Open AccessArticle
Sensors 2015, 15(8), 20053-20068;

Measurement Model and Precision Analysis of Accelerometers for Maglev Vibration Isolation Platforms

School of Mechatronics Engineering, Harbin Institute of Technology, Harbin 150001, China
Department of Mechanical Engineering, Nippon Institute of Technology, Saitama 345-8501, Japan
School of Engine and Energy, Northwestern Polytechnical University, Xi’an 71000, China
Authors to whom correspondence should be addressed.
Academic Editor: Vittorio M. N. Passaro
Received: 23 June 2015 / Revised: 5 August 2015 / Accepted: 6 August 2015 / Published: 14 August 2015
(This article belongs to the Special Issue Inertial Sensors and Systems)
Full-Text   |   PDF [922 KB, uploaded 18 August 2015]   |


High precision measurement of acceleration levels is required to allow active control for vibration isolation platforms. It is necessary to propose an accelerometer configuration measurement model that yields such a high measuring precision. In this paper, an accelerometer configuration to improve measurement accuracy is proposed. The corresponding calculation formulas of the angular acceleration were derived through theoretical analysis. A method is presented to minimize angular acceleration noise based on analysis of the root mean square noise of the angular acceleration. Moreover, the influence of installation position errors and accelerometer orientation errors on the calculation precision of the angular acceleration is studied. Comparisons of the output differences between the proposed configuration and the previous planar triangle configuration under the same installation errors are conducted by simulation. The simulation results show that installation errors have a relatively small impact on the calculation accuracy of the proposed configuration. To further verify the high calculation precision of the proposed configuration, experiments are carried out for both the proposed configuration and the planar triangle configuration. On the basis of the results of simulations and experiments, it can be concluded that the proposed configuration has higher angular acceleration calculation precision and can be applied to different platforms. View Full-Text
Keywords: angular acceleration; measurement precision; configuration; root mean square noise angular acceleration; measurement precision; configuration; root mean square noise

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Share & Cite This Article

MDPI and ACS Style

Wu, Q.; Yue, H.; Liu, R.; Zhang, X.; Ding, L.; Liang, T.; Deng, Z. Measurement Model and Precision Analysis of Accelerometers for Maglev Vibration Isolation Platforms. Sensors 2015, 15, 20053-20068.
