Advancing Balance Assessment in Stroke Rehabilitation: A Comparative Exploration of Sensor-Based and Conventional Balance Tests
Highlights
- Postural sway measures are less prone to floor and ceiling effects and may be well suited for monitoring balance progression in the future.
- Postural sway measurement provides complementary balance information: IMU stance-tasks correlated moderately with the BBS and Mini-BESTest, while IMU sitting-tasks showed weak to no association with the TCT.
- IMUs capture balance information that is partially distinct from conventional tests and therefore cannot replace conventional balance tests.
- The clinical value of postural sway measurement in clinical stroke rehabilitation requires further investigation.
Abstract
1. Introduction
2. Materials and Methods
2.1. Study Participants
2.2. Design
2.3. Sample Size Estimation
2.4. Measurements
2.4.1. IMU Balance Test
2.4.2. Trunk Control Test
2.4.3. Berg Balance Scale
2.4.4. Mini-BESTest
2.5. Analysis
2.5.1. Floor and Ceiling Effects
2.5.2. Relationship and Extent of Covariance Between the IMU and Conventional Tests
3. Results
3.1. Floor and Ceiling Effects
3.2. Relationship and Extent of Covariance Between IMU Measurements and Conventional Tests
4. Discussion
4.1. Study Limitations
4.2. Clinical Relevance
5. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
Abbreviations
| TCT | Trunk Control Test |
| BBS | Berg Balance Scale |
| Mini-BESTest | Mini Balance Evaluation Systems Test |
| IMU | Inertial Measurement Unit |
| ADL | Activities of Daily Living |
| CoM | Center of Mass |
| BoS | Base of Support |
| MDC | Minimal Detectable Change |
| PCA | Principal Component Analysis |
| SD | Standard Deviation |
Appendix A
| Sit | Sit Unstable * | Stance EO | Stance EC | Stance Unstable | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| PCA1 | PCA2 | PCA1 | PCA2 | PCA1 | PCA2 | PCA1 | PCA2 | PCA1 | PCA2 | |
| EVR | 57.2% | 27.6% | 55.8% | 27.4% | 57.8% | 26.4% | 60.4% | 21.3% | 64.6% | 16.6% |
| RMSE | 0.475 | 0.526 | - | - | 0.283 | 0.811 | 0.47 | 0.88 | 0.475 | 0.629 |
| ICC [CI] | 0.913 [0.84, 0.95] | 0.872 [0.77, 0.93] | - | - | 0.962 [0.92, 0.98] | 0.707 [0.48, 0.84] | 0.905 [0.8, 0.96] | 0.764 [0.55, 0.88] | 0.902 [0.79, 0.96] | 0.819 [0.63, 0.92] |
| MDC (SEM) | 0.815 (0.294) | 1.297 (0.468) | - | - | 1.29 (0.465) | 1.288 (0.465) | 3.311 (1.194) | 1.542 (0.556) | 3.453 (1.246) | 1.305 (0.471) |
References
- Bower, K.; Thilarajah, S.; Pua, Y.-H.; Williams, G.; Tan, D.; Mentiplay, B.; Denehy, L.; Clark, R. Dynamic balance and instrumented gait variables are independent predictors of falls following stroke. J. Neuroeng. Rehabil. 2019, 16, 1. [Google Scholar] [CrossRef]
- Botö, S.; Buvarp, D.; Hansson, P.; Sunnerhagen, K.; Persson, C. Physical inactivity after stroke: Incidence and early predictors based on 190 individuals in a 1-year follow-up of the Fall Study of Gothenburg. J. Rehabil. Med. 2021, 53, jrm00224. [Google Scholar] [CrossRef]
- Winstein, C.J.; Stein, J.; Arena, R.; Bates, B.; Cherney, L.R.; Cramer, S.C.; Deruyter, F.; Eng, J.J.; Fisher, B.; Harvey, R.L.; et al. Guidelines for Adult Stroke Rehabilitation and Recovery: A Guideline for Healthcare Professionals From the American Heart Association/American Stroke Association. Stroke 2016, 47, e98–e169. [Google Scholar] [CrossRef]
- Kwakkel, G.; Wagenaar, R.C.; Kollen, B.J.; Lankhorst, G.J. Predicting Disability in Stroke—A Critical Review of the Literature. Age Ageing 1996, 25, 479–489. [Google Scholar] [CrossRef]
- Louie, D.; Eng, J. Berg Balance Scale score at admission can predict walking suitable for community ambulation at discharge from inpatient stroke rehabilitation. J. Rehabil. Med. 2018, 50, 37–44. [Google Scholar] [CrossRef]
- Royal Dutch Society for Physical Therapy KNGF Guideline Stroke. 2014. Available online: www.fysionet.nl (accessed on 30 December 2025).
