Open AccessArticle
Sensors 2017, 17(2), 259;

Evaluation of the Vegetation Coverage Resilience in Areas Damaged by the Wenchuan Earthquake Based on MODIS-EVI Data

1,3,* , 1
State Key Laboratory of Earth Surface Processes and Resource Ecology, Beijing Normal University, Beijing 100875, China
Institute of Environmental Information, Chinese Research Academy of Environmental Sciences, Beijing 100012, China
Academy of Disaster Reduction and Emergency Management, Beijing Normal University, Beijing 100875, China
Author to whom correspondence should be addressed.
Academic Editor: Jason K. Levy
Received: 3 December 2016 / Revised: 20 January 2017 / Accepted: 24 January 2017 / Published: 28 January 2017
Full-Text   |   PDF [17459 KB, uploaded 9 February 2017]   |


The concept of resilience was integrated into post-earthquake ecological restoration assessments in 10 counties heavily impacted by the 2008 Wenchuan earthquake. Ecological resilience was defined as the time interval required for the vegetation coverage to recover to pre-earthquake levels in damaged areas. MODIS-EVI data from May to August in 2000 to 2016 were used to calculate the ecological resilience by fitting the curve of recovery rate (RR) versus time. The following conclusions were reached: (1) An area of 424.1 km2 sustained vegetation damage. (2) The vegetation recovery was found to be linear based on the statistical analysis of the most common components of the damaged areas; consequently, linear fitting was used to estimate the resilience. (3) In terms of vegetation coverage, 44.2% of the damaged areas have already recovered. The vast majority of damaged areas are predicted to achieve vegetation recovery by 2022, but 5.3% of the damaged areas will not recover within this time period and have no resilience. (4) The management of damaged areas near roads, rivers and mining operations, especially at elevations of 2000–2500 m, slopes greater than 30°, and precipitation levels greater than 1200 mm, should be prioritized in the future. (5) The innovations of this study include the method used to extract earthquake-related vegetation damage and the prediction of vegetation succession based on resilience. View Full-Text
Keywords: ecological resilience; MODIS-EVI; vegetation cover; earthquake; recovery interval ecological resilience; MODIS-EVI; vegetation cover; earthquake; recovery interval

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Share & Cite This Article

MDPI and ACS Style

Liu, X.; Jiang, W.; Li, J.; Wang, W. Evaluation of the Vegetation Coverage Resilience in Areas Damaged by the Wenchuan Earthquake Based on MODIS-EVI Data. Sensors 2017, 17, 259.
