Compressive Sensing-Based SAR Image Reconstruction from Sparse Radar Sensor Data Acquisition in Automotive FMCW Radar System
Abstract
:1. Introduction
2. SAR Image Reconstruction with FMCW Radar Sensor Data
2.1. Principles of FMCW Radar System
2.2. Fundamentals of Range Migration Algorithm
3. Proposed SAR Image Reconstruction with Compressive Sensing
4. Performance Evaluation
4.1. Radar Sensor Data Acquisition
4.2. SAR Image Reconstruction Results
5. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