- Sorrentino, G.; Sale, P.; Solaro, C.; Rabini, A.; Cerri, C.G.; Ferriero, G. Clinical measurement tools to assess trunk performance after stroke: A systematic review. Eur. J. Phys. Rehabil. Med. 2018, 54, 772–784. [Google Scholar] [CrossRef] [PubMed]
- Blum, L.; Korner-Bitensky, N. Usefulness of the Berg Balance Scale in Stroke Rehabilitation: A Systematic Review. Phys. Ther. 2008, 88, 559–566. [Google Scholar] [CrossRef]
- Van Criekinge, T.; Heremans, C.; Burridge, J.; E Deutsch, J.; Hammerbeck, U.; Hollands, K.; Karthikbabu, S.; Mehrholz, J.; Moore, J.L.; Salbach, N.M.; et al. Standardized measurement of balance and mobility post-stroke: Consensus-based core recommendations from the third Stroke Recovery and Rehabilitation Roundtable. Int. J. Stroke 2023, 19, 158–168. [Google Scholar] [CrossRef] [PubMed]
- Park, S.-H.; Lee, Y.-S. The Diagnostic Accuracy of the Berg Balance Scale in Predicting Falls. West. J. Nurs. Res. 2016, 39, 1502–1525. [Google Scholar] [CrossRef]
- Goljar, N.; Rudolf, M.; Bizovičar, N. Algorithm for selection of balance assessment tools in post-stroke patients. Int. J. Rehabil. Res. 2019, 42, 229–233. [Google Scholar] [CrossRef] [PubMed]
- Di Carlo, S.; Bravini, E.; Vercelli, S.; Massazza, G.; Ferriero, G. The Mini-BESTest: A review of psychometric properties. Int. J. Rehabil. Res. 2016, 39, 97–105. [Google Scholar] [CrossRef]
- Roaldsen, K.; Wakefield, E.; Jørgensen, V.; Opheim, A. Pragmatic evaluation of aspects concerning validity and feasibility of the mini balance evaluation system test in a specialized rehabilitation setting. Physiotherapy 2015, 101, e694–e695. [Google Scholar] [CrossRef]
- Horak, F.; King, L.; Mancini, M. Role of Body-Worn Movement Monitor Technology for Balance and Gait Rehabilitation. Phys. Ther. 2015, 95, 461–470. [Google Scholar] [CrossRef]
- Cho, K.; Lee, K.; Lee, B.; Lee, H.; Lee, W. Relationship between Postural Sway and Dynamic Balance in Stroke Patients. J. Phys. Ther. Sci. 2014, 26, 1989–1992. [Google Scholar] [CrossRef]
- Halmi, Z.; Stone, T.W.; Dinya, E.; Málly, J. Postural instability years after stroke. J. Stroke Cerebrovasc. Dis. 2020, 29, 105038. [Google Scholar] [CrossRef]
- Li, D.; Kaminishi, K.; Chiba, R.; Takakusaki, K.; Mukaino, M.; Ota, J. Evaluation of Postural Sway in Post-stroke Patients by Dynamic Time Warping Clustering. Front. Hum. Neurosci. 2021, 15, 726. [Google Scholar] [CrossRef] [PubMed]
