Article

Frustulia tunariensis sp. nov. (Bacillariophyceae) from the Andes of Bolivia, South America

1
Water Laboratory, University of Évora, P.I.T.E. Rua da Barba Rala 1, 7005-345 Évora, Portugal
2
Institute of Earth Sciences-ICT, University of Évora, Rua Romão Ramalho 59, 7000-671 Évora, Portugal
Diversity 2020, 12(9), 362; https://doi.org/10.3390/d12090362
Received: 20 August 2020 / Revised: 15 September 2020 / Accepted: 17 September 2020 / Published: 22 September 2020
(This article belongs to the Special Issue Taxonomy, Ecology and Biogeography of Diatoms)

Abstract

Frustulia tunariensis sp. nov. is originated from a high-altitude peatland in the Tunari Cordillera, a branch of the Andean range in Bolivia. The new taxon is distinguished by the thick longitudinal ribs, the globose polar nodule with faint helictoglossa that does not produce an apical extension, and by the high areola and stria density, not found in any of the morphologically closely related taxa. Features of the folded valvocopula, such as the presence of a siliceous membrane as pars interior, and poroids present in the tube-like portion opening as slits to the valve interior and as a single row of poroids to the exterior, are also unique characters in the new taxon. Based on a literature review, a comparison of the newly proposed species with morphologically similar taxa was made. Also, published information shows the potential of girdle bands to distinguish groups of species and species themselves within Frustulia. Likewise, remarks on the ecological and distribution aspects of Frustulia in the Bolivian Altiplano are included, focusing on taxonomic quality, geographic coverage and sampling, and potential to represent the genus in the high Bolivian Andean plateau.
Keywords: Bolivian Andean Altiplano; Bacillariophyta; biogeography; bogs; cingulum; girdle bands; high altitude wetlands Bolivian Andean Altiplano; Bacillariophyta; biogeography; bogs; cingulum; girdle bands; high altitude wetlands

1. Introduction

Despite a considerable number of studies, the diatoms from the Andean mountains remain poorly known [1]. Those studies have concentrated mainly on material collected from accessible, anthropogenically affected ecosystems or on paleo-material, often with a rather imprecise taxonomic accuracy [2]. The number of studies for the Bolivian Andean Altiplano (25% of the country’s territorial extension) are even more scarce, with those done by Frenguelli [3], Servant-Vildary [4,5,6], Metzeltin et al. [7], and Rumrich et al. [8] being the most representative.
Thus, additional sampling in the Altiplano is prone to yield new taxa (e.g., [1,2,9,10,11,12,13,14,15]), as in fact is the case of the material collected for the present study, coming from a high altitude peatland that has been subjected to human pressure only in the last decades. A new species of Frustulia Rabenhorst is described here from this material, a taxon that has unique features setting it readily apart from other taxa with similar valve outline and structure.
Though commonly reported from South America, the taxonomy of species in the genus Frustulia has not been revised in depth for the continent. The species frequently included in lists are those that also appear in samples from North America and Europe (e.g., Frustulia rhomboides (Ehrenberg) De Toni (an invalid name since the type does not correspond to a Frustulia species, but to a Navicula [16]) and F. vulgaris (Thwaites) De Toni). Whether this is the result of a cosmopolitan habit of those taxa, the effect of taxonomic drift, or force fitting into European identification keys [2] will remain subject to revision.
In terms of new taxa, the books of Metzeltin & Lange-Bertalot [7,17], Rumrich et al. [8], and Metzeltin et al. [18] presented 20 new species, three subspecies, and one variety described from South America, out of the total of 26 species they reported for the continent. In addition, 25 morphospecies designated with “sp.” or “cf.” appeared illustrated in these references and probably constitute additional species, new to science.
There are other publications presenting new Frustulia taxa for South American waters. For example, [19,20,21] list 12 taxa not reported in the above books (six of them being new to science and 3 morphospecies designated as “sp.”). However, all these references are insufficient to show the variation in the reported taxa at the regional or continental levels, since the numbers of samples are insufficient to represent the type of habitats studied or the total diversity of habitats in the continent (own observation of the cited literature, but also see a more general discussion in [7]). This is a major drawback for applied studies including biogeography [22]. On the other hand, those articles solely containing taxa lists, but lacking cross-referencing or illustrations, impede an in-depth historical analysis of the genus in South America.
In all Frustulia species, the sternum internally presents thickenings, called longitudinal ribs, on both sides of the raphe slit [23,24]. Externally, the raphe proximal ends are either straight or T-shaped, while internally they are straight and opposite to each other. The distal ends are straight or T-shaped externally, while internally they end in helictoglossa of varying sizes. These variations are species specific and constitute reliable diagnostic features [24].
The longitudinal ribs fuse with the central nodule, producing a conspicuously thickly silicified central region [25], which degree of silicification, size and shape can also be used to distinguish species. In the great majority of Frustulia species, the longitudinal ribs distally fuse with the helictoglossa forming a massive polar nodule [25], the silicification, size, and shape of which can also vary from a general pattern resembling a “pencil point” [26] or “porte-crayon” [23] structure that also provides useful taxonomic information.
Analysis of these latter features (raphe and its interaction with the longitudinal ribs) in published size diminution series under light (LM) and scanning electron microscopy (SEM) shows that they vary little with valve size reduction and are trustable characters for species recognition. See for example the material and discussions presented in [20,24,27]. Moreover, the stability of the raphe system and the central sternum seems to be related to other invariable structures such as the hymens internally covering the areolae [28].
The structure of the raphe and flanking longitudinal ribs in Frustulia are apparently sufficient to separate its species from other genera in the Family Amphipleuraceae, i.e., Amphipleura Kützing (with raphe branches restricted to the valve ends) [23], Frickea Heiden (in which the helictoglossa never fuse with the ribs, and the latter are separated from the raphe slit by at least two rows of areole) [23], and Pseudofrustulia Sawai & Nagumo (in which the longitudinal ribs are not fused with the central nodule only with the helictoglossae at the polar nodules) [29].
Very little is known regarding the structure of the cingulum in Frustulia and the available information is scattered through the literature with very little taxonomic consideration. Only some references contain SEM data on girdle bands (e.g., [23,27]), showing a variable morphological complexity that it is perhaps worth exploring taxonomically. The analysis done to date, though concentrated on only a few species, shows promising results to separate recognized genera (i.e., Frustulia, Frickea and Pseudofrustulia [29]), but patterns within Frustulia have not been explored to date.
The new Frustulia species is described in the context of what is known regarding the morphology of other species currently assigned to this genus. The ultrastructure of its cingulum is compared to other species for which there is published information, in an attempt to find patterns within Frustulia that would help in species recognition. Additionally, remarks are made on the biogeography and ecology of Frustulia in the Bolivian Andes, indicating which South American published records belong to this region.

