; Petrini, N.; Cannarozzo, G.; Bianchi, L.; Nisticò, S.P. Long-Term Follow-Up for Q-Switched Nd:YAG Treatment of Nevus of Ota: Are High Number of Treatments Really Required? A Case Report. Photobiomodul. Photomed. Laser Surg. 2021, 39, 137–140. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  37. Silvestri, M.; Bennardo, L.; Zappia, E.; Tamburi, F.; Cameli, N.; Cannarozzo, G.; Nisticò, S.P. Q-Switched 1064/532 nm Laser with Picosecond Pulse to Treat Benign Hyperpigmentations: A Single-Center Retrospective Study. Appl. Sci. 2021, 11, 7478. [Google Scholar] [CrossRef] [Scilit]
  38. Bennardo, L.; Cannarozzo, G.; Tamburi, F.; Patruno, C.; Provenzano, E.; Nisticò, S.P. Picosecond Q-Switched 1064/532 nm Laser in Tattoo Removal: Our Single Center Experience. Appl. Sci. 2021, 11, 9712. [Google Scholar] [CrossRef] [Scilit]
  39. Cannarozzo, G.; Nisticò, S.P.; Zappia, E.; del Duca, E.; Provenzano, E.; Patruno, C.; Negosanti, F.; Sannino, M.; Bennardo, L. Q-Switched 1064/532 nm Laser with Nanosecond Pulse in Tattoo Treatment: A Double-Center Retrospective Study. Life 2021, 11, 699. [Google Scholar] [CrossRef] [Scilit]
  40. Cannarozzo, G.; Negosanti, F.; Sannino, M.; Santoli, M.; Bennardo, L.; Banzola, N.; Negosanti, L.; Nisticò, S.P. Q-switched Nd:YAG laser for cosmetic tattoo removal. Dermatol. Ther. 2019, 32, e13042. [Google Scholar] [CrossRef] [Scilit]
  41. Bingol, U.A.; Cömert, A.; Cinar, C. The Overlapped Triple Circle Pulse Technique with Nd:YAG Laser for Refractory Hand Warts. Photomed. Laser Surg. 2015, 33, 338–342. [Google Scholar] [CrossRef] [Scilit]
  42. Kopera, D. Verrucae vulgares: Flashlamp-pumped pulsed dye laser treatment in 134 patients. Int. J. Dermatol. 2003, 42, 905–908. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  43. Weiss, R.A.; Weiss, M.A. Early clinical results with a multiple synchronized pulse 1064 NM laser for leg telangiectasias and reticular veins. Dermatol. Surg. 1999, 25, 399–402. [Google Scholar] [CrossRef] [Scilit]
  44. Yeh, Y.T.; Peng, J.H.; Peng, P. Histology of ex vivo skin after treatment with fractionated picosecond Nd:YAG laser in high and low-energy settings. J. Cosmet. Laser Ther. 2020, 22, 43–47. [Google Scholar] [CrossRef] [Scilit]
  45. El-Tonsy, M.H.; Anbar, T.E.; El-Domyati, M.; Barakat, M. Density of viral particles in pre and post Nd: YAG laser hyperthermia therapy and cryotherapy in plantar warts. Int. J. Dermatol. 1999, 38, 393–398. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  46. Han, T.Y.; Lee, J.H.; Lee, C.K.; Ahn, J.Y.; Seo, S.J.; Hong, C.K. Long-pulsed Nd:YAG laser treatment of warts: Report on a series of 369 cases. J. Korean Med. Sci. 2009, 24, 889–893. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  47. El-Mohamady, A.e.l.-S.; Mearag, I.; El-Khalawany, M.; Elshahed, A.; Shokeir, H.; Mahmoud, A. Pulsed dye laser versus Nd:YAG laser in the treatment of plantar warts: A comparative study. Lasers Med. Sci. 2014, 29, 1111–1116. [Google Scholar] [CrossRef] [Scilit]
  48. Zorman, A.; Koron, N. Wart removal without anesthesia using long-pulse 1064-nm Nd:YAG laser. J. Cosmet. Dermatol. 2021, 20, 506–512. [Google Scholar] [CrossRef] [Scilit]
  49. Khattab, F.M.; Khashaba, S.A. Evaluation of combined treatment with long-pulsed neodymium-doped yttrium aluminum garnet laser and potassium hydroxide for the treatment of recalcitrant wart: A prospective comparative study. J. Dermatol. Treat. 2020, 31, 56–60. [Google Scholar] [CrossRef] [Scilit]
  50. Mixter, R.C.; Carson, L.V.; Walton, B.J.; Gerson, R.W. Optic nerve decompression in fibrous dysplasia: Indications, efficacy, and safety. Plast. Reconstr. Surg. 1997, 100, 1612–1613. [Google Scholar] [CrossRef] [Scilit]
  51. Geronemus, R.G.; Kauvar, A.N.; McDaniel, D.H. Treatment of recalcitrant verrucae with both the ultrapulse CO2 and PLDL pulsed dye lasers. Plast. Reconstr. Surg. 1998, 101, 2010. [Google Scholar] [CrossRef] [Scilit]