- Wang, W.; Li, K.; Wei, N.; Yin, C.; Yue, S. Evaluation of postural instability in stroke patient during quiet standing. In Proceedings of the 2017 39th Annual International Conference of the IEEE Engineering in Medicine and Biology Society (EMBC), Seogwipo, Republic of Korea, 11–15 July 2017. [Google Scholar] [CrossRef]
- Horak, F.B. Postural orientation and equilibrium: What do we need to know about neural control of balance to prevent falls? Age Ageing 2006, 35, ii7–ii11. [Google Scholar] [CrossRef] [PubMed]
- Mancini, M.; Carlson-Kuhta, P.; Zampieri, C.; Nutt, J.G.; Chiari, L.; Horak, F.B. Postural sway as a marker of progression in Parkinson’s disease: A pilot longitudinal study. Gait Posture 2012, 36, 471. [Google Scholar] [CrossRef]
- Calcagni, M.; Kosa, P.; Bielekova, B. Smartphone postural sway and pronator drift tests as measures of neurological disability. BMC Neurol. 2025, 25, 50. [Google Scholar] [CrossRef] [PubMed]
- Hansson, E.E.; Tornberg, Å. Coherence and reliability of a wearable inertial measurement unit for measuring postural sway. BMC Res. Notes 2019, 12, 201. [Google Scholar] [CrossRef]
- Alsubaie, S.F.; Whitney, S.L.; Furman, J.M.; Marchetti, G.F.; Sienko, K.H.; Sparto, P.J. Reliability of Postural Sway Measures of Standing Balance Tasks. J. Appl. Biomech. 2019, 35, 11–18. [Google Scholar] [CrossRef]
- Felius, R.; Geerars, M.; Bruijn, S.; Wouda, N.; Van Dieën, J.; Punt, M. Reliability of IMU-based balance assessment in clinical stroke rehabilitation. Gait Posture 2022, 98, 62–68. [Google Scholar] [CrossRef]
- Mangalam, M.; Kelty-Stephen, D.G.; Seleznov, I.; Popov, A.; Likens, A.D.; Kiyono, K.; Stergiou, N. Older adults and individuals with Parkinson’s disease control posture along suborthogonal directions that deviate from the traditional anteroposterior and mediolateral directions. Sci. Rep. 2024, 14, 4117. [Google Scholar] [CrossRef] [PubMed]
- Geurts, A.C.; de Haart, M.; van Nes, I.J.; Duysens, J. A review of standing balance recovery from stroke. Gait Posture 2005, 22, 267–281. [Google Scholar] [CrossRef] [PubMed]
- Coupland, A.P.; Thapar, A.; I Qureshi, M.; Jenkins, H.; Davies, A.H. The definition of stroke. J. R. Soc. Med. 2017, 110, 9. [Google Scholar] [CrossRef] [PubMed]
- De Vet, H.; Terwee, C.; Mokkink, L.; Knol, D. Measurement in Medicine: A Practical Guide. 2011. Available online: https://sci-hub.do/https://books.google.com/books?hl=en&lr=&id=_OcdeTg9i28C&oi=fnd&pg=PR3&ots=1svRRFXlAn&sig=GzTudRTaNVCYqiAF9aMuqcCGSMM (accessed on 24 November 2021).
