Sensors 2016, 16(6), 909;

Mitigating BeiDou Satellite-Induced Code Bias: Taking into Account the Stochastic Model of Corrections

School of Geodesy and Geomatics, Wuhan University, Wuhan 430079, China
Key Laboratory of Geospace Environment and Geodesy, Ministry of Education, Wuhan 430079, China
Collaborative Innovation Center for Geospatial Technology, Wuhan 430079, China
Author to whom correspondence should be addressed.
Academic Editor: Assefa M. Melesse
Received: 8 May 2016 / Revised: 6 June 2016 / Accepted: 15 June 2016 / Published: 18 June 2016
(This article belongs to the Section Remote Sensors)
Full-Text   |   PDF [4806 KB, uploaded 18 June 2016]   |


The BeiDou satellite-induced code biases have been confirmed to be orbit type-, frequency-, and elevation-dependent. Such code-phase divergences (code bias variations) severely affect absolute precise applications which use code measurements. To reduce their adverse effects, an improved correction model is proposed in this paper. Different from the model proposed by Wanninger and Beer (2015), more datasets (a time span of almost two years) were used to produce the correction values. More importantly, the stochastic information, i.e., the precision indexes, were given together with correction values in the improved model. However, only correction values were given while the precision indexes were completely missing in the traditional model. With the improved correction model, users may have a better understanding of their corrections, especially the uncertainty of corrections. Thus, it is helpful for refining the stochastic model of code observations. Validation tests in precise point positioning (PPP) reveal that a proper stochastic model is critical. The actual precision of the corrected code observations can be reflected in a more objective manner if the stochastic model of the corrections is taken into account. As a consequence, PPP solutions with the improved model outperforms the traditional one in terms of positioning accuracy, as well as convergence speed. In addition, the Melbourne-Wübbena (MW) combination which serves for ambiguity fixing were verified as well. The uncorrected MW values show strong systematic variations with an amplitude of half a wide-lane cycle, which prevents precise ambiguity determination and successful ambiguity resolution. After application of the code bias correction models, the systematic variations can be greatly removed, and the resulting wide lane ambiguities are more likely to be fixed. Moreover, the code residuals show more reasonable distributions after code bias corrections with either the traditional or the improved model. View Full-Text
Keywords: BeiDou; code bias variation; code-phase divergence; stochastic model; precise point positioning BeiDou; code bias variation; code-phase divergence; stochastic model; precise point positioning

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
