UAV’s Status Is Worth Considering: A Fusion Representations Matching Method for Geo-Localization
Abstract
:1. Introduction
1.1. Related Work of Geo-Localization Methods
1.2. Related Work of Multimodal
1.3. Related Work of Pooling
1.4. Contributions
2. Datasets
2.1. University-1652
2.2. SUES-200
2.3. Evaluation Indicators
3. Method
3.1. Backbone
3.2. Multimodal
3.3. Bilinear Pooling
3.4. Improvement and Loss Function
4. Experiments
4.1. Implement Details
4.2. Comparison with the State-of-the-Art
4.3. Ablation Study of Methods
4.3.1. Effect of the Fusion Timing
4.3.2. Effect of the HBP Design
4.3.3. Effect of the Part Feature Numbers
4.3.4. Effect of the Proposed Methods
4.4. Shifted Query
4.5. Multi Query
4.6. Inference Time
4.7. Visualization
5. Discussion
6. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
Abbreviations
MBF | Multimodal Bilinear Feature Fusion Method |
HBP | Hierarchical Bilinear Pooling |
UAV | Unmanned Aerial Vehicles |
GNSS | Global Navigation Satellite System |
FPS | Feature Partition Strategy |
BERT | Bidirectional Encoder Representations from Transformers |
ReID | Re-identification |
VQA | Visual Question Answering |
R@K | Recall@K |
AP | Average Precision |
References