- Collin, C.; Wade, D. Assessing motor impairment after stroke: A pilot reliability study. J. Neurol. Neurosurg. Psychiatry 1990, 53, 576–579. [Google Scholar] [CrossRef]
- Berg, K.; Wood-Dauphinee, S.; Williams, J.I.; Gayton, D. Measuring balance in the elderly: Preliminary development of an instrument. Physiother. Can. 2009, 41, 304–311. [Google Scholar] [CrossRef]
- Franchignoni, F.; Horak, F.; Godi, M.; Nardone, A.; Giordano, A. Using psychometric techniques to improve the Balance Evaluation Systems Test: The mini-BESTest. J. Rehabil. Med. 2010, 42, 323–331. [Google Scholar] [CrossRef]
- Miyata, K.; Hasegawa, S.; Iwamoto, H.; Otani, T.; Kaizu, Y.; Shinohara, T.; Usuda, S. Comparing the measurement properties and relationship to gait speed recovery of the Mini-Balance Evaluation Systems Test and the Berg Balance Scale in ambulatory individuals with subacute stroke. Phys. Ther. Res. 2020, 23, 72–78. [Google Scholar] [CrossRef]
- Chan, A.C.; Pang, M.Y. Assessing Balance Function in Patients With Total Knee Arthroplasty. Phys. Ther. 2015, 95, 1397–1407. [Google Scholar] [CrossRef]
- Cain, M.K.; Zhang, Z.; Yuan, K.-H. Univariate and multivariate skewness and kurtosis for measuring nonnormality: Prevalence, influence and estimation. Behav. Res. Methods 2016, 49, 1716–1735. [Google Scholar] [CrossRef]
- Rodrigues, S.d.L.L.; Rodrigues, R.C.M.; Sao-Joao, T.M.; Pavan, R.B.B.; Padilha, K.M.; Gallani, M.-C. Impact of the disease: Acceptability, ceiling and floor effects and reliability of an instrument on heart failure. Rev. Esc. Enferm. USP 2013, 47, 1090–1097. [Google Scholar] [CrossRef]
- Arslan, J.; Benke, K. Statistical Analysis of Ceiling and Floor Effects in Medical Trials. Appl. Biosci. 2023, 2, 668–681. [Google Scholar] [CrossRef]
- Portney, L.; Watkins, M. Foundations of Clinical Research: Applications to Practice; Pearson/Prentice Hall: Upper Saddle River, NJ, USA, 2009; Volume 892, Available online: https://sci-hub.do/http://babymariam.gm/sites/default/files/webform/pdf-foundations-of-clinical-research-applications-to-practice-3rd-e-leslie-g-portney-mary-p-watkins-pdf-download-free-book-d3094a3.pdf (accessed on 2 August 2022).
- Rauch, A.; Cieza, A.; Stucki, G. How to apply the International Classification of Functioning, Disability and Health (ICF) for rehabilitation management in clinical practice. Eur. J. Phys. Rehabil. Med. 2008, 44, 329–342. Available online: https://pubmed.ncbi.nlm.nih.gov/18762742/ (accessed on 21 April 2023).
- Veerbeek, J.M.; Van Wegen, E.; Van Peppen, R.; Van Der Wees, P.J.; Hendriks, E.; Rietberg, M.; Kwakkel, G. What Is the Evidence for Physical Therapy Poststroke? A Systematic Review and Meta-Analysis. PLoS ONE 2014, 9, e87987. [Google Scholar] [CrossRef] [PubMed]
- Ghislieri, M.; Gastaldi, L.; Pastorelli, S.; Tadano, S.; Agostini, V. Wearable Inertial Sensors to Assess Standing Balance: A Systematic Review. Sensors 2019, 19, 4075. [Google Scholar] [CrossRef]
- van Nes, I.J.; Nienhuis, B.; Latour, H.; Geurts, A.C. Posturographic assessment of sitting balance recovery in the subacute phase of stroke. Gait Posture 2008, 28, 507–512. [Google Scholar] [CrossRef]
- Sawacha, Z.; Carraro, E.; Contessa, P.; Guiotto, A.; Masiero, S.; Cobelli, C. Relationship between clinical and instrumental balance assessments in chronic post-stroke hemiparesis subjects. J. Neuroeng. Rehabil. 2013, 10, 95. [Google Scholar] [CrossRef] [PubMed]
- Alessandrini, M.; Micarelli, A.; Viziano, A.; Pavone, I.; Costantini, G.; Casali, D.; Paolizzo, F.; Saggio, G. Body-worn triaxial accelerometer coherence and reliability related to static posturography in unilateral vestibular failure. Acta Otorhinolaryngol. Ital. 2017, 37, 231–236. [Google Scholar] [CrossRef]
- Hair, J.F.J.; Black, W.C.; Babin, B.J.; Anderson, R.E. Multivariate Data Analysis, 7th ed.; Pearson Education Inc.: Hoboken, NJ, USA, 2010; p. 761. Available online: https://www.worldcat.org/title/317669474 (accessed on 19 June 2023).