  52. Kong, S.H.; Suh, H.S.; Choi, Y.S. Treatment of Melasma with Pulsed-Dye Laser and 1,064-nm Q-Switched Nd:YAG Laser: A Split-Face Study. Ann. Dermatol. 2018, 30, 1–7. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  53. Bonan, P.; Bassi, A.; Bruscino, N.; Schincaglia, E.; Gavrilova, M.; Troiano, M.; Verdelli, A. Combined pulsed dye laser and Q-switched Nd:YAG laser intraumatic facial tattoo removal: A case series. Dermatol. Ther. 2019, 32, e13069. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  54. Lin, L.; Guo, P.; Wang, X.; Huo, R.; Li, Q.; Yin, S.; Cao, Y. Effective treatment for hypertrophic scar with dual-wave-length PDL and Nd:YAG in Chinese patients. J. Cosmet. Laser Ther. 2019, 21, 228–233. [Google Scholar] [CrossRef] [Scilit]
  55. Alcántara-González, J.; Boixeda, P.; Truchuelo-Díez, M.T.; Jiménez-Gómez, N.; Pérez-García, B.; Pérez-Carmona, L.; Olasolo, P.J. Capillary Malformations Treated With Sequential Pulsed Dye and Nd:YAG Laser Therapy: A Retrospective Study. Malformaciones capilares tratadas con aplicación secuencial de láser de colorante pulsado y Nd:YAG: Estudio retrospectivo. Actas Dermo-Sifiliográficas (Engl. Ed.) 2018, 109, 155–161. [Google Scholar] [CrossRef] [Scilit]
  56. Hartmann, F.; Lockmann, A.; Himpel, O.; Kühnle, I.; Hensen, J.; Schön, M.P.; Thoms, K. Combination therapy of oral propranolol and combined Nd:YAG/pulsed dye laser therapy in infantile hemangiomas: A retrospective analysis of 48 treated hemangiomas in 30 children. J. Dtsch. Dermatol. Ges. 2020, 18, 984–993. [Google Scholar] [CrossRef]
  57. Wang, T.; Chen, D.; Yang, J.; Ma, G.; Yu, W.; Lin, X. Safety and efficacy of dual-wavelength laser (1064 + 595 nm) for treatment of non-treated port-wine stains. J. Eur. Acad. Dermatol. Venereol. 2018, 32, 260–264. [Google Scholar] [CrossRef] [Scilit]
  58. Negosanti, F.; Silvestri, M.; Bennardo, L.; Durastante, C.; del Duca, E.; Cannarozzo, G.; Nisticò, S.P. Nd:YAG laser in association with pulsed dye laser for the treatment of PHACES syndrome. Derm. Rep. 2021, 13, 8751. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  59. Zeng, Y.; Li, X.Q.; Lin, Q.Z.; Zhan, K. Treatment of angiokeratoma of Mibelli alone or in combination with pulsed dye laser and long-pulsed Nd: YAG laser. Dermatol. Ther. 2014, 27, 348–351. [Google Scholar] [CrossRef] [Scilit]
  60. Park, J.S.; Kim, H.S.; Choi, C.P. Utilizing Combined Pulsed Dye and Nd: YAG Lasers in the Treatment of Connective Tissue Disease Cutaneous Symptoms. J. Clin. Rheumatol. 2019, 27, S451–S452. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  61. Nisticò, S.P.; Bennardo, L.; Sannino, M.; Negosanti, F.; Tamburi, F.; del Duca, E.; Giudice, A.; Cannarozzo, G. Combined CO2 and dye laser technique in the treatment of outcomes due to flap necrosis after surgery for basal cell carcinoma on the nose. Lasers Surg. Med. 2021. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  62. Piccolo, D.; Crisman, G.; Bovani, B.; Gennai, A.; Melfa, F.; Clementoni, M.T.; Conforti, C. Combined laser treatment for ear keloids: Case series: Comparison between two mini-invasive protocols. J. Cosmet. Dermatol. 2021, 21, 296–306. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  63. Sannino, M.; Ambrosio, A.G.; Lodi, G.; Cannarozzo, G.; Bennardo, L.; Nisticò, S.P. A giant epidermal nevus of the face treated with a CO2 and dye laser combination: A case report and literature review. J. Cosmet. Laser Ther. 2021, 23, 59–64. [Google Scholar] [CrossRef] [Scilit] [PubMed]
  64. Shin, Y.S.; Cho, E.B.; Park, E.J.; Kim, K.H.; Kim, K.J. A comparative study of pulsed dye laser versus long pulsed Nd:YAG laser treatment in recalcitrant viral warts. J. Dermatol. Treat. 2017, 28, 411–416. [Google Scholar] [CrossRef] [Scilit] [PubMed]
Medicina 58 00115 g001