2. Materials and Methods

2.1. Study Area

The Bolivian Andean region is an area of 142,815.53 km2 located on the western flank of the country. Once in Bolivian territory, the Andes range splits into the Western Cordillera with a highest peak of 6542 m a.s.l. (Sajama Volcano) and acts as a natural border with Peru and Chile, and the Eastern Cordillera with a highest peak of 4438 m a.s.l. (The Illimani). The Bolivian Altiplano itself is a plateau sandwiched between the two Andean branches with an average altitude of 3800 m a.s.l. and an extension of 307,000 km2. Politically, the Altiplano belongs to the Departments of La Paz (recognized here as the northern Altiplano), Cochabamba and Oruro (central Altiplano), Chuquisaca, Potosí and Tarija (central and southern Altiplano) [30].
The sample used in this study was collected from a peatland in the Eastern Andean Cordillera, from a section locally known as the Tunari Cordillera, on March, 2014 (end of the rainy season). The specific collection site was located near the town of Uyuni (not to be confused with the Uyuni Salt Flat located in the Department of Potosí, Bolivia), Quillacollo Province, Department of Cochabamba (coordinates given below under Type material) (Figure 1).
The peatland rests on deposits of organic material which depth has not been determined. On top of such deposits there is vegetation growing (see below) and rivulets and shallow pools spread throughout the entire area. The wetland freezes at night due to temperatures reaching values below −4 °C. Ice from shallow pools and surfaces melt due to high solar radiation at around 9–11 a.m.
The peatland has recently been subjected to human activity pressure, mainly livestock raising (llamas, sheep, and cows) and agriculture (mainly potatoes). Many of the local rivers draining melting and ground water in the area were diverted toward the dam, so much of the water feeding the peatlands was drastically reduced. Water was thus transported through pipes and channels to artificially maintain the peatlands and to supply water for the human population and livestock that were moved from the dam flooding area to nearby grounds. The town of Uyuni was created for a small group of that human population, a town located in a southwest direction from the type locality sampled for this study (Figure 1). Without proper technical support from the local and national governments, by 2015, a year after collection of the material studied here, roughly half of the peatland seen in Figure 2 had been plowed for agriculture.
Prior to plowing, the peatland, as seen in Figure 2a, was dominated by mounds of Distichia muscoides Nees & Meyen (Juncaceae) and flat growths of Plantago tubulosa Decaisne (Plantaginaceae) (dark green patches in Figure 2b). Associated to this, in non-flooded areas, there were growths of Deyeuxia rigescens (J.Presl) Türpe, D. curvula Weddell and D. eminens J.Presl (Poaceae), Gentiana sedifolia Kunth, Gentianella primuloides Gilg, G. larecajensis (Gilg) T.N.Ho & S.W.Liu (Gentianaceae), Werneria heterolba Weddell (Asteraceae) and Castilleja plumila (Bentham) Weddell (Orobanchaceae). In zones affected by human activity, Phyllloscirpus deserticola (Philippi) Dhooge & Goetghebeur (Cyperaceae) and Lachemilla diplophylla (Diels) Rothmaler (Rosaceae) are also present. In the water, there were growths of Lilaeopsis macloviana (Gandoger) A.W.Hill (Apiaceae) (Figure 2c) and Eleocharis sp. (Cyperaceae).

2.2. Sample Collection, Treatment and Analysis

Samples of cloudy growths were collected from a 40-cm-deep shallow pool after water surface melting (ca. 10 a.m.) with a turkey baster (Figure 2b,c). Samples were stored in Ziploc bags and fixed with 10 drops of a 40% formalin solution. Water chemistry variables (temperature, pH, electric conductivity, and total dissolved solids) were measured in situ using a portable meter calibrated prior to sampling (HI 99300, Hanna Instruments S.L., Eibar, Spain).
In the laboratory, wet mounts of samples were analyzed under the microscope at magnifications from ×125 to ×500 and soft algae (excluding diatoms) were identified to genus level based on [31].
From each sample, 20 mL portions were oxidized with hot nitric acid. After repeated rinsing and decantation with distilled water, air-dried aliquots were mounted on permanent glass slides using the resin Naphrax (R.I. = 1.74). At least 50 valves of the new species were measured in LM at a magnification of ×1250 using a Zeiss Universal microscope equipped with Nomarski interference contrast and a Plan ×100 (1.25 NA) immersion objective. Images of live and oxidized material were taken using a Jenoptik CF color digital camera and ProGres CapturePro v. 2.8 software.
In the absence of taxonomic keys and floras for the region, diatoms were identified to genus and species based on regional floras such as [7,8,17,18]. Taxonomic articles, such as [3,5,32,33,34], and the annotated checklist by Hohn [35], were also utilized. In limited cases, some European references were also used [24,36,37,38,39,40,41,42,43,44].
A count of 400 valves [45] was performed along a random transect on the type permanent slide. The transect was randomly positioned and its width was determined by the diameter of the field of view. All valves appearing along the transect were counted, even pieces that could be identified.
For SEM analysis, aliquots of cleaned slurries were dried onto aluminium stubs at room temperature before being coated with gold and examined using a Carl Zeiss SUPRA 40 (at 15 kV) at the Advanced Microcopy Center, University of Buenos Aires, Argentina. SEM images were used to confirm LM identifications and also to support the description of the new species.
Morphological terminology used in the description and comparison of the new taxon follows [23] for valve features and girdle bands. For the latter, [27,46,47] were additionally used.
In order to list the species of the genus Frustulia that occur in the Bolivian Altiplano, a search for literature was done and, in every article and book, records of species within the genus were annotated. The summarized information was tabulated, and localities and coordinates were included to express distribution.

3. Results

3.1. Accompanying Flora and Diatom Count

The cloudy growths found in the sampled shallow pool were slimy to the touch. Under LM, the growths were composed mainly by filamentous cyanobacteria (Anabaena A. Jussieu, Calothrix C. Agardh, Geitlerinema (Anagnostidis & Komárek) Anagnostidis, Nostoc Vaucher ex Bornet & Flahault, and Oscillatoria Vaucher ex Gomont), green algae (Bulbochaete C. Agardh, Oedogonium Link and Ulothrix (Kützing) De Toni, and Zygnema C. Agardh). Embedded in the mucilaginous matrix were various coccoid cyanobacteria, coccoid green algae, desmid, and diatom species (including the new species presented here, Table 1), together with bacteria of different shapes and sizes.
The most specious genera in the diatom community present in the sample were Pinnularia Ehrenberg (12 spp.), Encyonema Kützing (six), and Nitzschia Hassall (five) (Table 1). These species represented ca. 41% of the 56 taxa encountered under LM. Using the cited literature, 22 corresponded to morphospecies identified under “sp.” or “cf.”, representing ca. 39% of the total number of taxa. In terms of relative abundance, the diatom community was dominated by Nitzschia cf. perminuta Grunow (26.5%), N. cf. acidoclinata Lange-Bertalot (17.5%), Encyonopsis cf. thumensis (Hustedt) Krammer (11.25%), Frustulia tunariensis sp. nov. (7.5%), Encyonema neogracile Krammer (6.5%), Kobayasiella pseudosubtilissima (Manguin) Lange-Bertalot & E.Reichardt (5.75%), Fragilaria tenera (W. Smith) Lange-Bertalot (5.5%), Pinnularia subcapitata var. elongata Krammer, and Tabellaria flocculosa (Roth) Kützing, each reaching 1.25% of the total count.
The new taxon is one of two species of Frustulia found in the analyzed sample. The other species is Frustulia saxonica Rabenhorst, present in much lower abundance (Table 1, Figure 3b´,c´).

