Ultrasonic Guided Wave Testing on Cross-Ply Composite Laminate: An Empirical Study

1
Faculty of Engineering in Bilbao, University of the Basque Country, 48013 Bilbao, Spain
2
Institute for Aerospace Technology & The Composites Group, The University of Nottingham, Nottingham NG7 2RD, UK
3
Faculty of Engineering Vitoria-Gasteiz, University of the Basque Country, 01006 Vitoria-Gasteiz, Spain
*
Author to whom correspondence should be addressed.
Sensors 2020, 20(18), 5291; https://doi.org/10.3390/s20185291
Received: 23 July 2020 / Revised: 4 September 2020 / Accepted: 14 September 2020 / Published: 16 September 2020
Structural health monitoring comprises a set of techniques to detect defects appearing in structures. One of the most viable techniques is based on the guided ultrasonic wave test (UGWT), which consists of emitting waves throughout the structure, acquiring the emitted waves with various sensors, and processing the waves to detect changes in the structure. The UGWT of layered composite structures is challenging due to the anisotropic wave propagation characteristics of such structures and to the high signal attenuation that the waves experience. Hence, very low amplitude signals that are hard to distinguish from noise are typically recovered. This paper analyzes the propagation of guided waves along a cross-ply composite laminate following an empirical methodology. The research compares several implementations for UGWT with piezoelectric wafer active sensors. The reference for comparison is set on a basic mode, which considers the application of nominal voltage to a single sensor. The attenuation and spreading of the waves in several directions are compared when more energy is applied to the monitored structure. In addition, delayed multiple emission is also considered in multisensor tests. The goal of all the UGWT configurations is to transmit more energy to the structure such that the echoes of the emission are of greater amplitude and they ease the signal processing. The study is focused on the realization of viable monitoring systems for aeronautical composite made structures. View Full-Text
Keywords: structural health monitoring; ultrasonic guided wave testing; piezoelectric wafer active sensors; composite material structural health monitoring; ultrasonic guided wave testing; piezoelectric wafer active sensors; composite material
Show Figures

Figure 1

MDPI and ACS Style

Aranguren, G.; Etxaniz, J.; Cantero-Chinchilla, S.; Gil-Garcia, J.M.; Malik, M.K. Ultrasonic Guided Wave Testing on Cross-Ply Composite Laminate: An Empirical Study. Sensors 2020, 20, 5291.