Figure 1. Patient n. 3 before treatment (left), during laser therapy (central), and 4 months after treatment (right).
Figure 1. Patient n. 3 before treatment (left), during laser therapy (central), and 4 months after treatment (right).
Medicina 58 00115 g001
Medicina 58 00115 g002aMedicina 58 00115 g002b
Figure 2. (b) Patient n. 20 before treatment (left) and 1 month after treatment (right) dermatoscopic view; (a) patient n. 20 before treatment (left) and 1 month after treatment (right).
Figure 2. (b) Patient n. 20 before treatment (left) and 1 month after treatment (right) dermatoscopic view; (a) patient n. 20 before treatment (left) and 1 month after treatment (right).
Medicina 58 00115 g002aMedicina 58 00115 g002b
Medicina 58 00115 g003
Figure 3. Patient n. 6 before treatment (left), immediately after combined treatment (central), and 4 months after treatment (right).
Figure 3. Patient n. 6 before treatment (left), immediately after combined treatment (central), and 4 months after treatment (right).
Medicina 58 00115 g003
Medicina 58 00115 g004
Figure 4. Patient n. 27 before treatment (left), immediately after combined treatment (central), and 4 months after treatment (right).
Figure 4. Patient n. 27 before treatment (left), immediately after combined treatment (central), and 4 months after treatment (right).
Medicina 58 00115 g004
Medicina 58 00115 g005
Figure 5. Patient n. 19 before treatment (upper left), immediately after CO2 treatment (upper right), immediately after combined treatment (lower left), and 1 month after treatment (lower right).
Figure 5. Patient n. 19 before treatment (upper left), immediately after CO2 treatment (upper right), immediately after combined treatment (lower left), and 1 month after treatment (lower right).
Medicina 58 00115 g005
Table 1. Patient characteristics.
Table 1. Patient characteristics.
Patient NumberSexAgeNumber of WartsLocationResolutionRelapseSide EffectsVAS ScoreAnesthesia
1M711PPT 10Yes
2M94OT 10No
3F293OT 10Yes
4F385PPT H8Yes
5M684OT 10Yes
6F121PPT 10Yes
7M284OT 9No
8F673OT H7Yes
9M232OT 9Yes
10F651PPP 7Yes
11F144OTR 8No
12M453PPT 10Yes
13F347OT 10Yes
14F223PPT 10Yes
15F743OT 10Yes
16M671PPT H9Yes
17F681PPP 10Yes
18M255OT 10No
19M541PPT 10Yes
20F522OT 10No
21M781PPTR 7Yes
22F156OT 9Yes
23M193PPTR 9Yes
24F645OT 10No
25F431PPT H10Yes
26M374OT 8Yes
27F341PPT 9Yes
28M253OT H10Yes
29F274OT 9No
30F581PPT 9Yes
31M674OT 10Yes
32M653OT 9No
33M644PPT 10Yes
34F435PPT 10Yes
M: male, F: female, PP: palmoplantar region, O: other regions, T: total, P: partial, R: relapse, H: hypopigmentation.
Table 2. Treatment protocol.
Table 2. Treatment protocol.
First session of CO2 laser in super-pulsed mode, with a focused beam of 0.1–0.2 mm diameter, power 0.3–0.8 W, fre-quency 10 Hz, with the intent to remove the superficial layer of the epidermis, exposing the superficial dermis but without causing bleeding.
Right after CO2 laser, a second session with long-pulsed Nd:YAG laser for lesions interesting the palmoplantar region (90–120 J/cm2, 5 mm spot size, slightly defocused, double pulse 5–15 ms with a 10 ms interval performing multiple passes), and with a 595 nm Dye laser for all other regions (10 mm size spot, fluence 9–10 J/cm2, and frequency 0.5/s, per-forming multiple passes) was performed on the treated spot, in order to reduce the vascularization to the treated area.
After the combined treatment, topical fusidic acid was applied to the lesion twice a day for one week.
From the second week, a 20% salicylic acid cream in the evening and 40% urea in the morning were applied for the other three weeks up to clinical follow-up.
A first clinical follow-up at one month evaluated lesion disappearance.
A second clinical follow up at four months evaluated relapses.
Publisher’s Note: MDPI stays neutral with regard to jurisdictional claims in published maps and institutional affiliations.