3.2. New Species Description

Division Bacillariophyta.
Sub-division Bacillariophytina Medlin & Kaczmarska 2004.
Class Bacillariophyceae Haeckel 1878 (emend. Medlin & Kaczmarska 2004).
Subclass Bacillariophycidae D.G. Mann in Round et al. 1990.
Order Naviculales Bessey 1907 (emend. D.G. Mann in Round et al. 1990).
Family Amphipleuraceae Grunow 1862.
Genus Frustulia Rabenhorst 1853.
Frustulia tunariensis E.Morales sp. nov. (Figure 3 LM, Figure 4 and Figure 5 SEM)
Frustules solitary, rectangular in girdle view. Chromoplasts with granular appearance, H-shaped, golden greenish in color (Figure 3j). Some cells containing large oil droplets (Figure 3j). Valves elliptico-lanceolate with convex margins, with obtusely rounded apices (Figure 3a–z and Figure 4a). Valves 60–110 µm long, 17–18 µm wide. Stria density 39–50 in 10 µm, areolae 40–45 in 10 µm within transapical stria. Striae not clearly resolved under LM, uniseriate, parallel in valve center to convergent toward apices, extending around the latter in circumradiate fashion (Figure 4b–f and Figure 5b). Club-shaped area at apex devoid of ornamentation in external view marks polar nodule where longitudinal ribs and helictoglossa fuse internally (Figure 3a and Figure 4d). Externally, areolar openings from round to elliptic in central area to apically elongated or round toward the valve apices (Figure 4b,c). Internally, areolar openings larger, roundish (Figure 4d–f). Each areola occluded by fine hymen located closer to internal areolar opening (Figure 4f). Raphe filiform with external proximal and distal ends “T”-shaped with bent arms (Figure 4b,c). Proximal and distal raphe ends straight in internal view (Figure 4d,e). Raphe sternum with thick ribs, ca. 2.5 µm wide each (measured transapically), on each side of raphe (Figure 4d,e, externally seen as whitish shadows in Figure 4a). More or less widened structure formed by fusion of ribs with central nodule, constricted on its outer margin (Figure 4e). Distally, ribs fuse with helictoglossa forming globose apical nodules; no evident porte-crayon formation can be seen (Figure 4d). Copulae open, with single row of poroids (Figure 5a). Valvocopula folded, tube-like, lacking internal verrucae (Figure 5c,d). Poroids on valvocopula open as round perforations inside tube chamber (not shown), as single row of round poroids towards valve exterior (Figure 5b), as slits towards valve interior (Figure 5c). Siliceous membrane present on valvocopula as attachment to valve interior (Figure 5a).
Type Material: Bolivia, unnamed peatland northeast of the town of Uyuni (17°7′13.1″ S, 66°17′51″ W), 4155 m a.s.l., area of influence of the Misicuni Hydroelectrical Dam, province of Quillacollo, department of Cochabamba. Coll. March 11, 2014, E.A. Morales & S.F. Rivera.
Holotype: Slide BR-4598 (accession number in process), Meise Botanic Garden, Belgium, Figure 3a herein. Maltwood finder 33/34.
Isotype: Slide DBOL–0821, Diatomotheca Boliviensis, Cochabamba, Bolivia.
Habitat: Shallow pool in a high-altitude peatland with cloudy submerged growths in which cells of the new taxon were embedded. Pool freezes overnight at temperatures below −4 °C and melts between 9–11 a.m.
Distribution: Known from type locality only.
Etymology: The epithet “tunariensis” refers to the Tunari Cordillera where the type locality is found.
Ecology: The taxon was found in relatively cold (T = 18.6 °C at the moment of sampling) and slightly acidic water (pH = 6.3). The water was very clear where the cloudy algal growths were not present. The instrument recorded 0 ppt total dissolved solids and 0 µS/cm electric conductivity in these clear spots.

3.3. Distribution of Frustulia Species in the Bolivian Altiplano

Only five species have been recorded for the Altiplano region of Bolivia, including the new species described herein (Table 2). Four of these species are rather common in European and North American floras, namely F. crassinervia (Brébisson ex Smith) Lange-Bertalot & Krammer, F. rhomboides, F. saxonica and F. vulgaris (Thwaites) De Toni. One, namely F. franguelli Manguin, is rarely reported from the Altiplano, in general. Another one, the new species presented here, has been seen only in the type locality.
For the six species in Table 2, two have LM data, three appear named in lists and one (the new species) has been studied in detail using SEM. These species appear reported in northern or central parts of the Bolivian Altiplano, with no records for the southern portion of this region.

4. Discussion

4.1. Taxonomic Allocation and Distinction of Frustulia tunariensis sp. nov. from Similar Species

The morphological analysis presented here places F. tunariensis sp. nov in Frustulia mainly due to the structure of the raphe and flanking longitudinal ribs. The fusion of these ribs with the central nodule, and the helictoglossa at the polar nodules is similar to the most common species in the genus, also considered as the most representative species within it (e.g., F. crassinervia, F. rhomboides, F. saxonica, and F. vulgaris). The similarity with these taxa is also extended to the features of the raphe (filiform and characteristic terminations at both proximal and distal ends), striae (uniseriate, parallel to convergent), areolae (varying in shape, with larger internal opening) and their occlusions located toward the valve interior), and the general characteristics of the valves, highly determined by the association raphe-valve nodules-longitudinal ribs, that position these species apart from other Amphipleuraceae [23,29].
Table 3 includes species that are similar to F. tunariensis sp. nov. The similarity is given in the general elliptico-lanceolate valve outline, pattern of striation and overall features of the longitudinal ribs and their structural association to the polar and central nodules. At the ultrastructural level, however, the taxon has a unique combination of features that sets it apart from the rest of the species included in the mentioned table. Namely, the density of areola (40–45 per 10 µm) and stria (39–50 per 10 µm) are higher than in any of the considered taxa. The longitudinal ribs are also the widest (2.5 µm) recorded for these species and really stand out during LM and SEM analyses (Figure 3a–z and Figure 4d,e). One of the most notorious features of the new species at the LM and SEM levels is the bulbose apical nodule that embeds the helictoglossum (Figure 3a and Figure 4d), not leaving and apical extension in a porte-crayon fashion, a feature not present in any of the taxa included in Table 3.

4.2. Ecology of F. tunariensis sp. nov.

Table 1 shows that type material is dominated by species of Pinnularia, Encyonema and Nitzschia, found in oligo to mesotrophic, low electrolyte, acidic waters and in peatlands (Pinnularia) or with several species living in such places (Encyonema and Nitzschia) [8,24,41,42]. At the species level, the taxa accompanying the new species are all found in oligo to mesotrophic environments, with pH varying from slighty acidic to circumneutral [49,50,51], suggesting that the new taxon also falls within this autecological category. The high relative abundance reached by F. tunariensis sp. nov. (7.5%), places this taxon within the general definition of Frustulia as a conglomerate of acidophilous, oligo to mesotraphentic taxa living in peatlands and acid ponds and rivers with low electrolyte content [20,23,52].
Interestingly, the conductivity and total suspended solids were zero at the time of measurement (after 5 trials and making sure the same instrument worked properly in other sites). This suggests that there is a chemical process, unidentified during this study, which causes a scarcity of charged salts and other solids in the water column. Taking into account the presence of conspicuous healthy algal growth in the sampled shallow pool, it is possible that the nil values might be indicating a strong absorption of nutrients after the waters have melted and the algal growths started active photosynthetic activity.

4.3. Use of Girdle Bands to Characterize Frustulia spp.

Another structure that could produce potentially useful features to separate groups and species within Frustulia is the cingulum, which has not received sufficient attention thus far but that could yield a series of useful characters. I have found relatively complete information for only five species and one morphospecies, and I compared them to the information gathered for the new species presented herein (Table 4).
Table 4 provides evidence for the existence of two groups of taxa within Frustulia, groups that also differ in the structure of the longitudinal ribs and their association to the valvar nodules and raphe [46,53]. A first group is composed by F. creuzburgensis (Krasske) Hustedt and F. latita Graeff & Kociolek, taxa that have unilaterally deflected proximal raphe ends and that either lack longitudinal ribs or have them very little-developed. The cingulum of both of these species have closed valvocopulae and open copulae, a feature absent in the other Frustulia in Table 4, which have open girdle elements combined with well-developed longitudinal ribs.
At the species level, considering the structure of the cingulum is also useful to separate taxa. Each species in Table 4 has at least one unique feature. Frustulia tunariensis sp. nov. differs in at least two regards, the presence of a unique extended siliceous membrane in the pars interior that secures the valvocopula to the valve mantle interior. Other taxa have either finger-like projections (fimbriae, e.g., F. creuzburgensis), a flap that runs longitudinally atop the tube-like portion of the valvocopula (e.g., F. rhomboides), or they lack these structures altogether (e.g., F. blancheana). The poroids present in the tube-like portion of the valvocopula, opening as slits to the interior of the valve and as single row of poroids towards the valve exterior is also a unique character in the new species.
In agreement with [46,53], there is a need for a revision of the genus Frustulia, which I have defined here, (largely based on [23,26]), as a group of species with proximal raphe ends that are straightly opposite to each other and with well-developed longitudinal ribs interacting with the raphe and the valvar nodules. Now, it can be added that all girdle elements of typical Frustulia species are open. Information on additional species is required to confirm this.

