Robust Inertial Measurement Unit-Based Attitude Determination Kalman Filter for Kinematically Constrained Links

Inertial Motion Capture Lab, Department of Mechanical Engineering, Hankyong National University, Anseong 17579, Korea
*
Author to whom correspondence should be addressed.
Sensors 2019, 19(4), 768; https://doi.org/10.3390/s19040768
Received: 8 January 2019 / Revised: 7 February 2019 / Accepted: 11 February 2019 / Published: 13 February 2019
(This article belongs to the Section Physical Sensors)
  |
PDF [1368 KB, uploaded 13 February 2019]
  |

Abstract

The external acceleration of a fast-moving body induces uncertainty in attitude determination based on inertial measurement unit (IMU) signals and thus, frequently degrades the determination accuracy. Although previous works adopt acceleration-compensating mechanisms to deal with this problem, they cannot completely eliminate the uncertainty as they are, inherently, approaches to an underdetermined problem. This paper presents a novel constraint-augmented Kalman filter (KF) that eliminates the acceleration-induced uncertainty for a robust IMU-based attitude determination when IMU is attached to a constrained link. Particularly, this research deals with an acceleration-level kinematic constraint derived on the basis of a ball joint. Experimental results demonstrate the superiority of the proposed constrained KF over the conventional unconstrained KF: The average accuracy improved by 1.88° with a maximum of 4.18°. More importantly, whereas the accuracy of conventional KF is dependent to some extent on test acceleration conditions, that of the proposed KF is independent of these conditions. Due to the robustness of the proposed KF, it may be applied when accurate attitude estimation is needed regardless of dynamic conditions. View Full-Text
Keywords: attitude; constraint; external acceleration; Kalman filter; kinematic inertial measurement unit attitude; constraint; external acceleration; Kalman filter; kinematic inertial measurement unit
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Lee, J.K.; Choi, M.J. Robust Inertial Measurement Unit-Based Attitude Determination Kalman Filter for Kinematically Constrained Links. Sensors 2019, 19, 768.
