Open AccessArticle
Sensors 2019, 19(2), 263;

Evaluation of Machine Learning Approaches to Predict Soil Organic Matter and pH Using vis-NIR Spectra

Institute of Agricultural Remote Sensing and Information Technology Application, College of Environmental and Resource Sciences, Zhejiang University, Hangzhou 310058, China
Department of Environmental Engineering, Yuzhang Normal University, Nanchang 330103, China
The Institute National de la Recherche Agronomique (INRA), Unité InfoSol, 45075 Orléans, France
Department of Land Resource Management, Jiangxi University of Finance and Economics, Nanchang 330013, China
Key Laboratory of Spectroscopy Sensing, Ministry of Agriculture, Hangzhou 310058, China
Author to whom correspondence should be addressed.
Received: 8 October 2018 / Revised: 24 December 2018 / Accepted: 7 January 2019 / Published: 11 January 2019
(This article belongs to the Special Issue Proximal Soil Sensing)
PDF [4358 KB, uploaded 11 January 2019]


Soil organic matter (SOM) and pH are essential soil fertility indictors of paddy soil in the middle-lower Yangtze Plain. Rapid, non-destructive and accurate determination of SOM and pH is vital to preventing soil degradation caused by inappropriate land management practices. Visible-near infrared (vis-NIR) spectroscopy with multivariate calibration can be used to effectively estimate soil properties. In this study, 523 soil samples were collected from paddy fields in the Yangtze Plain, China. Four machine learning approaches—partial least squares regression (PLSR), least squares-support vector machines (LS-SVM), extreme learning machines (ELM) and the Cubist regression model (Cubist)—were used to compare the prediction accuracy based on vis-NIR full bands and bands reduced using the genetic algorithm (GA). The coefficient of determination (R2), root mean square error (RMSE), and ratio of performance to inter-quartile distance (RPIQ) were used to assess the prediction accuracy. The ELM with GA reduced bands was the best model for SOM (SOM: R2 = 0.81, RMSE = 5.17, RPIQ = 2.87) and pH (R2 = 0.76, RMSE = 0.43, RPIQ = 2.15). The performance of the LS-SVM for pH prediction did not differ significantly between the model with GA (R2 = 0.75, RMSE = 0.44, RPIQ = 2.08) and without GA (R2 = 0.74, RMSE = 0.45, RPIQ = 2.07). Although a slight increase was observed when ELM were used for prediction of SOM and pH using reduced bands (SOM: R2 = 0.81, RMSE = 5.17, RPIQ = 2.87; pH: R2 = 0.76, RMSE = 0.43, RPIQ = 2.15) compared with full bands (R2 = 0.81, RMSE = 5.18, RPIQ = 2.83; pH: R2 = 0.76, RMSE = 0.45, RPIQ = 2.07), the number of wavelengths was greatly reduced (SOM: 201 to 44; pH: 201 to 32). Thus, the ELM coupled with reduced bands by GA is recommended for prediction of properties of paddy soil (SOM and pH) in the middle-lower Yangtze Plain. View Full-Text
Keywords: machine learning approaches; vis-NIR spectra; paddy soil; soil organic matter; pH machine learning approaches; vis-NIR spectra; paddy soil; soil organic matter; pH

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Share & Cite This Article

MDPI and ACS Style

Yang, M.; Xu, D.; Chen, S.; Li, H.; Shi, Z. Evaluation of Machine Learning Approaches to Predict Soil Organic Matter and pH Using vis-NIR Spectra. Sensors 2019, 19, 263.