Share and Cite

MDPI and ACS Style

Bennardo, L.; Fasano, G.; Tamburi, F.; Zappia, E.; Rizzuto, F.; Nisticò, S.P.; Cannarozzo, G. Sequential Use of CO2 Laser Prior to Nd:YAG and Dye Laser in the Management of Non-Facial Warts: A Retrospective Study. Medicina 2022, 58, 115. https://doi.org/10.3390/medicina58010115

AMA Style

Bennardo L, Fasano G, Tamburi F, Zappia E, Rizzuto F, Nisticò SP, Cannarozzo G. Sequential Use of CO2 Laser Prior to Nd:YAG and Dye Laser in the Management of Non-Facial Warts: A Retrospective Study. Medicina. 2022; 58(1):115. https://doi.org/10.3390/medicina58010115

Chicago/Turabian Style

Bennardo, Luigi, Gaia Fasano, Federica Tamburi, Elena Zappia, Francesco Rizzuto, Steven Paul Nisticò, and Giovanni Cannarozzo. 2022. "Sequential Use of CO2 Laser Prior to Nd:YAG and Dye Laser in the Management of Non-Facial Warts: A Retrospective Study" Medicina 58, no. 1: 115. https://doi.org/10.3390/medicina58010115

APA Style

Bennardo, L., Fasano, G., Tamburi, F., Zappia, E., Rizzuto, F., Nisticò, S. P., & Cannarozzo, G. (2022). Sequential Use of CO2 Laser Prior to Nd:YAG and Dye Laser in the Management of Non-Facial Warts: A Retrospective Study. Medicina, 58(1), 115. https://doi.org/10.3390/medicina58010115

Article Metrics

Back to TopTop