4.4. Distribution of Frustulia spp. from the Bolivian Altiplano

Table 2 shows that knowledge of the genus Frustulia in the Bolivian Altiplano is scant and that the literature is centered on the northern and central parts of this geographical region. That is, data are only available for the northern and part of the central Altiplano, with no data for the rest of the central and the southern portions. Even for the areas represented with publications, the latter are insufficient given the extensive areas covered by peatlands in the Andean Altiplano, represented by the biogeographic provinces known as the Peruvian Puna (Lake Titicaca and surroundings) and the Altiplanic Province (down south up to the border with Argentina), both part of the High Andean Hydroecoregion in Bolivia [54,55].
Under-sampling is another issue regarding the knowledge of Frustulia in the Bolivian Altiplano, since the combination of all references in Table 2 does not yield more than 60 samples. Given the large number of species reported from other high mountain localities in South America [7,8,17,18], it can be inferred that this under-sampling is seriously biasing the knowledge of Frustulia in Bolivian high plateau peatlands.
A third problem denoted in Table 2 is that only F. tunariensis sp. nov. has been studied in detail by combination of LM and SEM techniques, while the other taxa have been either listed or studied only under LM. This is definitely a shortcoming for any taxonomic assessment since three taxa included in the mentioned table are only listed and three have only LM and no ultrastructure data. This observation is in agreement with [2], who implied that the taxonomic depth with which Andean taxa are usually treated is rather limited.
In the absence of detailed morphological analyses, it is extremely difficult to assess if the common European species reported for the Bolivian Altiplano (e.g., F. crassinervia, F. rhomboides, F. saxonica and F. vulgaris) do occur in Andean ecosystems. Also, with no means to verify the taxonomy of these taxa in Frustulia, making deep biogeographic interpretations is rather risky (e.g., [22]) because there is no way to know what is really being represented in lists or whether we are dealing with species complexes, in which case, SEM information is pivotal in solving species identities [1,2].
For the reasons exposed above, it can be inferred that any taxonomical or biogeographic assessment of Frustulia in the Andean Altiplano is currently premature. A higher sampling effort displayed on a wider geographic range is required, together with the application of combined LM and SEM, including molecular techniques if possible, to produce a taxonomically sound database that would then allow for a distributional and ecological characterization of the genus.

Funding

Co-funding was provided by the European Union through the European Regional Development Fund, framed in COMPETE 2020 (Operational Programme Competitiveness and Internationalization), through the ICT project (UID/GEO/04683/2013) with reference POCI-010145-FEDER-007690 and the Agencia Portuguesa do Ambiente, APA-000004DFIN.AALP/2017 integrated within the Operational Program for Sustainability and Efficiency in the Use of Resources 2014-20, POSEUR-03-2013-FC000001.

Acknowledgments

I thank the Misicuni Enterprise for providing transportation to the type locality and getting the permits from the local communities to sample in their territory. I also thank Nora Maidana and the Centro de Microscopías Avanzadas (CMA) (FCEyN, Universidad de Buenos Aires, Argentina) for reduced rates for use of their microscope and the help during analysis. Sinziana Rivera and students at the terminated Bolivian Catholic University Cryptogams Herbarium participated in sample collection and helped gather part of the data for the present contribution. I especially thank Dennis Pedrazas for kindly providing the list of vegetation from the studied area.

Conflicts of Interest

The author declares no conflict of interest. The sponsors had no role in the design, execution, interpretation, or writing of this study.