- Koo, T.K.; Li, M.Y. A Guideline of Selecting and Reporting Intraclass Correlation Coefficients for Reliability Research. J. Chiropr. Med. 2016, 15, 155–163. [Google Scholar] [CrossRef] [PubMed]


| IMU Task | Duration | Description | |
|---|---|---|---|
| Stable sit | 60 s | Sitting unsupported on a flat, stable underground, feet on the ground on a self-selected distance, hips and knees in a 90° position | ![]() |
| Unstable sit | 60 s | Sitting unsupported on an aircushion, placed on a flat, stable underground, feet on the ground, maximally 15 cm apart | |
| Stable stance EO | 60 s | Standing unsupported, self-selected foot position | |
| Stable stance EC | 30 s | Standing unsupported with eyes closed, self-selected foot position | |
| Unstable stance | 30 s | Standing unsupported on a foam cushion, self-selected foot position |
| Characteristics | All Participants Admission (N = 105) | All Participants Discharge (N = 90) |
|---|---|---|
| Demographics | ||
| Age (years) | 72.7 (12.2) [28–99] | 72.6 (12.3) [28–99] |
| Sex (female/male) n (%) | 51/54 (48.6/51.4%) | 45/45 (50/50%) |
| Body mass index (kg/m2) | 26.0 (5.3) [10.3–45.4] | 26.3 (5.5) [10.3–45.4] |
| Stroke characteristics | ||
| Ischaemic n (%) | 82 (78%) | 71 (78.9%) |
| Haemorrhagic n (%) | 18 (17.1%) | 16 (17.8%) |
| SAH n (%) | 5 (4.8%) | 3 (3.3%) |
| Location stroke n (%) | ||
| ▪cortical | 56 (55.0%) | 47 (52.2%) |
| ▪subcortical | 10 (10.0%) | 10 (11.1%) |
| ▪midbrain | 7 (7.0%) | 6 (6.7%) |
| ▪brainstem | 11 (11.0%) | 10 (11.1%) |
| ▪undetermined | 21 (17.0%) | 17 (18.9%) |
| Time since stroke (weeks) | 2.2 (2.2) [0.7–13.7] | 8.9 (4.7) [3.0–21.0] |
| Paretic side n | ||
| ▪Left | 46 | 40 |
| ▪Right | 35 | 28 |
| ▪Both sides | 4 | 3 |
| ▪None | 20 | 19 |
| Barthel Index (0–20) (n = 101/77) | 13.0 (4.9) [0–20] | 17.7 (4.0) [1–20] |
| MRS (0–5) (n = 72/62) | 3.5 (0.8) [2–5] | 2.4 (0.9) [1–4] |
| NIHSS (0–34) (n = 70/59) | 4.5 (3.5) [0–18] | 1.9 (2.6) [0–13] |
| Motor performance | ||
| MI LE L (0–100) (n = 93/75) | 87.1 (22.5) [0–100] | 89.4 (19.6) [9–100] |
| MI LE R (0–100) (n = 92/75) | 90.0 (18.6) [0–100] | 95.5 (13.0) [34–100] |
| FMA-LE score (0–34) (n = 47/48) | 26.8 (8.8) [4–34] | 30.0 (6.7) [8–34] |
| Conventional balance test performance | ||
