Fully Transparent Gas Sensor Based on Carbon Nanotubes

1
Institute for Nanoelectronics, Technical University of Munich, 80333 Munich, Germany
2
Faculty of Science and Technology, Free University of Bolzano, 39100 Bolzano-Bozen, Italy
3
Pervasive Electronics Advanced Research Laboratory (PEARL), Department of Electronics and Computer Technology, University of Granada, 18071 Granada, Spain
*
Author to whom correspondence should be addressed.
Sensors 2019, 19(20), 4591; https://doi.org/10.3390/s19204591
Received: 13 September 2019 / Revised: 13 October 2019 / Accepted: 15 October 2019 / Published: 22 October 2019
(This article belongs to the Section Chemical Sensors)
In this paper, we demonstrate the feasibility of realization of transparent gas sensors based on carbon nanotubes (CNTs). Both sensing layer and electrodes consist of CNTs deposited by spray deposition. The transparent sensor—with a transmittance higher than 60% in both sensing layer and electrodes—is characterized towards NH3 and CO2 and compared with a reference sensor with the same active layer but evaporated Au electrodes. In particular, the sensitivity towards NH3 is virtually identical for both reference and transparent sensors, whereas the transparent device exhibits higher sensitivity to CO2 than the reference electrode. The effect of the spacing among consecutive electrodes is also studied, demonstrating that a wider spacing in fully CNT based sensors results in a higher sensitivity because of the higher sensing resistance, whereas this effect was not observed in gold electrodes, as their resistance can be neglected with respect to the resistance of the CNT sensing layer. Overall, the transparent sensors show performance comparable—if not superior—to the traditionally realized ones, opening the way for seamlessly integrated sensors, which do not compromise on quality. View Full-Text
Keywords: ammonia; CO2; single-walled; spray deposition; transparent electrodes ammonia; CO2; single-walled; spray deposition; transparent electrodes
Show Figures

Graphical abstract

MDPI and ACS Style

Loghin, F.C.; Falco, A.; Salmeron, J.F.; Lugli, P.; Abdellah, A.; Rivadeneyra, A. Fully Transparent Gas Sensor Based on Carbon Nanotubes. Sensors 2019, 19, 4591.