References

  1. Morales, E.A.; Novais, M.H.; Chávez, G.; Hoffmann, L.; Ector, L. Diatoms (Bacillariophyceae) from the Bolivian Altiplano: Three new araphid species from the Desaguadero River draining Lake Titicaca. Fottea 2012, 12, 41–58. [Google Scholar] [CrossRef]
  2. Morales, E.A.; Wetzel, C.E.; Rivera, S.F.; Van de Vijver, B.; Ector, L. Current taxonomic studies on the diatom flora (Bacillariophyceae) of the Bolivian Altiplano, South America, with possible consequences for palaeoecological assessments. J. Micropalaeontol. 2014, 33, 121–129. [Google Scholar] [CrossRef]
  3. Frenguelli, J. Diatomeas del Lago Titicaca. Notas Mus. Plata Bot. 1939, 24, 175–196. [Google Scholar]
  4. Servant-Vildary, S. Altitudinal zonation of mountainous diatom flora in Bolivia: Application to the study of the Quaternary. Acta Geol. Acad. Sci. Hung. 1982, 25, 179–210. [Google Scholar]
  5. Servant-Vildary, S. Les diatomées actuelles des Andes de Bolivie (Taxonomie, écologie). Cah. Micropaléontol. 1986, 1, 99–124. [Google Scholar]
  6. Servant-Vildary, S. The diatoms. In Lake Titicaca; Dejoux, C., Iltis, A., Eds.; Kluwer Academic Publishers: Amsterdam, The Netherlands, 1991; pp. 163–175. [Google Scholar]
  7. Metzeltin, D.; Lange-Bertalot, H. Tropical diatoms of South America I. About 700 predominantly rarely known or new taxa representative of the neotropical flora. Iconogr. Diatomol. 1998, 5, 695. [Google Scholar]
  8. Rumrich, U.; Lange-Bertalot, H.; Rumrich, M. Diatomeen der Anden von Venezuela bis Patagonien/Feuerland. Iconogr. Diatomol. 2000, 9, 1–649. [Google Scholar]
  9. Tapia, P.M.; Theriot, E.C.; Fritz, S.C.; Cruces, F.; Rivera, P. Distribution and morphometric analysis of Cyclostephanos andinus comb. nov., a planktonic diatom from the central Andes. Diatom Res. 2004, 19, 311–327. [Google Scholar] [CrossRef]
  10. Van de Vijver, B.; Cocquyt, C. Four new diatom species from La Calera Hot Spring in the Peruvian Andes (Colca Canyon). Diatom Res. 2009, 29, 209–223. [Google Scholar] [CrossRef]
  11. Álvarez-Blanco, I.; Cejudo-Figueiras, C.; de Godos, I.; Muñoz, R.; Blanco, S. Las diatomeas de los salares del Altiplano boliviano: Singularidades florísticas. Bol. Real Soc. Esp. Hist. Nat. Secc. Biol. 2011, 105, 67–82. [Google Scholar]
  12. Blanco, S.; Álvarez-Blanco, I.; Cejudo-Figueiras, C.; de Godos, I.; Bécares, E.; Muñoz, R.; Guzman, H.O.; Vargas, V.A.; Soto, R. New diatom taxa from high-altitude Andean saline lakes. Diatom Res. 2013, 28, 13–27. [Google Scholar] [CrossRef]
  13. Furey, P.C.; Mayama, S.; Lowe, R.L.; Catenazzi, A. Frankophila wayqechae sp. nov., a new aerophilic diatom species from the Peruvian Andes, South America. Diatom Res. 2012, 27, 165–175. [Google Scholar] [CrossRef]
  14. Morales, E.A.; Rivera, S.F.; Wetzel, C.E.; Novais, M.H.; Hamilton, P.B.; Hoffmann, L.; Ector, L. New epiphytic araphid diatoms in the genus Ulnaria (Bacillariophyta) from Lake Titicaca, Bolivia. Diatom Res. 2014, 29, 41–54. [Google Scholar] [CrossRef]
  15. Seeligmann, C.T.; Maidana, N.I.; Morales, E.A. Fragilariaceae (Bacillariophyta) en humedales de altura de Catamarca (Argentina). Bol. Soc. Argent. Bot. 2018, 53, 507–519. [Google Scholar] [CrossRef]
  16. Lange-Bertalot, H.; Jahn, R. On the identity of Navicula (Frustulia) rhomboides and Frustulia saxonica (Bacillariophyceae). Syst. Geogr. Plants 2000, 70, 255–261. [Google Scholar] [CrossRef]
  17. Metzeltin, D.; Lange-Bertalot, H. Tropical diatoms of South America II. Special remarks on biogeographic disjunction. Iconogr. Diatomol. 2007, 18, 1–877. [Google Scholar]
  18. Metzeltin, D.; Lange-Bertalot, H.; García-Rodríguez, F. Diatoms of Uruguay compared with other taxa from South America and elsewhere. Iconogr. Diatomol. 2005, 15, 1–736. [Google Scholar]
  19. Soares, F.S.; Konoplya, B.I.B.; Da Silva, J.F.M.; de Andrade, C.G.T.J. Amphipleuraceae (Bacillariophyceae) do alto da bacia do Ribeirão Cambé, Londrina, Brasil. Rev. Bras. Bot. 2011, 34, 39–49. [Google Scholar] [CrossRef]
  20. Casa, V.; Mataloni, G.; Van de Vijver, B. Six new Frustulia species (Bacillariophyta) in Tierra del Fuego peatbogs, Patagonia, Argentina. Fottea 2018, 18, 55–71. [Google Scholar] [CrossRef]
  21. Brassac, N.M.; Ludwig, T.A.V. Amphipleuraceae e Diploneidaceae (Bacillariophyceae) da bacia do rio Iguaçu, PR, Brasil. Acta Bot. Bras. 2005, 19, 359–368. [Google Scholar] [CrossRef]
  22. Benito, X.; Fritz, S. Diatom diversity and biogeography across tropical South America. In Neotropical Diversification: Patterns and Processes; Rull, V., Carnaval, A.C., Eds.; Springer Nature: Geneva, Switzerland, 2020; Chapter 7; pp. 121–143. [Google Scholar]
  23. Round, F.E.; Crawford, R.M.; Mann, D.G. The Diatoms: Biology & Morphology of the Genera; Cambridge University Press: Cambridge, MA, USA, 1990; p. 747. [Google Scholar]
  24. Lange-Bertalot, H. Navicula sensu stricto. 10 genera separated from Navicula sensu lato, Frustulia. Diatoms Eur. 2001, 2, 1–256. [Google Scholar]
  25. Cox, E.J. Variation in patterns of valve morphogenesis between representatives of six biraphid diatom genera (Bacillariophyceae). J. Phycol. 1999, 35, 1297–1312. [Google Scholar] [CrossRef]
  26. Patrick, R.; Reimer, C.W. The diatoms of the United States I. Monogr. Acad. Nat. Sci. Phila. 1966, 13, 1–688. [Google Scholar]
  27. Graeff, C.L.; Kociolek, J.P.; Burliga, A.L. Valve morphology of four species of Frustulia (Bacillariophyta), including two described as new. Phytotaxa 2012, 42, 62–76. [Google Scholar] [CrossRef]
  28. Siver, P.; Baskette, G. A morphological examination of Frustulia (Bacillariophyceae) from the Ocala National Forest, Florida, USA. Can. J. Bot. 2004, 82, 629–644. [Google Scholar] [CrossRef]
  29. Sawai, Y.; Magumo, T.; Nelson, A.R. A brackish diatom, Pseudofrustulia lancea gen. et sp. nov. (Bacillariophyceae) from the Pacific coast of Oregon (USA). Phytotaxa 2016, 267, 103–112. [Google Scholar] [CrossRef]
  30. Montes de Oca, I. Geografía y Recursos Naturales de Bolivia, 3rd ed.; EDOBOL: La Paz, Bolivia, 1997; p. 614. [Google Scholar]
  31. Bicudo, C.E.d.M.; Menezes, M. Gêneros de Algas de Águas Continentais no Brasil, 3rd ed.; Rima Editora: Sâo Paulo, Brasil, 2017; p. 552. [Google Scholar]
  32. Manguin, E. Contribution à la connaissance des diatomées des Andes du Pérou. Mém. Mus. Natl. Hist. Nat. B Bot. 1964, 12, 41–98. [Google Scholar]
  33. Morales, E.A.; Vis, M.L. Epilithic diatoms (Bacillariophyceae) from cloud forest and alpine streams in Bolivia, South America. Proc. Acad. Nat. Sci. Phila. 2007, 156, 123–155. [Google Scholar] [CrossRef]
  34. Morales, E.A.; Vis, M.L.; Férnandez, E.; Kociolek, J.P. Epilithic diatoms (Bacillariophyta) from cloud forest and alpine streams in Bolivia, South America II: A preliminary report on the diatoms from Sorata, Department of La Paz. Acta Nova 2007, 3, 680–696. [Google Scholar]
  35. Hohn, M.H. Bacillariophyta. Monogr. Acad. Nat. Sci. Phila. 1966, 14, 459–495. [Google Scholar]
  36. Krammer, K. Die cymbelloiden Diatomeen. Eine Monographie der weltweit bekannten Taxa. Teil 1. Allgemeines und Encyonema Part. Bibl. Diatomol. 1997, 36, 1–382. [Google Scholar]
  37. Krammer, K. Die cymbelloiden Diatomeen. Eine Monographie der weltweit bekannten Taxa. Teil 2. Encyonema part, Encyonopsis and Cymbellopsis. Bibl. Diatomol. 1997, 37, 1–469. [Google Scholar]
  38. Krammer, K. The genus Pinnularia. In Diatoms of Europe. Diatoms of the European Inland Waters and Comparable Habitats; Lange-Bertalot, H., Ed.; Gantner Verlag: Ruggell, Liechtenstein, 2000; Volume 1, pp. 1–703. [Google Scholar]