| TCT (0–100) (n = 103/85) | 87.6 (22.8) [12–100] | 96.3 (18.1) [36–100] |
| BBS (0–56) (n = 100/80) | 34.7 (17.2) [3–56] | 46.1 (11.9) [4–56] |
| Mini-BESTest (0–28) (n = 23/28) | 20.8 (4.0) [14–27] | 22.1 (5.1) [8–28] |
| IMU balance performance | ||
| Stable sit (n = 100/80) | −0.29 (−0.67, 0.53) | −0.55 (−0.85, −0.05) |
| [−1.23, 4.31] | [−1.18, 6.95] | |
| Unstable sit (n = 93/79) | −0.17 (−1.28, 0.84) | −1.04 (−1.79, 0.06) |
| [−3.14, 11.44] | [−3.21, 17.97] | |
| Stable stance EO (n = 84/77) | −0.37 (−1.43, 0.83) | −0.81 (−1.46, 0.27) |
| [−2.49, 18.48] | [−2.50, 6.77] | |
| Stable stance EC (n = 75/74) | −0.44 (−1.64, 0.32) | −0.70 (−1.66, 0.52) |
| [−2.80, 11.12] | [−2.87, 11.53] | |
| Unstable stance (n = 65/73) | −0.42 (−1.50, 0.42) | −0.44 (−1.46, 0.60) |
| [−2.95, 17.20] | [−3.06, 8.52] |
| Balance Tests | Skewness (ϒ) | Kurtosis | Floor Effect (% Participants Obtaining the Worst 10% Score) | Ceiling Effect (% Participants Obtaining the Best 10% Score) | Ceiling Effect (% Participants with the Best Possible Score) |
|---|---|---|---|---|---|
| Trunk Control Test (n = 98/79) | −1.87/−3.53 | 2.71/11.65 | 0/0 | 76.1/89.7 | 69.8/89.7 |
| Berg Balance Scale (n = 97/74) | −0.62/−2.06 | −0.96/4.39 | 10.5/4.1 | 22.3/43.3 | 3.2/8.1 |
| Mini-BESTest (n = 23/28) | −0.19/−1.15 | −0.89/0.69 | 0/0 | 13.0/32.1 | 0/7.1 |
| IMU sit stable (n = 100/80) | 1.69/4.62 | 3.79/28.73 | 0/0 | 0/0 | N/A |
| IMU sit unstable (n = 93/79) | 1.99/5.20 | 4.81/36.53 | 3.3/0 | 0/0 | N/A |
| IMU stance EO (n = 84/77) | 3.94/2.01 | 20.7/4.74 | 1.2/4 | 0/0 | N/A |
| IMU stance EC (n = 75/74) | 2.45/2.26 | 7.37/6.44 | 0/1.4 | 0/0 | N/A |
| IMU stance unstable (n = 65/73) | 3.80/2.15 | 19.92/5.81 | 0/0 | 0/0 | N/A |
| IMU Task | Admission | Discharge | ||||
|---|---|---|---|---|---|---|
| TCT | BBS | Mini-BESTest | TCT | BBS | Mini-BESTest | |
| Sit | r = −0.23 * p < 0.02 n = 96 | r = −0.13 p < 0.26 n = 78 | ||||
| Sit unstable | r = −0.13 p < 0.22 n = 89 | r = −0.05 p < 0.67 n = 77 | ||||
| Stance EO | r = −0.54 ** p < 0.001 n = 81 | r = −0.53 ** p < 0.001 n = 71 | ||||
| Stance EC | r = −0.42 ** p < 0.001 n = 72 | r = −0.42 ** p < 0.001 n = 68 | ||||
| Stance unstable | r = −0.45 * p < 0.03 n = 23 | r = −0.44 * p < 0.02 n = 28 |
