Open AccessArticle
Molecules 2018, 23(11), 2994;

Derivatization of Methylglyoxal for LC-ESI-MS Analysis—Stability and Relative Sensitivity of Different Derivatives

Institute of Analytical Chemistry, Faculty of Chemistry and Mineralogy, University of Leipzig, 04103 Leipzig, Germany
Institute of Pharmacy, Faculty of Medicine, University of Leipzig, 04103 Leipzig, Germany
Department of Chemistry, Krishna University, Machilipatnam 521001, Andhra Pradesh, India
Department of Plant Physiology and Biochemistry, Faculty of Biology, Saint Petersburg State University, Saint Petersburg 199034, Russia
Library of the Russian Academy of Sciences, Saint Petersburg 199034, Russia
Faculty of Tropical AgriSciences, Czech University of Life Sciences Prague, 165 00 Prague-Suchdol, Czech Republic
Department of Bioorganic Chemistry, Leibniz Institute of Plant Biochemistry, 06120 Halle (Saale), Germany
Author to whom correspondence should be addressed.
Received: 12 October 2018 / Revised: 5 November 2018 / Accepted: 8 November 2018 / Published: 16 November 2018
(This article belongs to the Special Issue Method Development and Validation in Food and Pharmaceutical Analysis)
Full-Text   |   PDF [1334 KB, uploaded 16 November 2018]   |


The great research interest in the quantification of reactive carbonyl compounds (RCCs), such as methylglyoxal (MGO) in biological and environmental samples, is reflected by the fact that several publications have described specific strategies to perform this task. Thus, many reagents have also been reported for the derivatization of RCCs to effectively detect and quantify the resulting compounds using sensitive techniques such as liquid chromatography coupled with mass spectrometry (LC-MS). However, the choice of the derivatization protocol is not always clear, and a comparative evaluation is not feasible because detection limits from separate reports and determined with different instruments are hardly comparable. Consequently, for a systematic comparison, we tested 21 agents in one experimental setup for derivatization of RCCs prior to LC-MS analysis. This consisted of seven commonly employed reagents and 14 similar reagents, three of which were designed and synthesized by us. All reagents were probed for analytical responsiveness of the derivatives and stability of the reaction mixtures. The results showed that derivatives of 4-methoxyphenylenediamine and 3-methoxyphenylhydrazine—reported here for the first time for derivatization of RCCs—provided a particularly high responsiveness with ESI-MS detection. We applied the protocol to investigate MGO contamination of laboratory water and show successful quantification in a lipoxidation experiment. In summary, our results provide valuable information for scientists in establishing accurate analysis of RCCs. View Full-Text
Keywords: carbonyl derivatization; phenylhydrazine; phenylenediamine; hydroxylamine; water analysis; lipoxidation carbonyl derivatization; phenylhydrazine; phenylenediamine; hydroxylamine; water analysis; lipoxidation

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Supplementary material