  39. Krammer, K.; Lange-Bertalot, H. Bacillariophyceae 1. Teil: Naviculaceae. In Süsswasserflora von Mitteleuropa; Ettl, H., Gerloff, J., Heynig, H., Mollenhauer, D., Eds.; Gustav Fischer Verlag: Stuttgart, Germany, 1986; Volume 2, pp. 1–876. [Google Scholar]
  40. Krammer, K.; Lange-Bertalot, H. Bacillariophyceae 2. Teil: Bacillariaceae, Epithemiaceae, Surirellaceae. In Süsswasserflora von Mitteleuropa; Ettl, H., Gerloff, J., Heynig, H., Mollenauer, D., Eds.; Gustav Fischer Verlag: Stuttgart, Germany, 1988; Volume 2/2, pp. 1–596. [Google Scholar]
  41. Krammer, K.; Lange-Bertalot, H. Bacillariophyceae 3. Teil: Centrales, Fragilariaceae, Eunotiaceae. In Süsswasserflora von Mitteleuropa; Ettl, H., Gerloff, J., Heynig, H., Mollenhauer, D., Eds.; Gustav Fischer Verlag: Stuttgart/Jena, Germany, 1991; Volume 2/3, pp. 1–576. [Google Scholar]
  42. Krammer, K.; Lange-Bertalot, H. Bacillariophyceae 4. Teil: Achnanthaceae, Kritische Ergänzungen zu Navicula (Lineolatae) und Gomphonema. Gesamtliteraturverzeichnis Teil 1–4. In Süsswasserflora von Mitteleuropa; Ettl, H., Gärtner, G., Gerloff, J., Heynig, H., Mollenhauer, D., Eds.; Gustav Fischer Verlag: Stuttgart/Jena, Germany, 1991; Volume 2/4, pp. 1–437. [Google Scholar]
  43. Lange-Bertalot, H. 85 Neue Taxa und über 100 weitere neu defi nierte Taxa ergänzend zur Süsswasserfl ora von Mitteleuropa Vol. 2/1-4. Bibl. Diatomol. 1993, 27, 1–454. [Google Scholar]
  44. Lange-Bertalot, H.; Moser, G. Brachysira Monographie der Gattung. Wichtige Indikator-Species für das Gewässer-Monitoring und Naviculadicta nov. gen. Ein Lösungsvorschlag zu dem Problem Navicula sensu lato ohne Navicula sensu stricto. Bibl. Diatomol. 1994, 29, 1–212. [Google Scholar]
  45. Battarbee, R.W. Diatom analysis. In Handbook of Holocene Palaeoecology and Palaeohydrology; Berglund, B.E., Ed.; John Wiley and Sons: Chichester, UK, 1986; pp. 527–570. [Google Scholar]
  46. Kociolek, J.P.; Graeff, C.L.; Thomas, E.W. A description of the frustular morphology of Frustulia creuzburgensis (Krasske) Hustedt, with comments on its systematic position. Diatom Res. 2011, 26, 29–41. [Google Scholar] [CrossRef]
  47. Moser, G.; Steindorf, A.; Lange-Bertalot, H. Newkaledonien. Diatomeenflora einer Tropeninsel Revision der Collection Maillard und Untersuchung neuen Materials. Bibl. Diatomol. 1995, 32, 1–340. [Google Scholar]
  48. Edlund, M.B.; Brant, L.A. Frustulia Bahlsii sp. nov., a freshwater diatom from the Eastern U.S.A. Diatom Res. 1997, 12, 207–216. [Google Scholar] [CrossRef]
  49. Bourrelly, P.; Manguin, É. Algues D’eau Douce de la Guadeloupe et Dépendances: Recueillies par la Mission P. Allorge en 1936; Société d’Édition d’Enseignement Superiéur: Paris, France, 1952; pp. 1–282. [Google Scholar]
  50. Da Silva-Lehmkuhl, A.M.; Tremarin, P.I.; Vercellino, I.S.; Ludwig, T.A.V. Periphytic diatoms from an oligotrophic lentic system, Piraquara I reservoir, Paraná state, Brazil. Biota Neotrop. 2019, 19, e20180568. [Google Scholar] [CrossRef]
  51. Van Dam, H.; Mertens, A.; Sinkeldam, J. A coded checklist and ecological indicator values of freshwater diatoms from the Netherlands. Neth. J. Aquat. Ecol. 1994, 28, 117–133. [Google Scholar]
  52. Noga, T.; Peszek, Ł.; Stanek-Tarkowska, J.; Pajączek, A. The Pinnularia genus in south-eastern Poland with consideration or rare and taxa to Poland. Oceanol. Hydrobiol. Stud. 2014, 43, 77–99. [Google Scholar] [CrossRef]
  53. Graeff, C.L.; Kociolek, J.P. Investigations of the Frustulia weinholdii species complex with descriptions of three new species, F. capitata, F. latita, and F. soror from South Carolina and Hawaii. Proc. Acad. Nat. Sci. Phila. 2011, 161, 43–59. [Google Scholar] [CrossRef]
  54. Navarro, G.; Maldonado, M. Geografía Ecológica de Bolivia. Vegetación y Ambientes Acuáticos, 5th ed.; Fundación Simón I. Patiño: Cochabamba, Bolivia, 2011; p. 719. [Google Scholar]
  55. Navarro, G.; De la Barra, N.; Goitia, E.; Maldonado, M. Propuesta metodológica para la clasificación de humedales altoandinos en Bolivia. Rev. Boliv. Ecol. Conserv. Ambient. 2011, 29, 1–22. [Google Scholar]
Figure 1. Geographic location of the type locality of F. tunariensis sp. nov., depicted by a white dot in the right lower part, northeast of the town of Uyuni.
Figure 1. Geographic location of the type locality of F. tunariensis sp. nov., depicted by a white dot in the right lower part, northeast of the town of Uyuni.
Diversity 12 00362 g001
Figure 2. Photographs taken during sample collection. (a) Peatland area with small rivulets and shallow pools located on undecomposed organic material, several meters thick. (b) Shallow pool corresponding to the type locality, arrow shows cloudy growths in the water. (c) Sample collection using a turkey baster, absorbing the cloudy growths depicted by arrow.
Figure 2. Photographs taken during sample collection. (a) Peatland area with small rivulets and shallow pools located on undecomposed organic material, several meters thick. (b) Shallow pool corresponding to the type locality, arrow shows cloudy growths in the water. (c) Sample collection using a turkey baster, absorbing the cloudy growths depicted by arrow.
Diversity 12 00362 g002
Figure 3. LM photographs of Frustulia tunariensis sp. nov. (aj,ku) Size diminution series of part of the population present in type material (BR-4598). Notice thick longitudinal ribs, constricted central nodule and absence of the porte-crayon structure at the valve apices (black arrow in a). (a) depicts holotype specimen. (k) Live cell from type material before processing, showing H-shaped plastid and two large oil droplets (one of them depicted by black arrow head). (vz) Micrographs showing the notch on valvocopulae still attached to depicted valves (black arrows). () Detached girdle with valvocopula showing the notch (black arrow). (,) Frustulia saxonica found in the same sample. Scale bar in (): 10 µm.
Figure 3. LM photographs of Frustulia tunariensis sp. nov. (aj,ku) Size diminution series of part of the population present in type material (BR-4598). Notice thick longitudinal ribs, constricted central nodule and absence of the porte-crayon structure at the valve apices (black arrow in a). (a) depicts holotype specimen. (k) Live cell from type material before processing, showing H-shaped plastid and two large oil droplets (one of them depicted by black arrow head). (vz) Micrographs showing the notch on valvocopulae still attached to depicted valves (black arrows). () Detached girdle with valvocopula showing the notch (black arrow). (,) Frustulia saxonica found in the same sample. Scale bar in (): 10 µm.
Diversity 12 00362 g003
Figure 4. SEM images of Frustulia tunariensis sp. nov. from type material BR-4598. (a) Entire frustule. (b) Central area in external view showing T-shaped proximal raphe ends and round to transapically elliptic areolae, forming parallel striae. (c) Valve apex (external) showing club-shaped shadow area (polar nodule) with T-shaped distal raphe end, circumpolar convergent striae formed by apically elongated areolae below the polar nodule and round at the very apex. (d) Valve apical region (internal) showing polar nodule with fusion of longitudinal ribs and helictoglossa (open arrow), of which faint labia can still be seen, but no porte-crayon structure. Notice large internal areolar openings and the striae going from parallel to convergent toward the apex. White arrow depicts straight distal raphe end. (e) Central nodule with fused longitudinal ribs, parallel striae. White arrow shows straight proximal raphe end. (f) Zoom into apical area showing the areolar occlusions located toward the internal areolar border (black arrow). Scale bars: (a) 10 µm, (b) 5 µm, (cf) 1 µm.
Figure 4. SEM images of Frustulia tunariensis sp. nov. from type material BR-4598. (a) Entire frustule. (b) Central area in external view showing T-shaped proximal raphe ends and round to transapically elliptic areolae, forming parallel striae. (c) Valve apex (external) showing club-shaped shadow area (polar nodule) with T-shaped distal raphe end, circumpolar convergent striae formed by apically elongated areolae below the polar nodule and round at the very apex. (d) Valve apical region (internal) showing polar nodule with fusion of longitudinal ribs and helictoglossa (open arrow), of which faint labia can still be seen, but no porte-crayon structure. Notice large internal areolar openings and the striae going from parallel to convergent toward the apex. White arrow depicts straight distal raphe end. (e) Central nodule with fused longitudinal ribs, parallel striae. White arrow shows straight proximal raphe end. (f) Zoom into apical area showing the areolar occlusions located toward the internal areolar border (black arrow). Scale bars: (a) 10 µm, (b) 5 µm, (cf) 1 µm.
Diversity 12 00362 g004
Figure 5. SEM images of Frustulia tunariensis sp. nov. from type material BR-4598. (a) Valvocopula still attached to valve. White arrow depicts single row of round poroids. Black arrows point to siliceous membrane that attaches the valvocopula to the valve. (b) External view of valvocopula showing row of poroids opening externally. (c) Opening slits (white arrows) containing poroids communicating the tubular (partially eroded) valvocopula with the valve interior. (d) Same valvocopula but showing it as an open (split at ends), tubular (folded) structure (black arrows). Scale bars: (a,b) 1 µm, (c) 3 µm, (d) 5 µm.
Figure 5. SEM images of Frustulia tunariensis sp. nov. from type material BR-4598. (a) Valvocopula still attached to valve. White arrow depicts single row of round poroids. Black arrows point to siliceous membrane that attaches the valvocopula to the valve. (b) External view of valvocopula showing row of poroids opening externally. (c) Opening slits (white arrows) containing poroids communicating the tubular (partially eroded) valvocopula with the valve interior. (d) Same valvocopula but showing it as an open (split at ends), tubular (folded) structure (black arrows). Scale bars: (a,b) 1 µm, (c) 3 µm, (d) 5 µm.
Diversity 12 00362 g005
Table 1. List of species identified from the type preparation (BR-4598), and count and percentage of taxa appearing along a random transect in a count of 400 valves.
Table 1. List of species identified from the type preparation (BR-4598), and count and percentage of taxa appearing along a random transect in a count of 400 valves.
Taxon NameValve CountPercentage
Achnanthidium cf. nanum (F. Meister) Novais & I. Jüttner
Achnanthidium minutissimum (Kützing) Czarnecki20.5
Chammaepinnularia sp. 1
Cymbopleura naviculiformis (Auerswald) Krammer
Diploneis kahlii Lange-Bertalot & Rumrich
Encyonema aueri (Krasske) Krammer20.5
Encyonema dubium Krammer
Encyonema minutiforme Krammer
Encyonema neogracile Krammer266.5
Encyonema rumrichae Krammer41
Encyonema silesiacum (Bleisch) D.G. Mann20.5
Encyonopsis cf. ruttneri (Hustedt) Krammer153.75
Encyonopsis cf. thumensis Krammer4511.25
Encyonopsis recta Krammer
Encyonopsis sp. 1102.5
Eunotia cf. biggiba Kützing
Eunotia cf. major (W. Smith) Rabenhorst
Eunotia parapectinalis Lange-Bertalot & U. Rumrich
Fragilaria rumpens (Kützing) Carlson
Fragilaria tenera (W. Smith) Lange-Bertalot225.5
Frustulia saxonica Rabenhorst10.25
Frustulia tunariensis sp. nov.307.5
Gomphonema cf. gracile Ehrenberg
Gomphonema cf. parvulum (Kützing) Kützing
Gomphonema cf. subclavatum (Grunow) Grunow
Kobayasiella pseudosubtilissima (Manguin) Lange-Bertalot & E.Reichardt235.75
Krasskella sp. 1
Neidium cf. bisulcatum (Lagerstedt) Cleve
Nitzschia cf. acidoclinata Lange-Bertalot7017.5
Nitzschia cf. perminuta Grunow10626.5
Nitzschia cf. subacicularis Hustedt20.5
Nitzschia cf. strelnikovae Lange-Bertalot, Genkal & Vekhov
Nitzschia neotropica Lange-Bertalot & U. Rumrich20.5
Pinnularia borealis Ehrenberg
Pinnularia borealis var. islandica Krammer20.5
Pinnularia cf. ampulliformis Manguin71.75
Pinnularia divergentissima Grunow
Pinnularia microstauron (Ehrenberg) Cleve143.5
Pinnularia pseudogibba Krammer
Pinnularia rabenhorstii var. franconica Krammer
Pinnularia similiformis Krammer
Pinnularia spinosissima Lange-Bertalot, Rumrich & Krammer20.5
Pinnularia subcapitata var. elongata Krammer51.25
Pinnularia subgibba Krammer
Pinnularia tsoneka Lange-Bertalot & Metzeltin
Pseudostaurosira sp. 1
Rhopalodia cf. operculata (C.Agardh) Håkanasson
Sellaphora fusticulus (Østrup) Lange-Bertalot20.5
Stauroneis acidoclinata Lange-Bertalot & Werum
Stauroneis cf. frauenfeldianum (Grunow) Heiden
Stauroneis subgracilis Lange-Bertalot & Krammer
Stenopterobia cf. delicatissima (F.W.Lewis) Brébisson ex Van Heurck
Stenopterobia densistriata (Hustedt) Krammer
Tabellaria flocculosa (Roth) Kützing51.25
Ulnaria acus (Kützing) Aboal10.25
Ulnaria sp. 1
TOTAL400100
Table 2. Species of the genus Frustulia reported for the Bolivian Altiplano. The new taxon described herein is shaded.
Table 2. Species of the genus Frustulia reported for the Bolivian Altiplano. The new taxon described herein is shaded.
TaxaLocality and Altitude (m a.s.l.)CoordinatesGeneral EcologyReference & Comments
F. corneliae Lange-Bertalot & U. RumrichSmall unnamed stream in Sorata, La Paz, 405615°42′0.35″ S, 68°36′0.41″ WRare, in stream benthos, circumneutral to alkalibiont[34], as “F. sp. 1”, only LM
F. crassinervia (Brébisson ex Smith) Lange-Bertalot & KrammerSmall unnamed stream in Sorata, La Paz, 405615°42′0.35″ S, 68°36′0.41″ WRare, in stream benthos, alkalibiont[34], only LM
F. franguelli ManguinIchu Kota Valley, La Paz, 4200–490016°12′ S, 69°30′ WRare, in high altitude peatland, acidobiontic[4,5], only listed
F. rhomboides (Ehrenberg) De ToniIchu Kota Valley, La Paz, 4200–490016°12′ S, 69°30ʹ WRare, in high altitude peatland, acidobiontic[4,5], only listed
F. saxonica (Thwaites) De Toni-Ichu Kota Valley, La Paz, 4200–4900
-Peatland near town of Uyuni, Cochabamba, 4155
−16°12′ S, 69°30ʹ W
17°7′13.1″ S, 66°17′51″ W
Rare, in high altitude peatlands, acidobiontic[4,5], only listed
-This manuscript, only LM (Figure 3a´,b´)
F. tunariensis E. Morales sp. nov.Peatland near town of Uyuni, Cochabamba, 415517°7′13.1″S, 66°17′51″WCommon, in high altitude peatland, acidobionticThis manuscript, LM and SEM available
F. vulgaris (Thwaites) De Toni-Two small unnamed streams in Sorata, La Paz 3993–4056
-Lake Titicaca, La Paz, 3812
−15°42′0.35″ S, 68°36′0.41″ W; 15°51′2.47″ S, 68°38′6.39″ W
−15°45′ S, 69°25′ W
Rare, in lake and stream benthos, circumneutral to alkalibiont[6,34], only listed
Table 3. Comparative data for Frustulia spp. having lanceolate and elliptical shape with evident longitudinal ribs. Taxa with strictly rhomboid shape and taxa with curved raphe are not considered. Distinctive features of F. tunariensis sp. nov. (shaded row) are underlined.
Table 3. Comparative data for Frustulia spp. having lanceolate and elliptical shape with evident longitudinal ribs. Taxa with strictly rhomboid shape and taxa with curved raphe are not considered. Distinctive features of F. tunariensis sp. nov. (shaded row) are underlined.
Taxon/FeaturesValve ShapeValve Dimensions (µm)/Areola and Stria Density (in 10 µm), and OrientationRaphe EndingsLongitudinal Ribs/Helictoglossa ComplexComment/Reference
F. altimontana Metzeltin & Lange-BertalotLanceolate with obtusely to broadly rounded apicesLength: 115–145
Width: 22–27
Areolae: 15–19
Striae: 22–24, parallel to convergent; circumradial at apices
UnknownRibs ca. 1.3 µm thick. Helictoglossa unknown. Apical nodule non-bulbose, but unclear from LM; apical extension unclear. Central nodule biconvexOnly known from LM [7]
F. bahlsii Edlund & BrantLanceolate to rhombic-lanceolate with broadly rounded ends, sometimes rostrateLength: 98–193
Width: 24–33
Areolae: 16–23
Striae: 20–26, parallel; slightly circumparallel to circumradial at apices
Externally, proximal and distal ends T-shaped. Internally, the distal and proximal terminations straightRibs ca. 0.8 µm thick. Helictoglossa inconspicuous and porte-crayon structure very low. Apical nodule notably bulbose without an apical extension. Central nodule constricted[28,48]
F. chilensis Lange-Bertalot & RumrichElliptico-lanceolate with short, rostrate, widely rounded apicesLength: 94–110
Width: 20–24
Areolae: 26–29
Striae: 20–27, parallel to subparallel; unknown pattern at apices
UnknownRibs ca. 1.3 µm thick. Helictoglossa unknown. Polar nodule bulbose with very short apical extension. Central nodule diffuse and unclearOnly known from LM [8]
F. blancheana MaillardLanceolate with subrostrate, broadly rounded apicesLength: 70–84
Width: 10–13
Areolae: 25–30
Striae: 28–33, parallel to slightly convergent; circumradiate around apices
Externally, proximal ends slightly deflected in the same direction, distal ends straight. Internally, the distal and proximal terminations straightRibs ca. 1.7 µm thick. Helictoglossa a relatively high porte-crayon structure. Apical nodule notably bulbose with long apical extension. Central nodule constricted[47]
F. crassiareolaeta Metzeltin & Lange-BertalotLanceolate with faintly subrostrate, broadly rounded apicesLength: 77–100
Width: 17.5–21
Areolae: 20–22
Striae: 23–26.5, parallel to subparallel; circumradiate around apices
UnknownRibs ca. 1 µm thick. Helictoglossa unknown. Polar nodule non-bulbose with long apical extension. Central nodule irregular, sometimes constrictedOnly known from LM [7]
F. crassiareolaetoides Metzeltin & Lange-BertalotLanceolate with broadly rounded apicesLength: 77–115
Width: 17–23
Areolae: 20–22
Striae: 24–26, parallel to subparallel; circumradiate around apices
UnknownRibs ca. 1 µm thick. Helictoglossa unknown. Apical nodule bulbose with large apical extension. Central nodule highly constrictedOnly known from LM [17]
F. ellipticolanceolata Casa, Mataloni & Van de VijverLanceolate with subrostrate endsLength: 51–69
Width: 12.5–15.5
Areolae: 25–35
Striae: 30–32, parallel at center, weakly convergent toward ends; circumradiate around apices, sometimes reduced to a single apical areola per apical stria.
Externally, proximal and distal ends T-shaped. Internally, the distal and proximal terminations straightRibs up to ca. 0.9 µm thick. Helictoglossa a relatively high porte-crayon structure. Apical nodule bulbose with apical extension. Central nodule constricted[20]
F. fuegiana Casa, Mataloni & Van de VijverLanceolate with faint subrostrate to bluntly cuneate ends.Length: 44–90
Width: 12–17
Areolae: 24–28
Striae: 26–29, parallel at center becoming weakly convergent toward ends
Externally, proximal and distal ends T-shaped. Internally, the distal and proximal terminations straightRibs up to ca. 0.8 µm thick. Helictoglossa a faint porte-crayon structure. Apical nodule faintly bulbose. Central nodule weakly to noticeably constricted[20]
F. magna Metzeltin & Lange-BertalotLanceolate to rhombic-lanceolate with broadly rounded endsLength: 130–160
Width: 31–33
Areolae: 18–20
Striae: 20–22, parallel to convergent; circumradiate around apices
UnknownRibs ca. 1.7 µm thick. Helictoglossa unknown. Apical nodule non-bulbose with large apical extension. Central nodule slightly biconvex to highly constrictedOnly known from LM [7]
F. neofrenguellii Lange-Bertalot & RumrichElliptico-lanceolate, with short subrostrate and obstusely rounded apicesLength: 55–80
Width: 16–18
Areolae: 24–26
Striae: 24–26, parallel; circumradiate around apices
Externally, proximal and distal ends T-shaped. Internally, the distal terminations end in a small punctum; proximal ends unknownRibs ca. 1 µm thick. Helictoglossa, a low porte-crayon structure forming a short apical extension on a non-bulbose polar nodule. Central nodule constricted and only known in LM.SEM information incomplete [8]
F. pangaeopsis Lange-BertalotElliptico-lanceolate with rostrate to subcapitate, widely rounded apicesLength: 75–90
Width: 16–18.5
Areolae: 24–26
Striae: 6–27, parallel to slightly convergent; circumradiate around apices
Externally, proximal and distal ends unknown. Internally, the distal terminations straight; proximal ends unknownRibs ca. 0.7 µm thick. Helictoglossa, inconspicuous and porte-crayon structure faint, forming an also faint short apical extension on a slightly bulbose polar nodule. Central nodule constricted and only known in LM.SEM information incomplete [24]
F. tunariensis E. Morales sp. nov.Elliptico-lanceolate with obtusely rounded apicesLength: 60–110
Width: 15.5–18
Areolae: 40–45
Striae: 39–50, parallel to convergent, circumradiate around apices
Externally, proximal and distal ends T-shaped. Internally, the distal and proximal terminations straightRibs ca. 2.5 µm thick. Helictoglossa inconspicuous and porte-crayon structure faint. Apical nodule notably bulbose without an apical extension. Central nodule irregular, sometimes constrictedThis manuscript
F. turfosa Metzeltin & Lange-BertalotLanceolate with subrostrate, broadly rounded apicesLength: 100–150
Width: 16.6–19
Areolae: 18–21
Striae: 27, parallel to convergent, circumradiate around apices
UnknownRibs ca. 1 µm thick. Helictoglossa unknown. Apical nodule bulbose without an apical extension. Central nodule constrictedOnly known from LM [17]
Table 4. Comparison of girdle elements among Frustulia taxa with available published information.
Table 4. Comparison of girdle elements among Frustulia taxa with available published information.
Taxon/FeaturesCopulaValvocopulaOpenings in ValvocopulaNotch and Verrucae on ValvocopulaReference
F. blancheana MaillardOpen, with one row of poroidsOpen, without fimbriaeSlits in tube-like portion opening as slits toward the interior and as a single row of poroids toward valve exteriorPresent, absent[47]
F. creuzburgensis (Krasske) HustedtOpen, with two rows of poroidsClosed, bearing fimbriaWith two rows of poroids in tube-like portion, apparently not open to either valve interior or exteriorPresent, verrucae alternate with poroids[46]
F. cf. krammeriUnknownOpen, lacking fimbriae, but with a flap (pars interior) running on top of the tube-like portionWith one row of slits on the longitudinal flap and one row of slits in the tube-like portion, presumably opening as slits toward the valve interior and not opening towards the valve exteriorPresent, verrucae randomly distributed[27]
F. latita Graeff & KociolekOpen with one or two rows of poroidsClosed, fimbriae undeterminedPoroids inside tube-like portion, opening toward the valve interior undetermined, opening as single row of slits towards the valve exterior becoming a row of poroids toward the valve apicesPresent, verrucae alternate with poroids[43]
F. rhomboides (Ehrenberg) De ToniOpen with several rows of poroidsOpen, lacking fimbriae, but with an unornamented flap (pars interior) running on top of the tube-like portionSlits in tube-like portion, open as poroids towards the valve interior and as slits towards the exteriorPresent, absent[23,47]
F. tunariensis sp. nov.Open with one row of poroidsOpen, lacking fimbriae but with siliceous membrane on pars interiorPoroids in tube-like portion, open as slits to the interior and as single row of poroids towards the valve exteriorPresent, absentThis manuscript
Back to TopTop
